Instrument Operation

Bluetooth Printing

Bluetooth is a wireless communication protocol for exchanging data over short
distances. The iPac uses Bluetooth for printing and communicating with a computer
EMR system. To setup these options please refer to the iPac Menu Options, Bluetooth
section of this User's guide.
There are 3 Bluetooth modes which are visible from the measurement screen of the
iPac.
iPac Bluetooth Printer
To connect to the iPac Bluetooth printer follow the instructions
below:
1. Ensure the iPac Bluetooth option is turned on, see iPac Menu
Options, Bluetooth.
2. Press the ON/OFF button on the iPac printer so that the
printer is ON. A green LED will indicate the printer is working.
3. In the iPac Bluetooth setup mode select the search option,
and press (
blink on and off while the iPac searches for the printer.
4. Once the search is complete the iPac display will usually show
the iPac printer as MARTEL MCP7880. Highlight this option
and press the control button in, the iPac will then connect to the
printer. The display will show "Bluetooth connected."
Note: If the display shows "Bluetooth connection failed" ensure
that the printer is turned on and then repeat the process
described above.
26
Bluetooth OFF The Bluetooth icon is not shown.
Bluetooth ON
Bluetooth
Connected
) the control button, the Bluetooth icon will
-continued-
(continued)
The basic Bluetooth icon is shown.
The Bluetooth icon is blue with a highlight around
the icon and indicates that it is connected to a
device and ready to send data to the device.
16040-101 Rev. J
