KINO-DCM236 Industrial Motherboard
Pin
Description
9
HDMI_DATA0#
10
HDMI_CLK+
Table 3-29: HDMI Connector Pinouts
Figure 3-30: HDMI Connector
3.3.4 Power Connector (12 V, Power Adapter)
CN Label:
PWR1
4-pin Mini-DIN
CN Type:
CN Location:
See Figure 3-27
CN Pinouts:
See Figure 3-31
The connector supports a 12V power adapter.
Figure 3-31: 4-pin Power Mini-DIN Connection
Pin
Description
19
HDMI_HPD
Page 49
