KINO-DCM236 Industrial Motherboard
3.1.2 Peripheral Interface Connectors
The table below lists all the connectors on the board.
Connector
ATX power connector
Audio connector
Battery connector
Chassis intrusion connector
Debug connector
Digital I/O connector
Fan connector, CPU
Fan connector, system
Front panel connector
2
I
C connector
Keyboard/mouse connector
LAN link LED connectors
LVDS connector
LVDS backlight connector
M.2 slot
Memory slot
PCIe Mini card slot (full-size)
PCIe Mini card slot (half-size)
Power button (on board)
RS-232 connectors
RS-232/422/485 connectors
SATA 6Gb/s drive connectors
Type
4-pin Molex
10-pin header
2-pin wafer
2-pin header
12-pin wafer
10-pin header
4-pin wafer
4-pin wafer
10-pin header
4-pin wafer
6-pin wafer
2-pin header
30-pin crimp
5-pin wafer
A key slot
260-pin DDR4 SO-DIMM
Full-size PCIe Mini slot
Half-size PCIe Mini slot
Push button
9-pin wafer
9-pin wafer
7-pin SATA connector
Label
CPU12V2
FRONT-PANEL1
BAT1
CHASSIS1
DBG_PORT1
DIO1
CPU_FAN1
SYS_FAN1
F_PANEL1
I2C1
KB/MS1
LED_LAN1,
LED_LAN2
LVDS1
INV1
M2
DIMM1, DIMM2
MPCIE1
MPCIE2
PWR_SW1
COM2, COM3,
COM4
COM5, COM6
S_ATA1, S_ATA2,
Page 17
