MATRIX control panel
Control mode submenu
Unit type
Pipe system type
Heating only
Energy recovery submenu
Control mode
Control mode
Room temperature
Fan submenu
Fans
Control mode
Factor
Max. volume flow
Control mode
Supply fan <-----> Extract fan
Ext.speed Offset
PR-2011-0110-GB • Subject to modifications • R9-03-2016
EQUIPMENT DAMAGE!
It is mandatory to make the above-listed configurations (insofar as the individ-
ual unit functions are available). Otherwise, a correct functioning of the control
or the central air handling unit cannot be ensured.
The following unit types can be selected in the "Unit Type" submenu::
Value range: Unconfigured
Hating only
Cooling only
Heating or cooling
Heating+cooling (factory setting)
The following unit types can be selected in the "Control Mode" submenu:
Value range: Unconfigured
Room temperature (factory setting)
Supply-air temperature
Room-/supply-air cascade
The "Fan" submenu is for setting the parameters for the continuously variable
speed regulation of supply-air and extract-air motors. It appears when using the
control panel with central or low-profile unit control MATRIX 4700 in connection
with frequency converters.
The individual parameters are specified by selecting the following submenus:
– Control mode
– Factor or speed offset
– Maximum volume flow
Whether the submenu "Factor" or "Speed offset" is shown or not is determined
dynamically by the selected "Control mode" (see Fans Ü Control mode on
Page 71).
Fans ➜ Control mode
In the "Type of the control" submenu you must select how the speed setpoint
value for the supply-air and/or extract-air fan should be set.
The following table demonstrates different combination options for supply-air and
extract-air fans. If the setting "Offset" or "Factor" for a fan is selected, the associ-
ated submenu appears (see fans Ü factor on Page 73 or fans Ü fan speed offset
onPage 73).
Operating MATRIX control panel
71
