Appendix A: Power Consumption
a
a: P
PPendIx
Power Consumption Management
Purpose
The purpose of the power consumption test is to verify the power dissipation
of the system and the load of the power supply.
Test Data
System
(M)PPC-080T-BT-01
Modes
Sleep Mode
Total Watts
Idle Mode
Total Watts
Full-Loading Mode
Total Watts
Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved.
C
ower
onsumPtIon
Sys#1
Sys#2
(M)PPC-120T-BT-01/02
+24V
+24V
0.09A
0.07A
2.16W
1.68W
0.63A
0.9A
15.12W
21.6W
0.75A
1.05A
18W
25.2W
57
(M)PPC-080T-BT-01 and (M)PPC-120T-BT-01/02 User Manual
