Technical data
10.1 Technical data of the DM-F Local and DM-F PROFIsafe fail-safe digital modules
Mounting
Power consumption
Protective separation according to
IEC 60947-1
Rated insulation voltage U
Rated impulse withstand voltage U
Power loss ride-through time
Relay outputs
Quantity
•
Function
•
Electrical service life of relay outputs
Relay enabling circuits
Quantity
•
Function
•
Prescribed short-circuit protection
•
for relay enabling circuits/relay
outputs
Rated uninterrupted current of
•
relay enabling circuits
Rated switching capacity of relay
•
enabling circuits
Electrical service life of relay
•
enabling circuits
Switching rate of the relay enabling
•
circuits
94
Snap-mounted onto 35 mm DIN rail or screw-mounted using additional push-in
lugs
DM-F Local:
24 V DC: 3 W
•
110 V to 240 V AC/DC: 9.5 VA/4.5 W
•
DM-F PROFIsafe:
24 V DC: 4 W
•
110 V to 240 V AC/DC: 11.0 VA/5.5 W
•
Between relay enabling circuits/relay outputs and electronics
300 V (at pollution degree 3)
i
4 kV
imp
110 V - 240 V AC/DC,
typ. 20 ms at
0.85 x U
, typ. 200 ms
s
at 230 V
2 monostable relay outputs
Common connection is internally disconnected in a fail-safe manner by a relay
•
enabling circuit
Normally open contact, freely assignable to the control functions
•
0.1 million switching cycles (AC-15, 230 V/3 A)
2 common switching-type, fail-safe relay enabling circuits
Fail-safe normally open contacts
Fuse links operating class gL/gG 4 A (IEC 60947-5-1), separate for each relay
enabling circuit
5 A
AC-15
3 A/24 V AC
DC-13
4 A/24 V DC
0.1 million switching cycles (AC-15, 240 V/2 A)
2000/h
24 V DC, typ. 20 ms at 0.8 x U
3 A/120 V AC
1.5 A/230 V AC
0.55 A/60 V DC
0.22 A/125 V DC
SIMOCODE pro - Fail-Safe Digital Modules
Manual, 11/2017, NEB631679702000/RS-AA/002
s
0.11 A/250 V DC
