Deif AGC 200 Operator's Manual page 16

Advanced genset controller display readings,push-button functions, alarm handling,log list
Table of Contents

Advertisement

AGC 200 operators manual 4189340607
UK
Status text
---xx-------- >00< ------------
TOO SLOW 00<-------------
-----------> 00 TOO FAST
EXT. START ORDER
SELECT GENSET MODE
QUICK SETUP ERROR
MOUNT CAN CONNEC-
TOR
ADAPT IN PROGRESS
SETUP IN PROGRESS
SETUP COMPLETED
REMOVE CAN CONNEC-
TOR
RAMP TO #####kW
DERATED TO #####kW
UNEXPECTED GB ON BB
WARM UP RAMP
DEIF A/S
Condition
Generator is synchronising
Generator running too slow during synchronising
Generator running too fast during synchronising
A planned AMF sequence is activated
Power management has been deactivated and no
other genset mode has been selected
Quick setup of the application failed
Connect the power management CAN line
The AGC 200 is receiving the application, to which it
has just been connected
The new AGC is being added to the existing applica-
tion
Successful update of the application in all AGC units
Remove the power management CAN lines
The power ramp is ramping in steps, and the next
step that will be reached after the timer has expired
will be displayed
Displays the ramp-down set point
Another generator breaker is closed on to the bus-
bar (due to a GB position failure) while no voltage is
present on the busbar
Warm up ramp is active
Display and menu structure
Comment
The "xx" marks the
actual generator
phase angle position
in the synchronisa-
tion. When the "xx" is
aligned over the 00
centre, the generator
is in synchronism
There is no failure on
the mains during this
sequence
Option G5 must be
available
This indicates that
other breakers can-
not close to the bus-
bar because of posi-
tion failure on one or
more GBs
The available power
is limited until the
predefined tempera-
ture is reached or
when the input which
activated warm up
ramp is set low
Page 16 of 24
