IEI Technology KINO-DH110 Quick Installation Manual

Hide thumbs Also See for KINO-DH110:

Advertisement

Quick Links

Download this manual
Mini-ITX SBC supports 14nm 6th/7th Generation LGA1151 Intel®
Core™ i7/i5/i3, Celeron® and Pentium® Processor, DDR4, Dual
Independent Display, Dual GbE LAN, USB 3.0, SATA 6Gb/s,
Quick Installation Guide
Package List
KINO-DH110 package includes the following items:
1 x KINO-DH110 single board computer
1 x I/O shielding
1 x SATA cable
1 x QIG
M.2, HD Audio and RoHS
KINO-DH110
Version 1.0
November 02, 2018.
©2018 Copyright by IEI Integration corp.
All rights reserved.

Advertisement

loading
Need help?

Need help?

Do you have a question about the KINO-DH110 and is the answer not in the manual?

Questions and answers

Related Manuals for IEI Technology KINO-DH110

Summary of Contents for IEI Technology KINO-DH110

  • Page 1 Independent Display, Dual GbE LAN, USB 3.0, SATA 6Gb/s, M.2, HD Audio and RoHS KINO-DH110 Quick Installation Guide Version 1.0 November 02, 2018. Package List KINO-DH110 package includes the following items:  1 x KINO-DH110 single board computer  1 x I/O shielding  1 x SATA cable ...
  • Page 2 Specifications  CPU: LGA1151 socket supports 6th/7th generation Intel® Core™ i7/i5/i3, Celeron® and Pentium® processor  System Chipset: Intel® H110  Memory: Two 260-pin 2133MHz dual-channel DDR4 SDRAM unbuffered SO-DIMM slots support up to 32GB  BIOS: UEFI BIOS  Graphics Engine: ntel®...
  • Page 3  Audio: Realtek ALC662 HD codec 2 x Audio jacks (line-out, mic-in) on rear IO 1 x Front audio (2x5 pin)  Front Panel: 1 x Front panel (1x10 pin, power LED, HDD LED, power button, reset button)  LEN LED: 2 x LAN LED (1x2 pin) ...

  • Page 4: Ordering Information

    All the drivers and One Key Recovery https://download.ieiworld.com utility for the KINO-DH110 are available on IEI Resource Download Center. Type KINO-DH110 and press Enter to find all the relevant software, utilities, and documentation. To install software from the downloaded ISO file, mount the file as a virtual drive to view its content.
  • Page 5  DP-LVDS-R10: DisplayPort to 24 bit dual channel LVDS converter board (for IEI connector)  DP-VGA-R10: DisplayPort to VGA converter board (for IEI connector)

  • Page 6: Jumpers Setting And Connectors

    Jumpers setting and connectors LABEL FUNCTION AT/ATX Power Mode Setting J_ATX_AT1 J_CMOS1 Clear CMOS Button USB SW1, USB SW2 USB Power Setting J_FLASH1 Flash Descriptor Security Override F_PANEL1 PWR & RST Buttons and Indicators Display Port /HDMI COMBO Connector HDMI_DP1 Internal Display Port Connector LAN1_USB1 RJ-45 LAN and USB 3.0 Connector...
  • Page 7 J_ATX_AT1: AT/ATX Power Mode Setting PIN NO. DESCRIPTION Short 1 - 2 ATX Mode (default) Short 2 - 3 AT Mode J_CMOS1: Clear CMOS Button PIN NO. DESCRIPTION Keep CMOS Setup NC (default) (Normal Operation) Press button Clear CMOS Setup USB SW1, USB SW2: USB Power Setting USB SW1 DESCRIPTION...
  • Page 8 F_PANEL1: PWR & RST Buttons and Indicators DESCRIPTION DESCRIPTION PWRLED PWRBTSW# PWRLED +V5S RESET+ RESET HDD_LED- HDMI_DP1: Display Port /HDMI COMBO Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION LANE0P TMDS_DATA2P LANE0N TMDS_DATA2N LANE1P TMDS_DATA1P LANE1N TMDS_DATA1N LANE2P TMDS_DATA0P LANE2N TMDS_DATA0N LANE3P TMDS_CLKP LANE3N...
  • Page 9 DP1: Internal Display Port Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION AUXP LANE1N AUXN LANE1P LANE2P LANE3N LANE2N LANE3P LANE0P AUX_CTRL_DET_D LANE0N +3.3V LAN1_USB1: Ethernet and USB 3.0 connectors USB1: External USB 3.0 connectors PIN NO. DESCRIPTION PIN NO. DESCRIPTION USB_DATA- USB_DATA- USB_DATA+...
  • Page 10 LAN2_USB2: Ethernet and USB 3.0 connectors USB2: External USB 3.0 connectors PIN NO. DESCRIPTION PIN NO. DESCRIPTION USB_DATA- USB_DATA- USB_DATA+ USB_ DATA+ USB3_RX- USB3_RX- USB3_RX+ USB3_ RX+ USB3_TX- USB3_TX- USB3_TX+ USB3_TX+ LAN2: RJ-45 LAN connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION LAN1_MDI0P LAN1_MDI2P...
  • Page 11 COM3, COM4: Internal RS-232 Serial Port Connectors PIN NO. DESCRIPTION PIN NO. DESCRIPTION COM1: External RS-232/422/485 Serial Port Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION DCD1 RXD1 TXD1 DTR1 GND1 DSR1 RTS1 CTS1 RS422 Pin define(device) RS485 Pin define(device) RS232 Pin define(device) TX-(TXD422#) TX-(TXD485#) DCD(1)
  • Page 12 FRONT_PANEL1: Front Panel Audio Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION LMIC2-L AUD_GND LMIC2-R PRESENCE# LLINE2-R MIC2-JD FRONT-IO LLINE2-L LINE2-JD SATA1, SATA2: SATA 6Gb/s Connectors PIN NO. DESCRIPTION PIN NO. DESCRIPTION SATA_RX- SATA_TX+ SATA RX+ SATA_TX- CPU_FAN1: CPU Fan Connector PIN NO.
  • Page 13 M_PCIE1: PCIe Mini Card Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION PCIE_WAKE# VCC3 1.5V PCIE_CLK# PCIE_CLK PCIRST# PCIE_RXN VCC3 PCIE_RXP 1.5V SMBCLK PCIE_TXN SMBDATA PCIE_TXP USBD- USBD+ VCC3 VCC3 1.5V VCC3...
  • Page 14 PWR1: Power Connector (9 V–28 V, Power Adapter) PIN NO. DESCRIPTION PIN NO. DESCRIPTION CN2: Power Supply DC12V Power IN PIN NO. DESCRIPTION PIN NO. DESCRIPTION SMB1: SMBus Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION SMB_DATA SMB_CLK I2C1: I C Connector (to EC) PIN NO.
  • Page 15 M_2_SATA1: M.2 B-Key Slot for SATA Device PIN NO. DESCRIPTION PIN NO. DESCRIPTION CFG3(GND) 3.3V 3.3V CFG1(GND) SATA RXP SATA RXN SATA TXN SATA TXP CLKN CLKP...
  • Page 16 3.3V 3.3V 3.3V CFG2(GND) CN1: EC Debug Port Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION EC_EPP_STB# EC_EPP_BUSY EC_EPP_PD0 EC_EPP_KSI5 EC_EPP_PD1 EC_EPP_KSI4 EC_EPP_PD2 EC_EPP_AFD# EC_EPP_PD3 EC_EPP_PD4 EC_EPP_INIT# EC_EPP_PD5 EC_EPP_SLIN# EC_EPP_PD6 EC_EPP_PD7 SATA_PWR1, SATA_PWR2: SATA Power Connectors PIN NO. DESCRIPTION PIN NO. DESCRIPTION +V12S +V5S...
  • Page 17 Board Layout: Jumper and Connector Locations (Unit: mm)
