AGC 200 operators manual 4189340607
UK
4. Display and menu structure

4.1 About display and menu structures

4.1.1 LCD display
The display is a backlit LCD graphical display. The display light intensity, LED indication and contrast can be
adjusted from menu 9150.
Basically, all measured and calculated values can be read in the display. These may be selected via the PC
utility software (USW).
For selection of values, see the Designer's reference handbook.
4.1.2 Menu structure
The display includes two menu systems which can be used without password entry:
View menu system
This is the commonly used menu system. 20 windows are configurable and can be entered by using the ar-
row push-buttons.
Setup menu system (not commonly used by the operator)
This menu system is used to set up the unit, and if the operator needs detailed information that is not availa-
ble in the view menu system.
Changing of parameter settings is password-protected.
4.1.3 Entry window
When the unit is powered up, an entry window appears. The entry window is the turning point in the menu
structure and as such the gateway to the other menus. It can always be reached by pushing the BACK push-
button three times.
The event and alarm list will appear at power-up if an alarm is present.
MAINS FAILURE
U-supply
G
0.001 PF
G
0 kVA
Energy Total
Run Absolute
4.1.4 View menu
The view menus (V1, V2 and V3) are the daily use menus for the operator.
DEIF A/S
24.1 V
0 kW
0 kVAr
0 kWh
0 hrs
Display and menu structure
Page 12 of 24
