Chapter 1: Product Introduction

Specifications

Panel
(M)PPC-080T-BT-01
▪ LED size: 8", 16:9
▪ Resolution: WVGA 800 x 480
▪ Luminance: 600cd/m
2
▪ Contrast ratio: 600
▪ LCD color: 16.2M
▪ Viewing angle: 60(U), 60(D), 70(L), 70(R)
▪ Backlight: LED

(M)PPC-120T-BT-01/02

▪ LED size: 12", 16:9
▪ Resolution: WXGA 1280 x 800
▪ Luminance: 500cd/m
2
▪ Contrast ratio: 1000
▪ LCD color: 16.2M
▪ Viewing angle: 88(U), 88(D), 88(L), 88(R)
▪ Backlight: LED
Touch Screen
▪ Projected capacitive (flush panel type)
▪ Light transmission: 89%
▪ Interface: USB
▪ With AR coating
System
▪ CPU: onboard Intel Atom
processor E3845, 1.91 GHz, 2M L2 Cache
®
▪ BIOS AMI BIOS
Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved.
▪ System memory
– PPC-080T-BT-01: 1x 204-pin DDR3L SO-DIMM socket, 4GB DDR3L
(default), support up to 4GB DDR3L-1067/1333, non-ECC and un-
buffered
– PPC-120T-BT-01: 1x 204-pin DDR3L SO-DIMM socket, 4GB DDR3L
(default), support up to 4GB DDR3L-1067/1333, non-ECC and un-
buffered
– PPC-120T-BT-02: 1x 204-pin DDR3L SO-DIMM socket, 2GB DDR3L
(default), support up to 4GB DDR3L-1067/1333, non-ECC and un-
buffered
▪ Storage Device:
– PPC-080T-BT-01:
1x SATA connector, support SATA 3Gb/s and SATA 6Gb/s
1x SATA M.2 connector, 128G M.2 SATA (default)
– PPC-120T-BT-01:
1x SATA M.2 connector, 128G M.2 SATA (default)
1x SATA connector, support SATA 3Gb/s and SATA 6Gb/s
1x swappable SSD tray for 2.5" SSD
– PPC-120T-BT-02:
1x SATA M.2 connector, 32G M.2 SATA (default)
1x SATA connector, support SATA 3Gb/s and SATA 6Gb/s
1x swappable SSD tray for 2.5" SSD
▪ Graphics: Intel
® HD Graphics
▪ Watchdog timer: Watchdog timeout can be programmed by software
from 1 second to 255 seconds and from 1 minute to 255 minutes
(tolerance 15% under room temperature 25°C)
▪ H/W status monitor: monitoring system temperature, and voltage
