Mounting
Connection
Tightening torque
•
Connection cross-sections
•
Engineering with
SIMOCODE pro - Fail-Safe Digital Modules
Manual, 11/2017, NEB631679702000/RS-AA/002
10.1 Technical data of the DM-F Local and DM-F PROFIsafe fail-safe digital modules
Snap-mounted onto 35 mm DIN rail or screw-mounted using additional push-in
lugs
Removable terminal block with screw connection
TORQUE 7 lb.in ... 10.3 lb.in
0.8 Nm to 1.2 Nm
Solid:
2 x 0.5 mm to 2.5 mm
2
1 x AWG 20 to 12
Finely stranded with end sleeve:
2 x 0.5 mm to 1.5 mm
2
1 x AWG 20 to 14
STEP 7 TIA Portal V12 SP1 and higher
•
STEP 7 V5.2 and higher (with installed SIMOCODE pro Integration in STEP 7
•
from SIMOCODE ES 2007 + SP2 and higher)
/ 1 x 0.5 mm to 4 mm / 2 x AWG 20 to 14 /
2 2
/ 1 x 0.5 mm to 2.5 mm
2 2
Technical data
/ 2 x AWG 20 to 16 /
