KINO-945GSE3 User Manual
IEI Technology Corp.
MODEL:
KINO-945GSE3
Mini-ITX Single Board Computer with Intel® Atom™ N270 1.6
GHz Processor, Dual Gigabit Ethernet, Audio, VGA/
LVDS/DVI-D/HDTV-out, Six USB, Nine RS-232, RS-232/422/485,
CompactFlash® Type II, Two SATA, RoHS Compliant
Rev. 1.00 – 7 September, 2010

User Manual

NANO-945GSE3
Page i

Advertisement

Table of Contents
loading

Related Manuals for IEI Technology KINO-945GSE3

Summary of Contents for IEI Technology KINO-945GSE3

  • Page 1: User Manual

    KINO-945GSE3 User Manual NANO-945GSE3 IEI Technology Corp. MODEL: KINO-945GSE3 Mini-ITX Single Board Computer with Intel® Atom™ N270 1.6 GHz Processor, Dual Gigabit Ethernet, Audio, VGA/ LVDS/DVI-D/HDTV-out, Six USB, Nine RS-232, RS-232/422/485, CompactFlash® Type II, Two SATA, RoHS Compliant User Manual Page i Rev.
  • Page 2 KINO-945GSE3 User Manual Revision Date Version Changes 7 September, 2010 1.00 Initial release Page ii...
  • Page 3 KINO-945GSE3 User Manual Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.

  • Page 4: Table Of Contents

    KINO-945GSE3 User Manual Table of Contents 1 INTRODUCTION......................1 1.1 I ......................2 NTRODUCTION 1.2 KINO-945GSE3 O ..................3 VERVIEW 1.2.1 Dimensions......................4 1.2.2 Data Flow ......................5 1.2.3 Technical Specifications..................6 2 UNPACKING ......................... 8 2.1 U ..................... 9...
  • Page 5 KINO-945GSE3 User Manual 3.3.14 SATA Drive Connectors ................. 30 3.3.15 Serial Port Connector ..................31 3.3.16 SPI Flash Connector..................33 3.3.17 HDTV Out Connector ..................34 3.3.18 USB Connectors (Internal) ................34 3.4 E ......... 35 XTERNAL ERIPHERAL NTERFACE ONNECTOR ANEL 3.4.1 Audio Connector ....................
  • Page 6 KINO-945GSE3 User Manual 4.6 E ........... 60 XTERNAL ERIPHERAL NTERFACE ONNECTION 4.6.1 DVI Display Device Connection..............61 4.6.2 LAN Connection (Single Connector) ............... 62 4.6.3 PS/2 Keyboard and Mouse Connection ............62 4.6.4 Serial Device Connection ................63 4.6.5 USB Connection (Dual Connector) ..............64 4.6.6 VGA Monitor Connection ................
  • Page 7 KINO-945GSE3 User Manual 5.5.5 CD/DVD Drives ..................... 108 5.6 S ....................... 109 ECURITY 5.7 C ........................110 HIPSET 5.7.1 Northbridge Configuration ................111 5.7.2 Southbridge Configuration ................114 5.8 E ........................115 A BIOS OPTIONS ......................118 B ONE KEY RECOVERY ................... 122 B.1 O ..............
  • Page 8 KINO-945GSE3 User Manual E WATCHDOG TIMER....................156 F COMPATIBILITY..................... 159 F.1 C ................ 160 OMPATIBLE PERATING YSTEMS G HAZARDOUS MATERIALS DISCLOSURE ............161 G.1 H IPB P AZARDOUS ATERIALS ISCLOSURE ABLE FOR RODUCTS ERTIFIED AS HS C 2002/95/EC W ........162...
  • Page 9 List of Figures Figure 1-1: KINO-945GSE3 ......................2 Figure 1-2: KINO-945GSE3 Overview ...................3 Figure 1-3: KINO-945GSE3 Dimensions (mm) ................4 Figure 1-4: Data Flow Block Diagram ...................5 Figure 3-1: Connector and Jumper Locations [Front Side] .............13 Figure 3-2: ATX Power Connector Pinout Locations..............15 Figure 3-3: Backlight Inverter Connector Pinout Locations ............16...
  • Page 10 KINO-945GSE3 User Manual Figure 4-1: SO-DIMM Installation ....................46 Figure 4-2: CompactFlash® Card Installation ................47 Figure 4-3: AT Power Select Jumper Location................49 Figure 4-4: AT/ATX Power Mode Jumper Location..............50 Figure 4-5: CompactFlash® Setup Jumper Location ...............50 Figure 4-6: Clear CMOS Jumper ....................52 Figure 4-7: COM2 Function Select Jumper Location..............53...
  • Page 11 KINO-945GSE3 User Manual Figure B-14: Compress Image....................135 Figure B-15: Image Creation Confirmation ................136 Figure B-16: Image Creation Complete ................... 136 Figure B-17: Image Creation Complete ................... 136 Figure B-18: Press Any Key to Continue ................137 Figure B-19: Partitions for Linux....................138 Figure B-20: System Configuration for Linux.................
  • Page 12 KINO-945GSE3 User Manual List of Tables Table 1-1: Technical Specifications....................7 Table 3-1: Peripheral Interface Connectors ................14 Table 3-2: Rear Panel Connectors ....................14 Table 3-3: ATX Power Connector Pinouts .................16 Table 3-4: Panel Backlight Connector Pinouts................16 Table 3-5: Battery Connector Pinouts ..................17 Table 3-6: CF Card Socket Pinouts.....................19...
  • Page 13 KINO-945GSE3 User Manual Table 4-2: AT Power Select Jumper Settings ................48 Table 4-3: AT/ATX Power Supply Type Jumper Settings ............49 Table 4-4: CompactFlash® Setup Jumper Settings ..............50 Table 4-5: Clear CMOS Jumper Settings..................51 Table 4-6: JP1, JP2 COM2 Function Select Jumper Settings ..........52 Table 4-7: LVDS Panel Resolution Jumper Settings..............53...
  • Page 14 KINO-945GSE3 User Manual BIOS Menus BIOS Menu 1: Main ........................71 BIOS Menu 2: Advanced ......................73 BIOS Menu 3: CPU Configuration ....................73 BIOS Menu 4: IDE Configuration....................74 BIOS Menu 5: IDE Master and IDE Slave Configuration ............77 BIOS Menu 6: Super IO Configuration..................82 BIOS Menu 7: Hardware Health Configuration ................89...

  • Page 15: Introduction

    KINO-945GSE3 User Manual Chapter Introduction Page 1...

  • Page 16: Introduction

    The Intel® Atom™ processor N270 embedded on the KINO-945GSE3 has a 1.60 GHz clock speed, a 533 MHz FSB and a 512 KB L2 cache. The KINO-945GSE3 supports one 200-pin 400/533 MHz 2.0 GB (max.) DDR2 SDRAM SO-DIMM. The KINO-945GSE3 comes with an 18-bit dual-channel LVDS connector, a VGA port, a HDTV-out connector, and a DVI-D port.

  • Page 17: Kino-945Gse3 Overview

    KINO-945GSE3 User Manual 1.2 KINO-945GSE3 Overview The KINO-945GSE3 has a wide variety of peripheral interface connectors. F igure 1-2 is a labeled photo of the peripheral interface connectors on the KINO-945GSE3. Figure 1-2: KINO-945GSE3 Overview Page 3...

  • Page 18: Dimensions

    KINO-945GSE3 User Manual 1.2.1 Dimensions The dimensions of the board are listed below: Length: 170 mm Width: 170 mm Figure 1-3: KINO-945GSE3 Dimensions (mm) Page 4...

  • Page 19: Data Flow

    KINO-945GSE3 User Manual 1.2.2 Data Flow F igure 1-4 shows the data flow between the two on-board chipsets and other components installed on the motherboard and described in the following sections of this chapter. Figure 1-4: Data Flow Block Diagram...

  • Page 20: Technical Specifications

    KINO-945GSE3 User Manual 1.2.3 Technical Specifications KINO-945GSE3 technical specifications are listed below. Specification/Model KINO-945GSE3 Mini-ITX Form Factor 1.6 GHz Intel® Atom™ N270 Front Side Bus (FSB) 533 MHz Northbridge Chipset Intel® 945GSE Intel® 945GSE, Intel® Generation 3.5 integrated GFX Core Integrated Graphics (133Mhz), Intel®...

  • Page 21: Table 1-1: Technical Specifications

    KINO-945GSE3 User Manual Specification/Model KINO-945GSE3 Two PS/2 ports Keyboard/Mouse One KB/MS (internal) connector Serial Ports One RS-232 serial ports One RS-232/422/485 serial port Eight RS-232 via internal pin headers Four external USB ports USB 2.0/1.1 ports Two via internal pin headers...

  • Page 22: Unpacking

    KINO-945GSE3 User Manual Chapter Unpacking Page 8...

  • Page 23: Unpacking Checklist

    Only handle the edges of the PCB: Don't touch the surface of the motherboard. Hold the motherboard by the edges when handling. 2.2 Unpacking Precautions When the KINO-945GSE3 is unpacked, please do the following: Follow the antistatic guidelines above. Make sure the packing box is facing upwards when opening.

  • Page 24: Packing List

    NOTE: If any of the components listed in the checklist below are missing, do not proceed with the installation. Contact the IEI reseller or vendor the KINO-945GSE3 was purchased from or contact an IEI sales representative directly by sending an email to ales@iei.com.tw.

  • Page 25: Optional Items

    KINO-945GSE3 User Manual Quick Installation Guide 2.2.1 Optional Items The following components are optional: Item and Part Number Image Dual USB cable (w bracket) (P/N: CB-USB02-RS) IDE cable, 44-pin to 44-pin (P/N: 32200-000009-RS) RS-232/422/485 cable (P/N: 32200-0833600-RS) HDTV out cable...

  • Page 26: Connectors

    KINO-945GSE3 User Manual Chapter Connectors Page 12...

  • Page 27: Peripheral Interface Connectors

    Figure 3-1 shows the on-board peripheral connectors, rear panel peripheral connectors and on-board jumpers. Figure 3-1: Connector and Jumper Locations [Front Side] 3.2 Peripheral Interface Connectors The table below lists all the connectors on the KINO-945GSE3. Detailed descriptions of these connectors can be found below. Connector Type...

  • Page 28: External Interface Panel Connectors

    KINO-945GSE3 User Manual Connector Type Label CPU Fan connector 3-pin wafer Front panel connector 14-pin header F_PANEL1 Infrared interface (IrDA) connector 5-pin header Keyboard/Mouse connector 6-pin wafer KB_MS1 LVDS connector 30-pin crimp LVDS1 Parallel ATA (IDE) 44-pin box header IDE1...

  • Page 29: Internal Peripheral Connectors

    KINO-945GSE3 User Manual 3.3 Internal Peripheral Connectors The section describes all of the connectors on the KINO-945GSE3. 3.3.1 ATX Power Connector CN Label: PWR1 20-pin ATX (2x10) CN Type: CN Location: See Figure 3-2 CN Pinouts: See Table 3-3 The ATX power connector connects to an ATX power supply.

  • Page 30: Backlight Inverter Connector

    See Figure 3-3 CN Pinouts: See Table 3-4 The backlight inverter connector provides the backlight on the LCD display connected to the KINO-945GSE3 with +12V of power. Figure 3-3: Backlight Inverter Connector Pinout Locations PIN NO. DESCRIPTION LCD Backlight Control...

  • Page 31: Battery Connector

    KINO-945GSE3 User Manual 3.3.3 Battery Connector CN Label: BAT1 2-pin wafer (1x2) CN Type: CN Location: See Figure 3-4 CN Pinouts: See Table 3-5 This is connected to the system battery. The battery provides power to the system clock to retain the time when power is turned off.

  • Page 32: Figure 3-5: Cf Card Socket Location

    KINO-945GSE3 User Manual Figure 3-5: CF Card Socket Location PIN NO. DESCRIPTION PIN NO. DESCRIPTION GROUND VCC-IN CHECK1 DATA 3 DATA 11 DATA 4 DATA 12 DATA 5 DATA 13 DATA 6 DATA 14 DATA 7 DATA 15 HDC_CS0# HDC_CS1...

  • Page 33: Cpu Fan Connector (+12V, 3-Pin)

    KINO-945GSE3 User Manual PIN NO. DESCRIPTION PIN NO. DESCRIPTION DATA 1 DATA 8 DATA 2 DATA 9 DATA 10 VCC-IN CHECK2 GROUND Table 3-6: CF Card Socket Pinouts 3.3.5 CPU Fan Connector (+12V, 3-pin) CN Label: CN Type: 3-pin header...

  • Page 34: Digital Input/Output (Dio) Connector

    KINO-945GSE3 User Manual PIN NO. DESCRIPTION FANIO1 PWM1 Table 3-7: +12V Fan Connector Pinouts 3.3.6 Digital Input/Output (DIO) Connector CN Label: DIO1 CN Type: 10-pin header (2x5) CN Location: See Figure 3-7 See Table 3-8 CN Pinouts: The digital input/output connector is managed through a Super I/O chip. The DIO connector pins are user programmable.

  • Page 35: Front Panel Connector (8-Pin)

    KINO-945GSE3 User Manual 3.3.7 Front Panel Connector (8-pin) CN Label: F_PANEL1 14-pin header (2x7) CN Type: CN Location: See Figure 3-8 CN Pinouts: See Table 3-9 The front panel connector connects to external switches and indicators to monitor and controls the CPU card.

  • Page 36: Infrared Interface Connector

    KINO-945GSE3 User Manual 3.3.8 Infrared Interface Connector CN Label: 5-pin header (1x5) CN Type: CN Location: F igure 3-9 CN Pinouts: T able 3-10 The infrared interface connector supports both Serial Infrared (SIR) and Amplitude Shift Key Infrared (ASKIR) interfaces.

  • Page 37: Lvds Lcd Connector

    KINO-945GSE3 User Manual The keyboard/mouse connector connects to a PS/2 Y-cable that can be connected to a PS/2 keyboard and mouse. Figure 3-10: Keyboard/Mouse Connector Location Description +5 V KB DATA MS DATA MS CLK KB DATA KB CLK GROUND Table 3-11: Keyboard/Mouse Connector Pinouts 3.3.10 LVDS LCD Connector...

  • Page 38: Figure 3-11: Lvds Connector Location

    KINO-945GSE3 User Manual Figure 3-11: LVDS Connector Location Description Description GROUND GROUND LVDSA_Y0+ LVDSA_Y0- LVDSA_Y1+ LVDSA_Y1- LVDSA_Y2+ LVDSA_Y2- LVDSA_CLK+ LVDSA_CLK- GROUND GROUND LVDSB_Y0+ LVDSB_Y0- LVDSB_Y1+ LVDSB_Y1- LVDSB_Y2+ LVDSB_Y2- LVDSB_CLK+ LVDSB_CLK- GROUND GROUND VCC_LVDS VCC_LVDS VCC_LVDS VCC_LVDS Table 3-12: LVDS Connector Pinouts...

  • Page 39: Parallel Ata (Ide)

    KINO-945GSE3 User Manual 3.3.11 Parallel ATA (IDE) CN Label: IDE1 44-pin box header (2x22) CN Type: CN Location: See Figure 3-12 CN Pinouts: See Table 3-13 The Parallel ATA (IDE) connector can connect to an IDE hard drive or optical device.

  • Page 40: Pci Slot

    KINO-945GSE3 User Manual Description Description IDE CHRDY GROUND IDE DACK GROUND–DEFAULT INTERRUPT HDC CS0# HDC CS1# HDD ACTIVE# GROUND GROUND Table 3-13: IDE Connector Pinouts 3.3.12 PCI Slot CN Label: PCI1 CN Type: PCI Slot CN Location: See Figure 3-13...
  • Page 41 KINO-945GSE3 User Manual Description Description TRST -12 V +12 V +5 V +5 V INTA +5 V INTC INTB +5 V INTD RESERVED3 PRSNT1 +5 V RESERVED1 RESERVED4 PRSNT2 3.3 V_AUX RESERVED2 +5 V +5 V AD30 AD31 +3.3 V...

  • Page 42: Table 3-14: Pci Slot

    KINO-945GSE3 User Manual Description Description +3.3 V C/BE2 FRAME IRDY TRDY +3.3 V DEVSEL STOP +3.3 V LOCK SDONE PERR +3.3 V SERR +3.3 V AD15 C/BE1 +3.3 V AD14 AD13 AD11 AD12 AD10 C/BE0 +3.3 V +3.3 V +5 V...

  • Page 43: Pcie Mini Card Slot

    KINO-945GSE3 User Manual 3.3.13 PCIe Mini Card Slot CN Label: MINIPCIE1 PCIe Mini card slot CN Type: CN Location: F igure 3-14 CN Pinouts: See Table 3-15 The PCIe Mini card slot is for installing PCIe Mini expansion cards. Figure 3-14: PCIe Mini Card Slot Location...

  • Page 44: Sata Drive Connectors

    KINO-945GSE3 User Manual Description Description PETN2 SMBDATA PETP2 USBD- USBD+ RF_LINK# BLUELED# 1.5 V VCC3 Table 3-15: PCIe Mini Card Slot Pinouts 3.3.14 SATA Drive Connectors CN Label: SATA1, SATA2 CN Type: 7-pin SATA drive connectors F igure 3-15 CN Location:...

  • Page 45: Serial Port Connector

    KINO-945GSE3 User Manual Figure 3-15: SATA Drive Connector Locations PIN NO. DESCRIPTION Table 3-16: SATA Drive Connector Pinouts 3.3.15 Serial Port Connector CN Label: COM3-6, COM7-10 CN Type: 40-pin header (2x20) CN Location: See Figure 3-16 See Table 3-17 CN Pinouts: Each connector provides RS-232 connections for four serial ports.

  • Page 46: Figure 3-16: Serial Port Connector Location

    KINO-945GSE3 User Manual Figure 3-16: Serial Port Connector Location Description Description DATA CARRIER DETECT (DCD1) DATA SET READY (DSR1) RECEIVE DATA (RXD1) REQUEST TO SEND (RTS1) TRANSMIT DATA (TXD1) CLEAR TO SEND (CTS1) DATA TERMINAL READY (DTR1) RING INDICATOR (RI1)

  • Page 47: Spi Flash Connector

    KINO-945GSE3 User Manual Description Description Table 3-17: Serial Port Connector Pinouts 3.3.16 SPI Flash Connector CN Label: JSPI1 8-pin header (2x4) CN Type: CN Location: See Figure 3-17 CN Pinouts: See Table 3-18 The 8-pin SPI Flash connector is used to flash the BIOS.

  • Page 48: Hdtv Out Connector

    KINO-945GSE3 User Manual 3.3.17 HDTV Out Connector CN Label: 6-pin header (2x3) CN Type: CN Location: See Figure 3-18 CN Pinouts: See Table 3-19 The HDTV out connector connects to a TV by using S-Video, Composite or Component interfaces. Figure 3-18: TV Connector Pinout Locations...

  • Page 49: External Peripheral Interface Connector Panel

    KINO-945GSE3 User Manual The 2x4 USB pin connector provides connectivity to two USB 1.1 or two USB 2.0 ports. Each USB connector can support two USB devices. Additional external USB ports are found on the rear panel. The USB ports are used for I/O bus expansion.

  • Page 50: Audio Connector

    KINO-945GSE3 User Manual 3.4.1 Audio Connector CN Label: AUDIO1 Audio jacks CN Type: CN Location: See Figure 3-20 The audio jacks connect to external audio devices. Line Out port (Lime): Connects to a headphone or a speaker. With multi-channel configurations, this port can also connect to front speakers.

  • Page 51: Keyboard/Mouse Connector

    KINO-945GSE3 User Manual Description Description Description DDC Clock [SCL] PVDD1 DDC Data [SDA] TMDS Clock + Analog vertical sync TMDS Clock - Analog Red Analog Green Analog Blue Analog Horizontal Sync Analog GND Table 3-21: DVI Connector Pinouts 3.4.3 Keyboard/Mouse Connector...

  • Page 52: Lan Connector

    KINO-945GSE3 User Manual Description Description L_KDAT L_MDAT L_KCLK L_MCLK Table 3-22: PS/2 Connector Pinouts 3.4.4 LAN Connector CN Label: LAN/USB1, LAN/USB2 CN Type: RJ-45 CN Location: See Figure 3-20 CN Pinouts: See Table 3-23 and Figure 3-23 A 10/100/1000 Mb/s connection can be made to a Local Area Network.

  • Page 53: Serial Port Connector (Com1 Rs-232)

    KINO-945GSE3 User Manual Description Description on: linked off: 10 Mb/s blinking: data is being sent/received green: 100 Mb/s orange: 1000 Mb/s Table 3-24: Connector LEDs 3.4.5 Serial Port Connector (COM1 RS-232) CN Label: COM1 (top) CN Type: DB-9 connectors CN Location:...

  • Page 54: Serial Port Connectors (Com3 Rs-232/422/485)

    KINO-945GSE3 User Manual 3.4.6 Serial Port Connectors (COM3 RS-232/422/485) CN Label: COM1 (bottom) DB-9 connector CN Type: CN Location: See Figure 3-20 CN Pinouts: See Table 3-26 and Figure 3-25 The pinouts for RS-232, RS-422 and RS-485 communication are shown below.

  • Page 55: Usb Connector

    KINO-945GSE3 User Manual 3.4.7 USB Connector CN Label: USB_C23, USB_C45 USB port CN Type: CN Location: See Figure 3-20 CN Pinouts: See Table 3-27 The USB connector can be connected to a USB device. Description Description USBV3L 5 V USBP4N...

  • Page 56: Table 3-28: Vga Connector Pinouts

    KINO-945GSE3 User Manual Description Description GREEN BLUE VCC / NC DDC DAT HSYNC VSYNC DDCCLK Table 3-28: VGA Connector Pinouts Page 42...

  • Page 57: Installation

    KINO-945GSE3 User Manual Chapter Installation Page 43...

  • Page 58: Anti-Static Precautions

    KINO-945GSE3 and severe injury to the user. Electrostatic discharge (ESD) can cause serious damage to electronic components, including the KINO-945GSE3. Dry climates are especially susceptible to ESD. It is therefore critical that whenever the KINO-945GSE3 or any other electrical component is handled, the following anti-static precautions are strictly adhered to.

  • Page 59: So-Dimm Installation

    This helps to prevent potential ESD damage. Turn all power to the KINO-945GSE3 off: When working with the KINO-945GSE3, make sure that it is disconnected from all power supplies and that no electricity is being fed into the system.

  • Page 60: Compactflash® Installation

    KINO-945GSE3 User Manual Figure 4-1: SO-DIMM Installation Step 1: Locate the SO-DIMM socket. Place the board on an anti-static mat. Step 2: Align the SO-DIMM with the socket. Align the notch on the memory with the notch on the memory socket.

  • Page 61: Jumper Settings

    KINO-945GSE3 User Manual Figure 4-2: CompactFlash® Card Installation 4.3 Jumper Settings NOTE: A jumper is a metal bridge used to close an electrical circuit. It consists of two or three metal pins and a small metal clip (often protected by a plastic cover) that slides over the pins to connect them.

  • Page 62: At Power Select Jumper Settings

    KINO-945GSE3 User Manual Description Label Type AT power mode setting ATXCTL1 2-pin header AT/ATX power supply type J_PSON1 3-pin header CF card setup J_CF1 2-pin header Clear CMOS J_CMOS1 3-pin header COM2 RS-232/4222/485 mode select JP1, JP2 6-pin header LVDS voltage selection...

  • Page 63: At/Atx Power Supply Type Jumper

    KINO-945GSE3 User Manual Figure 4-3: AT Power Select Jumper Location 4.3.2 AT/ATX Power Supply Type Jumper Jumper Label: J_PSON1 Jumper Type: 3-pin header Jumper Settings: See Table 4-3 See Figure 4-4 Jumper Location: The AT/ATX Power Supply Type jumper specifies the systems power mode as AT or ATX.

  • Page 64: Cf Card Setup

    KINO-945GSE3 User Manual Figure 4-4: AT/ATX Power Mode Jumper Location 4.3.3 CF Card Setup Jumper Label: J_CF1 Jumper Type: 2-pin header Jumper Settings: See Table 4-4 See Figure 4-5 Jumper Location: The CompactFlash® slot is connected through an IDE connection. This jumper sets the CompactFlash®...

  • Page 65: Clear Cmos Jumper

    Jumper Location: F igure 4-6 If the KINO-945GSE3 fails to boot due to improper BIOS settings, the clear CMOS jumper clears the CMOS data and resets the system BIOS information. To do this, use the jumper cap to close pins 2 and 3 for a few seconds then reinstall the jumper clip back to pins 1 and 2.

  • Page 66: Com2 Function Select Jumper

    KINO-945GSE3 User Manual Figure 4-6: Clear CMOS Jumper 4.3.5 COM2 Function Select Jumper Jumper Label: JP1, JP2 Jumper Type: 6-pin header See Table 4-6 Jumper Settings: Jumper Location: See Figure 4-7 The COM2 Function Select jumper sets the communication protocol used by the second serial communications port (COM2) as RS-232, RS-422 or RS-485.

  • Page 67: Lvds1 Panel Resolution Jumper

    KINO-945GSE3 User Manual Figure 4-7: COM2 Function Select Jumper Location 4.3.6 LVDS1 Panel Resolution Jumper Jumper Label: J_LCD_TYPE1 Jumper Type: 8-pin header Jumper Settings: See Table 4-7 Jumper Location: See Figure 4-8 The LVDS1 Panel Resolution jumper allows the resolution of the LVDS screens connected to the LVDS1 connector to be configured.

  • Page 68: Lvds Voltage Selection

    Figure 4-8: LVDS Panel Resolution Jumper Pinout Locations 4.3.7 LVDS Voltage Selection WARNING: Permanent damage to the screen and KINO-945GSE3 may occur if the wrong voltage is selected with this jumper. Please refer to the user guide that cam with the monitor to select the correct voltage.

  • Page 69: Usb Power Supply Type Setting

    KINO-945GSE3 User Manual Figure 4-9: LVDS Voltage Selection Jumper Pinout Locations 4.3.8 USB Power Supply Type Setting Jumper Label: J_USBP1 Jumper Type: 3-pin header Jumper Settings: See Table 4-8 Jumper Location: See Figure 4-9 The USB Power Supply Type Setting jumper allows the USB port voltages to be set.

  • Page 70: Chassis Installation

    The chassis should have fans and vents as necessary to keep things cool. The KINO-945GSE3 must be installed in a chassis with ventilation holes on the sides allowing airflow to travel through the heat sink surface. In a system with an individual power supply unit, the cooling fan of a power supply can also help generate airflow through the board surface.

  • Page 71: Four Serial Port Connector

    KINO-945GSE3 User Manual 4.5.1 Four Serial Port Connector The 40-pin serial port connector connects the board connector to four DB-9 connectors. To install, please follow the steps below. Step 4: Locate the COM connector. The locations of the COM port connectors are shown in Chapter 4.

  • Page 72: Sata Drive Connection

    KINO-945GSE3 User Manual Figure 4-12: Serial Device Connector 4.5.2 SATA Drive Connection The KINO-945GSE3 is shipped with two SATA drive cables and one SATA drive power cable. To connect the SATA drives to the connectors, please follow the steps below. Step 1: Locate the connectors.

  • Page 73: Figure 4-13: Sata Drive Cable Connection

    KINO-945GSE3 User Manual Figure 4-13: SATA Drive Cable Connection Step 3: Connect the cable to the SATA disk. Connect the connector on the other end of the cable to the connector at the back of the SATA drive. See Figure 4-14.

  • Page 74: External Peripheral Interface Connection

    RJ-45 Ethernet cable connectors PS/2 keyboard/mouse Serial port devices USB devices VGA monitors To install these devices, connect the corresponding cable connector from the actual device to the corresponding KINO-945GSE3 external peripheral interface connector making sure the pins are properly aligned. Page 60...

  • Page 75: Dvi Display Device Connection

    KINO-945GSE3 User Manual 4.6.1 DVI Display Device Connection The KINO-945GSE3 has a single female DVI-D connector on the external peripheral interface panel. The DVI-D connector is connected to a digital display device. To connect a digital display device to the KINO-945GSE3, please follow the instructions below.

  • Page 76: Lan Connection (Single Connector)

    Step 0: 4.6.3 PS/2 Keyboard and Mouse Connection The KINO-945GSE3 has a dual PS/2 connector on the external peripheral interface panel. The dual PS/2 connector is used to connect to a keyboard and mouse to the system. Follow the steps below to connect a keyboard and mouse to the KINO-945GSE3.

  • Page 77: Serial Device Connection

    Figure 4-17: PS/2 Keyboard/Mouse Connector 4.6.4 Serial Device Connection The KINO-945GSE3 has two female DB-9 connectors (one for RS-232 and one for RS-232/422/485) on the external peripheral interface panel for a serial device. Follow the steps below to connect a serial device to the KINO-945GSE3.

  • Page 78: Usb Connection (Dual Connector)

    KINO-945GSE3 User Manual Figure 4-18: Serial Device Connector Step 5: Secure the connector. Secure the serial device connector to the external interface by tightening the two retention screws on either side of the connector. Step 0: 4.6.5 USB Connection (Dual Connector) The external USB Series "A"...

  • Page 79: Vga Monitor Connection

    Figure 4-19: USB Connector 4.6.6 VGA Monitor Connection The KINO-945GSE3 has a single female DB-15 connector on the external peripheral interface panel. The DB-15 connector is connected to a CRT or VGA monitor. To connect a monitor to the KINO-945GSE3, please follow the instructions below.

  • Page 80: Software Installation

    Step 0: 4.7 Software Installation All the drivers for the KINO-945GSE3 are on the CD that came with the system. To install the drivers, please follow the steps below. Step 1: Insert the CD into a CD drive connected to the system.

  • Page 81: Figure 4-21: Introduction Screen

    KINO-945GSE3 User Manual Figure 4-21: Introduction Screen Step 3: Click KINO-945GSE3. Step 4: A new screen with a list of available drivers appears (Figure 4-22). Figure 4-22: Available Drivers Step 5: Install all of the necessary drivers in this menu.

  • Page 82: Bios Screens

    KINO-945GSE3 User Manual Chapter BIOS Screens Page 68...

  • Page 83: Introduction

    KINO-945GSE3 User Manual 5.1 Introduction The BIOS is programmed onto the BIOS chip. The BIOS setup program allows changes to certain system settings. This chapter outlines the options that can be changed. 5.1.1 Starting Setup The AMI BIOS is activated when the computer is turned on. The setup program can be activated in one of two ways.

  • Page 84: Getting Help

    KINO-945GSE3 User Manual Function F2 /F3 key Change color from total 16 colors. F2 to select color forward. F10 key Save all the CMOS changes, only for Main Menu Table 5-1: BIOS Navigation Keys 5.1.3 Getting Help When F1 is pressed a small help window describing the appropriate keys to use and the possible selections for the highlighted item appears.

  • Page 85: Main

    KINO-945GSE3 User Manual 5.2 Main The Main BIOS menu (BIOS Menu 1) appears when the BIOS Setup program is entered. The Main menu gives an overview of the basic system information. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset...

  • Page 86: Advanced

    KINO-945GSE3 User Manual The System Overview field also has two user configurable fields: System Time [xx:xx:xx] Use the System Time option to set the system time. Manually enter the hours, minutes and seconds. System Date [xx/xx/xx] Use the System Date option to set the system date. Manually enter the day, month and year.

  • Page 87: Cpu Configuration

    KINO-945GSE3 User Manual BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Power Exit Advanced Settings Configure CPU ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ WARNING: Setting wrong values in below sections may cause system to malfunction > CPU Configuration > IDE Configuration > SuperIO Configuration Select Screen >...

  • Page 88: Ide Configuration

    KINO-945GSE3 User Manual Frequency: Lists the CPU processing speed FSB Speed: Lists the FSB speed Cache L1: Lists the CPU L1 cache size Cache L2: Lists the CPU L2 cache size 5.3.2 IDE Configuration Use the IDE Configuration menu (BIOS Menu 4) to change and/or set the configuration of the IDE devices installed in the system.
  • Page 89 KINO-945GSE3 User Manual Enhanced Configures the on-board ATA/IDE controller to be in EFAULT Enhanced mode. In this mode, IDE channels and SATA channels are separated. This mode supports up to 6 storage devices. Some legacy OS do not support this mode.

  • Page 90: Ide Master, Ide Slave

    KINO-945GSE3 User Manual Disabled Allows hard disks to be overwritten EFAULT Prevents hard disks from being overwritten Enabled IDE Detect Time Out (Sec) [35] Use the IDE Detect Time Out (Sec) BIOS to specify the maximum time (in seconds) the AMI BIOS can search for IDE devices.

  • Page 91: Bios Menu 5: Ide Master And Ide Slave Configuration

    KINO-945GSE3 User Manual BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Power Exit Primary IDE Master Select the type of device ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ connected to the system Device :Not Detected Type [Auto] LBA/Large Mode [Auto] Block (Multi-Sector Transfer) [Auto] PIO Mode...
  • Page 92 KINO-945GSE3 User Manual 32Bit Data Transfer: Enables 32-bit data transfer. Type [Auto] Use the Type BIOS option select the type of device the AMIBIOS attempts to boot from after the Power-On Self-Test (POST) is complete. Not Installed BIOS is prevented from searching for an IDE disk drive on the specified channel.
  • Page 93 KINO-945GSE3 User Manual Block (Multi Sector Transfer) [Auto] Use the Block (Multi Sector Transfer) to disable or enable BIOS to auto detect if the device supports multi-sector transfers. Disabled BIOS is prevented from using Multi-Sector Transfer on the specified channel. The data to and from the device occurs one sector at a time.
  • Page 94 KINO-945GSE3 User Manual Auto BIOS auto detects the DMA mode. Use this value if the IDE EFAULT disk drive support cannot be determined. Single Word DMA mode 0 selected with a maximum data SWDMA0 transfer rate of 2.1 MB/s SWDMA1 Single Word DMA mode 1 selected with a maximum data transfer rate of 4.2 MB/s...

  • Page 95: Super Io Configuration

    KINO-945GSE3 User Manual S.M.A.R.T [Auto] Use the S.M.A.R.T option to auto-detect, disable or enable Self-Monitoring Analysis and Reporting Technology (SMART) on the drive on the specified channel. S.M.A.R.T predicts impending drive failures. The S.M.A.R.T BIOS option enables or disables this function.

  • Page 96: Bios Menu 6: Super Io Configuration

    KINO-945GSE3 User Manual BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Power Exit Configure ITE8718 Super I/O Chipset Allows BIOS to select ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ Serial Port Base Addresses Serial Port1 Address [3F8] Serial Port1 IRQ [IRQ4] Serial Port2 Address [2F8]...
  • Page 97 KINO-945GSE3 User Manual Serial Port1 IRQ [IRQ4] Use the Serial Port1 IRQ option to select the interrupt address for serial port 1. Serial port 1 IRQ address is 3. IRQ3 IRQ4 Serial port 1 IRQ address is 4. EFAULT IRQ10 Serial port 1 IRQ address is 10.
  • Page 98 KINO-945GSE3 User Manual 2F8/IRQ3 Serial Port 2 I/O port address is 3F8 and the interrupt EFAULT address is IRQ3 Serial Port 2 I/O port address is 3E8 and the interrupt 3E8/IRQ4 address is IRQ4 2E8/IRQ3 Serial Port 2 I/O port address is 2E8 and the interrupt...
  • Page 99 KINO-945GSE3 User Manual IRQ10 Serial port 3 IRQ address is 10. Select RS232 or RS485/RS422 [RS/232] Use the Select RS232 or RS485/RS422 option to select the Serial Port 3 signaling mode. Serial Port 3 signaling mode is RS-232 RS232 EFAULT...
  • Page 100 KINO-945GSE3 User Manual Serial Port 5 I/O port address is 3F8. Serial Port 5 I/O port address is 2F8 Serial Port 5 I/O port address is 3E8. Serial Port 5 I/O port address is 2E8. Serial Port 5 I/O port address is 3E0.
  • Page 101 KINO-945GSE3 User Manual IRQ4 Serial port 6 IRQ address is 4. Serial port 6 IRQ address is 10. IRQ10 EFAULT IR Function Use the IR Function option sets the protocol for IrDA. Disabled IrDA is disabled. EFAULT I.6 uS IrDA protocol is 1.6 uS.
  • Page 102 KINO-945GSE3 User Manual Serial Port 7 I/O port address is 280. Serial Port8 IRQ [11] Use the Serial Port8 IRQ option to select the interrupt address for serial port 8. Serial Port9 Address [380] Use the Serial Port9 Address option to select the Serial Port 9 base address.

  • Page 103: Hardware Health Configuration

    BIOS Menu 7: Hardware Health Configuration FAN 1 Mode Setting [Auto Fan by RPM] The FAN 1 Mode Setting options are not supported on the KINO-945GSE3. Hardware Health Monitoring The following system parameters and values are shown. The system parameters that are...

  • Page 104: Power Configuration

    KINO-945GSE3 User Manual VBAT 5.3.5 Power Configuration The Power Configuration menu (BIOS Menu 8) configures the Advanced Configuration and Power Interface (ACPI) and Power Management (APM) options. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Power Exit Select AT/ATX Power...

  • Page 105: Acpi Configuration

    KINO-945GSE3 User Manual 5.3.5.1 ACPI Configuration Use the ACPI Configuration menu (BIOS Menu 9) to select the ACPI state when the system is suspended. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Power Exit ACPI Settings ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ Suspend Mode...

  • Page 106: Bios Menu 10: Apm Configuration

    KINO-945GSE3 User Manual BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Power Exit APM Configuration Go into On/Off, or ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ Suspend when Power button is pressed Restore on AC Power Loss [Power On] Power Button Mode [On/Off] Advanced Resume Event Controls...
  • Page 107 KINO-945GSE3 User Manual Resume on Keyboard/Mouse [Disabled] Use the Resume on Keyboard/Mouse BIOS option to enable activity on either the keyboard or mouse to rouse the system from a suspend or standby state. That is, the system is roused when the mouse is moved or a button on the keyboard is pressed.

  • Page 108: Remote Access Configuration

    KINO-945GSE3 User Manual Enabled If selected, the following appears with values that can be selected: RTC Alarm Date (Days) System Time After setting the alarm, the computer turns itself on from a suspend state when the alarm goes off. Resume on PCI-Express WAKE# [Enabled] The Resume on PCI-Express WAKE# BIOS option specifies if the system is roused from a suspended or standby state when there is activity on the PCI-Express bus.
  • Page 109 KINO-945GSE3 User Manual Remote Access [Disabled] Use the Remote Access option to enable or disable access to the remote functionalities of the system. Disabled Remote access is disabled. EFAULT Remote access configuration options shown below Enabled appear: Serial Port Number...
  • Page 110 KINO-945GSE3 User Manual 115200 8,n,1 EFAULT 57600 8,n,1 38400 8,n,1 19200 8,n,1 09600 8,n,1 NOTE: Identical baud rate setting musts be set on the host (a management computer running a terminal software) and the slave Redirection After BIOS POST [Always] Use the Redirection After BIOS POST option to specify when console redirection should occur.

  • Page 111: Usb Configuration

    KINO-945GSE3 User Manual The VT100 Terminal Definition is the standard convention used to configure and conduct emergency management tasks with UNIX-based servers. VT100 does not support all keys on the standard PC 101-key layout, however. The VT-UTF8 convention makes available additional keys that are not provided by VT100 for the PC 101 keyboard.
  • Page 112 KINO-945GSE3 User Manual USB Function [Enabled] Use the USB Function BIOS option to enable or disable USB function support. USB function support disabled Disabled Enabled USB function support enabled EFAULT USB 2.0 Controller [Enabled] Use the USB 2.0 Controller BIOS option to enable or disable the USB 2.0 controller Disabled USB 2.0 controller disabled...

  • Page 113: Usb Mass Storage Device Configuration

    KINO-945GSE3 User Manual 5.3.8.1 USB Mass Storage Device Configuration Use the USB Mass Storage Device Configuration menu (BIOS Menu 13) to configure USB mass storage class devices. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Power Exit USB Mass Storage Device Configuration ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯...

  • Page 114: Pci/Pnp

    KINO-945GSE3 User Manual Emulation Type [Auto] Use the Emulation Type BIOS option to specify the type of emulation BIOS has to provide for the USB device. Auto BIOS auto-detects the current USB. EFAULT The USB device will be emulated as a floppy drive.

  • Page 115: Bios Menu 14: Pci/Pnp Configuration

    KINO-945GSE3 User Manual BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Power Exit Advanced PCI/PnP Settings Available: Specified IRQ ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ is available to be use the PCI/PnP devices WARNING: Setting wrong values in below sections Reserved: Specified IRQ may cause system to malfunction...
  • Page 116 KINO-945GSE3 User Manual IRQ9 IRQ10 IRQ 11 IRQ 14 IRQ 15 DMA Channel# [Available] Use the DMA Channel# option to assign a specific DMA channel to a particular PCI/PnP device. Available The specified DMA is available to be used by...

  • Page 117: Boot

    KINO-945GSE3 User Manual 5.5 Boot Use the Boot menu (BIOS Menu 15) to configure system boot options. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Power Exit Boot Settings Configure settings ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ during system boot. > Boot Settings Configuration >...
  • Page 118 KINO-945GSE3 User Manual Quick Boot [Enabled] Use the Quick Boot BIOS option to make the computer speed up the boot process. No POST procedures are skipped Disabled Enabled Some POST procedures are skipped to decrease EFAULT the system boot time...
  • Page 119 KINO-945GSE3 User Manual Bootup Num-Lock [On] Use the Bootup Num-Lock BIOS option to specify if the number lock setting must be modified during boot up. Does not enable the keyboard Number Lock automatically. To use the 10-keys on the keyboard, press the Number Lock key located on the upper left-hand corner of the 10-key pad.

  • Page 120: Boot Device Priority

    KINO-945GSE3 User Manual 5.5.2 Boot Device Priority Use the Boot Device Priority menu (BIOS Menu 17) to specify the boot sequence from the available devices. The drive sequence also depends on the boot sequence in the individual device section. BIOS SETUP UTILITY...

  • Page 121: Hard Disk Drives

    KINO-945GSE3 User Manual 5.5.3 Hard Disk Drives Use the Hard Disk Drives menu to specify the boot sequence of the available HDDs. Only installed hard drives are shown. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Power Exit Hard Disk Drives Specifies the boot ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯...

  • Page 122: Removable Drives

    KINO-945GSE3 User Manual 5.5.4 Removable Drives Use the Removable Drives menu (BIOS Menu 19) to specify the boot sequence of the removable drives. Only connected drives are shown. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Power Exit Hard Disk Drives Specifies the boot ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯...

  • Page 123: Security

    KINO-945GSE3 User Manual The boot sequence from the available devices is selected. If the “1st Drive” option is selected a list of available CD/DVD drives is shown. Select the first CD/DVD drive the system boots from. If the “1st Drive” is not used for booting this option may be disabled.

  • Page 124: Chipset

    KINO-945GSE3 User Manual Change Supervisor Password Use the Change Supervisor Password to set or change a supervisor password. The default for this option is Not Installed. If a supervisor password must be installed, select this field and enter the password. After the password has been added, Install appears next to Change Supervisor Password.

  • Page 125: Northbridge Configuration

    KINO-945GSE3 User Manual BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Power Exit Advanced Chipset Settings ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ WARNING: Setting wrong values in below section may cause system to malfunction. > Northbridge Configuration > Southbridge Configuration Select Screen ↑ ↓...
  • Page 126 KINO-945GSE3 User Manual Memory Hole [Disabled] Use the Memory Hole option to reserve memory space between 15 MB and 16 MB for ISA expansion cards that require a specified area of memory to work properly. If an older ISA expansion card is used, please refer to the documentation that came with the card to see if it is necessary to reserve the space.
  • Page 127 KINO-945GSE3 User Manual DVMT/FIXED Memory [128 MB] Use the DVMT/FIXED Memory option to specify the maximum amount of memory that can be allocated as graphics memory. This option can only be configured for if DVMT Mode or Fixed Mode is selected in the DVMT Mode Select option. If Combo Mode is selected, the maximum amount of graphics memory is 128 MB.

  • Page 128: Southbridge Configuration

    KINO-945GSE3 User Manual LVDS1 Current Jumper Setting The LVDS1 Current Jumper Setting displays the current jumper setting configuration. TV Standard [VBIOS] Use the TV Standard option to select the standard of the television connected to the system. The configuration options are listed below.

  • Page 129: Exit

    KINO-945GSE3 User Manual BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Power Exit Southbridge Configuration ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ Audio Controller [Auto] Select Screen ↑ ↓ Select Item Enter Go to SubScreen General Help Save and Exit Exit v02.61 ©Copyright 1985-2006, American Megatrends, Inc.

  • Page 130: Bios Menu 25: Exit

    KINO-945GSE3 User Manual BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Power Exit Exit Options Exit system setup after ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ saving the changes. Save Changes and Exit F10 key can be used for Discard Changes and Exit this operation...
  • Page 131 KINO-945GSE3 User Manual Page 117...

  • Page 132: Abios Options

    KINO-945GSE3 User Manual Appendix BIOS Options Page 118...
  • Page 133 KINO-945GSE3 User Manual Below is a list of BIOS configuration options in the BIOS chapter. 　 System Overview .........................71 　 System Time [xx:xx:xx] .......................72 　 System Date [xx/xx/xx] ......................72 　 ATA/IDE Configurations [Compatible]................74 　 Legacy IDE Channels [PATA Pri, SATA Sec] ..............75 　...
  • Page 134 KINO-945GSE3 User Manual 　 Serial Port7 IRQ [11] ......................87 　 Serial Port8 Address [288] ....................87 　 Serial Port8 IRQ [11] ......................88 　 Serial Port9 Address [380] ....................88 　 Serial Port9 IRQ [11] ......................88 　 Serial Port10 Address [280] ....................88 　...
  • Page 135 KINO-945GSE3 User Manual 　 DMA Channel# [Available] ....................102 　 Reserved Memory Size [Disabled] .................. 102 　 Quick Boot [Enabled] ....................... 104 　 Boot From LAN Support [Disabled] ................104 　 Quiet Boot [Disabled] ....................... 104 　 AddOn ROM Display Mode [Force BIOS] ............... 104 　...

  • Page 136: B One Key Recovery

    KINO-945GSE3 User Manual Appendix One Key Recovery Page 122...

  • Page 137: One Key Recovery Introduction

    KINO-945GSE3 User Manual B.1 One Key Recovery Introduction The IEI one key recovery is an easy-to-use front end for the Norton Ghost system backup and recovery tool. The one key recovery provides quick and easy shortcuts for creating a backup and reverting to that backup or for reverting to the factory default settings.
  • Page 138 KINO-945GSE3 User Manual Microsoft Windows Windows XP (Service Pack 2 or 3 required) Windows Vista Windows 7 Windows CE 5.0 Windows CE 6.0 Windows XP Embedded Linux Fedora Core 12 (Constantine) Fedora Core 11 (Leonidas) Fedora Core 10 (Cambridge) Fedora Core 8 (Werewolf) Fedora Core 7 (Moonshine) RedHat RHEL-5.4...

  • Page 139: Setup Procedure For Windows

    KINO-945GSE3 User Manual NOTE: The recovery CD can only be used with IEI products. The software will fail to run and a warning message will appear when used on non-IEI hardware. B.2 Setup Procedure for Windows Prior to using the recovery tool to backup or restore system, a few setup procedures are required.

  • Page 140: Hardware And Bios Setup

    Step 2: Install a hard driver or SSD in the KINO-945GSE3. An unformatted and unpartitioned disk is recommended. Step 3: Connect an optical disk drive to the KINO-945GSE3 and insert the recovery CD. Step 4: Turn on the system. Step 5: Press the <DELETE>...

  • Page 141: Figure B-1: Recovery Tool Setup Menu

    KINO-945GSE3 User Manual Figure B-1: Recovery Tool Setup Menu Step 5: Press <5> then <Enter>. Figure B-2: Command Mode Step 6: The command prompt window appears. Type the following commands (marked in red) to create two partitions. One is for the OS installation; the other is for saving recovery files and images which will be an invisible partition.

  • Page 142: Figure B-3: Partition Creation Commands

    KINO-945GSE3 User Manual system32>format F: /fs:ntfs /q /v:Recovery /y system32>exit Figure B-3: Partition Creation Commands Page 128...

  • Page 143: Install Operating System, Drivers And Applications

    KINO-945GSE3 User Manual NOTE: Use the following commands to check if the partitions were created successfully. Step 7: Press any key to exit the recovery tool and automatically reboot the system. Please continue to the following procedure: Build-up Recovery Partition.S t e p 0 : B.2.3 Install Operating System, Drivers and Applications...

  • Page 144: Build-Up Recovery Partition

    KINO-945GSE3 User Manual B.2.4 Build-up Recovery Partition Step 1: Put the recover CD in the optical drive. Step 2: Start the system. Step 3: Press any key to boot from the recovery CD. It will take a while to launch the recovery tool.

  • Page 145: Figure B-5: Build-Up Recovery Partition

    KINO-945GSE3 User Manual Figure B-5: Build-up Recovery Partition Step 6: After completing the system configuration, press any key in the following window to reboot the system. Figure B-6: Press any key to continue Step 7: Eject the recovery CD. S t e p 0 :...

  • Page 146: Create Factory Default Image

    KINO-945GSE3 User Manual B.2.5 Create Factory Default Image NOTE: Before creating the factory default image, please configure the system to a factory default environment, including driver and application installations. To create a factory default image, please follow the steps below.

  • Page 147: Figure B-9: About Symantec Ghost Window

    KINO-945GSE3 User Manual Figure B-9: About Symantec Ghost Window Step 4: Use mouse to navigate to the option shown below (Figure B-10). Figure B-10: Symantec Ghost Path Step 5: Select the local source drive as shown in Figure B-11. Then click OK.

  • Page 148: Figure B-11: Select A Local Source Drive

    Select 1.2: [Recovery] NTFS drive and enter a file name called (Figure B-13). Click Save. The factory default image will then be saved in the selected recovery drive and named IEI.GHO. WARNING: The file name of the factory default image must be iei.GHO. Page 134...

  • Page 149: Figure B-13: File Name To Copy Image To

    KINO-945GSE3 User Manual Figure B-13: File Name to Copy Image to Step 8: When the Compress Image screen in Figure B-14 prompts, click High to make the image file smaller. Figure B-14: Compress Image Page 135...

  • Page 150: Figure B-15: Image Creation Confirmation

    KINO-945GSE3 User Manual Step 9: The Proceed with partition image creation window appears, click Yes to continue. Figure B-15: Image Creation Confirmation Step 10: The Symantec Ghost starts to create the factory default image (Figure B-16). Figure B-16: Image Creation Complete Step 11: When the image creation completes, a screen prompts as shown in Figure B-17.

  • Page 151: Setup Procedure For Linux

    KINO-945GSE3 User Manual Step 12: The recovery tool main menu window is shown as below. Press any key to reboot the system. S t e p 0 : Figure B-18: Press Any Key to Continue B.3 Setup Procedure for Linux The initial setup procedures for Linux system are mostly the same with the procedure for Microsoft Windows.

  • Page 152: Figure B-19: Partitions For Linux

    KINO-945GSE3 User Manual NOTE: Please reserve enough space for partition 3 for saving recovery images. Figure B-19: Partitions for Linux Step 3: Create a recovery partition. Insert the recovery CD into the optical disk drive. Follow Step 1 Step 3 described in Section B.2.2.

  • Page 153: Figure B-20: System Configuration For Linux

    KINO-945GSE3 User Manual recovery partition. After completing the system configuration, press any key to reboot the system. Eject the recovery CD. Figure B-20: System Configuration for Linux Step 5: Access the recovery tool main menu by modifying the “menu.lst”. To first access the recovery tool main menu, the menu.lst must be modified.

  • Page 154: Recovery Tool Functions

    KINO-945GSE3 User Manual Step 7: The recovery tool menu appears. (Figure B-22) Figure B-22: Recovery Tool Menu Step 8: Create a factory default image. Follow Step 2 Step 12 described in Section B.2.5 to create a factory default image. S t e p 8 : B.4 Recovery Tool Functions...

  • Page 155: Figure B-23: Recovery Tool Main Menu

    KINO-945GSE3 User Manual Figure B-23: Recovery Tool Main Menu The recovery tool has several functions including: 1. Factory Restore: Restore the factory default image (iei.GHO) created in Section B.2.5. 2. Backup system: Create a system backup image (iei_user.GHO) which will be saved in the hidden partition.

  • Page 156: Factory Restore

    Type <1> and press <Enter> in the main menu. Step 10: The Symantec Ghost window appears and starts to restore the factory default. A factory default image called iei.GHO is created in the hidden Recovery partition. Figure B-24: Restore Factory Default Step 11: The screen is shown as in Figure B-25 when completed.

  • Page 157: Backup System

    KINO-945GSE3 User Manual B.4.2 Backup System To backup the system, please follow the steps below. Step 12: Type <2> and press <Enter> in the main menu. Step 13: The Symantec Ghost window appears and starts to backup the system. A backup image called iei_user.GHO is created in the hidden Recovery partition.

  • Page 158: Restore Your Last Backup

    KINO-945GSE3 User Manual B.4.3 Restore Your Last Backup To restore the last system backup, please follow the steps below. Step 15: Type <3> and press <Enter> in the main menu. Step 16: The Symantec Ghost window appears and starts to restore the last backup image (iei_user.GHO).

  • Page 159: Manual

    KINO-945GSE3 User Manual B.4.4 Manual To restore the last system backup, please follow the steps below. Step 18: Type <4> and press <Enter> in the main menu. Step 19: The Symantec Ghost window appears. Use the Ghost program to backup or recover the system manually.

  • Page 160: Other Information

    KINO-945GSE3 User Manual B.5 Other Information B.5.1 Using AHCI Mode or ALi M5283 / VIA VT6421A Controller When the system uses AHCI mode or some specific SATA controllers such as ALi M5283 or VIA VT6421A, the SATA RAID/AHCI driver must be installed before using one key recovery.
  • Page 161 KINO-945GSE3 User Manual Step 5: When the following window appears, press <S> to select “Specify Additional Device”. Step 6: In the following window, select a SATA controller mode used in the system. Then press <Enter>. The user can now start using the SATA HDD.

  • Page 162: System Memory Requirement

    KINO-945GSE3 User Manual Step 7: After pressing <Enter>, the system will get into the recovery tool setup menu. Continue to follow the setup procedure from Step 4 in Section 126 to finish the whole setup process. S t e p 0 : B.5.2 System Memory Requirement...

  • Page 163: C Terminology

    KINO-945GSE3 User Manual Appendix Terminology Page 149...
  • Page 164 KINO-945GSE3 User Manual AC ’97 Audio Codec 97 (AC’97) refers to a codec standard developed by Intel® in 1997. ACPI Advanced Configuration and Power Interface (ACPI) is an OS-directed configuration, power management, and thermal management interface. AHCI Advanced Host Controller Interface (AHCI) is a SATA Host controller register-level interface.
  • Page 165 KINO-945GSE3 User Manual Direct Memory Access (DMA) enables some peripheral devices to bypass the system processor and communicate directly with the system memory. DIMM Dual Inline Memory Modules are a type of RAM that offer a 64-bit data bus and have separate electrical contacts on each side of the module.
  • Page 166 KINO-945GSE3 User Manual Liquid crystal display (LCD) is a flat, low-power display device that consists of two polarizing plates with a liquid crystal panel in between. LVDS Low-voltage differential signaling (LVDS) is a dual-wire, high-speed differential electrical signaling system commonly used to connect LCD displays to a computer.

  • Page 167: D Digital I/O Interface

    KINO-945GSE3 User Manual Appendix Digital I/O Interface Page 153...

  • Page 168: Introduction

    KINO-945GSE3 User Manual D.1 Introduction The DIO connector on the KINO-945GSE3 is interfaced to GPIO ports on the Super I/O chipset. The DIO has both 4-bit digital inputs and 4-bit digital outputs. The digital inputs and digital outputs are generally control signals that control the on/off circuit of external devices or TTL devices.

  • Page 169: Assembly Language Samples

    KINO-945GSE3 User Manual D.3 Assembly Language Samples D.3.1 Enable the DIO Input Function The BIOS interrupt call INT 15H controls the digital I/O. An assembly program to enable digital I/O input functions is listed below. Sets the digital port as input...

  • Page 170: E Watchdog Timer

    KINO-945GSE3 User Manual Appendix Watchdog Timer Page 156...
  • Page 171 KINO-945GSE3 User Manual NOTE: The following discussion applies to DOS. Contact IEI support or visit the IEI website for drivers for other operating systems. The Watchdog Timer is a hardware-based timer that attempts to restart the system when it stops working. The system may stop working because of external EMI or software bugs.
  • Page 172 KINO-945GSE3 User Manual NOTE: The Watchdog Timer is activated through software. The software application that activates the Watchdog Timer must also deactivate it when closed. If the Watchdog Timer is not deactivated, the system will automatically restart after the Timer has finished its countdown.

  • Page 173: F Compatibility

    KINO-945GSE3 User Manual Appendix Compatibility Page 159...

  • Page 174: Compatible Operating Systems

    KINO-945GSE3 User Manual NOTE: The compatible items described here have been tested by the IEI R&D team and found to be compatible with the KINO-945GSE3 F.1 Compatible Operating Systems The following operating systems have been successfully run on the KINO-945GSE3.

  • Page 175: G Hazardous Materials Disclosure

    KINO-945GSE3 User Manual Appendix Hazardous Materials Disclosure Page 161...

  • Page 176: Hazardous Materials Disclosure Table For Ipb Products Certified As Rohs Compliant Under 2002/95/Ec Without Mercury

    KINO-945GSE3 User Manual G.1 Hazardous Materials Disclosure Table for IPB Products Certified as RoHS Compliant Under 2002/95/EC Without Mercury The details provided in this appendix are to ensure that the product is compliant with the Peoples Republic of China (China) RoHS standards. The table below acknowledges the presences of small quantities of certain materials in the product, and is applicable to China RoHS only.
  • Page 177 KINO-945GSE3 User Manual Part Name Toxic or Hazardous Substances and Elements Lead Mercury Cadmium Hexavalent Polybrominated Polybrominated Biphenyls Diphenyl (Pb) (Hg) (Cd) Chromium (CR(VI)) (PBB) Ethers (PBDE) Housing Display Printed Circuit Board Metal Fasteners Cable Assembly Fan Assembly Power Supply...
  • Page 178 KINO-945GSE3 User Manual 此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符 合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的 年限。本产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些元 件将会单独标示出来。 部件名称 有毒有害物质或元素 铅 汞 镉 六价铬 多溴联苯 多溴二苯 醚 (Pb) (Hg) (Cd) (CR(VI)) (PBB) (PBDE) 壳体 显示 印刷电路板 金属螺帽 电缆组装 风扇组装 电力供应组装 电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T11363-2006 标准规定的限量要求以下。 X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T11363-2006 标准规定的限量要求。...

Table of Contents
