Summary of Contents for EDAN SE-1201

  • Page 2: About This Manual

    This manual will help you understand the operation and maintenance of the product better. It is reminded that the product shall be used strictly complying with this manual. User’s operation failing to comply with this manual may result in malfunction or accident for which EDAN INSTRUMENTS, INC. (hereinafter called EDAN) can not be held liable.
  • Page 3 Terms Used in this Manual This guide is designed to give key concepts on safety precautions. WARNING A WARNING label advises against certain actions or situations that could result in personal injury or death. CAUTION A CAUTION label advises against actions or situations that could damage equipment, produce inaccurate data, or invalidate a procedure.

  • Page 4: Table Of Contents

    Table of Contents Chapter 1 Safety Guidance ......................1 1.1 Intended Use ........................... 1 1.2 Warnings and Cautions ......................1 1.2.1 Safety Warnings ....................... 1 1.2.2 Li-ion Battery Care Warnings ..................4 1.2.3 General Cautions......................5 1.3 List of Symbols........................6 Chapter 2 Introduction........................
  • Page 5 4.2 Configuring the Electrocardiograph ..................33 4.3 Screen Description........................ 34 4.3.1 About the Main Screen....................34 4.3.2 About the System Setup Screen ..................37 4.3.3 About the Order Manager Screen................... 38 4.3.4 About the File Manager Screen..................39 4.4 Work Mode Description......................42 Chapter 5 Entering Patient Information ...................
  • Page 6 8.1 Loading Orders ........................71 8.2 Examining Orders......................... 72 8.3 Deleting Orders........................72 8.4 Searching Orders ........................73 8.5 Setting Orders ........................73 8.5.1 Factory Defaults of Orders..................... 73 8.5.2 Order Setup ........................74 Chapter 9 Managing Files ......................76 9.1 Transmitting Files .........................
  • Page 7 13.1.3 Cleaning the Print Head ..................... 113 13.2 Disinfection ........................113 13.3 Care and Maintenance ...................... 113 13.3.1 Recharge and Replacement of Battery ............... 114 13.3.2 Recorder Paper ......................115 13.3.3 Visual inspection ......................115 13.3.4 Maintenance of the Main Unit and the Patient Cable ..........116 Chapter 14 Accessories ......................

  • Page 8: Chapter 1 Safety Guidance

    1.1 Intended Use The intended use of SE-1201 12-channel electrocardiograph (hereinafter called SE-1201) is to acquire ECG signals from adult and pediatric patients through body surface ECG electrodes. The electrocardiograph is only intended to be used in hospitals or healthcare facilities by doctors and trained healthcare professionals.
  • Page 9 SE-1201 Electrocardiograph User Manual Safety Guidance WARNING 2. Only qualified service engineers can install this equipment, and only service engineers authorized by the manufacturer can open the shell. 3. EXPLOSION HAZARD - Do not use the electrocardiograph in the presence of flammable anesthetic mixtures with oxygen or other flammable agents.
  • Page 10 SE-1201 Electrocardiograph User Manual Safety Guidance WARNING 17. The use of equipment that applies high frequency voltages to the patient (including electrosurgical equipment and some respiration transducers) is not supported and may produce undesired results. Disconnect the patient data cable from the electrocardiograph, or detach the leads from the patient prior to performing any procedure that uses high frequency surgical equipment.

  • Page 11: Li-Ion Battery Care Warnings

    SE-1201 Electrocardiograph User Manual Safety Guidance WARNING Therefore anybody, who connects additional equipment to the signal input or output connector to configure a medical system, must make sure that it complies with the requirements of the valid version of the system standard IEC/EN 60601-1-1. If in doubt, consult our technical service department or your local distributor.

  • Page 12: General Cautions

    SE-1201 Electrocardiograph User Manual Safety Guidance WARNING 4. Do not heat or splash the battery or throw it into fire or water. 5. Do not destroy the battery; Do not pierce battery with a sharp object such as a needle;...

  • Page 13: List Of Symbols

    SE-1201 Electrocardiograph User Manual Safety Guidance CAUTION 5. The device and accessories are to be disposed of according to local regulations after their useful lives. Alternatively, they can be returned to the dealer or the manufacturer for recycling or proper disposal. Batteries are hazardous waste. Do NOT dispose of them together with house-hold garbage.
  • Page 14 SE-1201 Electrocardiograph User Manual Safety Guidance Mains supply Battery indicator Battery recharging indicator Enter key Delete key Esc key RESET key Shift key Fn key Power On/Off key 1mV/COPY key MODE key PRINT/STOP key Tab key FEED Paper key Lead switch key/LEFT/RIGHT Arrow key...
  • Page 15 SE-1201 Electrocardiograph User Manual Safety Guidance UP/DOWN Arrow key REVIEW key Gender key Age Group key Recycle Part Number Serial Number Date of Manufacture Manufacturer Authorized Representative in the European Community The symbol indicates that the device complies with the European Council Directive 93/42/EEC concerning medical devices.

  • Page 16: Chapter 2 Introduction

    Introduction Chapter 2 Introduction SE-1201 gathers ECG signals of 12 leads simultaneously. It displays the operation menu, ECG parameters as well as electrocardiograms. The 12-channel ECG waves can be viewed on the LCD screen and printed out by using a high-quality thermal recorder.

  • Page 17: Keyboard And Keys

    SE-1201 Electrocardiograph User Manual Introduction Symbol Name Explanation Mains supply When the device is powered by the mains supply, indicator this indicator is lit. When the device is powered by the battery, this Battery indicator indicator is lit. When the device is powered on, the indicator flashes for a few seconds.
  • Page 18 SE-1201 Electrocardiograph User Manual Introduction Name Explanation Function Key Press to select menu functions on the screen. Press to select the gender for the patient when Gender is Gender Key selected in the Patient Information Setup window. Press to select the age group on the main screen when you set Age Group Key Age to Age Group in the Patient Information Setup window.

  • Page 19: Rear Panel

    Press Fn and a letter key to type special characters. Pressing Fn + a can type è. Press to cancel operation or return to the previous screen. Power On/Off Power-on/Power-off 2.3 Rear Panel Figure 2-3 SE-1201 Rear Panel - 12 -...

  • Page 20: Right Panel

    Part for people to hold Heat Emission Hole Path for internal heat emission Fuse The specification is: T3.15AH 250V Ø5×20 2.4 Right Panel Figure 2-4 SE-1201 Right Panel Name Explanation Patient Cable Socket Connecting to the patient cable SD Card Socket...
  • Page 21 SE-1201 Electrocardiograph User Manual Introduction 1) Patient Cable Socket : Applied part of type CF with defibrillator proof : Caution Definitions of corresponding pins: Signal Signal Signal C2 (input)/ F (input)/ V2 (input) LL (input) C3 (input)/ C1 (input) / V1 (input)
  • Page 22 SE-1201 Electrocardiograph User Manual Introduction Definitions of corresponding pins: Signal Signal Signal CD DAT3 DAT2 DAT0 DAT1 3) USB Socket 1/USB Socket 2/USB Socket 3 CAUTION Only the USB equipment recommended by the manufacturer can be connected to the USB socket 1/2.

  • Page 23: Bottom Panel

    4) External Input/Output Socket Definitions of corresponding pins: Signal Signal ECG Signal (input) ECG Signal (output) 2.5 Bottom Panel Figure 2-5 SE-1201 Bottom Panel Name Explanation Speaker Hole Path for sound from speaker Battery Compartment Compartment for the battery Heat Emission Hole...

  • Page 24: Function Features

    SE-1201 Electrocardiograph User Manual Introduction 1) Battery Compartment Rated Voltage: 14.8V Rated Capacity: 2200mAh WARNING 1. Improper operation may cause the battery to be hot, ignited or exploded, and it may lead to the decrease of the battery capacity. Therefore, it is necessary to read the user manual carefully and pay more attention to warning messages.
  • Page 25 SE-1201 Electrocardiograph User Manual Introduction ♦ High resolution thermal recorder, recording frequency response ≤150Hz ♦ Supporting external USB printer ♦ Supporting accurate digital filter to decrease the polarization voltage and other interferences ♦ Supporting folded paper recorded with high resolution waveforms, calibration mark, gain, speed and filter ♦...

  • Page 26: Chapter 3 Operation Preparations

    SE-1201 Electrocardiograph User Manual Operation Preparations Chapter 3 Operation Preparations WARNING Before use, the equipment, patient cable and electrodes should be checked. Replace them if there is any evident defectiveness or aging which may impair the safety or the performance, and make sure that the equipment is in proper working condition.

  • Page 27: Connecting The Patient Cable To Electrodes

    SE-1201 Electrocardiograph User Manual Operation Preparations 3.1.2 Connecting the Patient Cable to Electrodes Align all lead wires of the patient cable to avoid twisting, and connect the lead wires to the reusable electrodes or the alligator clips. Firmly attach them.

  • Page 28: Preparing The Skin

    SE-1201 Electrocardiograph User Manual Operation Preparations 3.2.2 Preparing the Skin Thorough skin preparation is very important. The skin is a poor conductor of electricity and frequently creates artifacts that distort the ECG signals. By performing methodical skin preparation, you can greatly reduce the possibility of noise caused by muscle tremor and baseline drift, ensuring high-quality ECG waves.
  • Page 29 SE-1201 Electrocardiograph User Manual Operation Preparations Standard 12-Lead Placement Only for the Disposable Electrodes Only for the Reusable Electrodes European American Electrode Placement Label Label Fourth intercostal space at the right border of the sternum Fourth intercostal space at the left border of the sternum...

  • Page 30: Attaching The Reusable Electrodes

    SE-1201 Electrocardiograph User Manual Operation Preparations NEHB Placement European American Electrode Placement Label Label Attachment point of the second rib to the right sternal edge Fifth intercostal space on the left posterior axillary line Left mid-clavicular line in the fifth intercostal space...

  • Page 31: Attaching The Chest Electrodes

    SE-1201 Electrocardiograph User Manual Operation Preparations Limb Electrode Connection: 1) Ensure that the electrodes are clean; 2) Clean the electrode area which is a short distance above the ankle or the wrist with 75% alcohol; 3) Daub the electrode area on the limb with gel evenly;...

  • Page 32: Attaching The Disposable Electrodes

    SE-1201 Electrocardiograph User Manual Operation Preparations 3.3.3 Attaching the Disposable Electrodes CAUTION The disposable electrodes can only be used for one time. Disposable Electrode: Alligator Clip: Disposable electrodes must be used together with alligator clips. Disposable Electrode Connection 1) Align all lead wires of the patient cable to avoid twisting, and connect the alligator clips to the lead wires.

  • Page 33: Turning On/Off The Electrocardiograph

    SE-1201 Electrocardiograph User Manual Operation Preparations 1) Environment: ♦ Make sure that there is no electromagnetic interference source around the equipment, especially large medical electrical equipment such as electrosurgical equipment, radiological equipment, magnetic resonance imaging equipment etc. Turn off these devices when necessary.
  • Page 34 SE-1201 Electrocardiograph User Manual Operation Preparations The electrocardiograph can be powered by either the mains supply or the battery. To turn on the Electrocardiograph: ♦ When operating on AC power Make sure that the mains supply meets the requirements (refer to A1.4 Power Supply...

  • Page 35: Loading/Replacing Recorder Paper

    SE-1201 Electrocardiograph User Manual Operation Preparations To turn off the Electrocardiograph: ♦ When operating on AC power Hold down the key to display the hint System is shutting down… on the screen. Then the device will be off a few seconds later. Remove the plug from the outlet.
  • Page 36 SE-1201 Electrocardiograph User Manual Operation Preparations Loading/Replacing Paper: 1) Press the casing button downwards to open the recorder. 2) Remove the remainder paper from the paper tray if necessary. 3) Take off the wrapper of the new folded paper, and then put it in the paper tray.
  • Page 37 SE-1201 Electrocardiograph User Manual Operation Preparations 6) Advance the recorder paper. If Paper Marker is set to Yes, you can press FEED to advance the recorder paper to the next black marker; if Paper Marker is set to No, you can press FEED to advance the paper for 2.5cm.

  • Page 38: Chapter 4 Basic Operation Guidance

    SE-1201 Electrocardiograph User Manual Basic Operation Guidance Chapter 4 Basic Operation Guidance The following sections provide an overview of the main operations and functions. You can operate the electrocardiograph by using the touch screen (optional). CAUTION Do not touch the LCD screen with sharp things such as pencils or pens; otherwise, it will be damaged.

  • Page 39: Entering Data

    SE-1201 Electrocardiograph User Manual Basic Operation Guidance 4.1.2 Entering Data Take the Patient Information window for example: 1. Press F1 below Patient on the main screen1 to open the Patient Information window. 2. Press Tab or Shift + Tab to move the cursor to the Name textbox.

  • Page 40: Selecting An Item

    SE-1201 Electrocardiograph User Manual Basic Operation Guidance 4.1.3 Selecting an Item Take the Work Mode Setup window for example: Check Box Textbox Dropdown List Box 1. In the Work Mode Setup window, press Tab or Shift + Tab to move the cursor among different check boxes.

  • Page 41: Screen Description

    SE-1201 Electrocardiograph User Manual Basic Operation Guidance 4.3 Screen Description 4.3.1 About the Main Screen After the electrocardiograph is turned on, the main screen appears. Figure 4-1 SE-1201 Main Screen1 Figure 4-2 SE-1201 Main Screen2 - 34 -...
  • Page 42 SE-1201 Electrocardiograph User Manual Basic Operation Guidance Name Explanation Patient Name: within 60 ASCII characters or the equivalent Name number of other characters that can be supported by equivalent memory used by 60 ASCII characters When ID Mode is set to Manual, the patient ID is within 30 ASCII characters.
  • Page 43 SE-1201 Electrocardiograph User Manual Basic Operation Guidance Gain: 2.5 mm/mV, 5 mm/mV, 10 mm/mV, 20 mm/mV, 10/5 mm/mV or AGC Gain NOTE: This setup modified on the main screen is only effective for the current patient. In the manual mode, you can set Speed to 5mm/s, 6.25mm/s, 10mm/s, 12.5mm/s, 25mm/s or 50mm/s.

  • Page 44: About The System Setup Screen

    SE-1201 Electrocardiograph User Manual Basic Operation Guidance 4.3.2 About the System Setup Screen Select Setup on the main screen2 to display the System Setup screen. NOTE: If you set the system password in the System Maintenance window, you need enter the password before opening the System Setup screen. For details, refer to Section 10.11, “System Maintenance Setup”.

  • Page 45: About The Order Manager Screen

    SE-1201 Electrocardiograph User Manual Basic Operation Guidance 4.3.3 About the Order Manager Screen Select Order on the main screen2 to open the Order Manager screen. You can press Load to load orders and select a loaded order to start an order examination.

  • Page 46: About The File Manager Screen

    SE-1201 Electrocardiograph User Manual Basic Operation Guidance 200 is the total number of orders that can be stored in the electrocardiograph. 2 is the current number of orders stored in the electrocardiograph. Orders will be loaded and displayed in the order list.
  • Page 47 SE-1201 Electrocardiograph User Manual Basic Operation Guidance Figure 4-4 File Manager Screen1 Figure 4-5 File Manager Screen2 - 40 -...
  • Page 48 SE-1201 Electrocardiograph User Manual Basic Operation Guidance Name Explanation Trans All Press to transmit all the files to the PC. Press to export all the files from the electrocardiograph to the U Export All disk or SD card. Del All Press to delete all the files from the electrocardiograph.

  • Page 49: Work Mode Description

    SE-1201 Electrocardiograph User Manual Basic Operation Guidance 4.4 Work Mode Description There are five work modes in SE-1201. In the auto mode, the ECG data can analyzed, saved, printed and transmitted. The AUTO: lead groups are switched automatically according to the lead sequence during the printing course.

  • Page 50: Chapter 5 Entering Patient Information

    SE-1201 Electrocardiograph User Manual Entering Patient Information Chapter 5 Entering Patient Information 5.1 Entering Patient Information Manually Operation procedures are as follows: 1. Configure the Patient Information Setup window. (Optional) 1) Select the desired items. Select the desired items in the Patient Information Setup window, and then press Enter to confirm.

  • Page 51: Entering Patient Information By Using A Bar Code Reader (Optional)

    SE-1201 Electrocardiograph User Manual Entering Patient Information First Name Within 30 ASCII characters Last Name Within 30 ASCII characters Age Unit: Years, Months, Weeks or Days Gender Patient Gender (Male/Female/Empty) If you select Pacemaker in the Patient Information Setup window, Pacemaker appears in the Patient Information window.

  • Page 52: Entering Patient Information By Acquiring Orders

    SE-1201 Electrocardiograph User Manual Entering Patient Information 3. When the main screen is displayed, scan the patient’s bar code with the bar code reader, and then the patient information will appear in the corresponding box. NOTE: Only bar code readers, complying with the standards Bar Code 128 and Bar Code 93 and recommended by the manufacturer, can be used.
  • Page 53 SE-1201 Electrocardiograph User Manual Entering Patient Information 6. Enter the patient ID manually in the ID textbox and press Order, then the matched order will be loaded from Smart ECG Viewer software and the order information will be displayed in the corresponding textboxes.

  • Page 54: Chapter 6 Printing Ecg Reports

    SE-1201 Electrocardiograph User Manual Printing ECG Reports Chapter 6 Printing ECG Reports NOTE: 1. The working mode can not be changed during the printing course. Stop printing reports before changing the working mode. 2. Within three seconds after returning to the main screen, if you press the PRINT/STOP key to print an ECG report in the auto quick mode or the manual mode, the recorder will not respond.

  • Page 55: Manual Mode

    SE-1201 Electrocardiograph User Manual Printing ECG Reports 2. When the main screen is displayed, press the MODE key to select the auto mode. Press F3 to select a paper speed. Press F4 to switch the gain. Press F5 to set the EMG filter or the Lowpass filter.

  • Page 56: Rhythm Mode

    SE-1201 Electrocardiograph User Manual Printing ECG Reports 2. When the main screen is displayed, press the MODE key to select the manual mode. Press F3 to select a paper speed. Press F4 to switch the gain. Press F5 to set the EMG filter or the Lowpass filter.

  • Page 57: R-R Analysis Mode

    SE-1201 Electrocardiograph User Manual Printing ECG Reports 2. When the main screen is displayed, press the MODE key to select the rhythm mode. Press F3 to select a paper speed. Press F4 to switch the gain. Press F5 to set the EMG filter or the Lowpass filter.

  • Page 58: Review Printing

    SE-1201 Electrocardiograph User Manual Printing ECG Reports 2. When the main screen is displayed, press the MODE key to select the R-R analysis mode. Press F4 to switch the gain. Press F5 to set the EMG filter or the Lowpass filter.

  • Page 59: Freezing Ecg Waves

    SE-1201 Electrocardiograph User Manual Printing ECG Reports 6.3 Freezing ECG Waves You can freeze the ECG waves displayed on the main screen. Operation Method: 1) Press F3 to set the paper speed, press F4 to set the gain, and press F5 to set the filter on the main screen1.

  • Page 60: Printing A Stored Ecg Report

    SE-1201 Electrocardiograph User Manual Printing ECG Reports 6.4 Printing a Stored ECG Report 6.4.1 Printing on the File Manager Screen1/2 On the File Manager screen 1: 1. Select File on the main screen to open the File Manager screen1. 2. Select a file on the File Manager screen1, and then press PRINT/STOP to print the file.

  • Page 61: Sample Ecg Reports

    SE-1201 Electrocardiograph User Manual Printing ECG Reports 6.5 Sample ECG Reports 6.5.1 ECG Reports in the Auto Mode Quick Mode - 54 -...
  • Page 62 SE-1201 Electrocardiograph User Manual Printing ECG Reports The above figure (a) and (b) show an ECG report in the auto mode. Template is selected, and Record Style is set to 6×2+1r. The ECG report includes: Patient Information, Measure Information, Diagnosis Information, Report Confirmed by, Current Date and Current Time, 6×2+1r ECG waves, 0.67~100Hz (0.67Hz DFT Filter, 100Hz Lowpass Filter),...
  • Page 63 2*5s+1r (12 leads are printed in 2 groups of 6 with the ECG wave of one lead on the bottom, and every group is printed for about 5s), V1.0 (Software Version), SEMIP V1.6 (Algorithm Version), SE-1201 (Electrocardiograph Model), Institution Name. Measure Information includes: Heart Rate...
  • Page 64 SE-1201 Electrocardiograph User Manual Printing ECG Reports Save Paper Mode The above figure shows an ECG report in the auto mode. The style is 6×2+1R. - 57 -...

  • Page 65: Ecg Reports In The Rhythm Mode

    SE-1201 Electrocardiograph User Manual Printing ECG Reports 6.5.2 ECG Reports in the Rhythm Mode The above figure shows an ECG report in the rhythm mode, and Rhythm Style is set to Three Leads. - 58 -...

  • Page 66: Ecg Reports In The Manual Mode

    SE-1201 Electrocardiograph User Manual Printing ECG Reports 6.5.3 ECG Reports in the Manual Mode The above figure shows an ECG report in the manual mode, and Manual Style is set to 12 channels. - 59 -...

  • Page 67: Ecg Reports In The R-R Analysis Mode

    SE-1201 Electrocardiograph User Manual Printing ECG Reports 6.5.4 ECG Reports in the R-R Analysis Mode - 60 -...
  • Page 68 SE-1201 Electrocardiograph User Manual Printing ECG Reports - 61 -...
  • Page 69 SE-1201 Electrocardiograph User Manual Printing ECG Reports The above figure (a) and (b) show an ECG report in the R-R analysis mode. Figure (a) shows: Current Date & Current Time Patient Information (Name, ID, Gender, Age, Height, Weight) Measuring Time...

  • Page 70: Ecg Reports Printed By The Usb Printer

    SE-1201 Electrocardiograph User Manual Printing ECG Reports 6.5.5 ECG Reports Printed by the USB Printer - 63 -...

  • Page 71: Ecg Report Of Patient With Pacemaker

    SE-1201 Electrocardiograph User Manual Printing ECG Reports 6.5.6 ECG Report of Patient with Pacemaker The above figure shows the ECG report of a patient with a pacemaker. - 64 -...

  • Page 72: Ecg Report Of Nehb Lead

    SE-1201 Electrocardiograph User Manual Printing ECG Reports 6.5.7 ECG Report of Nehb Lead The above figure shows the ECG report of Nehb lead. - 65 -...

  • Page 73: Chapter 7 Transmitting Ecg Data

    SE-1201 Electrocardiograph User Manual Transmitting ECG Data Chapter 7 Transmitting ECG Data 7.1 Transmitting ECG Data to the PC ECG data in DAT\PDF\SCP\FDA-XML format can be transmitted to the PC. To transmit ECG data in DAT format, the Smart ECG Viewer software of the manufacturer must be installed in the PC.
  • Page 74 SE-1201 Electrocardiograph User Manual Transmitting ECG Data c) The last section of the Local IP item can be set at random. For the same network transmission, a) Set the first three sections of the Local IP item to the first three sections of the IP of the PC.

  • Page 75: Transmitting Ecg Data In Scp/Fda-Xml/Pdf Format Through Ethernet Cable

    SE-1201 Electrocardiograph User Manual Transmitting ECG Data 7.1.2 Transmitting ECG Data in SCP/FDA-XML/PDF Format Ethernet through Cable NOTE: SCP/FDA-XML function can be activated on the Advanced Setup screen. For details, please contact the manufacturer or the local distributor. 1. Log into the FTP receiving software.

  • Page 76: Real-Time Transmission To Pc Ecg

    SE-1201 Electrocardiograph User Manual Transmitting ECG Data 4. In the auto or rhythm mode, ECG data will be transmitted through the net cable automatically after an ECG report is printed out. In the off mode, 10s ECG data sampled after pressing the PRINT/STOP key will be transmitted through the net cable automatically.
  • Page 77 SE-1201 Electrocardiograph User Manual Transmitting ECG Data 1) Double-click on the shortcut icon on the desktop to start up the PC ECG software. 2) Click on the System Setting button to open the System Setting screen, and then click on the Device tab.

  • Page 78: Chapter 8 Managing Orders

    SE-1201 Electrocardiograph User Manual Managing Orders Chapter 8 Managing Orders NOTE: To use the order function, the Smart ECG Viewer software of the manufacturer must be installed in the PC. Select Order on the main screen2 to open the Order Manager screen.

  • Page 79: Examining Orders

    SE-1201 Electrocardiograph User Manual Managing Orders NOTE: If orders are modified on the Smart ECG Viewer software, the corresponding orders existing on the Order Manager screen will be refreshed after you load orders from the software. 5. If you select Exam.Room Filter on the Order Setup screen, orders will be filtered after you press Load.

  • Page 80: Searching Orders

    SE-1201 Electrocardiograph User Manual Managing Orders 8.4 Searching Orders Select Search on the Order Manager screen to display the following window. Select the search type, such as ID, Name, Request No., Exam. Room, Time, enter the search information, and then press Enter to confirm. All the orders which meet the requirements will be searched and displayed on the Order Manager screen.

  • Page 81: Order Setup

    SE-1201 Electrocardiograph User Manual Managing Orders 8.5.2 Order Setup Select Setup on the Order Manager screen to make settings of orders. Item Description Condition Choose from: Default, ID, Order Date, Request No. or State Select Default, orders will be displayed in sequence of the time when the orders are loaded from the Smart ECG Viewer software.
  • Page 82 SE-1201 Electrocardiograph User Manual Managing Orders Exam.Room Filter Choose from: Select or Deselect Select this item, a check mark √ appears in the box before Exam.Room Filter. You can enter an exact exam.room in the textbox, such as Electrocardiograph. If the room you entered exists in the Smart ECG Viewer software, all the related information will be searched and displayed on the Order Manager screen.

  • Page 83: Chapter 9 Managing Files

    SE-1201 Electrocardiograph User Manual Managing Files Chapter 9 Managing Files If you want to save the ECG data in the electrocardiograph, you should set Auto Save to to ECG in the File Setup window. Then the ECG data in the auto, off or rhythm mode will be saved on the File Manager screen automatically.

  • Page 84: Transmitting Files

    On the File Manager screen, files can be printed, transmitted, exported, displayed, edited searched or deleted. SE-1201 can accommodate 200 files. If there is no file on the File Manager screen, the following dialog box will pop up when you press function keys.

  • Page 85: Deleting Files

    SE-1201 Electrocardiograph User Manual Managing Files CAUTION It is forbidden to connect or disconnect a U disk, an SD card or a USB printer during the transmission course. NOTE: 1. Please insert the U disk or SD card recommended by the manufacturer. Please set the format to FAT or FAT32 when formatting the U disk or SD card.

  • Page 86: Importing Files

    SE-1201 Electrocardiograph User Manual Managing Files 9.5 Importing Files Operation procedures are as follows: 1. Connect the U disk or SD card recommended by the manufacturer to the electrocardiograph. 2. Save files to the directory of ECGDAT\Import of the U disk or SD card.

  • Page 87: Previewing A File

    SE-1201 Electrocardiograph User Manual Managing Files 9.8 Previewing a File 1. Select Preview on the File Manager screen2 to open the file preview screen. 2. Select Waveform to display the waveform screen. You can press the Left or Right arrow to switch between the lead groups when previewing a file on the waveform screen.
  • Page 88 SE-1201 Electrocardiograph User Manual Managing Files 4. Select Measure to display the measure screen which shows the measurement information. 5. Press PRINT/STOP or select Record on the preview screen to print the selected file.Or, press PRINT/STOP again to stop printing the file.

  • Page 89: Chapter 10 System Setup

    SE-1201 Electrocardiograph User Manual System Setup Chapter 10 System Setup Select Setup on the main screen 2 to display the System Setup screen. Figure 10-1 System Setup Screen 10.1 Factory Defaults Table 10-1 Factory Defaults Work Mode Setup Items Default...
  • Page 90 SE-1201 Electrocardiograph User Manual System Setup Filter Setup Items Default AC filter EMG filter DFT filter 0.67Hz Lowpass filter 100Hz Record Info Setup-Setup1 Items Default Record Style 6×2 Record Mode Save Paper Record Sequence Sequential Gain 10mm/mV Record Device Thermal...
  • Page 91 SE-1201 Electrocardiograph User Manual System Setup ID Mode Auto ID Hint Age Mode H/W Unit cm/kg BP Unit mmHg Prompt Confirmed By Patient Information Refreshed Order Acquired User-defined Cleared Transmission Setup Items Default Auto Transmission FTP User Name/FTP Password/ Cleared...
  • Page 92 SE-1201 Electrocardiograph User Manual System Setup Key Volume Medium Notify Volume Medium Date & Time Setup Items Default Date Mode DD-MM-YYYY Time Mode 24 Hours Power Off/ LCD Off Cleared File Setup Items Default Auto Save To ECG File Format Delete After Trans.

  • Page 93: Work Mode Setup

    SE-1201 Electrocardiograph User Manual System Setup 10.2 Work Mode Setup Select Work Mode on the System Setup screen, and then press Enter to open the Work Mode Setup window. Figure 10-2 Work Mode Setup Window Item Description Mode Options Choose from: AUTO, MANU, RHYT, R-R, or OFF...
  • Page 94 SE-1201 Electrocardiograph User Manual System Setup Item Description Auto DispStyle Choose from: 3×4, 3×4+1R, 3×4+3R, 6×2, 6×2+1R or 12×1 Select 3×4 to display ECG waves of 12 leads in 4 groups of 3. Select 3×4+1R to display ECG waves of 12 leads in 4 groups of 3 with the ECG wave of one rhythm lead on the bottom.

  • Page 95: Filter Setup

    SE-1201 Electrocardiograph User Manual System Setup 10.3 Filter Setup Select Filter on the System Setup screen, and then press Enter to open the Filter Setup window. Figure 10-3 Filter Setup Window Item Description AC Filter Choose from: On or Off...

  • Page 96: Record Info Setup

    SE-1201 Electrocardiograph User Manual System Setup 10.4 Record Info Setup Select Record Info on the System Setup screen, and then press Enter to open the Record Info Setup window. 10.4.1 Setup 1 Press F1 to switch to the Setup 1 window.
  • Page 97 SE-1201 Electrocardiograph User Manual System Setup Item Description Record Mode Choose from: Save Paper or Quickly Select Save Paper, 10s after pressing the PRINT/STOP key on the main screen, an ECG report is printed. The patient information, measure information, interpretation and ECG waves are printed at the same time.
  • Page 98 SE-1201 Electrocardiograph User Manual System Setup Item Description Record Device Options Corresponding USB Printers HP Deskjet 2010 HP Deskjet 1050 2010/1050/2000 HP Deskjet 2000 HP Deskjet 2050 HP Laserjet P2015 HP2035 HP Laserjet P2035 NOTE: 1. During the USB printing course，pressing the PRINT/STOP key again can not stop printing ECG reports.
  • Page 99 SE-1201 Electrocardiograph User Manual System Setup Item Description Paper Marker Select No, the device can not identify the start point of each page of the recorder paper while printing ECG reports. Sample Time If Record Style is set to 12×1, you can set the time period.
  • Page 100 SE-1201 Electrocardiograph User Manual System Setup 210×295mm 215×280mm - 93 -...

  • Page 101: Setup 2

    SE-1201 Electrocardiograph User Manual System Setup 10.4.2 Setup 2 Press F2 to switch to the Setup 2 window. Figure 10-5 Record Info Setup2 Item Description Auto Record Info Select Position Marker, Analysis, Template, Measure or Minnesota Code, the item will be printed in the ECG reports.

  • Page 102: Patient Information Setup

    SE-1201 Electrocardiograph User Manual System Setup 10.5 Patient Information Setup Select Patient Info on the System Setup screen, and then press Enter to open the Patient Information Setup window. Figure 10-6 Patient Information Setup Window Item Description Patient Options Select First/Last Name, Gender, Height, Weight, BP, Race,...
  • Page 103 SE-1201 Electrocardiograph User Manual System Setup Item Description ID Hint Choose from: On or Off In the auto, rhythm or off mode, when ID is set to Manual and ID Hint is set to On, if you do not input the patient ID before pressing the PRINT/STOP key, a hint will pop up to remind you to input the patient Choose from: Age, D.O.B or Age Group...

  • Page 104: Transmission Setup

    SE-1201 Electrocardiograph User Manual System Setup 10.6 Transmission Setup NOTE: 1. To transmit ECG data in DAT format to the PC, the Smart ECG Viewer software of the manufacturer must be installed in the PC. You should log into the Smart ECG Viewer software before transmission.

  • Page 105: Lead Setup

    SE-1201 Electrocardiograph User Manual System Setup Item Description FTP Information Enter data in the FTP Path, FTP User Name textboxes. IP Addresses Set Server IP, Local IP, Set Gateway, Set Subnet Mask For details, please refer to Section 7.1.1 “Transmitting ECG Data in DAT Format through Ethernet Cable”.

  • Page 106: Display&Sound Setup

    SE-1201 Electrocardiograph User Manual System Setup Item Description Rhythm Lead1/2/3 In the R-R analysis mode: The R-R analysis report of the rhythm lead selected in the Rhythm Lead1 list box will be printed. Lead Sequence Choose from: Standard or Cabrera...
  • Page 107 SE-1201 Electrocardiograph User Manual System Setup Item Description Brightness Set the brightness within 0~20. Key Volume Choose from: Low, Medium, High or Off Select Low, Medium or High, the electrocardiograph gives a short sound when you press keys on the keyboard.

  • Page 108: Date&Time Setup

    SE-1201 Electrocardiograph User Manual System Setup 10.9 Date&Time Setup Select Date&Time on the System Setup screen, and press Enter to open the Date&Time Setup window. Figure 10-10 Date &Time Setup Window NOTE: Please set DATE&TIME correctly when it’s the first time you use the electrocardiograph.

  • Page 109: File Setup

    SE-1201 Electrocardiograph User Manual System Setup 10.10 File Setup Select File on the System Setup screen, and press Enter to open the File Setup window. Figure 10-11 File Setup Window Item Description Auto Save Choose from: Off, To ECG or To External Memory Select Off, ECG data will not be saved.
  • Page 110 SE-1201 Electrocardiograph User Manual System Setup Item Description Delete After Trans. Choose from: On or Off Or Export Select On, the files will be automatically deleted from the File Manager screen after they are transmitted to the PC or exported to the U disk or SD card.

  • Page 111: System Maintenance Setup

    SE-1201 Electrocardiograph User Manual System Setup 10.11 System Maintenance Setup Select Maintenance on the System Setup screen, and press Enter to open the System Maintenance window. Figure 10-12 System Maintenance Window Item Description Export Settings Press to export the system settings to the U disk or SD card...

  • Page 112: Other Setup

    SE-1201 Electrocardiograph User Manual System Setup 10.12 Other Setup Select Other on the System Setup screen, press Enter to open the Other Setup window. Figure 10-13 Other Setup Window Item Description Institution Input the institution name manually within 40 ASCII characters.
  • Page 113 SE-1201 Electrocardiograph User Manual System Setup Item Description External Output The external output socket is equipped in the electrocardiograph, through which the electrocardiograph can send signals to the external equipment. Choose from: Off, Standard or Triggered If External Input is set to On, and External Output is set to Standard or Triggered, the electrocardiograph sends the signals which it receives.

  • Page 114: Chapter 11 Hint Information

    ECG data fails to be transmitted from the electrocardiograph to the Transmit Fail PC through the net in the auto, rhythm or off mode. The amount of files on the File Manager screen of SE-1201 Memory Full reaches 200. Module Error There is something wrong with the signal sample module.

  • Page 115: Chapter 12 Troubleshooting

    In the same way, if the transmission settings are configured, the ECG data could be transmitted to the PC without printing. Q4: The screen of SE-1201 is too shiny. Could it be possible to weaken the brightness of the screen? A4: There is a setup item named brightness in the Display &...
  • Page 116 SE-1201 Electrocardiograph User Manual Troubleshooting Q6: The hint “Memory full! Replace the earliest file?” pops up every time when I operate the electrocardiograph. What am I supposed to do? A6: The hint is used to remind you that the amount of stored file reaches 200. You can just make a choice every time when the hint pops up.
  • Page 117 SE-1201 Electrocardiograph User Manual Troubleshooting Reload the paper in the paper tray, close the recorder casing firmly. If the problem still exists, please contact the manufacturer or the local distributor for further disposal. Q4: I want to print the hospital name in the report, but I can’t find the place to enter it, where is A4: Please open the Other Setup window, and move the cursor to the Institution textbox, and then input the hospital name.
  • Page 118 SE-1201 Electrocardiograph User Manual Troubleshooting 3. Transmitting Problems Q1: The ECG doesn’t respond to any keys after a long time of transmission. It transmits nothing for there is no new data appearing on the screen of the PC software. What should I do? A1: Some error may occur during the transmission course, for example, the connection between the ECG and the net cable may loosen.

  • Page 119: Chapter 13 Cleaning, Care And Maintenance

    SE-1201 Electrocardiograph User Manual Cleaning, Care and Maintenance Chapter 13 Cleaning, Care and Maintenance CAUTION 1. Turn off the power before cleaning and disinfection. The mains supply must be switched off if it is used. 2. Prevent the detergent from seeping into the equipment.

  • Page 120: Cleaning The Print Head

    SE-1201 Electrocardiograph User Manual Cleaning, Care and Maintenance CAUTION Do not clean the unit and accessories with abrasive fabric and avoid scratching the electrodes. 13.1.3 Cleaning the Print Head 1. Open the recorder casing and remove the paper. 2. Wipe the print head gently with a clean soft cloth damped in 75 alcohol.

  • Page 121: Recharge And Replacement Of Battery

    : 1/4 capacity; : Low capacity 2) Recharge SE-1201 electrocardiograph is equipped with the recharge control circuit together with the battery. When the unit is connected to the mains supply, the battery will be recharged automatically. Then the battery recharging indicator ( ) and the mains supply indicator ) will be lit at the same time.

  • Page 122: Recorder Paper

    SE-1201 Electrocardiograph User Manual Cleaning, Care and Maintenance WARNING 3. When the battery’s useful life is over, contact the manufacturer or the local distributor for disposal or dispose of the battery according to local regulations. 4. Remove the battery from the electrocardiograph when the electrocardiograph isn’t used for a long time.

  • Page 123: Maintenance Of The Main Unit And The Patient Cable

    SE-1201 Electrocardiograph User Manual Cleaning, Care and Maintenance 13.3.4 Maintenance of the Main Unit and the Patient Cable CAUTION Besides the maintenance requirements recommended in this manual, comply with local regulations on maintenance and measurement. The following safety checks should be performed at least every 12 months by a qualified person who has adequate training, knowledge, and practical experience to perform these tests.
  • Page 124 SE-1201 Electrocardiograph User Manual Cleaning, Care and Maintenance 1) Main Unit ♦ Avoid excessive temperature, sunshine, humidity and dirt. ♦ Put the dustproof coat on the main unit after use and prevent shaking it violently when moving it to another place.

  • Page 125: Chapter 14 Accessories

    SE-1201 Electrocardiograph User Manual Accessories Chapter 14 Accessories WARNING Only the patient cable and other accessories supplied by the manufacturer can be used. Or else, the performance and electric shock protection can not be guaranteed. 14.1 Standard Accessories Table 14-1 Standard Accessory List...
  • Page 126 SE-1201 Electrocardiograph User Manual Accessories Alligator Clip/Banana Socket 01.57.040173 Adapters Adult Disposable Adhesive 11.57.471056 Electrodes Pediatric Disposable Adhesive 11.57.471057 Electrodes Disposable Resting Tab electrodes 11.57.471031-10 (1 piece) Electrode gel 11.25.78047 Input/Output connector 11.13.19907 Grounding Wire 11.13.114114 03.24.38952 Smart ECG Viewer 03.24.38953...

  • Page 127: Chapter 15 Warranty & Service

    EDAN will, at its discretion, repair or replace the defective part(s) free of charge. EDAN will not provide a substitute product for use when the defective product is being repaired.

  • Page 128: Appendix 1 Technical Specifications

    SE-1201 Electrocardiograph User Manual Technical Specifications Appendix 1 Technical Specifications A1.1 Safety Specifications IEC/EN 60601-1+A1+A2, IEC/EN60601-1-2+A1, Comply with: IEC/EN60601-2-25, ANSI/AAMI EC11, IEC/EN 60601-2-51 Anti-electric-shock type: Class І with internal power supply Anti-electric-shock degree: CF type with defibrillation-proof Degree of protection against...

  • Page 129: A1.3 Physical Specifications

    Input Current = 0.9-0.4A Rated voltage = 14.8V Rated capacity = 2200mAh When the battery is fully charged, SE-1201 can work normally about 4 hours, and it can continually print about 1.5 hours in the MANU mode or print about 300 ECG reports of 3×4+1R in the auto mode.

  • Page 130: A1.5 Performance Specifications

    SE-1201 Electrocardiograph User Manual Technical Specifications A1.5 Performance Specifications Recording Recorder: Thermal dot-matrix recorder 8 dots per mm / 200 dots per inch (amplitude axes) Printing Density 40 dots per mm / 1000 dots per inch (time axes, @ 25...
  • Page 131 SE-1201 Electrocardiograph User Manual Technical Specifications AC Filter: On/Off DFT Filter: 0.05Hz/0.15Hz/0.25Hz/0.32Hz/0.5Hz/0.67Hz Filter EMG Filter: 25Hz/35Hz/45Hz/OFF LOWPASS Filter:150Hz/100Hz/75Hz CMRR ≥115dB Sampling Frequency 1000 Hz Pacemaker Detection Amplitude ±2 to ±700 mV Width 0.1 to 2.0 ms Sampling Frequency 10,000/sec/channel External Input/Output (Optional) ≥100kΩ;...

  • Page 132: Appendix 2 Emc Information

    SE-1201 Electrocardiograph User Manual EMC Information Appendix 2 EMC Information Guidance and manufacture’s declaration - electromagnetic emissions- for all EQUIPMENT and SYSTEMS Guidance and manufacture’s declaration – electromagnetic emission The 12-channel electrocardiograph is intended for use in the electromagnetic environment specified below.
  • Page 133 SE-1201 Electrocardiograph User Manual EMC Information Guidance and manufacture’s declaration - electromagnetic immunity - for all EQUIPMENT and SYSTEMS Guidance and manufacture’s declaration – electromagnetic immunity The 12-channel electrocardiograph is intended for use in the electromagnetic environment specified below. The customer or the user of 12-channel electrocardiograph should assure that it is used in such an environment.
  • Page 134 SE-1201 Electrocardiograph User Manual EMC Information for 25 cycles for 25 cycles powered from uninterruptible power supply or a battery. <5% U <5% U (>95% dip in U (>95% dip in U for 5 sec for 5 sec NOTE is the a.c. mains voltage prior to application of the test level.
  • Page 135 SE-1201 Electrocardiograph User Manual EMC Information metres (m). Field strengths from fixed transmitters, as determined by an electromagnetic site survey, should be less than the compliance level in each frequency range. Interference may occur in the vicinity equipment marked with following symbol: NOTE 1 At 80 MHz and 800 MHz, the higher frequency range applies.
  • Page 136 SE-1201 Electrocardiograph User Manual EMC Information Recommended separation distances between portable and mobile RF communications equipment and the EQUIPMENT or SYSTEM - for EQUIPMENT or SYSTEM that are not LIFE-SUPPORTING Recommended separation distances between portable and mobile RF communications equipment and the 12-channel...

  • Page 137: Appendix 3 Abbreviation

    SE-1201 Electrocardiograph User Manual Abbreviation Appendix 3 Abbreviation Abbreviation Statement Liquid Crystal Display Blood Pressure Electrocardiogram/Electrocardiograph Heart Rate Left Foot Augmented Lead Left Arm Augmented Lead Right Arm Augmented Lead Left Arm Left Leg Right Arm Right Leg Identification Alternating Current...
  • Page 138 - 131 -...

Table of Contents

Save PDF
