Overview of units and packaged content
1.1

Using MATRIX control panels

1.2

Packaged content

6
In combination with the MATRIX controllers, the MATRIX control panels let you
specify setpoint values for the room air conditioning as well as the display of sta-
tus and error messages. The features are summarized as follows:
The assignment of...
– setpoints such as room or supply air temperature
– fan operating modes such as automatic operation
– operating modes of the unit, such as day-night operation
– switching times
– system parameters
The display of...
– actual values
– unit status
– error messages
MATRIX OPxxC control panel:
– Control panel for flush-mounted socket installation (protection type IP20)
consisting of a front panel and a mounting plate
– Operation manual – document comprising all relevant instructions
MATRIX OPxxl control panel:
– Control panel for surface mounting (protection type IP54)
consisting of a front panel and a mounting plate, including surface-mounted
socket with cable entry through membrane grommets
– Sensor type 903.454 (IP54), R=10 kOhm/25 °C
– Operation manual – document comprising all relevant instructions
