Technical Description

4 Technical Description
4.1

Product features and functions

OP5xx
Display of OP5xx
12
The MATRIX control panels are designed to control DencoHappel air treatment
units and are available in two types:
– Series OPxxC (Comfort) for normal environment (IP20) and
– Series OPxxI (Industry) for commercial/industrial environment (IP54).
Both series of control panels enable communication between the user and the
MATRIX control system.
The OP5xx MATRIX control panels are equipped with MATRIX.Net bus, through
which communication with air treatment units is performed.
The MATRIX control panels with display enable a menu structure as plain text
from where users can directly access numerous functions of the DencoHappel
units. The menus are adapted dynamically according to the configuration of the
unit. Thus, menus are also available for access to remote systems such as
damper or lighting controls (only through MATRIX.LON).
NOTICE!
For further information about the MATRIX.Net refer to the operation manual of
the relevant air treatment unit.
PR-2011-0110-GB • Subject to modifications • R9-03-2016
MATRIX control panel
