Technical data

10.1 Technical data of the DM-F Local and DM-F PROFIsafe fail-safe
digital modules

Technical data of the DM-F Local and DM-F PROFIsafe fail-safe digital modules

Table 10- 1 Technical data of the DM-F Local and DM-F PROFIsafe fail-safe digital modules
Mounting
Enclosure width
System interfaces
Permissible ambient temperature
Degree of protection (according to
IEC 60529)
Shock resistance (sine pulse)
Mounting position
Frequencies
EMC interference immunity in
accordance with
Rated control supply voltage U
according to DIN EN 61131-2
Operating range
SIMOCODE pro - Fail-Safe Digital Modules
Manual, 11/2017, NEB631679702000/RS-AA/002
Snap-mounted onto 35 mm DIN rail or screw-mounted using additional push-in
lugs
45 mm
For connection to
a basic unit
•
another expansion module
•
a current measuring module or current/voltage measuring module
•
the operator-control block
•
In operation
During storage and
transportation
At installation altitude above sea level
≤ 2000 m
≤ 3000 m
≤ 4000 m
IP 20
15 g / 11 ms
Any
50/60 Hz ± 5 %
IEC 60947-5-1, Edition 3.1:2009, SN 27095:2006, IEC 61326-3-1:2008,
IEC 62061:2005
110 V - 240 V AC/DC,
s
50/60 Hz
24 V DC: 0.8 to 1.2xU
•
110 V to 240 V AC/DC: 0.85 to 1.1xU
•
-25 °C ... +60 °C
-40 °C ... +80 °C
Max. +50 °C (no protective separation)
Max. +40 °C (no protective separation)
24 V DC
s
s
10
93
