Specifications

PHYSICAL DIMENSIONS
Size
Length: 7.05 in. (179 mm)
Width: 1.46 in. (37.0 mm)
Height: 2.20 in. (56.0 mm)
Weight: 3.53 oz.(100 g)
Measurement Tip Diameter:
.08 in. (2.0 mm)
45°C
5°C
10%
RANGE OF MEASUREMENTS
200 to 1000 µm, ±5 µm
ELECTRICAL
Measurement tip Ultrasound Frequency: 10.5 MHz Straight Probe
Battery Pack Voltage: 3.7V LI-ION Battery Pack
A/C Adaptor Input Voltage: 100-240 Vac, 50-60 Hz, 0.16 A max
A/C Adaptor Output: 5Vdc, 1.2A max

Disposal

This product does not generate any environmentally hazardous residues. At the end of
its product life, follow your local laws and ordinances regarding the proper disposal of
this equipment.

Software Revision

The software revision can be obtained by contacting Reichert, Inc. The serial number
identifies the manufacture date and will provide access to the software version.
32
90%
106 kPa
50 kPa
ENVIRONMENTAL REQUIREMENTS
Operational Environment
Ambient Temperature range:
50°F to 95°F (10 °C to 35°C)
Relative Humidity range:
20 to 80% RH
Atmospheric Pressure range:
70 to 106 kPa (20.7 to 31.6 in.Hg)
Transport and Storage Environment
Ambient Temperature range:
41°F to 113°F (5 °C to 45°C)
Relative Humidity range:
10 to 90% RH (non-condensing)
Atmospheric Pressure range:
50 to 106 kPa (14.8 to 31.6 in.Hg)
16040-101 Rev. J
