TECHNICAL SPECIFICATIONS

Models
Input/Output phases
Electrical specifi cations - Input
Mains voltage
Input frequency
Input power factor
THDI
Electrical specifi cations - Output
Output voltage (P+N)
Frequency
Automatic bypass
Nominal power
Overload on mains power supply
Crest factor
Voltage distortion
* @ Pout = 90% Pnom
Environment
Operating temperature
Storage temperature
Relative humidity
Protection level
Max. altitude
Acoustic noise (dB)
3
Required cooling capacity (m /h)
Dissipated power max
Dissipated power
Standards
Safety
Type and performance
EMC
Product certifi cation
Protection level
3/1
3P+N 400 V ±20% (up to -35% @70% of nominal load)
50-60 Hz ±10%
0,99
< 10%
230 V single phase (selectable: 208*/220/230/240 V) ±1%
50-60 Hz ±2% (from 1% to 8% if generator is used)
nominal output voltage ±15%
(from 10% to 20% selectable if generator is used)
40 kVA: 32 kW
60 kVA: 48 kW
125% 10 minutes
150% 1 minute
2.5:1
1% with linear load
0÷40 °C (15÷25 °C recommended for longer battery life)
-5÷45 °C
0÷95% condensation-free
IP31
1.000 m (3.300 ft) without derating; 3.000 m (10.000 ft) max
< 62
1810
40 kVA: 3800 W
60 kVA: 5500 W
40 kVA: 13100 BTU/h
60 kVA: 18800 BTU/h
EN 62040-1-1, EN 60950-1
EN 62040-3 (VFI-SS-111)
EN 62040-2
IP31
MASTERYS IP+
40-60 kVA 3/1
1000
Weight:
- 40 kVA: 490 kg
- 60 kVA: 540 kg
IOMMASIPXX07-GB 02
835
51
