KINO-SE-i2
KINO-SE-i2 CPU Card
MODEL:
KINO-S E-i2
Min i-ITX S BC with AMD® Em b e d d e d G-S e rie s S o C with VGA/Du a l
HDMI, Du a l Gb E, Du a l P CIe Min i, US B 3.0, S ATA 6GB/s ,
Au d io , iRIS -2400 a n d Ro HS
Us e r Ma n u a l
Page I
Re v. 1.00 - 27 J a n u a ry, 2015

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KINO-SE-i2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IEI Technology KINO-SE-i2

Summary of Contents for IEI Technology KINO-SE-i2

  • Page 1 KINO-SE-i2 KINO-SE-i2 CPU Card MODEL: KINO-S E-i2 Min i-ITX S BC with AMD® Em b e d d e d G-S e rie s S o C with VGA/Du a l HDMI, Du a l Gb E, Du a l P CIe Min i, US B 3.0, S ATA 6GB/s ,...
  • Page 2 KINO-SE-i2 Re vis io n Date Version Changes 27 January, 2015 1.00 Initial release Page II...
  • Page 3 KINO-SE-i2 Co p yrig h t COP YRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer.

  • Page 4: Table Of Contents

    PTIONAL TEMS 3 CONNECTORS ......................14 3.1 P ..............15 ERIPHERAL NTERFACE ONNECTORS 3.1.1 KINO-SE-i2 Layout ..................15 3.1.2 Peripheral Interface Connectors ..............15 3.1.3 External Interface Panel Connectors ............... 17 3.2 I ..............17 NTERNAL ERIPHERAL ONNECTORS 3.2.1 AT/ATX Mode Select Switch ................17 3.2.2 Battery Connector ....................
  • Page 5 KINO-SE-i2 3.2.11 Keyboard/Mouse Connector ................29 3.2.12 LAN LED Connector ..................30 3.2.13 PCIe x4 Slot ....................31 3.2.14 PCIe Mini Card Slot ..................33 3.2.15 RS-232 Serial Port Connector ............... 36 3.2.16 RS-422/485 Serial Port Connector ..............37 3.2.17 SATA 6Gb/s Drive Connector ................ 37 3.2.18 SATA Power Connector ..................
  • Page 6 KINO-SE-i2 4.4.5 USB Connection ....................63 4.4.6 VGA Monitor Connection ................64 5 BIOS ..........................66 5.1 I ......................67 NTRODUCTION 5.1.1 Starting Setup ....................67 5.1.2 Using Setup ...................... 67 5.1.3 Getting Help ..................... 68 5.1.4 Unable to Reboot after Configuration Changes ..........68 5.1.5 BIOS Menu Bar ....................
  • Page 7 KINO-SE-i2 B TERMINOLOGY ...................... 102 C WATCHDOG TIMER ....................107 D HAZARDOUS MATERIALS DISCLOSURE ............110 D.1 H IPB P AZARDOUS ATERIAL ISCLOSURE ABLE FOR RODUCTS ERTIFIED AS HS C 2002/95/EC W ........111 OMPLIANT NDER ITHOUT ERCURY Page VII...
  • Page 8 KINO-SE-i2 Lis t o f Fig u re s Figure 1-1: KINO-SE-i2 ........................2 Figure 1-2: Connectors ........................4 Figure 1-3: Dimensions (mm) ......................5 Figure 1-4: Data Flow Diagram ...................... 6 Figure 3-1: Connector and Jumper Locations ................15 Figure 3-2: AT/ATX Mode Select Switch Location ..............18 Figure 3-3: Battery Connector Location ..................19...
  • Page 9 KINO-SE-i2 Figure 3-28: Audio Connector .....................47 Figure 3-29: LAN Connector ......................48 Figure 3-30: Serial Port Pinout Locations ..................51 Figure 3-31: VGA Connector .......................52 Figure 4-1: SO-DIMM Installation ....................56 Figure 4-2: SATA Drive Cable Connection .................57 Figure 4-3: Single RS-232 Cable Installation ................58 Figure 4-4: Audio Connector .......................60...
  • Page 10 KINO-SE-i2 Lis t o f Ta b le s Table 1-1: KINO-SE-i2 Model Variations ..................2 Table 1-2: Technical Specifications ....................9 Table 3-1: Peripheral Interface Connectors ................17 Table 3-2: Rear Panel Connectors ....................17 Table 3-3: AT/ATX Mode Select Switch Settings ...............18 Table 3-4: Battery Connector Pinouts ..................19...
  • Page 11 KINO-SE-i2 Table 3-30: Power Connector Pinouts ..................51 Table 3-31: Serial Port Pinouts ....................51 Table 3-32: VGA Connector Pinouts ...................52 Table 5-1: BIOS Navigation Keys ....................68 Page XI...
  • Page 12 KINO-SE-i2 Lis t o f BIOS Me n u s BIOS Menu 1: Main ........................69 BIOS Menu 2: Advanced ......................70 BIOS Menu 3: ACPI Configuration ....................71 BIOS Menu 4: Trusted Computing ....................72 BIOS Menu 5: RTC Wake Settings ....................73 BIOS Menu 6: CPU Configuration ....................74 BIOS Menu 7: IDE Configuration ....................75...

  • Page 13: Introduction

    KINO-SE-i2 Chapter In tro d u c tio n P a g e 1...

  • Page 14: Introduction

    1600/1333 MHz DDR3 & DDR3L SO-DIMM modules up to 8.0 GB. The KINO-SE-i2 includes a VGA connector and two HDMI connectors. Expansion and I/O include two USB 3.0 connectors on the rear panel, two USB 2.0 connectors on the rear panel, two USB 2.0 connectors by pin header and two SATA 6Gb/s connectors.

  • Page 15: Features

    KINO-SE-i2 1.3 Fe a tu re s Some of the KINO-SE-i2 motherboard features are listed below:  Mini-ITX form factor with AMD® Embedded G-Series SoC  12V only single voltage design for AT/ATX power  Dual independent display by VGA, dual HDMI ...

  • Page 16: Connectors

    KINO-SE-i2 1.4 Co n n e c to rs The connectors on the KINO-SE-i2 are shown in the figure below. Figure 1-2: Connectors P a g e 4...

  • Page 17: Dimensions

    KINO-SE-i2 1.5 Dim e n s io n s The dimensions of the board are listed below: Figure 1-3: Dimensions (mm) P a g e 5...

  • Page 18: Data Flow

    KINO-SE-i2 1.6 Da ta Flow Figure 1-4 shows the data flow between the system chipset, the CPU and other components installed on the motherboard. Figure 1-4: Data Flow Diagram P a g e 6...

  • Page 19: Technical Specifications

    KINO-SE-i2 1.7 Te c h n ic a l Sp e c ific a tio n s KINO-SE-i2 technical specifications are listed below. S p e c ific a tio n KINO-S E-i2 S o C AMD® Embedded G-Series G-Series SoC GX-424CC on-board Soc (2.4GHz, quad-core, 2MB cache,...
  • Page 20 KINO-SE-i2 S p e c ific a tio n KINO-S E-i2 I/O In te rfa c e s 1 x RS-422/485 4 x RS-232 (1 on rear I/O, 3 by pin header) 1 x SD card 2 x SATA 6Gb/s with SATA power connector 2 x USB 3.0 (2 on rear I/O)

  • Page 21: Table 1-2: Technical Specifications

    KINO-SE-i2 S p e c ific a tio n KINO-S E-i2 P o we r Co n s u m p tio n +12V@ 2.7A (AMD GX-424CC 2.4GHz CPU with 1600MHz 8GB DDR3 memory) Op e ra tin g Te m p e ra tu re -10°C ~ 60°C...

  • Page 22: Unpacking

    KINO-SE-i2 Chapter Un p a c kin g P a g e 10...

  • Page 23: Anti Static Precautions

    Only handle the edges of the PCB: Don't touch the surface of the motherboard. Hold the motherboard by the edges when handling. 2.2 Un pa c kin g P re c a u tio n s When the KINO-SE-i2 is unpacked, please do the following:  Follow the antistatic guidelines above.

  • Page 24: Packing List

    If any of the components listed in the checklist below are missing, do not proceed with the installation. Contact the IEI reseller or vendor the KINO-SE-i2 was purchased from or contact an IEI sales representative directly by sending an email to sales@iei.com.tw.

  • Page 25: Optional Items

    KINO-SE-i2 2.4 Op tio n a l Ite m s The following are optional components which may be separately purchased: Ite m a n d P a rt Nu m b e r Im a g e RS -232 c a b le with b ra c ke t, 300m m...

  • Page 26: Connectors

    KINO-SE-i2 Chapter Co n n e c to rs P a g e 14...

  • Page 27: Peripheral Interface Connectors

    KINO-SE-i2 3.1 P e rip h e ra l In te rfa c e Co n n e c to rs This chapter details all the jumpers and connectors. 3.1.1 KINO-S E-i2 La yo u t The figures below show all the connectors and jumpers.
  • Page 28 KINO-SE-i2 Co n n e c to r Typ e La b e l AT/ATX mode select switch switch J_ATX_AT1 Battery connector 2-pin wafer BAT1 Clear CMOS button button J_CMOS1 CPU fan connector 4-pin wafer FAN1 DC-IN connector 4-pin Molex...

  • Page 29: External Interface Panel Connectors

    3.2 In te rn a l P e rip h e ra l Co n n e c to rs The section describes all of the connectors on the KINO-SE-i2. 3.2.1 AT/ATX Mo d e S e le c t S witc h...

  • Page 30: Battery Connector

    KINO-SE-i2 CN Lo c a tio n : See Figure 3-2 CN S e ttin g s : See Table 3-3 The AT/ATX mode select switch specifies the systems power mode as AT or ATX. AT/ATX mode select switch settings are shown in Table 3-3.

  • Page 31: Clear Cmos Button

    See Table 3-5 CN S e ttin g s : If the KINO-SE-i2 fails to boot due to improper BIOS settings, use the button to clear the CMOS data and reset the system BIOS information. The clear CMOS button settings are shown in Table 3-5.

  • Page 32: Cpu Fan Connector

    KINO-SE-i2 Setting Description Open Normal Operation Default Push Clear CMOS Setup Table 3-5: Clear CMOS Button Settings The location of the clear CMOS button is shown in Figure 3-4. Figure 3-4: Clear CMOS Button Location 3.2.4 CP U Fa n Co n n e c to r...

  • Page 33: Cpu Power Connector

    KINO-SE-i2 Figure 3-5: CPU Fan Connector Locations PIN NO. DESCRIPTION PIN NO. DESCRIPTION +12V FAN1IN FAN1OUT Table 3-6: CPU Fan Connector Pinouts 3.2.5 DC-IN Co n n e c to r CN La b e l: P WR1 4-pin Molex, P=4.20 mm...

  • Page 34: Ddr3 So-Dimm Slots

    KINO-SE-i2 Figure 3-6: CPU Power Connector Location PIN NO. DESCRIPTION PIN NO. DESCRIPTION GND_VIN GND_VIN 12VIN_1 12VIN_1 Table 3-7: CPU Power Connector Pinouts 3.2.6 DDR3 S O-DIMM S lo ts CN La b e l: DIMM1, DIMM2 DDR3 SO-DIMM slot...

  • Page 35: Digital I/O Connector

    KINO-SE-i2 Figure 3-7: DDR3 SO-DIMM Slot Location 3.2.7 Dig ita l I/O Co n n e c to r CN La b e l: DIO1 CN Typ e : 10-pin header, P=2.00 mm CN Lo c a tio n :...

  • Page 36: Ec Debug Connector

    KINO-SE-i2 Figure 3-8: Digital I/O Connector Location PIN NO. DESCRIPTION PIN NO. DESCRIPTION DOUT3 DOUT2 DOUT1 DOUT0 DIN3 DIN2 DIN1 DIN0 Table 3-8: Digital I/O Connector Pinouts 3.2.8 EC De b u g Co n n e c to r...

  • Page 37: Front Panel Connector

    KINO-SE-i2 Figure 3-9: EC Debug Connector Location Description Description KSI0 KSO9 KSO0 KSO10 KSO1 KSO12 KSO2 KSI1 KSO3 KSO11 KSO4 KSI2 KSO5 KSI3 KSO6 KSO7 KSO8 Table 3-9: EC Debug Connector Pinouts 3.2.9 Fro n t P a n e l Co n n e c to r...

  • Page 38: Ipmi Slot

    KINO-SE-i2 Figure 3-10: Front Panel Connector Location PIN NO. DESCRIPTION PIN NO. DESCRIPTION PWRBTN+ HDD LED+ HDD LED- PWR LED+ PWR LED+ PWR LED- RST BTN+ Table 3-10: Front Panel Connector Pinouts 3.2.10 IP MI S lo t CN La b e l:...

  • Page 39: Figure 3-11: Ipmi Slot Location

    KINO-SE-i2 Figure 3-11: IPMI Slot Location DESCRIPTION DESCRIPTION DESCRIPTION DESCRIPTION VGA_G2 NC_SI_RXD1 PMBUS_ALERT# SDATA1_LAN1 NC_SI_TXD1 VGA_R2 +5V_DUAL +5V_DUAL VGA_B2 DATA5_P DATA4_P NC_SI_CRS_DV DATA5_N NC_SI_CLK_IN DATA4_N NC_SI_TX_EN VSYNC2 +5V_DUAL +5V_DUAL RTS#4 HSYNC2 APU_PROCHOT# APU_VDD_RUN RXD4 _IPMI DTR#4 VI_DDCDAT +3.3V +0.95V_ALW TXD4...
  • Page 40 KINO-SE-i2 SPI_SWITCH SMB_PCIE_3V3 +3.3V BMC_TXD5 _CLK SMB_IPMB_3VS APU_VDD_RUN +3.3V DSR#4 B_CLK SMB_PCIE_3V3 ID_BT_FP# BMC_RXD5 _DATA SMB_IPMB_3VS +3.3V_DUAL CTS#4 B_DATA +3.3V_DUAL IPMI_DET# BMC_SPKR AMBER_LED-_B SPI_BMC_BIOS_CS LAD2 SPI_PATBRG_R_CS LAD0 APU_VDD_PWR GREEN_LED-_B SPI_BMC_BIOS_CL LAD3 GD_IPMI +3.3V_DUAL SPI_PATBRG_R_CL LAD1 +3.3V_DUAL SMB_TEMP_3VS ID_LED#_BMC SMI_ACTIVE# PWRBTSW#...

  • Page 41: Keyboard/Mouse Connector

    KINO-SE-i2 SDATA1_BMC GPP_CLK3P SPI_BMC_BIOS_MI SERIRQ SDATA1_LAN2 +3.3V_DUAL +3.3V_DUAL IPMI_RXN PM_RSMRST#_ SYS_PWRGD_IP IPMI_TXN PME# IPMI_RXP SYS_PWRGD_IP IPMI_TXP SLP_S3# +5V_DUAL SLP_S4# +5V_DUAL SLP_S5# NC_SI_RXD0 PBG_SYS_RESET_N BMC_PSON _BMC ACLK_LAN1 NC_SI_TXD0 PS_ON# Table 3-11: IPMI Slot Pinouts 3.2.11 Ke yb o a rd /Mo u s e Co n n e c to r...

  • Page 42: Lan Led Connector

    KINO-SE-i2 Figure 3-12: Keyboard/Mouse Connector Location Description VCC5_KBMS MSDATA MSCLK KBDATA KBCLK KBMS_GND Table 3-12: Keyboard/Mouse Connector Pinouts 3.2.12 LAN LED Co n n e c to r CN La b e l: LED_LAN2, LED_LAN3 2-pin header, P=2.54 mm CN Typ e :...

  • Page 43: Pcie X4 Slot

    KINO-SE-i2 Figure 3-13: LAN LED Connector Location PIN NO. DESCRIPTION PIN NO. DESCRIPTION L1/2_LINK_ACT- Table 3-13: LAN LED Connector Pinouts 3.2.13 P CIe x4 S lo t CN La b e l: P CIEX4 PCIe x4 slot, P=1.00 mm CN Typ e :...

  • Page 44: Figure 3-14: Pcie X4 Slot Location

    KINO-SE-i2 Figure 3-14: PCIe x4 Slot Location PIN NO. DESCRIPTION PIN NO. DESCRIPTION +12V +12V +12V +12V +12V SCLK1 SDATA1 +3.3V +3.3V +3.3V +3.3V_DUAL PCIE_RST# PCIE_WAKE_UP# GFX_CLK0P GFX_CLK0N P_GFX_TXP0 P_GFX_TXN0 P_GFX_RXP0 P_GFX_RXN0 P_GFX_TXP1 P_GFX_TXN1 P a g e 32...

  • Page 45: Pcie Mini Card Slot

    KINO-SE-i2 P_GFX_RXP1 P_GFX_RXN1 P_GFX_TXP2 P_GFX_TXN2 P_GFX_RXP2 P_GFX_RXN2 P_GFX_TXP3 P_GFX_TXN3 P_GFX_RXP3 P_GFX_RXN3 Table 3-14: PCIe x4 Slot Pinouts 3.2.14 P CIe Min i Ca rd S lo t CN La b e l: M_P CIE1, M_P CIE2 PCIe Mini card slot, P=0.80 mm...

  • Page 46: Figure 3-15: Pcie Mini Card Slot Location

    KINO-SE-i2 Figure 3-15: PCIe Mini Card Slot Location PIN NO. DESCRIPTION PIN NO. DESCRIPTION VCC3_MINI_1 +V1.5_MINI_1 SCLK1 MPCIE_TXDN +V1.5_MINI_1 SDATA1 MPCIE_TXDP USB6N GPP_CLK2N USB6P GPP_CLK2P VCC3_MINI_1 VCC3_MINI_1 PCIE_RST# N48174558 P a g e 34...

  • Page 47: Table 3-15: Pcie Mini Card Slot Pinouts (M_Pcie1)

    KINO-SE-i2 PIN NO. DESCRIPTION PIN NO. DESCRIPTION PCIE_RST# +V1.5_MINI_1 MPCIE_RXDN +3.3V_DUAL MPCIE_RXDP mSATA_DET# VCC3_MINI_1 Table 3-15: PCIe Mini Card Slot Pinouts (M_PCIE1) PIN NO. DESCRIPTION PIN NO. DESCRIPTION VCC3_MINI_2 +V1.5_MINI_2 SCLK1 MINISLOT1_TXDN +V1.5_MINI_2 SDATA1 MINI_PCIE_SLT1_CLKREQ# MINISLOT1_TXDP USB7N USB7P VCC3_MINI_2 VCC3_MINI_2...

  • Page 48: Serial Port Connector

    KINO-SE-i2 PIN NO. DESCRIPTION PIN NO. DESCRIPTION MINISLOT1_RXDN +3.3V_DUAL MINISLOT1_RXDP VCC3_MINI_2 Table 3-16: PCIe Mini Card Slot Pinouts (M_PCIE2) 3.2.15 RS -232 S e ria l P o rt Co n n e c to r CN La b e l:...

  • Page 49: Rs-422/485 Serial Port Connector

    KINO-SE-i2 PIN NO. DESCRIPTION PIN NO. DESCRIPTION NDTR2/3/5 NRI2/3/5 Table 3-17: RS-232 Serial Port Connector Pinouts 3.2.16 RS -422/485 S e ria l P ort Co n n e c to r CN La b e l: COM6 4-pin wafer, P=2.00 mm...

  • Page 50: Sata Power Connector

    KINO-SE-i2 CN Typ e : 7-pin SATA connector CN Lo c a tio n : See Figure 3-18 The SATA 6Gb/s drive connector is connected to a SATA 6Gb/s drive. The SATA 6Gb/s drive transfers data at speeds as high as 6Gb/s.

  • Page 51: Sd Card Slot

    CN La b e l: SD card slot CN Typ e : See Figure 3-20 CN Lo c a tio n : An SD memory card can be inserted to the SD card slot on the KINO-SE-i2. P a g e 39...

  • Page 52: Smbus Connector

    KINO-SE-i2 Figure 3-20: SD Card Slot Location 3.2.20 S MBUS Co n n e c to r CN La b e l: CN1, CN2 CN Typ e : 4-pin wafer, P=1.25 mm See Figure 3-21 CN Lo c a tio n :...

  • Page 53: Spdif Connector

    KINO-SE-i2 Figure 3-21: SMBus Connector Location PIN NO. DESCRIPTION PIN NO. DESCRIPTION SDATA0/1 SCLK0/1 Table 3-20: SMBus Connector Pinouts 3.2.21 S P DIF Co n n e c to r CN La b e l: S P DIF1 5-pin header, P=2.54 mm...

  • Page 54: Spi Flash Connector

    KINO-SE-i2 Figure 3-22: SPDIF Connector Location Description SPDIF OUT SPDIF IN Table 3-21: SPDIF Connector Pinouts 3.2.22 S P I Fla s h Co n n e c to r CN La b e l: S P I1, S P I2 6-pin wafer, P=1.25 mm...

  • Page 55: System Fan Connector

    KINO-SE-i2 Figure 3-23: SPI Flash Connector Location PIN NO. DESCRIPTION PIN NO. DESCRIPTION SPI_POWER SPI_CS#_CONN SPI_DATAIN_CONN SPI_CLK_CONN SPI_DATAOUT_CONN Table 3-22: SPI Flash Connector Pinouts (SPI1) PIN NO. DESCRIPTION PIN NO. DESCRIPTION EC_SPI_VCC FSCE# FMISO FSCK FMOSI Table 3-23: SPI Flash Connector Pinouts (SPI2) 3.2.23 S ys te m Fa n Co n n e c to r...

  • Page 56: Tpm Connector

    KINO-SE-i2 Figure 3-24: System Fan Connector Locations PIN NO. DESCRIPTION PIN NO. DESCRIPTION +12V FAN2IN FAN2OUT Table 3-24: System Fan Connector Pinouts 3.2.24 TP M Co n n e c to r CN La b e l: TPM1 CN Typ e : 20-pin header, P=2.54 mm...

  • Page 57: Usb Connector

    KINO-SE-i2 Figure 3-25: TPM Connector Location PIN NO. DESCRIPTION PIN NO. DESCRIPTION LPC_CLK1 LFRAME# LPC_RST# LAD3 LAD2 +3.3V LAD1 LAD0 SCLK0 SDATA0 SERIRQ +3.3V_DUAL LPC_CLKRUN# LPCPD# LDRQ#0 Table 3-25: TPM Connector Pinouts 3.2.25 US B Co n n e c to r...

  • Page 58: Figure 3-26: Usb Connector Locations

    KINO-SE-i2 The USB connector provides two USB 2.0 ports by dual-port USB cable. Figure 3-26: USB Connector Locations PIN NO. DESCRIPTION PIN NO. DESCRIPTION USBV2L DATA2_N DATA3_P DATA2_P DATA3_N USBV2L Table 3-26: USB Connector Pinouts P a g e 46...

  • Page 59: External Peripheral Interface Connector Panel

    3.3 Exte rn a l P e rip h e ra l In te rfa c e Co n n e c to r P a n e l Figure 3-27 shows the KINO-SE-i2 external peripheral interface connector (EPIC) panel.

  • Page 60: Ethernet And Usb Connectors

    KINO-SE-i2 3.3.2 Eth e rn e t a n d US B Con n e c to rs CN La b e l: LAN1_USB2, LAN2_USB2 CN Typ e : RJ-45 , USB 2.0 and USB 3.0 ports CN Lo c a tio n :...

  • Page 61: Hdmi Connector

    KINO-SE-i2 L1_LINK_ACT- +V3.3LAN1 Table 3-27: LAN1_USB2 Connector Pinouts The USB 3.0 ports are for attaching USB 3.0 peripheral devices to the system. To be able to use the USB 3.0 ports, please make sure the USB 3.0 driver is installed. The pinouts of LAN2 and USB 3.0 connectors are shown below.

  • Page 62: Power Connector

    KINO-SE-i2 HDMI connector CN Typ e : See Figure 3-27 CN Lo c a tio n : See Table 3-29 CN P in o u ts : The HDMI connector connects to a display device with HDMI interface. Description Description...

  • Page 63: Serial Port Connector (Com1)

    KINO-SE-i2 PIN NO. DESCRIPTION PIN NO. DESCRIPTION Table 3-30: Power Connector Pinouts 3.3.5 S e ria l P o rt Co n n e c tor (COM1) CN La b e l: COM1 DB-9 Male connector CN Typ e :...

  • Page 64: Figure 3-31: Vga Connector

    KINO-SE-i2 See Figure 3-31 an Table 3-32 CN P in o u ts : The standard 15-pin female VGA connector connects to a CRT or LCD monitor. Description Description Description GREEN 5VDDCDA BLUE VGA_HSYNC CRT_VCC VGA_VSYNC 5VDDCLK Table 3-32: VGA Connector Pinouts...

  • Page 65: Installation

    KINO-SE-i2 Chapter In s ta lla tio n P a g e 53...

  • Page 66: Anti - Static Precautions

    Electrostatic discharge (ESD) can cause serious damage to electronic components, including the KINO-SE-i2. Dry climates are especially susceptible to ESD. It is therefore critical that whenever the KINO-SE-i2 or any other electrical component is handled, the following anti-static precautions are strictly adhered to.

  • Page 67: So-Dimm Installation

     Turn all power to the KINO-SE-i2 off: When working with the KINO-SE-i2, make sure that it is disconnected from all power supplies and that no electricity is being fed into the system. Before and during the installation of the KINO-SE-i2 DO NOT: ...

  • Page 68: Figure 4-1: So-Dimm Installation

    KINO-SE-i2 Figure 4-1: SO-DIMM Installation S te p 1: Open the SO-DIMM socket handles. Open the two handles outwards as far as they can. See Figure 4-1. Align the SO-DIMM with the socket. Align the DIMM so the notch on the S te p 2: memory lines up with the notch on the memory socket.

  • Page 69: Internal Peripheral Device Connections

    This section outlines the installation of peripheral devices to the on-board connectors 4.3.1 S ATA Drive Co n n e c tio n The KINO-SE-i2 is shipped with two SATA drive cable. To connect the SATA drive to the connector, please follow the steps below.

  • Page 70: Single Rs-232 Cable

    KINO-SE-i2 4.3.2 S in g le RS -232 Ca ble The single RS-232 cable consists of one serial port connector attached to a serial communications cable that is then attached to a D-sub 9 male connector. To install the single RS-232 cable, please follow the steps below.

  • Page 71: External Peripheral Interface Connection

    4.4.1 Au d io Co n n e c tio n The audio jacks on the external audio connector enable the KINO-SE-i2 to be connected to a stereo sound setup. To install the audio devices, follow the steps below.

  • Page 72: Hdmi Display Device Connection

    4.4.2 HDMI Dis p la y De vic e Co n n e c tio n The HDMI connector transmits a digital signal to compatible HDMI display devices such as a TV or computer screen. To connect the HDMI cable to the KINO-SE-i2, follow the steps below.

  • Page 73: Lan Connection

    Locate the RJ-45 connectors. The locations of the LAN connectors are shown S te p 1: in Chapter 3. S te p 2: Align the connectors. Align the RJ-45 connector on the LAN cable with one of the RJ-45 connectors on the KINO-SE-i2. See Figure 4-6. P a g e 61...

  • Page 74: Serial Device Connection

    4.4.4 S e ria l De vic e Co n n e c tio n The KINO-SE-i2 has two single female DB-9 connectors on the external peripheral interface panel for a serial device. Follow the steps below to connect a serial device to the KINO-SE-i2.

  • Page 75: Usb Connection

    4.4.5 US B Co n n e c tio n The external USB Series "A" receptacle connectors provide easier and quicker access to external USB devices. Follow the steps below to connect USB devices to the KINO-SE-i2. Locate the USB Series "A" receptacle connectors. The locations of the USB S te p 1: Series "A"...

  • Page 76: Vga Monitor Connection

    4.4.6 VGA Mo n ito r Co n n e c tio n The KINO-SE-i2 has a single female DB-15 connector on the external peripheral interface panel. The DB-15 connector is connected to a CRT or VGA monitor. To connect a monitor to the KINO-SE-i2, please follow the instructions below.

  • Page 77: Figure 4-9: Vga Connector

    KINO-SE-i2 Figure 4-9: VGA Connector Secure the connector. Secure the DB-15 VGA connector from the VGA S te p 4: monitor to the external interface by tightening the two retention screws on either side of the connector. P a g e 65...

  • Page 78: Bios

    KINO-SE-i2 Chapter BIOS P a g e 66...

  • Page 79: Introduction

    KINO-SE-i2 5.1 In tro d u c tio n The BIOS is programmed onto the BIOS chip. The BIOS setup program allows changes to certain system settings. This chapter outlines the options that can be changed. 5.1.1 Sta rtin g S e tu p The UEFI BIOS is activated when the computer is turned on.

  • Page 80: Getting Help

    KINO-SE-i2 Ke y Fu n c tio n Main Menu – Quit and do not save changes into CMOS Status Page Setup Menu and Option Page Setup Menu -- Exit current page and return to Main Menu General help, only for Status Page Setup Menu and Option...

  • Page 81: Main

    KINO-SE-i2 5.2 Ma in The Main BIOS menu (BIOS Menu 1) appears when the BIOS Setup program is entered. The Main menu gives an overview of the basic system information. Aptio Setup Utility – Copyright (C) 2013 American Megatrends, Inc.

  • Page 82: Advanced

    KINO-SE-i2  S ys te m Tim e [xx:xx:xx] Use the System Time option to set the system time. Manually enter the hours, minutes and seconds. 5.3 Ad va n c e d Use the Advanced menu (BIOS Menu 2) to configure the CPU and peripheral devices...

  • Page 83: Trusted Computing

    KINO-SE-i2 Aptio Setup Utility – Copyright (C) 2013 American Megatrends, Inc. Advanced ACPI Settings Select ACPI sleep state the system will enter ACPI Sleep State [S3 only(Suspend to…] when the SUSPEND button is pressed. ---------------------- : Select Screen ↑ ↓: Select Item Enter Select +/-: Change Opt.

  • Page 84: Rtc Wake Settings

    KINO-SE-i2 Aptio Setup Utility – Copyright (C) 2013 American Megatrends, Inc. Advanced Configuration Enables or Disables BIOS Security Device Support [Disable] support for security device. O.S. will not Current Status Information show Security Device. NO Security Device Found TCG EFI protocol and INT1A interface will not be available.

  • Page 85: Bios Menu 5: Rtc Wake Settings

    KINO-SE-i2 Aptio Setup Utility – Copyright (C) 2013 American Megatrends, Inc. Advanced RTC Wake Settings Enable or disable System wake on alarm event. When Wake system with Fixed Time [Disabled] enabled, System will wake on the date::hr::min::sec specified ---------------------- : Select Screen ↑...

  • Page 86: Cpu Configuration

    KINO-SE-i2 5.3.4 CP U Co n fig u ra tio n Use the CPU Configuration menu (BIOS Menu 6) to view detailed CPU specifications and configure the CPU. Aptio Setup Utility – Copyright (C) 2013 American Megatrends, Inc. Advanced CPU Configuration...

  • Page 87: Ide Configuration

    KINO-SE-i2  Active three of the processor cores Three cores per processor  cores Active two of the processor cores processor  core Active one of the processor cores processor 5.3.5 IDE Co n fig u ra tio n Use the IDE Configuration menu (BIOS Menu 7) to change and/or set the configuration of the SATA devices installed in the system.

  • Page 88: Usb Configuration

    KINO-SE-i2  Configures SATA devices as normal IDE device. EFAULT  AHCI Configures SATA devices as AHCI device. 5.3.6 US B Co n fig u ra tio n Use the USB Configuration menu (BIOS Menu 10) to read USB configuration information and configure the USB settings.

  • Page 89: F81866 Super Io Configuration

    KINO-SE-i2 keyboard can control the system even when there is no USB driver loaded onto the system.  Enabled Legacy USB support enabled EFAULT  Disabled Legacy USB support disabled  Auto Legacy USB support disabled if no USB devices are connected 5.3.7 F81866 S u pe r IO Co nfig u ra tio n...

  • Page 90: Serial Port N Configuration

    KINO-SE-i2 5.3.7.1 S e ria l P o rt n Co n fig u ra tio n Use the Serial Port n Configuration menu (BIOS Menu 10) to configure the serial port n. Aptio Setup Utility – Copyright (C) 2013 American Megatrends, Inc.
  • Page 91 KINO-SE-i2  Serial Port I/O port address is 3F8h and the IO=3F8h; IRQ=3, 4,5,6,7,10,11,12 interrupt address is IRQ3,4,5,6,7,10,11,12  IO=2F8h; IRQ=3, Serial Port I/O port address is 2F8h and the interrupt address is IRQ3,4,5,6,7,10,11,12 4,5,6,7,10,11,12  IO=3E8h; IRQ=3, Serial Port I/O port address is 3E8h and the...
  • Page 92 KINO-SE-i2  Serial Port I/O port address is 2E8h and the IO=2E8h; IRQ=3, 4,5,6,7,10,11,12 interrupt address is IRQ3,4,5,6,7,10,11,12 5.3.7.1.3 S e ria l P o rt 3 Co n fig u ra tio n  S e ria l P o rt [En a b le d ] Use the Serial Port option to enable or disable the serial port.
  • Page 93 KINO-SE-i2 5.3.7.1.4 S e ria l P o rt 5 Co n fig u ra tio n  S e ria l P o rt [En a b le d ] Use the Serial Port option to enable or disable the serial port.
  • Page 94 KINO-SE-i2  Disable the serial port Disabled  Enabled Enable the serial port EFAULT  Ch a n g e S e ttin g s [Au to ] Use the Change Settings option to change the serial port IO port address and interrupt address.

  • Page 95: F81866 H/W Monitor

    KINO-SE-i2 5.3.8 F81866 H/W Mo n ito r The F8186 H/W Monitor menu (BIOS Menu 11) shows the operating temperature, fan speeds and system voltages. Aptio Setup Utility – Copyright (C) 2013 American Megatrends, Inc. Advanced PC Health Status Enable or Disable Smart...

  • Page 96: Smart Fan Mode Configuration

    KINO-SE-i2  Disables the smart fan function. Disabled  Enabled Enables the smart fan function. EFAULT 5.3.8.1 S m a rt Fa n Mo d e Co nfig u ra tio n Use the Smart Fan Mode Configuration submenu (BIOS Menu 12) to configure the smart fan temperature and speed settings.

  • Page 97: Serial Port Console Redirection

    KINO-SE-i2  CP U Te m p e ra tu re n Use the + or – key to change the fan CPU Temperature n value. Enter a decimal number between 1 and 100.  FAN2 S m a rt Fa n Co n tro l [Au to Du ty-Cyc le Mo d e ] Use the FAN2 Smart Fan Control option to configure the System Smart Fan.

  • Page 98: Console Redirection Settings

    KINO-SE-i2 Aptio Setup Utility – Copyright (C) 2013 American Megatrends, Inc. Advanced COM1 Console Redirection Console Redirection [Disabled] Enable or Disable > Console Redirection Settings COM2 Console Redirection [Disabled] > Console Redirection Settings COM3 Console Redirection [Disabled] > Console Redirection Settings --------------------- : Select Screen...

  • Page 99: Bios Menu 14: Console Redirection Settings

    KINO-SE-i2 Aptio Setup Utility – Copyright (C) 2013 American Megatrends, Inc. Advanced COM1 Emulation: ANSI: Console Redirection Settings Extended ASCII char set. VT100: ASCII char set. Terminal Type [ANSI] VT100+: Extends VT100 to Bits per second [115200] support color, function Data Bits keys, etc.
  • Page 100 KINO-SE-i2  Sets the serial port transmission speed at 38400. 38400  57600 Sets the serial port transmission speed at 57600.  115200 Sets the serial port transmission speed at 115200. EFAULT  Da ta Bits [8] Use the Data Bits option to specify the number of data bits.

  • Page 101: Chipset

    KINO-SE-i2 5.4 Ch ips e t Use the Chipset menu (BIOS Menu 15) to access the Southbridge and Northbridge configuration menus. WARNING! Setting the wrong values for the Chipset BIOS selections in the Chipset BIOS menu may cause the system to malfunction.

  • Page 102: Bios Menu 17: South Bridge Configuration

    KINO-SE-i2 Aptio Setup Utility – Copyright (C) 2013 American Megatrends, Inc. Chipset Auto Power Button Function [Enabled(AT)] HD Audio Azalia Device [Enabled] Power Saving Function(ERP) [Disabled] --------------------- : Select Screen ↑ ↓: Select Item Enter Select +/-: Change Opt. General Help...

  • Page 103: North Bridge Configuration

    KINO-SE-i2 5.4.2 No rth Brid g e Co n fig u ra tio n Use the North Bridge menu (BIOS Menu 18) to view the memory information. Aptio Setup Utility – Copyright (C) 2013 American Megatrends, Inc. Chipset North Bridge Configuration...
  • Page 104 KINO-SE-i2  Bo o tu p Nu m Lo c k Sta te [On ] Use the Bootup NumLock State BIOS option to specify if the number lock setting must be modified during boot up.  Allows the Number Lock on the keyboard to be...

  • Page 105: Boot Option Priority

    KINO-SE-i2  La u n c h P XE Op ROM [Dis a b le d ] Use the Launch PXE OpROM option to enable or disable boot option for legacy network devices.  Ignore all PXE Option ROMs Disabled EFAULT ...

  • Page 106: Security

    KINO-SE-i2 5.6 S e c u rity Use the Security menu (BIOS Menu 18) to set system and user passwords. Aptio Setup Utility – Copyright (C) 2013 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit Server Mgmt...

  • Page 107: Bios Menu 21:Exit

    KINO-SE-i2 Aptio Setup Utility – Copyright (C) 2013 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit Server Mgmt Save Changes and Reset Reset the system after Discard Changes and Reset saving the changes. Restore Defaults Save as User Defaults...

  • Page 108: Server Mgmt

    KINO-SE-i2 5.8 S e rve r Mg m t Use the Server Mgmt menu (BIOS Menu 13) to access the server management menus. Aptio Setup Utility – Copyright (C) 2013 American Megatrends, Inc. Server Mgmt BMC Self Test Status FAILED Press <Enter>...

  • Page 109: System Event Log

    KINO-SE-i2 5.8.1.1 S ys te m Eve n t Lo g Use the System Event Log menu (BIOS Menu 19) to configure the event log. Aptio Setup Utility – Copyright (C) 2013 American Megatrends, Inc. Server Mgmt Enabling/Disabling Options Change this to anable or...

  • Page 110: Bmc Network Configuration

    KINO-SE-i2  Wh e n S EL is Fu ll [Do No th in g ] Use When SEL is FULL option to select options for reactions to a full SEL. The following options are available:  Do Nothing Default ...

  • Page 111: A Bios Menu Options

    KINO-SE-i2 Ap p e n d ix BIOS Me n u Op tio n s P a g e 99...
  • Page 112 KINO-SE-i2  BIOS Information .........................69  System Date [xx/xx/xx] ......................69  System Time [xx:xx:xx] .......................70  ACPI Sleep State [S3 only (Suspend to RAM)] ..............71  Security Device Support [Disable] ..................72  Wake system with Fixed Time [Disabled] ................73 ...
  • Page 113 KINO-SE-i2  HD Audio Azalia Device [Enabled] ..................90  Power Saving Function(ERP) [Disabled] ................90  Bootup NumLock State [On] ....................92  Quiet Boot [Enabled] ......................92  Option ROM Messages [Force BIOS] .................92  Launch PXE OpROM [Disabled] ..................93  UEFI Boot [Disabled] ......................93 ...
  • Page 114 KINO-SE-i2 Ap p e n d ix Te rm in o lo g y P a g e 102...
  • Page 115 KINO-SE-i2 AC ’97 Audio Codec 97 (AC’97) refers to a codec standard developed by Intel® in 1997. ACPI Advanced Configuration and Power Interface (ACPI) is an OS-directed configuration, power management, and thermal management interface. AHCI Advanced Host Controller Interface (AHCI) is a SATA Host controller register-level interface.
  • Page 116 KINO-SE-i2 computer is usually a male DE-9 connector. The Digital-to-Analog Converter (DAC) converts digital signals to analog signals. Double Data Rate refers to a data bus transferring data on both the rising and falling edges of the clock signal. Direct Memory Access (DMA) enables some peripheral devices to bypass the system processor and communicate directly with the system memory.
  • Page 117 KINO-SE-i2 PCIe PCI Express (PCIe) is a communications bus that uses dual data lines for full-duplex (two-way) serial (point-to-point) communications between the SBC components and/or expansion cards and the SBC chipsets. Each line has a 2.5 Gbps data transmission rate and a 250 MBps sustained data transfer rate.
  • Page 118 KINO-SE-i2 USB 2.0 supports 480Mbps data transfer rates. The Video Graphics Array (VGA) is a graphics display system developed by IBM. P a g e 106...
  • Page 119 KINO-SE-i2 Ap p e n d ix Wa tc h d o g Tim e r P a g e 107...
  • Page 120 KINO-SE-i2 NOTE: The following discussion applies to DOS environment. IEI support is contacted or the IEI website visited for specific drivers for more sophisticated operating systems, e.g., Windows and Linux. The Watchdog Timer is provided to ensure that standalone systems can always recover from catastrophic conditions that cause the CPU to crash.
  • Page 121 KINO-SE-i2 NOTE: When exiting a program it is necessary to disable the Watchdog Timer, otherwise the system resets. Example program: ; INITIAL TIMER PERIOD COUNTER W_LOOP: AX, 6F02H ;setting the time-out value BL, 30H ;time-out value is 48 seconds ; ADD THE APPLICATION PROGRAM HERE EXIT_AP, 1 ;is the application over?
  • Page 122 KINO-SE-i2 Ap p e n d ix Ha za rd o u s Ma te ria ls Dis c lo s u re P a g e 110...
  • Page 123 KINO-SE-i2 D.1 Ha za rd o u s Ma te ria l Dis c lo s ure Ta b le fo r IP B P ro d u c ts Ce rtifie d a s Ro HS Co m p lia n t Un d e r 2002/95/EC With o u t...
  • Page 124 KINO-SE-i2 Part Name Toxic or Hazardous Substances and Elements Lead Mercury Cadmium Hexavalent Polybrominated Polybrominated (Pb) (Hg) (Cd) Chromium Biphenyls Diphenyl Ethers (CR(VI)) (PBB) (PBDE) Housing Display Printed Circuit Board Metal Fasteners Cable Assembly Fan Assembly Power Supply Assemblies Battery...
  • Page 125 KINO-SE-i2 此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符 合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的 年限。本 产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些元 件将会单独标示出来。 部件名称 有毒有害物质或元素 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (CR(VI)) (PBB) (PBDE) 壳体 显示 印刷电路板 金属螺帽 电缆组装 风扇组装 电力供应组装 电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T11363-2006 标准规定的限量要求以下。 X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T11363-2006 标准规定的限量要求。...

Table of Contents
