COMMUNICATION
9.2.2 Description of the functions available.
The main web page shows the general status of the UPS.
This page like all the "sub-pages" are dynamic i.e. the data, images or type of messages shown vary in accord-
ance with the UPS status and confi guration.
9.2.2-1
A
B
Legend.
A Navigation bar.
B Menu bar.
C system information area.
38
IOMMASIPXX07-GB 02
MASTERYS IP+
40-60 kVA 3/1
C
