Ametek iPac User Manual page 36

Guidance & Manufacturer's Declaration
Guidance and Manufacturer's Declaration – Electromagnetic Immunity
The iPac is intended for use in the electromagnetic environment specified below. The
customer or user of the iPac should ensure that it is used in such an environment.
Immunity
Test
Conducted RF
IEC 61000-4-6
Radiated RF
IEC 61000-4-3
Note 1: At 80 MHz and 800 MHz, the higher frequency range applies.
Note 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption
and reflection from structures, objects and people.
* Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land
mobile radios, amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicted theoretically
with accuracy. To assess the electromagnetic environment due to fixed RF transmitters, an electromagnetic
site survey should be considered. The measured field strength in the location in which the ME Equipment or
ME System should be observed to verify normal operation. If abnormal performance is observed, additional
measures many be necessary, such as re-orienting or relocating the ME Equipment or ME System.
* Over the frequency range 150 kHz to 80 MHz, field strengths should be less then [V1] V/m.
36
Table 204
– Guidance and Manufacturer's Declaration
Electromagnetic Immunity
Equipment and Systems that are NOT Life-supporting
IEC 60601
Test Level
3 Vrms
150 kHz to 80
MHz
80 MHz to 2.5
GHz @ 3V/m
Compliance
Level
Portable and mobile RF communications
(V1) = 3 Vrms
equipment should be no closer to any
part of the
the recommended separation distance
calculated from the equation applicable to
the frequency of the transmitter.
V/m
(E1) = 3
Recommended Separation Distance:
d=(3.5/V1)(Sqrt P)
d=(3.5/E1)(Sqrt P)
80 to 800 MHz
d=(7/E1)(Sqrt P)
800 MHz to 2.5 GHz
Where P is the max output power rating
of the transmitter in watts (W) according
to the transmitter manufacturer and d is
the recommended separation distance in
meters (m).
Field strengths from fixed transmitters,
as determined by an electromagnetic site
survey, should be less than the compliance
levels in each frequency range.
Interference may occur in the vicinity
of equipment marked with the following
symbol.
Electromagnetic
Environment
- Guidance
,
iPac including cables, than
16040-101 Rev. J
(continued)
