5. Programmers' Reference

5.6.5. Querying the Core Version

Command format: GET●/SYS/MB.CoreVersion
Response format: pr●/SYS/MB.CoreVersion=<core_version>
˃ GET /SYS/MB.CoreVersion
˂ pr /SYS/MB.CoreVersion=v1.0.0b4 r7
5.6.6. Resetting the Device
The extender can be restarted; the current connections (RS-232, USB, etc...) will be terminated.
Command format: CALL●/SYS:reset()
Response format: mO●/SYS:Reset
Example:
˃ CALL /SYS:reset()
˂ mO /SYS:reset
5.6.7. Restoring the Factory Default Settings
Command format: CALL●/SYS:factoryDefaults()
Response format: mO●/SYS:factoryDefaults=
Example:
˃ CALL /SYS:factoryDefaults()
˂ mO /SYS:factoryDefaults=
The device is restarted, the current connections are terminated, and the default settings are restored. See
the complete list in the Factory Default Settings
5.7. Network Configuration
ATTENTION! When you change a network property the applySettings method must be called always to
store the new settings. After that, the device is restarted automatically.
5.7.1. Querying the DHCP State
Command format: GET●/MANAGEMENT/NETWORK.DhcpEnabled
Response format: pw●/MANAGEMENT/NETWORK.DhcpEnabled=true|false
Example:
˃ GET /MANAGEMENT/NETWORK.DhcpEnabled
˂ pw /MANAGEMENT/NETWORK.DhcpEnabled=true
Explanation:
The IP address assignment is dynamic, the device gets the IP address from the DHCP server.
section.
VINX-1x0-HDMI Extenders – User's Manual
5.7.2. Changing the DHCP State
Command format: SET●/MANAGEMENT/NETWORK.DhcpEnabled=true|false
Response format: pw●/MANAGEMENT/NETWORK.DhcpEnabled=true|false
Example:
˃ SET /MANAGEMENT/NETWORK.DhcpEnabled=false
˂ pw /MANAGEMENT/NETWORK.DhcpEnabled=false
Explanation:
The IP address assignment is set to static, thus, you have to set it manually.
5.7.3. Querying the IP Address
Command format: GET●/MANAGEMENT/NETWORK.IpAddress
Response format: pr●/MANAGEMENT/NETWORK.IpAddress=<IP_Address>
Example:
˃ GET /MANAGEMENT/NETWORK.IpAddress
˂ pr /MANAGEMENT/NETWORK.IpAddress=192.168.0.100
5.7.4. Setting a Static IP Address
When the DhcpEnabled property is false you can set a static IP address.
Command format: SET●/MANAGEMENT/NETWORK.StaticIpAddress=<IP_address>
Response format: pw●/MANAGEMENT/NETWORK.StaticIpAddress=<IP_address>
Example:
˃ SET /MANAGEMENT/NETWORK.StaticIpAddress=192.168.0.85
˂ pw /MANAGEMENT/NETWORK.StaticIpAddress=192.168.0.85
5.7.5. Querying the Subnet Mask
Command format: GET●/MANAGEMENT/NETWORK.NetworkMask
Response format: pr●/MANAGEMENT/NETWORK.NetworkMask=<netmask>
Example:
˃ GET /MANAGEMENT/NETWORK.NetworkMask
˂ pr /MANAGEMENT/NETWORK.NetworkMask=255.255.255.0
