MATRIX control panel
9

Menu Structure OP5xx

All possible menus are shown in this menu structure. According to the configuration of the controller
some menus can exclude one another or not appear at all.
−
Basic menu
→
( 38)
−
Home screen (alternative)
→
( 39)
−
Fan mode
→
( 40)
−
plant/fan
→
( 41)
−
→
Fan speed ( 42)
Supply-air duct pressure/
−
extract-air duct pressure
→
( 42)
−
Supply air volume flow/
→
Extract air volume flow( 43)
−
→
Operating mode ( 43)
−
→
Controller mode ( 44)
−
→
Secondary-air louvre ( 45)
−
→
Adjust louvre angle ( 45)
−
→
46)
Mixing-air damper position (
−
→
Outside air flow ( 46)
−
→
Outside air automatic ( 46)
−
→
FOS Test menu ( 46)
−
1)
Fast aerate
→
( 46)
−
Basic ventilation
→
( 47)
Room air flow
−
(SWIRL-function)
→
( 47)
−
Other menus
→
( 49)
−
1)
This menu is not available if MATRIX 4700 controls is used for standard and low-profile air handling units.
2)
This menu is only available if MATRIX 4700 controls is used with standard and low-profile air handling units.
PR-2011-0110-GB • Subject to modifications • R9-03-2016
Setpoint
Room temperature
Entering setpoint
Supply-air temperature
OFF
Automatic
Auto (mute)
Speed xx % or stage x
OFF
On - manual
On - air quality
Speed xx %
Pressure in Pa
Volume flow in m³/h
Normal operation
Economy mode
Clock Timer
(Preference)
Bypass
Heating only
Cooling only
Automatic
Passive Cooling
Change position in %
Adjust louvre angle in degrees
Air volume flow in %
Change position in %
Recirculating air
Mixed air
Only with LON module -
See MATRIX.LON operation
manual
Enter time for fast aerate
On
Automatic
Automatic
Manual
Turbo
Breath
−
Error list (only for errors)
→
( 49)
→
Clock timer ( 50)
−
e.g. sensor errors
→
Week programme ( 51)
−
−
−
−
−
−
−
Menu Structure OP5xx
Activation
Delete program
All week days
Monday - Friday
Saturday - Sunday
Monday
...
Sunday
