8.2 "MEASUREMENTS" menu.

This menu is used to display all the measurements relating to the UPS input, output and to the battery.
For models with single phase input or output, the voltage and current displays are adjusted automatically.
PRESENT MEASURES menu
Type of measurements
OUTPUT STAR VOLTAGE
OUTPUT LOAD
OUTPUT ACTIVE POWER
OUT APPARENT POWER
OUTPUT CURRENT
OUTPUT FREQUENCY
AUXILIARY VOLTAGE
AUXILIARY FREQUENCY
INPUT STAR VOLTAGE
INPUT PH-PH VOLTAGE
INPUT FREQUENCY
INPUT APPARENT POWER
BATTERY VOLTAGE
BATTERY CAPACITY
BACKUP
INTERNAL TEMPERATURE
BATTERY TEMPERATURE
8.2.1 "Statistical measurements" menu.
Once a (programmable) reference period has been defi ned, the system reports measurements that are made
available in digital or graphical format.
The values that are represented graphically can be used to analyse the situation over the last 24 hours. This
information, together with the programmed interval information, provides an enhanced evaluation on the
operating mode of the equipment in order to verify whether certain critical operating situations are repetitive
or only casual.
STATISTICAL MEASUREMENTS menu
Measurement
INPUT APPARENT POWER
BACKUP TIME LESS THAN 2 MINUTES
BACKUP TIME BETWEEN 2 AND 5 MINUTES
BACKUP TIME MORE THAN 5 MINUTES
OUTPUT LOAD
OVERLOAD TIME LESS THAN 5 SECONDS
OVERLOAD TIME MORE THAN 5 SECONDS
REDUNDANCY LOST
INTERNAL TEMPERATURE
BATTERY TEMPERATURE
WORKING TIME ON GEN SET
30
IOMMASIPXX07-GB 02
Value Value
___ V
__ %
___ kW
__._ kVA
__._ A
__._ Hz
___ V
__._ Hz
___ V ___ V
___ V ___ V
__._ Hz
__._ kVA __._ kVA
B1___ V B2___ V
__ %
T___MIN
__ °C
__ °C
Value
MIN. AVERAGE MAX.
NUMBER OF EVENTS
NUMBER OF EVENTS
NUMBER OF EVENTS
MIN. AVERAGE MAX.
NUMBER OF EVENTS
NUMBER OF EVENTS
NUMBER OF EVENTS
MIN. AVERAGE MAX.
MIN. AVERAGE MAX.
NUMBER OF HOURS
MASTERYS IP+
Value Note
___ V
___ V
__._ kVA
Charging
Discharging
Only with a sensor present and set
Option
ENTER displays
weekly graphics
ENTER displays
weekly graphics
ENTER displays
weekly graphics
ENTER displays
weekly graphics
40-60 kVA 3/1
Option
ENTER displays
24 hr graphics
ENTER displays
24 hr graphics
ENTER displays
24 hr graphics
ENTER displays
24 hr graphics
