MIMIC PANEL
Parallel UPS
MAIN
26
IOMMASIPXX07-GB 02
Single UPS
SYSTEM
MODULE 1
MODULE 2
MASTERYS IP+
1 ALARMS
2 MEASUREMENTS
3 COMMANDS
4 PARAMETERS
5 SERVICE
6 HYSTORY
1 ALARMS
2 MEASUREMENTS
3 COMMANDS
4 PARAMETERS
5 SERVICE
40-60 kVA 3/1
1.1 ACTIVE ALARMS
2.1 PRESENT MEASURES
2.2 STATISTICS
3.1 IMMEDIATE COMMANDS
3.2 EXTENDED COMMANDS
4.1 PRESENT CONFIG.
4.2 PRESENT DATA
5.1 COMMISSIONING
5.2 SETTING
5.3 SERVICE CODE
6.1 HISTORY LOG
1.1 ACTIVE ALARMS
2.1 PRESENT MEASURES
3.1 IMMEDIATE COMMANDS
3.2 EXTENDED COMMANDS
4.1 PRESENT CONFIG
5.1 SERVICE CODE
