DencoHappel MATRIX OP21C Operation Manual page 75

MATRIX control panel
Max. volume flow
Supply-air fan
Extract-air fan
Supply-air fan
m³/h
7500
Extract-air fan
m³/h
7500
Energy Recovery System submenu
Energy recovery
ERS type
Disabled
Air damper system submenu
Air damper system
Operating mode
Outside/outgoing-air
PR-2011-0110-GB • Subject to modifications • R9-03-2016
Fans ➜ Max. volume flow
The maximum volume flow or the maximum volume flows in m³/h of the con-
nected air handling unit must be entered by selecting "supply air fan" or extract
air fan" in the submenu "max. volume flow". The volume flow control is also based
on these data. Refer to the technical documentation of the respective air handling
unit for the maximum volume flow.
Value range: 0 to 65,000 m
Adjustable steps: 10 m
Factory setting: 1000 m
You can select the following energy recovery systems in the "ERS" submenu:
Value range: Disabled (factory setting)
Ecoflow 2-point
Ecoflow 3-point
Ecostat
Ecoplat
Ecorot 0..10V
EcoplatTwin
Multiflow
The following air damper types can be selected in the "air damper system" sub-
menu:
Value range: Disabled
Outside/outgoing-air damper
(Factory setting)
Manual 2-point
Manual 3-point
Air volume
3
/h
3
/h
3
/h
Display
Disabled
2-point damper
2-point damper
3-point damper
3-point damper
Operating MATRIX control panel
Type of damper
75
