Operating MATRIX control panel
Electric heating submenu
E heating
E-heating type
Disabled
Service submenu
DX evaporator
Type of refrigeration unit
Disabled
76
Automatic 2-point
Autom.+fan 2-P.
Automatic 3-point
Autom.+fan 3-P.
NOTICE!
Notice: Description of the dampers control type, see "Submenu MA damper
mode" on page 65.
The following types of electrical heating can be selected in the "Electric heating"
submenu (even if it is not configured for every MATRIX 4700 unit):
Value range:
Disabled
1-speed
2-speed
3-speed
0..10 V
2..10 V
0..10 V+1-speed
0..10 V+2-speed
0..10 V+3-speed
2..10 V+1-speed
2..10 V+2-speed
2..10 V+3-speed
Unit-related default settings are performed at the factory.
The refrigeration unit control can be set in the "direct evaporator" submenu:
Value range:
Disabled (factory setting)
1-speed
2-speed
0..10 Volt
10..0 Volt
Display
2-point damper
2-point damper
3-point damper
2-point damper
PR-2011-0110-GB • Subject to modifications • R9-03-2016
