MATRIX control panel
7.20.4 Operation mode "Breath"
Room air flow
Automatic
Manual
60 min
Turbo
Breath
Room air flow
Automatic
Manual
Turbo
Breath
00:59
7.21

Menu "additional menus"

Other menus
Clock timer
Actual values
System
Settings
7.21.1 Submenu: Operation messages
Operation messages
1. Sensor error
2. Operation info
3. Operation warning
PR-2011-0110-GB • Subject to modifications • R9-03-2016
The option for the operating mode "Breath" is only displayed on the home screen
when the plant is designed for cooling function. The operating mode "Breath" is
only available in normal operation for a limited time.
In "Breath" mode, the direction of airflow changes continuously between the two
extreme discharge angles.
The maximum duration of "Breath" mode is configurable via MATRIX.PC on con-
trol panel. The duration is adjustable between 10 and 240 minutes.
When using the first time the operation mode "Breath" the factory setting, showing
60° minutes, is displayed. For each further use, the last set time is specified. The
remaining time is shown on the home screen in hours and minutes (format
hh:mm).
When the predetermined time passed, the last operating mode settings are
restored.
The "Other menus" menu provides access to functions that are not directly re-
quired during normal operation. This is where
– actual values (like current temperature values) can be queried,
– and fundamental settings (such as date and time or the temperature unit) are
made.
Behind "Additional menus", additional submenu are concealed which are
explained on the following pages:
– Operation messages submenu (see Page 49)
– Submenu clock timer (see Page 50)
– Actual values submenu (See Page 54)
– System submenu (see Page 55)
– Settings submenu (See Page 57)
– Air handling unit submenu (See Page 70)
– Service submenu (see Page 79)
– Full blocking submenu (see Page 81)
– Partial blocking submenu (see Page 81)
* The "operation messages" submenu is displayed only if a message has been
registered.
The submenu "Operation messages" is only shown if one or several errors, warn-
ings, or information messages were registered. The individual messages are
shown in the sequence of their occurrence.
Operating MATRIX control panel
