Chapter 2: Jumpers and Connectors
USB Connector
Connector type: 1x4 4-pin header, 1.25mm pitch
Connector location: J5
1
4
Pin
Definition
1
5VSB
3
USB2P
MH1
GND
Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved.
Pin
Definition
2
USB2N
4
GND
MH2
GND
USB Connector
Connector type: 1x4 4-pin header, 1.25mm pitch
Connector location: J4
1
4
Pin
Definition
1
5VSB
3
USB3P
MH1
GND
21
Pin
Definition
2
USB3N
4
GND
MH2
GND
