5. Alarm handling and log list

5.1 Alarm handling

When an alarm occurs, the unit will automatically go to the alarm list in the display. If this has been disabled
by setting "Alarm jump" (channel 6900) to OFF, you must press
If reading of the alarms is not desired, use the ESC push-button to exit the alarm list.
If you decide to enter the alarm list later, use the
The alarm list contains both acknowledged and unacknowledged alarms, provided that they are still active
(that is, the alarm condition is still present). Once an alarm is acknowledged and the condition has disap-
peared, the alarm will no longer be displayed in the alarm list.
This means that if there are no alarms, the alarm list will read "No alarms".
If an alarm is blocking a genset in AUTO from starting, the genset will automatically start and
close the breaker if the condition that triggered the alarm has disappeared and the alarm has
been acknowledged.
MAINS FAILURE
Alarm list:
Ch 1300 UNACK
BB U< 1
10-01-06 15:20:21:0
This display example indicates an unacknowledged alarm. The display can show only one alarm at a time.
Therefore, all other alarms are hidden.
To see the other alarms, use the
To acknowledge an alarm, place the cursor (grey area) over the channel number and then press
5.2 Log list
The log is divided into three different lists:
1. Events
2. Alarms
3. Battery test
The log list contains up to 150 events, the alarm list contains up to 30 historical alarms and the battery test list
contains up to 52 historical battery tests.
An event is for example closing of breaker and starting of engine. An alarm is for example over-current or
high cooling water temperature. A battery test is for example test OK or test failed.
DEIF A/S
1/1 alarm (s)
and push-buttons to scroll in the display.
to enter the alarm list.
push-button to jump directly to the alarm list reading.
