Technical data

10.2 Technical data of the DM-F Local fail-safe digital module

10.2 Technical data of the DM-F Local fail-safe digital module
Technical data of the DM-F Local fail-safe digital module
Table 10- 2 Technical data of the DM-F Local fail-safe digital modules
LED Status
READY Off
Green
Flashing green
DEVICE Off
Green
Flashing green
Yellow
Flashing yellow
Red
OUT Off
Green
Flashing green
IN Off
Green
Flashing green
SF Off
Red
Flashing red
1 Off
Yellow
Flashing yellow
Flickering yellow
2 Off
Yellow
Flashing yellow
Flickering yellow
3 Off
Yellow
Flashing yellow
Flickering yellow
4 Off
Yellow
Flashing yellow
96
Meaning
System interface not connected/supply voltage too low/device defective
Device ON/system interface OK
Device ON/system interface not active or not OK
Supply voltage too low
Device ON
Self-test
Configuration mode
Configuration error
Device defective or faulty
Safety-related output not active
Safety-related output active
Feedback circuit not closed although start condition satisfied
Input not active
Input active
Fault detected (e.g. cross-circuit at input, sensor simultaneity not satisfied)
No group fault
Group fault (wiring error, cross-circuit, configuration error)
Group fault (feedback circuit fault, simultaneity condition not satisfied)
Cross-circuit detection Off
Cross-circuit detection On
Configuration mode, waiting for confirmation
Configuration error
NC contact/NO contact
NC contact/NC contact
Configuration mode, waiting for confirmation
Configuration error
2 x 1-channel
1 x 2-channel
Configuration mode, waiting for confirmation
Configuration error
Debouncing time Y12, Y22, Y34 ~ 50 ms
Debouncing time Y12, Y22, Y34 ~ 10 ms
Configuration mode, waiting for confirmation
