KINO-DCM236 Industrial Motherboard
KINO-DCM236 CPU Card
MODEL:
KINO-DCM236
th
®
®
Mini-ITX SBC Supports 6
GEN Intel
Xeon® E3, Core™ i3 or Celeron
®
CPU with Intel
CM236, HDMI 2.0, HDMI 1.4, Dual PCIe GbE,
PCIe Mini, PCIe x16, M.2, SATA 6Gb/s, USB 3.0, HD Audio, and RoHS

User Manual

Page I
Rev. 1.00 - October 4, 2016

Advertisement

Table of Contents
loading

Related Manuals for IEI Technology KINO-DCM236

Summary of Contents for IEI Technology KINO-DCM236

  • Page 1: User Manual

    KINO-DCM236 Industrial Motherboard KINO-DCM236 CPU Card MODEL: KINO-DCM236 ® ® Mini-ITX SBC Supports 6 GEN Intel Xeon® E3, Core™ i3 or Celeron ® CPU with Intel CM236, HDMI 2.0, HDMI 1.4, Dual PCIe GbE, PCIe Mini, PCIe x16, M.2, SATA 6Gb/s, USB 3.0, HD Audio, and RoHS...
  • Page 2 KINO-DCM236 Industrial Motherboard Revision Date Version Changes October 4, 2016 1.00 Initial release Page II...

  • Page 3: Safety Instructions

    KINO-DCM236 Industrial Motherboard Safety Instructions Warning! Read the user manual before connecting the system to the power source. Vorsicht! Bitte lesen Sie die Bedienungsanleitung, bevor Sie das System an eine Stromquelle anschließen. Attention! Avant de brancher le système à la source d'alimentation, consultez le mode d'emploi.
  • Page 4 KINO-DCM236 Industrial Motherboard Warning! Use only the adapter and power cord approved for this system. Use of another type of adapter may risk fire or explosion. Please refer to the user manual for the power adapter specifications. Vorsicht! Nur zugelassene Netzteile und Netzkabel dürfen verwendet werden. Die Benutzung von anderen Netzteilen kann einen Brand oder eine Explosion zur Folge haben.
  • Page 5 KINO-DCM236 Industrial Motherboard Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
  • Page 6 KINO-DCM236 Industrial Motherboard Manual Conventions WARNING Warnings appear where overlooked details may cause damage to the equipment or result in personal injury. Warnings should be taken seriously. CAUTION Cautionary messages should be heeded to help reduce the chance of losing data or damaging the product.

  • Page 7: Table Of Contents

    PTIONAL TEMS 3 CONNECTORS ......................15 3.1 P ..............16 ERIPHERAL NTERFACE ONNECTORS 3.1.1 KINO-DCM236 Layout..................16 3.1.2 Peripheral Interface Connectors ..............17 3.1.3 External Interface Panel Connectors............... 18 3.2 I ..............19 NTERNAL ERIPHERAL ONNECTORS 3.2.1 ATX Power Connector ..................19 3.2.2 Audio Connector ....................
  • Page 8 KINO-DCM236 Industrial Motherboard 3.2.11 LVDS Connector..................... 29 3.2.12 LVDS Backlight Connector ................30 3.2.13 M.2 Module Slot..................... 31 3.2.14 PCI Express x16 Slot..................33 3.2.15 PCIe Mini Card Slot, Full-size ..............33 3.2.16 PCIe Mini Card Slot, Half-size ..............35 3.2.17 Power Button ....................
  • Page 9 KINO-DCM236 Industrial Motherboard 4.7.6 LVDS Voltage Selection..................63 4.7.7 USB Power Selection ..................64 4.8 C .................... 65 HASSIS NSTALLATION 4.8.1 Airflow......................65 4.8.2 Motherboard Installation................. 65 4.9 I ............65 NTERNAL ERIPHERAL EVICE ONNECTIONS 4.9.1 SATA Drive Connection ................... 65 ®...
  • Page 10 KINO-DCM236 Industrial Motherboard 5.3.7 CPU Configuration..................93 5.3.8 SATA Configuration ..................95 5.3.9 NVMe Configuration..................96 5.3.10 USB Configuration..................97 5.3.11 IEI Feature ..................... 98 5.4 C ........................99 HIPSET 5.4.1 System Agent (SA) Configuration ..............99 5.4.1.1 Graphics Configuration................100 5.4.1.1.1 LCD Control ..................
  • Page 11 Figure 1-1: KINO-DCM236 Industrial Motherboard ..............2 Figure 1-2: Connectors ........................4 Figure 1-3: Dimensions (mm) ......................5 Figure 1-4: KINO-DCM236 Height Dimensions 1 (mm) ...............6 Figure 1-5: KINO-DCM236 Height Dimensions 2 (mm) ...............6 Figure 1-6: Data Flow Diagram......................7 Figure 3-1: Connector and Jumper Locations (Front Side) .............16 Figure 3-2: +12V DC-IN Power Connector Location..............19...
  • Page 12 KINO-DCM236 Industrial Motherboard Figure 3-26: USB Connector Locations..................45 Figure 3-27: External Interface Connectors................46 Figure 3-28: Audio Jacks ......................46 Figure 3-29: Ethernet Connector....................47 Figure 3-30: HDMI Connector ......................49 Figure 3-31: 4-pin Power Mini-DIN Connection .................49 Figure 3-32: Serial Port Pinouts ....................50 Figure 4-1: SO-DIMM Installation ....................54...
  • Page 13 KINO-DCM236 Industrial Motherboard List of Tables Table 1-1: Model Variations ......................3 Table 1-2: Technical Specifications....................10 Table 3-1: Peripheral Interface Connectors ................18 Table 3-2: Rear Panel Connectors ....................18 Table 3-3: +12V DC-IN Power Connector Pinouts ..............19 Table 3-4: Audio Connector Pinouts ..................20 Table 3-5: Battery Connector Pinouts ..................21...
  • Page 14 KINO-DCM236 Industrial Motherboard Table 3-30: Serial Port Pinouts....................50 Table 4-1: AT/ATX Mode Select Switch Settings...............59 Table 4-2: Flash Descriptor Security Override Jumper Settings..........61 Table 4-3: LVDS Resolution Selection Jumper Settings ............62 Table 4-4: LVDS Backlight Mode Select Jumper Settings............63 Table 4-5: LVDS Voltage Jumper Settings .................63 Table 4-6: BIOS Options and Configured USB Ports..............64...
  • Page 15 KINO-DCM236 Industrial Motherboard List of BIOS Menus BIOS Menu 1: Main ........................72 BIOS Menu 2: Advanced ......................73 BIOS Menu 3: ACPI Settings .......................74 BIOS Menu 4: AMT Configuration....................75 BIOS Menu 5: Super IO Configuration..................76 BIOS Menu 6: Serial Port n Configuration .................77 BIOS Menu 7: iWDD H/W Monitor ....................83...

  • Page 17: Introduction

    KINO-DCM236 Industrial Motherboard Chapter Introduction Page 1...

  • Page 18: Introduction

    260-pin 2133 MHz dual-channel DDR4 SDRAM SO-DIMM slots supporting ECC and up to 64 GB of memory. The KINO-DCM236 series includes an HDMI 2.0 port, two HDMI 1.4 ports and a LVDS connector for triple independent display. Expansions include one full-size PCIe Mini slot supporting mSATA modules, one half-size PCIe Mini slot, one M.2 A-key slot and one PCIe x16 slot.

  • Page 19: Model Variations

    KINO-DCM236 Industrial Motherboard 1.2 Model Variations There are four models of the KINO-DCM236 series. The model variations are listed in Table 1-1. On-board Processor Model Name Speed Cache Max TDP ® ® KINO-DCM236-E3 Intel Xeon processor E3-1505M v5 2.8 GHz...

  • Page 20: Connectors

    KINO-DCM236 Industrial Motherboard 1.4 Connectors The connectors on the KINO-DCM236 are shown in the figures below. Figure 1-2: Connectors Page 4...

  • Page 21: Dimensions

    KINO-DCM236 Industrial Motherboard 1.5 Dimensions The dimensions of the board are listed below: Figure 1-3: Dimensions (mm) Page 5...

  • Page 22: Figure 1-4: Kino-Dcm236 Height Dimensions 1 (Mm)

    KINO-DCM236 Industrial Motherboard The height of the KINO-DCM236 series varies depending on the cooler module installed on the board. Figure 1-4 shows the height dimensions of the following models:  KINO- DCM236-E3E  KINO-DCM236-i3E  KINO-DCM236-CE Figure 1-4: KINO-DCM236 Height Dimensions 1 (mm) Figure 1-5 shows the height dimensions of the following model: ...

  • Page 23: Data Flow

    KINO-DCM236 Industrial Motherboard 1.6 Data Flow Figure 1-6 shows the data flow between the system chipset, the CPU and other components installed on the motherboard. Figure 1-6: Data Flow Diagram Page 7...

  • Page 24: Technical Specifications

    KINO-DCM236 Industrial Motherboard 1.7 Technical Specifications KINO-DCM236 technical specifications are listed below. Specification KINO-DCM236 Form Factor Mini-ITX ® ® Intel Xeon processor E3-1505M v5 (2.8 GHz, quad-core, 8 MB cache, 45 W TDP) ® ® Intel Xeon processor E3-1505L v5 (2.0 GHz, quad-core, 8 MB cache, 25 W TDP)
  • Page 25 KINO-DCM236 Industrial Motherboard Specification KINO-DCM236 Realtek ALC662 HD Audio codec Audio Watchdog Timer Software programmable support 1~255 sec. system reset I/O Interface Audio Connector 2 x Audio jacks (line-out, mic-in) 1 x Audio connector by 10-pin (2x5) header Digital I/O...

  • Page 26: Table 1-2: Technical Specifications

    KINO-DCM236 Industrial Motherboard Specification KINO-DCM236 12 V DC Power Supply ® ® 12 V @ 6.93 A (2.8 GHz Intel Xeon E3-1505M v5 CPU with 32 Power Consumption GB (two 16 GB) 2133 MHz DDR4 memory) ® ® 19100-000219-00-RS for Intel...

  • Page 27: Unpacking

    KINO-DCM236 Industrial Motherboard Chapter Unpacking Page 11...

  • Page 28: Anti-Static Precautions

    Only handle the edges of the PCB: Don't touch the surface of the motherboard. Hold the motherboard by the edges when handling. 2.2 Unpacking Precautions When the KINO-DCM236 is unpacked, please do the following:  Follow the antistatic guidelines above.

  • Page 29: Packing List

    If any of the components listed in the checklist below are missing, do not proceed with the installation. Contact the IEI reseller or vendor the KINO-DCM236 was purchased from or contact an IEI sales representative directly by sending an email to sales@ieiworld.com.

  • Page 30: Optional Items

    KINO-DCM236 Industrial Motherboard 2.4 Optional Items The following are optional components which may be separately purchased: Item and Part Number Image KB/MS PS/2 Y-cable (P/N: 32000-023800-RS) SATA cable, 500 mm (P/N: 32000-062800-RS) Dual USB cable (wo bracket), 210 mm, p=2.0 (P/N: 32000-070301-RS) Dual USB cable (wo bracket, double layer), 220 mm, p=2.0...

  • Page 31: Connectors

    KINO-DCM236 Industrial Motherboard Chapter Connectors Page 15...

  • Page 32: Peripheral Interface Connectors

    KINO-DCM236 Industrial Motherboard 3.1 Peripheral Interface Connectors This chapter details all the jumpers and connectors. 3.1.1 KINO-DCM236 Layout The figures below show all the connectors and jumpers. Figure 3-1: Connector and Jumper Locations (Front Side) Page 16...

  • Page 33: Peripheral Interface Connectors

    KINO-DCM236 Industrial Motherboard 3.1.2 Peripheral Interface Connectors The table below lists all the connectors on the board. Connector Type Label ATX power connector 4-pin Molex CPU12V2 Audio connector 10-pin header FRONT-PANEL1 Battery connector 2-pin wafer BAT1 Chassis intrusion connector 2-pin header...

  • Page 34: External Interface Panel Connectors

    KINO-DCM236 Industrial Motherboard S_ATA3, S_ATA4 SATA power connectors 2-pin wafer SATA_PWR1, SATA_PWR2 SMBus connector 4-pin wafer SMB1 SPI flash connector, BIOS 6-pin wafer JSPI1 SPI flash connector, EC 6-pin wafer JSPI2 USB 2.0 connectors 8-pin header USB1, USB2 Table 3-1: Peripheral Interface Connectors 3.1.3 External Interface Panel Connectors...

  • Page 35: Internal Peripheral Connectors

    KINO-DCM236 Industrial Motherboard 3.2 Internal Peripheral Connectors The section describes all of the connectors on the KINO-DCM236. 3.2.1 ATX Power Connector CN Label: CPU12V2 4-pin Molex, p=4.2 mm CN Type: CN Location: See Figure 3-2 CN Pinouts: See Table 3-3 The connector supports the +12V power supply.

  • Page 36: Audio Connector

    KINO-DCM236 Industrial Motherboard 3.2.2 Audio Connector CN Label: FRONT-PANEL1 CN Type: 10-pin header, p=2.54 mm CN Location: See Figure 3-3 CN Pinouts: See Table 3-4 The audio connector is connected to external audio devices including speakers and microphones for the input and output of audio signals to and from the system.

  • Page 37: Battery Connector

    KINO-DCM236 Industrial Motherboard 3.2.3 Battery Connector CAUTION: Risk of explosion if battery is replaced by an incorrect type. Only certified engineers should replace the on-board battery. Dispose of used batteries according to instructions and local regulations. CN Label: BAT1 CN Type: 2-pin wafer, p=1.25 mm...

  • Page 38: Chassis Intrusion Connector

    KINO-DCM236 Industrial Motherboard 3.2.4 Chassis Intrusion Connector CN Label: CHASSIS1 CN Type: 2-pin header, p=2.54 mm CN Location: See Figure 3-5 CN Pinouts: See Table 3-6 The chassis intrusion connector is for a chassis intrusion detection sensor or switch that detects if a chassis component is removed or replaced.

  • Page 39: Digital I/O Connector

    KINO-DCM236 Industrial Motherboard 3.2.5 Digital I/O Connector CN Label: DIO1 10-pin header, p=2.00 mm CN Type: CN Location: See Figure 3-6 CN Pinouts: See Table 3-7 The 8-bit digital I/O connector provides programmable input and output for external devices. Figure 3-6: Digital I/O Connector Location PIN NO.

  • Page 40: Fan Connectors

    KINO-DCM236 Industrial Motherboard 3.2.6 Fan Connectors CN Label: CPU_FAN1, SYS_FAN1 4-pin wafer, p=2.54 mm CN Type: CN Location: See Figure 3-7 CN Pinouts: See Table 3-8 The fan connector attaches to a cooling fan. Figure 3-7: Fan Connector Locations Description...

  • Page 41: Front Panel Connector

    KINO-DCM236 Industrial Motherboard 3.2.7 Front Panel Connector CN Label: F_PANEL1 10-pin header, p=2.54 mm CN Type: CN Location: See Figure 3-8 CN Pinouts: See Table 3-9 The front panel connector connects to the indicator LEDs and buttons on the computer's front panel.

  • Page 42: I 2 C Connector

    KINO-DCM236 Industrial Motherboard 3.2.8 I C Connector CN Label: I2C1 4-pin wafer, p=1.25 mm CN Type: CN Location: F igure 3-9 CN Pinouts: T able 3-10 The I C connector is used to connect I C-bus devices to the motherboard.

  • Page 43: Keyboard/Mouse Connector

    KINO-DCM236 Industrial Motherboard 3.2.9 Keyboard/Mouse Connector CN Label: KB/MS1 6-pin wafer, p=2.00 mm CN Type: CN Location: See Figure 3-10 CN Pinouts: See Table 3-11 The keyboard/mouse connector connects to a PS/2 Y-cable that can be connected to a PS/2 keyboard and mouse.

  • Page 44: Lan Led Connectors

    KINO-DCM236 Industrial Motherboard 3.2.10 LAN LED Connectors CN Label: LED_LAN1, LED_LAN2 2-pin header, p=2.54 mm CN Type: CN Location: See Figure 3-11 CN Pinouts: See Table 3-12 The LAN LED connectors connect to the LAN link LEDs on the system.

  • Page 45: Lvds Connector

    KINO-DCM236 Industrial Motherboard 3.2.11 LVDS Connector CN Label: LVDS1 30-pin crimp, p=1.25 mm CN Type: CN Location: See Figure 3-12 CN Pinouts: See Table 3-13 The LVDS connector is for an LCD panel connected to the board. Figure 3-12: LVDS Connector Location...

  • Page 46: Lvds Backlight Connector

    KINO-DCM236 Industrial Motherboard Description Description +LCD Vcc +LCD Vcc +LCD Vcc +LCD Vcc Table 3-13: LVDS Connector Pinouts 3.2.12 LVDS Backlight Connector CN Label: INV1 CN Type: 5-pin wafer, p=2.00 mm CN Location: See Figure 3-13 CN Pinouts: See Table 3-14 The backlight inverter connectors provide power to LCD panels.

  • Page 47: Module Slot

    KINO-DCM236 Industrial Motherboard 3.2.13 M.2 Module Slot CN Label: M.2 A-key slot CN Type: CN Location: See Figure 3-14 CN Pinouts: See Table 3-15 The M.2 slot is for installing M.2 2230 modules with A-key edge connector. Figure 3-14: M.2 Slot Location...

  • Page 48: Table 3-15: M.2 Slot Pinouts

    KINO-DCM236 Industrial Motherboard Description Description PCIE_TXP11_M2 PCIE_TXN11_M2 PCIE_RXP11_M2 PCIE_RXN11_M2 CK_M2_100M_DP CK_M2_100M_DN PLT_GATED_RST# +3.3V W_DISABLE# (ACTIVE LOW) PCIE_TXP10_M2 PCIE_TXN10_M2 PCIE_RXP10_M2 PCIE_RXN10_M2 CK_M2_100M_D10P +3.3V CK_M2_100M_D10N +3.3V Table 3-15: M.2 Slot Pinouts Page 32...

  • Page 49: Pci Express X16 Slot

    KINO-DCM236 Industrial Motherboard 3.2.14 PCI Express x16 Slot CN Label: PCIEX16_1 PCIe x16 slot CN Type: CN Location: See Figure 3-15 The PCIe x16 expansion card slot is for PCIe x16 cards. Figure 3-15: PCIe x16 Slot Location 3.2.15 PCIe Mini Card Slot, Full-size...

  • Page 50: Figure 3-16: Full-Size Pcie Mini Card Slot Location

    KINO-DCM236 Industrial Motherboard Figure 3-16: Full-size PCIe Mini Card Slot Location Description Description PCIE_WAKE# +3.3V 1.5V CLK- CLK+ PCIRST# +3.3V PCIRST# PERN(SATA_RX+) 3VDual PERP(SATA_RX-) 1.5V SMBCLK PETN(SATA_TX-) SMBDATA PETP(SATA_TX+) USBD- USBD+ Page 34...

  • Page 51: Pcie Mini Card Slot, Half-Size

    KINO-DCM236 Industrial Motherboard Description Description SATA_DET_R_N 1.5V MSATA_SEL# +3.3V Table 3-16: Full-size PCIe Mini Card Slot Pinouts 3.2.16 PCIe Mini Card Slot, Half-size CN Label: MPCIE2 CN Type: Half-size PCIe Mini card slot CN Location: F igure 3-17 CN Pinouts: See Table 3-17 The PCIe Mini card slot supports PCIe Mini cards with USB interface.

  • Page 52: Table 3-17: Half-Size Pcie Mini Card Slot Pinouts

    KINO-DCM236 Industrial Motherboard Description Description PCIE_CLK# PCIE _CLK PLTRST_N +3.3V PLTRST_N PCIE_RX+ +3.3V PCIE_RX- 1.5V SMB_CLK PCIE_TX+ SMB_DATA PCIE_TX- USB_DATA- USB_DATA+ +3.3V +3.3V +3.3V CLINK_CLK CLINK_DATA 1.5V CLINK_RST# +3.3V Table 3-17: Half-size PCIe Mini Card Slot Pinouts Page 36...

  • Page 53: Power Button

    KINO-DCM236 Industrial Motherboard 3.2.17 Power Button CN Label: PWR_SW1 Push button CN Type: CN Location: See Figure 3-18 The on-board power button controls system power. Figure 3-18: Power Button Location 3.2.18 RS-232 Serial Port Connectors CN Label: COM2, COM3, COM4 CN Type: 9-pin wafer, p=1.25 mm...

  • Page 54: Rs-232/422/485 Serial Port Connectors

    KINO-DCM236 Industrial Motherboard Figure 3-19: RS-232 Connector Locations Description Description SOUT Table 3-18: RS-232 Connector Pinouts 3.2.19 RS-232/422/485 Serial Port Connectors CN Label: COM5, COM6 CN Type: 9-pin wafer, p=1.25 mm CN Location: See Figure 3-20 CN Pinouts: See Table 3-19 This connector provides RS-232, RS-422 or RS-485 communications.

  • Page 55: Figure 3-20: Rs-232/422/485 Connector Locations

    KINO-DCM236 Industrial Motherboard Figure 3-20: RS-232/422/485 Connector Locations Description Description SOUT Table 3-19: RS-232/422/485 Connector Pinouts Use the optional RS-232/422/485 cable to connect to a serial device. The pinouts of the DB-9 connector are listed below. PIN NO. RS-232 RS-422...

  • Page 56: Sata 6Gb/S Drive Connectors

    KINO-DCM236 Industrial Motherboard 3.2.20 SATA 6Gb/s Drive Connectors CN Label: S_ATA1, S_ATA2, S_ATA3, S_ATA4 CN Type: 7-pin SATA connector CN Location: See Figure 3-21 The SATA 6Gb/s drive connector is connected to a SATA 6Gb/s drive. The SATA 6Gb/s drive transfers data at speeds as high as 6Gb/s.

  • Page 57: Sata Power Connectors

    KINO-DCM236 Industrial Motherboard 3.2.21 SATA Power Connectors CN Label: SATA_PWR1, SATA_PWR2 2-pin wafer, p=2.00 mm CN Type: CN Location: See Figure 3-22 CN Pinouts: See Table 3-21 Use the SATA Power Connector to connect to SATA device power connections. Figure 3-22: SATA Power Connector Locations...

  • Page 58: Smbus Connector

    KINO-DCM236 Industrial Motherboard 3.2.22 SMBus Connector CN Label: SMB1 4-pin wafer, p=1.25 mm CN Type: CN Location: See Figure 3-23 CN Pinouts: See Table 3-22 The SMBus (System Management Bus) connector provides low-speed system management communications. Figure 3-23: SMBus Connector Location...

  • Page 59: Spi Flash Connector, Bios

    KINO-DCM236 Industrial Motherboard 3.2.23 SPI Flash Connector, BIOS CN Label: JSPI1 6-pin wafer, p=1.25 mm CN Type: CN Location: See Figure 3-24 CN Pinouts: See Table 3-23 The 6-pin SPI Flash connector is used to flash the BIOS. Figure 3-24: SPI Flash Connector Location Description +3.3VA...

  • Page 60: Spi Flash Connector, Ec

    KINO-DCM236 Industrial Motherboard 3.2.24 SPI Flash Connector, EC CN Label: JSPI2 6-pin wafer, p=1.25 mm CN Type: CN Location: See Figure 3-25 CN Pinouts: See Table 3-24 The 6-pin SPI Flash connector is used to flash the embedded controller. Figure 3-25: SPI Flash Connector Location Description +3.3VA...

  • Page 61: Usb 2.0 Connectors

    KINO-DCM236 Industrial Motherboard 3.2.25 USB 2.0 Connectors CN Label: USB1, USB2 CN Type: 8-pin header, p=2.00 mm CN Location: See Figure 3-26 CN Pinouts: See Table 3-25 The USB connector provides two USB 2.0 ports by dual-port USB cable. Figure 3-26: USB Connector Locations...

  • Page 62: External Interface Connectors

    KINO-DCM236 Industrial Motherboard 3.3 External Interface Connectors Figure 3-27 shows the KINO-DCM236 motherboard external interface connectors. The KINO-DCM236 on-board external interface connectors are shown in Figure 3-27. Figure 3-27: External Interface Connectors 3.3.1 Audio Connector CN Label: AUDIO_CV1 Audio jack...

  • Page 63: Ethernet And Usb 3.0 Connectors

    KINO-DCM236 Industrial Motherboard 3.3.2 Ethernet and USB 3.0 Connectors CN Label: LAN1_USB1, LAN2_USB2 RJ-45 and USB 3.0 combo connector CN Type: CN Location: See Figure 3-27 CN Pinouts: See Table 3-26 and Table 3-28 ® The LAN connector connects to a local network and supports Intel AMT 11.0.

  • Page 64: Hdmi Connectors

    KINO-DCM236 Industrial Motherboard Each USB 3.0 connector can be connected to a USB device. Description VBUS GND1 STDA_SSRX1_N STDA_SSRX1_P GND_DRAIN STDA_SSTX1_N STDA_SSTX1_P Table 3-28: External USB 3.0 Port Pinouts 3.3.3 HDMI Connectors CN Label: HDMI1, HDMI2, HDMI3 CN Type: HDMI connector...

  • Page 65: Power Connector (12 V, Power Adapter)

    KINO-DCM236 Industrial Motherboard Description Description HDMI_DATA0# HDMI_HPD HDMI_CLK+ Table 3-29: HDMI Connector Pinouts Figure 3-30: HDMI Connector 3.3.4 Power Connector (12 V, Power Adapter) CN Label: PWR1 4-pin Mini-DIN CN Type: CN Location: See Figure 3-27 CN Pinouts: See Figure 3-31 The connector supports a 12V power adapter.

  • Page 66: Serial Port Connector (Com1)

    KINO-DCM236 Industrial Motherboard 3.3.5 Serial Port Connector (COM1) CN Label: COM1 D-sub 9 CN Type: CN Location: See Figure 3-27 CN Pinouts: See Table 3-30 The serial port connects to a RS-232 serial communications device. Description Description DATA CARRIER DETECT (DCD1)

  • Page 67: Installation

    KINO-DCM236 Industrial Motherboard Chapter Installation Page 51...

  • Page 68: Anti-Static Precautions

    Electrostatic discharge (ESD) can cause serious damage to electronic components, including the KINO-DCM236. Dry climates are especially susceptible to ESD. It is therefore critical that whenever the KINO-DCM236 or any other electrical component is handled, the following anti-static precautions are strictly adhered to.
  • Page 69  Turn all power to the KINO-DCM236 off: When working with the KINO-DCM236, make sure that it is disconnected from all power supplies and that no electricity is being fed into the system. Before and during the installation of the KINO-DCM236 DO NOT: ...

  • Page 70: So-Dimm Installation

    KINO-DCM236 Industrial Motherboard 4.3 SO-DIMM Installation To install an SO-DIMM, please follow the steps below and refer to Figure 4-1. Figure 4-1: SO-DIMM Installation Step 1: Open the SO-DIMM socket handles. Open the two handles outwards as far as they can. See Figure 4-1.

  • Page 71: Module Installation

    KINO-DCM236 Industrial Motherboard 4.4 M.2 Module Installation To install an M.2 module, please follow the steps below. Step 1: Locate the M.2 module slot. See Chapter 3. Step 2: Line up the notch on the card with the notch on the slot. Slide the PCIe Mini card into the socket at an angle of about 20º...

  • Page 72: Full-Size Pcie Mini Card Installation

    KINO-DCM236 Industrial Motherboard 4.5 Full-size PCIe Mini Card Installation To install a full-size PCIe Mini card, please follow the steps below. Step 1: Locate the full-size PCIe Mini card slot. See Chapter 3. Step 2: Remove the retention screw as shown in Figure 4-4.

  • Page 73: Half-Size Pcie Mini Card Installation

    KINO-DCM236 Industrial Motherboard Figure 4-6: Securing the Full-size PCIe Mini Card 4.6 Half-size PCIe Mini Card Installation To install a half-size PCIe Mini card, please follow the steps below. Step 1: Locate the half-size PCIe Mini card slot. See Chapter 3.

  • Page 74: Figure 4-8: Inserting The Half-Size Pcie Mini Card Into The Slot At An Angle

    KINO-DCM236 Industrial Motherboard Figure 4-8: Inserting the Half-size PCIe Mini Card into the Slot at an Angle Step 4: Secure the half-size PCIe Mini card with the retention screw previously removed (Figure 4-9). Figure 4-9: Securing the Half-size PCIe Mini Card...

  • Page 75: System Configuration

    KINO-DCM236 Industrial Motherboard 4.7 System Configuration The system configuration is controlled by buttons, jumpers and switches. The system configuration should be performed before installation. 4.7.1 AT/ATX Mode Select Switch The AT/ATX mode select switch specifies the systems power mode as AT or ATX.

  • Page 76: Clear Cmos Button

    KINO-DCM236 Industrial Motherboard 4.7.2 Clear CMOS Button If the KINO-DCM236 fails to boot due to improper BIOS settings, press the button for three seconds to clear the CMOS data and reset the system BIOS information. After updating to a new version of BIOS, the user has to follow the steps described below to boot up the system.

  • Page 77: Flash Descriptor Security Override Jumper

    KINO-DCM236 Industrial Motherboard 4.7.3 Flash Descriptor Security Override Jumper The Flash Descriptor Security Override jumper (J_FLASH1, p=2.00 mm) allows users to enable or disable the ME firmware update. Refer to Figure 4-12 and Table 4-2 for the jumper location and settings.

  • Page 78: Lvds Resolution Selection

    KINO-DCM236 Industrial Motherboard 4.7.4 LVDS Resolution Selection The DIP switch (SW1) selects the resolution of the LCD panel connected to the LVDS connector. * ON=0, OFF=1; Single=S, Dual=D SW1 (4-3-2-1) Description 0000 800x600 18bit S (default) 0001 1024x768 18bit S...

  • Page 79: Lvds Backlight Mode Selection

    KINO-DCM236 Industrial Motherboard 4.7.5 LVDS Backlight Mode Selection This LVDS backlight mode select jumper (BL_MODE1, p=2.00 mm) selects the LVDS backlight mode. Description Short 1-2 PWM mode (Default) Short 2-3 DC mode Table 4-4: LVDS Backlight Mode Select Jumper Settings Figure 4-14: LVDS Backlight Mode Select Jumper Location 4.7.6 LVDS Voltage Selection...

  • Page 80: Usb Power Selection

    KINO-DCM236 Industrial Motherboard Figure 4-15: LVDS Voltage Jumper Location 4.7.7 USB Power Selection The USB power selection is made through the BIOS menu in “Chipset  PCH-IO Configuration”. Use the USB Power SW1 and the USB Power SW2 BIOS options to configure the correspondent USB ports (see Table 4-6) and refer to Table 4-7 to select the USB power source.

  • Page 81: Chassis Installation

    This section outlines the installation of peripheral devices to the on-board connectors 4.9.1 SATA Drive Connection The KINO-DCM236 is shipped with two SATA drive cables. To connect the SATA drives to the connectors, please follow the steps below. Step 1: Locate the connectors.

  • Page 82: Figure 4-16: Sata Drive Cable Connection

    KINO-DCM236 Industrial Motherboard NOTE: The connector locations in the following diagram are just for reference. For the exact locations, please see Section 3.2.20. Figure 4-16: SATA Drive Cable Connection Step 3: Connect the connector on the other end of the cable to the connector at the back of the SATA drive.

  • Page 83: Intel ® Amt Setup Procedure

    KINO-DCM236 Industrial Motherboard ® 4.10 Intel AMT Setup Procedure ® The KINO-DCM236 is featured with the Intel Active Management Technology (AMT). To ® enable the Intel AMT function, follow the steps below. Step 1: Make sure at least one of the memory sockets is installed with a DDR4 SO-DIMM.

  • Page 84: Windows 7 Installation-Usb 3.0 Creator Utility

    The Windows 7 USB 3.0 Creator Utility automates the steps to update a Windows 7 installation image so that it contains USB 3.0 drivers. To install Windows 7 from a USB drive onto the KINO-DCM236, please follow the steps described below. Step 1: Create a USB flash drive installer.

  • Page 85: Bios

    KINO-DCM236 Industrial Motherboard Chapter BIOS Page 69...

  • Page 86: Introduction

    KINO-DCM236 Industrial Motherboard 5.1 Introduction The BIOS is programmed onto the BIOS chip. The BIOS setup program allows changes to certain system settings. This chapter outlines the options that can be changed. NOTE: Some of the BIOS options may vary throughout the life cycle of the product and are subject to change without prior notice.

  • Page 87: Getting Help

    KINO-DCM236 Industrial Motherboard Function Decrease the numeric value or make changes F1 key General help, only for Status Page Setup Menu and Option Page Setup Menu F2 key Load previous values. F3 key Load optimized defaults F4 key Save changes and Exit BIOS Esc key Main Menu –...

  • Page 88: Main

    KINO-DCM236 Industrial Motherboard 5.2 Main The Main BIOS menu (BIOS Menu 1) appears when the BIOS Setup program is entered. Aptio Setup Utility – Copyright (C) 2016 American Megatrends, Inc. Main Advanced Chipset Security Boot Save & Exit BIOS Information...

  • Page 89: Advanced

    KINO-DCM236 Industrial Motherboard  System Date [xx/xx/xx] Use the System Date option to set the system date. Manually enter the day, month and year.  System Time [xx:xx:xx] Use the System Time option to set the system time. Manually enter the hours, minutes and seconds.

  • Page 90: Acpi Settings

    KINO-DCM236 Industrial Motherboard 5.3.1 ACPI Settings The ACPI Settings menu ( B IOS Menu 3) configures the Advanced Configuration and Power Interface (ACPI) options. Aptio Setup Utility – Copyright (C) 2016 American Megatrends, Inc. Advanced ACPI Settings Select the highest ACPI...

  • Page 91: Amt Configuration

    KINO-DCM236 Industrial Motherboard 5.3.2 AMT Configuration ® The AMT Configuration menu (BIOS Menu 4) allows Intel Active Management Technology (AMT) options to be configured. Aptio Setup Utility – Copyright (C) 2016 American Megatrends, Inc. Advanced Intel AMT [Enabled] Enable/Disable Intel (R)

  • Page 92: Super Io Configuration

    KINO-DCM236 Industrial Motherboard  Enabled To perform ME unconfigure 5.3.3 Super IO Configuration Use the Super IO Configuration menu (BIOS Menu 5) to set or change the configurations for the serial ports. Aptio Setup Utility – Copyright (C) 2016 American Megatrends, Inc.

  • Page 93: Serial Port N Configuration

    KINO-DCM236 Industrial Motherboard 5.3.3.1 Serial Port n Configuration Use the Serial Port n Configuration menu (BIOS Menu 6) to configure the serial port n. Aptio Setup Utility – Copyright (C) 2016 American Megatrends, Inc. Advanced Serial Port 1 Configuration Enable or Disable Serial...

  • Page 94: Serial Port 2 Configuration

    KINO-DCM236 Industrial Motherboard  IO=3F8h; IRQ=3, Serial Port I/O port address is 3F8h and the 4, 11 interrupt address is IRQ3, 4, 11  Serial Port I/O port address is 2F8h and the IO=2F8h; IRQ=3, interrupt address is IRQ3, 4, 11 4, 11 ...

  • Page 95: Serial Port 3 Configuration

    KINO-DCM236 Industrial Motherboard  IO=2E8h; IRQ=3, Serial Port I/O port address is 2E8h and the 4, 11 interrupt address is IRQ3, 4, 11 5.3.3.1.3 Serial Port 3 Configuration  Serial Port [Enabled] Use the Serial Port option to enable or disable the serial port.

  • Page 96: Serial Port 4 Configuration

    KINO-DCM236 Industrial Motherboard 5.3.3.1.4 Serial Port 4 Configuration  Serial Port [Enabled] Use the Serial Port option to enable or disable the serial port.  Disabled Disable the serial port  Enabled Enable the serial port EFAULT  Change Settings [Auto] Use the Change Settings option to change the serial port IO port address and interrupt address.

  • Page 97: Serial Port 5 Configuration

    KINO-DCM236 Industrial Motherboard 5.3.3.1.5 Serial Port 5 Configuration  Serial Port [Enabled] Use the Serial Port option to enable or disable the serial port.  Disabled Disable the serial port  Enable the serial port Enabled EFAULT  Change Settings [Auto] Use the Change Settings option to change the serial port IO port address and interrupt address.

  • Page 98: Serial Port 6 Configuration

    KINO-DCM236 Industrial Motherboard  Transfer Mode [RS232] Use the Transfer Mode option to select the Serial Port 5 signaling mode.  Serial Port 5 signaling mode is RS-422 RS422  RS485 Serial Port 5 signaling mode is RS-485  RS232...

  • Page 99: Iwdd H/W Monitor

    KINO-DCM236 Industrial Motherboard  IO=2D0h; IRQ=3, Serial Port I/O port address is 2D0h and the 4, 11 interrupt address is IRQ3, 4, 11  Serial Port I/O port address is 2E0h and the IO=2E0h; IRQ=3, interrupt address is IRQ3, 4, 11 4, 11 ...
  • Page 100 KINO-DCM236 Industrial Motherboard  PC Health Status The following system parameters and values are shown. The system parameters that are monitored are:  System Temperatures: CPU Temperature System temperature  Fan Speed: CPU Fan Speed System Fan Speed  Voltages...

  • Page 101: Smart Fan Mode Configuration

    KINO-DCM236 Industrial Motherboard 5.3.4.1 Smart Fan Mode Configuration Use the Smart Fan Mode Configuration submenu (BIOS Menu 8) to configure fan temperature and speed settings. Aptio Setup Utility – Copyright (C) 2016 American Megatrends, Inc. Advanced Smart Fan Mode Configuration...
  • Page 102 KINO-DCM236 Industrial Motherboard  SYS_FAN1 Smart Fan Control [Auto Mode] Use the SYS_FAN1 Smart Fan Control BIOS option to configure the system smart fan.  The fan spins at the speed set in the Manual Manual Mode Mode option ...
  • Page 103 KINO-DCM236 Industrial Motherboard  Auto mode fan off temperature [20] WARNING: Setting this value too high may cause the fan to speed up only when the CPU is at a very high temperature and therefore cause the system to be damaged.

  • Page 104: Rtc Wake Settings

    KINO-DCM236 Industrial Motherboard 5.3.5 RTC Wake Settings The RTC Wake Settings menu (BIOS Menu 9) configures RTC wake event. Aptio Setup Utility – Copyright (C) 2016 American Megatrends, Inc. Advanced Wake system with Fixed Time [Disabled] Enable or disable System wake on alarm event.

  • Page 105: Serial Port Console Redirection

    KINO-DCM236 Industrial Motherboard Wake up hour Wake up minute Wake up second After setting the alarm, the computer turns itself on from a suspend state when the alarm goes off. 5.3.6 Serial Port Console Redirection The Serial Port Console Redirection menu (BIOS Menu 10) allows the console redirection options to be configured.

  • Page 106: Legacy Console Redirection Settings

    KINO-DCM236 Industrial Motherboard  Console Redirection [Disabled] Use Console Redirection option to enable or disable the console redirection function.  Disabled the console redirection function Disabled EFAULT  Enabled Enabled the console redirection function 5.3.6.1 Legacy Console Redirection Settings The Legacy Console Redirection Settings menu ( B IOS Menu 11) allows the legacy console redirection options to be configured.

  • Page 107: Console Redirection Settings

    KINO-DCM236 Industrial Motherboard  COM6  COM7 (Pci Bus0, Dev0, Func0) (Disabled) 5.3.6.2 Console Redirection Settings The Console Redirection Settings menu ( B IOS Menu 12) allows the console redirection options to be configured. The option is active when Console Redirection option is enabled.
  • Page 108 KINO-DCM236 Industrial Motherboard  Bits per second [115200] Use the Bits per second option to specify the serial port transmission speed. The speed must match the other side. Long or noisy lines may require lower speeds.  9600 Sets the serial port transmission speed at 9600.

  • Page 109: Cpu Configuration

    KINO-DCM236 Industrial Motherboard  Stop Bits [1] Use the Stop Bits option to specify the number of stop bits used to indicate the end of a serial data packet. Communication with slow devices may require more than 1 stop bit.
  • Page 110 KINO-DCM236 Industrial Motherboard  Active Processor Cores [All] Use the Active Processor Cores BIOS option to enable numbers of cores in the processor package.  Enable all cores in the processor package. EFAULT  Enable one core in the processor package.

  • Page 111: Sata Configuration

    KINO-DCM236 Industrial Motherboard 5.3.8 SATA Configuration Use the SATA Configuration menu (BIOS Menu 14) to change and/or set the configuration of the SATA devices installed in the system. Aptio Setup Utility – Copyright (C) 2016 American Megatrends, Inc. Advanced STAT Controller(s)

  • Page 112: Nvme Configuration

    KINO-DCM236 Industrial Motherboard NOTE: Before accessing the RAID configuration utility, ensure to set the Option ROM Messages BIOS option in the Boot menu to Force BIOS. This is to allow the “Press <CTRL+I> to enter Configuration Utility……” message to appear during POST. Press Ctrl+I when prompted to enter the RAID configuration utility.

  • Page 113: Usb Configuration

    KINO-DCM236 Industrial Motherboard 5.3.10 USB Configuration Use the USB Configuration menu (BIOS Menu 16) to read USB configuration information and configure the USB settings. Aptio Setup Utility – Copyright (C) 2016 American Megatrends, Inc. Advanced USB Configuration Enables Legacy USB support.

  • Page 114: Iei Feature

    KINO-DCM236 Industrial Motherboard  Enabled Legacy USB support enabled EFAULT  Legacy USB support disabled Disabled  Auto Legacy USB support disabled if no USB devices are connected 5.3.11 IEI Feature Use the IEI Feature menu (BIOS Menu 17) to configure One Key Recovery function.

  • Page 115: Chipset

    KINO-DCM236 Industrial Motherboard 5.4 Chipset Use the Chipset menu (BIOS Menu 18) to configure the system chipset. Aptio Setup Utility – Copyright (C) 2016 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit Server Mgmt > System Agent (SA) Configuration System Agent (SA) >...

  • Page 116: Graphics Configuration

    KINO-DCM236 Industrial Motherboard  VT-d [Disabled] Use the VT-d option to enable or disable VT-d support.  Disable VT-d support. Disabled EFAULT  Enabled Enable VT-d support. 5.4.1.1 Graphics Configuration Use the Graphics Configuration menu ( B IOS Menu 20) to configure the graphics settings.
  • Page 117 KINO-DCM236 Industrial Motherboard  Internal Graphics [Enabled] Use the Internal Graphics option to enable or disable the internal graphics device.  The internal graphics device is automatically detected Auto and enabled.  Disable the internal graphics device. Disabled  Enabled Enable the internal graphics device.
  • Page 118 KINO-DCM236 Industrial Motherboard  DVMT Total Gfx Mem [MAX] Use the DVMT Total Gfx Mem option to select DVMT 5.0 total graphic memory size used by the internal graphics device. The following options are available:  128M  256M ...

  • Page 119: Lcd Control

    KINO-DCM236 Industrial Motherboard 5.4.1.1.1 LCD Control Use the LCD Control submenu (BIOS Menu 21) to select a display device which will be activated during POST. Aptio Setup Utility – Copyright (C) 2016 American Megatrends, Inc. Chipset LCD Control Select the LVDS Enabled/Disabled.

  • Page 120: Peg Port Configuration

    KINO-DCM236 Industrial Motherboard  Backlight Control Type [PWM] Use the Backlight Control Type option to specify the backlight control type. Configuration options are listed below.  EFAULT  5.4.1.2 PEG Port Configuration Aptio Setup Utility – Copyright (C) 2016 American Megatrends, Inc.

  • Page 121: Memory Configuration

    KINO-DCM236 Industrial Motherboard  Detect Non-Compliance Device [Disabled] Use the Detect Non-Compliance Device option to enable or disable detecting if a non-compliance PCI Express device is connected to the PCI Express slot.  Disabled Disables to detect if a non-compliance PCI...

  • Page 122: Pch-Io Configuration

    KINO-DCM236 Industrial Motherboard 5.4.2 PCH-IO Configuration Use the PCH-IO Configuration menu (BIOS Menu 24) to configure the PCH-IO chipset. Aptio Setup Utility – Copyright (C) 2016 American Megatrends, Inc. Chipset Auto Power Button Status [Disable (ATX)] Select AC power state when...

  • Page 123: Table 5-1: Bios Options And Configured Usb Ports

    KINO-DCM236 Industrial Motherboard  USB Power SW1 [+5V DUAL] Use the USB Power SW1 BIOS option to configure the USB power source for the corresponding USB connectors (Table 5-1).  +5V DUAL Sets the USB power source to +5V dual EFAULT ...

  • Page 124: Pci Express Configuration

    KINO-DCM236 Industrial Motherboard 5.4.2.1 PCI Express Configuration Use the PCI Express Configuration submenu (BIOS Menu 25) to configure the PCI Express slots. Aptio Setup Utility – Copyright (C) 2016 American Megatrends, Inc. Chipset PCI Express Configuration MPCIE1 Settings. > MPCIE1 >...

  • Page 125: Hd Audio Configuration

    KINO-DCM236 Industrial Motherboard  Disabled Disables to detect if a non-compliance PCI EFAULT Express device is connected to the PCI Express slot.  Enables to detect if a non-compliance PCI Express Enabled device is connected to the PCI Express slot.

  • Page 126: Security

    KINO-DCM236 Industrial Motherboard  Auto onboard High Definition Audio controller EFAULT automatically detected and enabled. 5.5 Security Use the Security menu (BIOS Menu 27) to set system and user passwords. Aptio Setup Utility – Copyright (C) 2016 American Megatrends, Inc.

  • Page 127: Boot

    KINO-DCM236 Industrial Motherboard 5.6 Boot Use the Boot menu (BIOS Menu 28) to configure system boot options. Aptio Setup Utility – Copyright (C) 2016 American Megatrends, Inc. Main Advanced Chipset Security Boot Save & Exit Boot Configuration Select the keyboard...
  • Page 128 KINO-DCM236 Industrial Motherboard  Quiet Boot [Enabled] Use the Quiet Boot BIOS option to select the screen display when the system boots.  Normal POST messages displayed Disabled  Enabled OEM Logo displayed instead of POST messages EFAULT  Launch PXE OpROM [Disabled] Use the Launch PXE OpROM option to enable or disable boot option for legacy network devices.

  • Page 129: Save & Exit

    KINO-DCM236 Industrial Motherboard 5.7 Save & Exit Use the Save & Exit menu (BIOS Menu 29) to load default BIOS values, optimal failsafe values and to save configuration changes. Aptio Setup Utility – Copyright (C) 2016 American Megatrends, Inc. Main...
  • Page 130 KINO-DCM236 Industrial Motherboard  Save as User Defaults Use the Save as User Defaults option to save the changes done so far as user defaults.  Restore User Defaults Use the Restore User Defaults option to restore the user defaults to all the setup options.

  • Page 131: Software Drivers

    KINO-DCM236 Industrial Motherboard Chapter Software Drivers Page 115...

  • Page 132: Software Installation

    Visit the IEI website or contact technical support for the latest updates. 6.1 Software Installation All the drivers for the KINO-DCM236 are on the CD that came with the system. To install the drivers, please follow the steps below. Step 1: Insert the CD into a CD drive connected to the system.

  • Page 133: Available Software Drivers

    KINO-DCM236 Industrial Motherboard 6.2 Available Software Drivers All the drivers for the KINO-DCM236 are on the utility CD that came with the system. The utility CD contains drivers for Windows 7, Windows 8 and Windows 10 operating systems. If the drivers are not installed automatically, please install the following drivers manually.

  • Page 134: A Regulatory Compliance

    KINO-DCM236 Industrial Motherboard Appendix Regulatory Compliance Page 118...
  • Page 135 KINO-DCM236 Industrial Motherboard DECLARATION OF CONFORMITY This equipment has been tested and found to comply with specifications for CE marking. If the user modifies and/or installs other devices in the equipment, the CE conformity declaration may no longer apply. FCC WARNING This equipment complies with Part 15 of the FCC Rules.

  • Page 136: B Product Disposal

    KINO-DCM236 Industrial Motherboard Appendix Product Disposal Page 120...
  • Page 137 KINO-DCM236 Industrial Motherboard CAUTION: Risk of explosion if battery is replaced by an incorrect type. Only certified engineers should replace the on-board battery. Dispose of used batteries according to instructions and local regulations.  Outside the European Union–If you wish to dispose of used electrical and electronic products outside the European Union, please contact your local authority so as to comply with the correct disposal method.

  • Page 138: Cbios Menu Options

    KINO-DCM236 Industrial Motherboard Appendix BIOS Menu Options Page 122...
  • Page 139 KINO-DCM236 Industrial Motherboard 　 System Date [xx/xx/xx] ......................73 　 System Time [xx:xx:xx] .......................73 　 ACPI Sleep State [S3 (Suspend to RAM)]................74 　 Intel AMT [Enabled] ......................75 　 Un-configure ME [Disabled]....................75 　 Serial Port [Enabled]......................77 　 Change Settings [Auto] .......................77 　...
  • Page 140 KINO-DCM236 Industrial Motherboard 　 Active Processor Cores [All] ....................94 ® 　 Intel Virtualization Technology [Disabled] ..............94 ® 　 Intel SpeedStep™ [Enabled] .....................94 　 CPU C State [Disabled]......................94 　 STAT Controller(s) [Enabled]....................95 　 SATA Mode Selection [AHCI]....................95 　 Hot Plug [Disabled]......................96 　...
  • Page 141 KINO-DCM236 Industrial Motherboard 　 Boot Option Priority......................112 　 Save Changes and Reset ....................113 　 Discard Changes and Reset .................... 113 　 Restore Defaults ....................... 113 　 Save as User Defaults ...................... 114 　 Restore User Defaults ...................... 114...

  • Page 142: D Terminology

    KINO-DCM236 Industrial Motherboard Appendix Terminology Page 126...
  • Page 143 KINO-DCM236 Industrial Motherboard AC ’97 Audio Codec 97 (AC’97) refers to a codec standard developed by Intel® in 1997. ACPI Advanced Configuration and Power Interface (ACPI) is an OS-directed configuration, power management, and thermal management interface. AHCI Advanced Host Controller Interface (AHCI) is a SATA Host controller register-level interface.
  • Page 144 KINO-DCM236 Industrial Motherboard computer is usually a male DE-9 connector. The Digital-to-Analog Converter (DAC) converts digital signals to analog signals. Double Data Rate refers to a data bus transferring data on both the rising and falling edges of the clock signal.
  • Page 145 KINO-DCM236 Industrial Motherboard PCIe PCI Express (PCIe) is a communications bus that uses dual data lines for full-duplex (two-way) serial (point-to-point) communications between the SBC components and/or expansion cards and the SBC chipsets. Each line has a 2.5 Gbps data transmission rate and a 250 MBps sustained data transfer rate.
  • Page 146 KINO-DCM236 Industrial Motherboard USB 2.0 supports 480Mbps data transfer rates. The Video Graphics Array (VGA) is a graphics display system developed by IBM. Page 130...

  • Page 147: E Digital I/O Interface

    KINO-DCM236 Industrial Motherboard Appendix Digital I/O Interface Page 131...
  • Page 148 KINO-DCM236 Industrial Motherboard The DIO connector on the KINO-DCM236 is interfaced to GPIO ports on the Super I/O chipset. The DIO has both 8-bit digital inputs and 8-bit digital outputs. The digital inputs and digital outputs are generally control signals that control the on/off circuit of external devices or TTL devices.
  • Page 149 KINO-DCM236 Industrial Motherboard AH – 6FH Sub-function: AL – 9 :Set the digital port as OUTPUT :Digital I/O output value Assembly Language Sample 2 AX, 6F09H ;setting the digital port as output BL, 09H ;digital value is 09H Digital Output is 1001b...

  • Page 150: F Watchdog Timer

    KINO-DCM236 Industrial Motherboard Appendix Watchdog Timer Page 134...
  • Page 151 KINO-DCM236 Industrial Motherboard NOTE: The following discussion applies to DOS. Contact IEI support or visit the IEI website for drivers for other operating systems. The Watchdog Timer is a hardware-based timer that attempts to restart the system when it stops working. The system may stop working because of external EMI or software bugs.
  • Page 152 KINO-DCM236 Industrial Motherboard NOTE: The Watchdog Timer is activated through software. The software application that activates the Watchdog Timer must also deactivate it when closed. If the Watchdog Timer is not deactivated, the system will automatically restart after the Timer has finished its countdown.

  • Page 153: G Hazardous Materials Disclosure

    KINO-DCM236 Industrial Motherboard Appendix Hazardous Materials Disclosure Page 137...
  • Page 154 KINO-DCM236 Industrial Motherboard The details provided in this appendix are to ensure that the product is compliant with the Peoples Republic of China (China) RoHS standards. The table below acknowledges the presences of small quantities of certain materials in the product, and is applicable to China RoHS only.
  • Page 155 KINO-DCM236 Industrial Motherboard 此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符 合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的 年限。本产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些元 件将会单独标示出来。 部件名称 有毒有害物质或元素 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (CR(VI)) (PBB) (PBDE) 壳体 显示 印刷电路板 金属螺帽 电缆组装 风扇组装 电力供应组装 电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T11363-2006 (现由 GB/T 26572-2011 取代)标...

Table of Contents
