Technical Description
4.3

Technical data and accessories

Type series
Area of application
Ambient conditions
Allowed ambient temperature
Allowed storage temperature
Allowed relative humidity
Electromagnetic compatibility
Electromagnetic interference
(EMI)
Electromagnetic interference
shielding (EMS)
Mechanical data
External dimensions (W/H/D)
Fixation
Weight
Casing material
Casing front panel
Casing rear section (if necessary
surface-mounted socket)
Pushbutton
Protection type (according to DIN
40050)
Application position
Cable entry point
Electrical data
Supply voltage
Temperature sensor
14
83 mm
135 mm
OPxxC (Comfort)
Comfort area
according to DIN EN 55022/DIN EN 61000
83 x 135 x 30 mm
directly on the wall or socket for flush
mounting
184 g
similar to RAL 9016 (traffic white)
similar to RAL 9016 (traffic white)
similar to RAL 7074 (telegrey 4)
IP20
installed vertically
from behind
integrated
30 mm
135 mm
OPxxI (Industry)
Industrial area
0 °C to 45 °C
-10 °C to 65 °C
15% to 75% no condensation
according to DIN EN 61000
83 x 135 x 55 mm
on the wall
248 g
N185 Noryl UL 94 V-0
similar to RAL 7035 (light grey)
similar to RAL 7016 (anthracite)
similar to RAL 7016 (anthracite)
IP54
installed vertically
from behind via 3 membrane grommets
M16
Through power supply of the unit
room temperature sensor type 903.454
supplied loose
PR-2011-0110-GB • Subject to modifications • R9-03-2016
MATRIX control panel
83 mm
55 mm
