Mounting and connection
4.2 Mounting
4.2
Mounting
Note
Taking the ambient conditions into account, you must install the devices in control cabinets
with the IP23, IP43 or IP54 degree of protection.
Note
Please note the information in the operating instructions.
Mounting on a standard rail
The 3UF73 fail-safe digital module is suitable for snap mounting on a standard 35 mm rail to
DIN EN 60715.
Danger! High Voltage
Will result in death or serious injury. Can lead to electric shock and burns.
Disconnect the terminal blocks from the power supply.
Figure 4-1
24
WARNING
Mounting on a standard rail (1)
SIMOCODE pro - Fail-Safe Digital Modules
Manual, 11/2017, NEB631679702000/RS-AA/002
