HARDWARE INSTALLATION GUIDE
Brocade DCX Backbone
Hardware Installation Guide
53-1000685-24
28 February 2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DCX Backbone and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Brocade Communications Systems DCX Backbone

Summary of Contents for Brocade Communications Systems DCX Backbone

  • Page 1 HARDWARE INSTALLATION GUIDE Brocade DCX Backbone Hardware Installation Guide 53-1000685-24 28 February 2017...
  • Page 2 United States government. The authors and Brocade Communications Systems, Inc. assume no liability or responsibility to any person or entity with respect to the accuracy of this document or any loss, cost, liability, or damages arising from the information contained herein or the computer programs that accompany it.

  • Page 3: Table Of Contents

    Parts list – NEBS kit............................................. 33 Assembling the rack hardware......................................... 34 Installing the device in the rack........................................ 37 Installing the 14U Chassis Mid-Mount Rack Kit for Two-Post Racks (XBR-DCX-0121)..................39 Time and Items required..........................................40 Parts list................................................40 Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 4 Cable Management.......................................... 47 Requirements and precautions..........................................47 Qualified cables for the FC8-64 port blade....................................48 Installing ICL cables (optional)........................................... 49 Logging In and Configuring the DCX Backbone............................... 51 Items required................................................51 Providing power to the DCX Backbone......................................52 Configuring the Brocade DCX...........................................52 Establishing a serial connection and logging on to the Brocade DCX..........................53 Logging in to the serial console port.......................................54...
  • Page 5 Removal and replacement of the Brocade DCX chassis..............................125 Time and items required..........................................125 Verifying need for replacement......................................125 Recording critical Brocade DCX and SAN information.............................. 126 Disconnecting from network and fabric.................................... 129 Removing components from the chassis..................................130 Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 6 Canadian requirements............................................157 CE statement................................................. 157 China ROHS................................................158 FCC warning (US only)............................................158 KCC statement (Republic of Korea)......................................158 VCCI statement..............................................158 Brocade DCX Backbone Technical Specifications..............................159 System specifications............................................159 Fibre Channel.................................................159 LEDs..................................................159 Other..................................................160 Weight and physical dimensions........................................160 Environmental requirements........................................... 160 Power supply specifications (per PSU).......................................
  • Page 7 Caution and Danger Notices....................................... 165 Cautions................................................... 165 Danger notices..............................................166 Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 8 Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 9: Preface

    Identifies command names. Identifies keywords and operands. Identifies the names of GUI elements. Identifies text to enter in the GUI. italic text Identifies emphasis. Identifies variables. Identifies document titles. Identifies CLI output. Courier font Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 10: Command Syntax Conventions

    By sending your feedback to documentation@brocade.com Provide the publication title, part number, and as much detail as possible, including the topic heading and page number if applicable, as well as your suggestions for improvement. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 11: Contacting Brocade Technical Support

    Brocade Supplemental Support augments your existing OEM support contract, providing direct access to Brocade expertise. For more information, contact Brocade or your OEM. • For questions regarding service levels and response times, contact your OEM/solution provider. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 12 Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 13: About This Document

    WWN cards as this will cause licensing and RMA problems. Note also describes license transfer process. – Removing components from the chassis on page 130 – Installing components into the new chassis on page 131 • Editorial changes in rack mount kit procedures. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 14 Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 15: Overview

    The chassis can be mounted with the cables facing the front of the equipment rack or to the rear, and consists of the following: • Up to eight hot-swappable port blade assemblies that can be configured in a single chassis, delivering up to 512 Fibre Channel ports. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 16 The 8-Gbps SFPs and mSFPs auto-negotiate at 2, 4, and 8 Gbps. The 4-Gbps SFPs auto-negotiate at 1, 2, and 4 Gbps. • Blades that are serviced from the port side of the Brocade DCX. Blowers, power supplies, and power cables that are serviced from the nonport side. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 17: Port Side Of The Brocade Dcx

    The following illustration displays a sample configuration of the port side of the Brocade DCX. FIGURE 1 Port side of the Brocade DCX (sample configuration) Exhaust Vent Core switch blade (CR8) Control processor blade (CP8) Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 18: Nonport Side Of The Brocade Dcx

    WWN bezel (logo plate) Power supply (4x) Blower assembly (3x) Brocade DCX blades The following table summarizes the port, application, control processor, and core switch blades that are supported on the Brocade DCX. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 19 This application blade is compatible with the Brocade DCX and Brocade DCX-4S.This blade cannot be used in the same chassis with an FC8-64 high density port blade or any of the other application blades (FX8-24 or FS8-18). Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 20: Chassis Slots

    The following features contribute to the Brocade DCX high-availability design: • Redundant, hot-swappable blades and FRUs • Enhanced data integrity on all data paths • Fabric Shortest Path First (FSPF) rerouting around failed links Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 21: Reliability

    Memory scrubber, self test, and bus ping to determine if a bus is not functioning • RASlog messages • SMI-S compliant • Watchdog timers • Status LEDs • Predictive diagnostics analysis through Fabric Watch Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 22: Software Features

    IP filters (block listeners) Configurable RSCN suppression by port Secure passwords (centralized control through RADIUS/CHAP) NTPv3 (to synchronize timestamps) Up to 255 multiple user accounts (MUAs). Event auditing Role-based access controls (RBACs) Change tracking Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 23: Network Manageability

    Fibre Alliance Fibre Channel Management (FCMGMT) and Storage Management Initiative (SMI) MIBs, which allow common information necessary for management software to provide information to a SAN administrator. Refer to the Brocade Fabric OS Administration Guide for additional MIB information. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 24 Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 25: Preparing For The Installation

    Cables can be managed in a variety of ways, such as by routing cables below the chassis, to either side of the chassis, through cable channels on the sides of the cabinet, or by using patch panels. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 26: Time And Items Required For Installation

    Ethernet cabling (optional) for Telnet access. session, and configuring the Brocade DCX Refer to the Brocade Fabric OS Administration domain ID, date and time, and additional system Guide. parameters. Verify and back up configuration. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 27: Items Included With The Device

    Order the optical transceivers (SFP, SFP+, mSFP, and XFP) from Brocade. The Brocade DCX supports SWL, LWL, and ELWL transceivers. The mSFPs are SWL transceivers only. NOTE For information about the SFP, SFP+, mSFP, and XFP transceivers that are qualified for the Brocade DCX, go to http:// www.brocade.com/products/interop_and_compatibility.jsp. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 28 Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 29: Mounting The Device

    Mount the devices you install in a rack as low as possible. Place the heaviest device at the bottom and progressively place lighter devices above. DANGER Use safe lifting practices when moving the product. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 30: Mounting Options

    Use safe lifting practices when moving the product. DANGER A fully populated Brocade DCX (eight FC8-64 port cards, 512 ports) weighs approximately 159.2 kg (351 lbs) and requires a hydraulic or assisted lift to install it. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 31: Installing The 14U Rack Mount Kit For Four-Post Racks (Xbr-Dcx-0120 And Xbr-Dcx-0152)

    Before mounting your device, review any specific installation and facility requirements in this Hardware Installation Guide. • Hardware devices illustrated in these procedures are only for reference and may not depict the device you are installing into the rack. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 32: Time And Items Required

    For rack rails with square holes cm-kg]) 3/8 in. (0.953 cm) alignment washer For rack rails with square holes NOTE Depending on the device and installation, not all the parts may be used on the device type. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 33: Parts List - Nebs Kit

    NOTE Depending on the device and installation, not all of the parts may be used. Verify that the items listed in the following figure are included in the NEBS kit. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 34: Assembling The Rack Hardware

    Attach the left and right rack mount shelf brackets to the rack rails. NOTE If cables are to be routed down through the cable management comb, allow space below the brackets for cable management Locate the shelf brackets in the device. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 35 3/8 in. (0.953 cm) alignment washer for rails with square Exhaust air direction holes (4 on each end of each bracket, 16 total) CAUTION Use the screws specified in the procedure. Using longer screws can damage the device. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 36 Standard EIA rails have holes in sets of three; spaces between the holes are 5/8 in., 5/8 in., and 1/2 in. (1.58 cm, 1.58 cm, and 1.27 cm). Tighten the adjusting screws on the sliding portion of the rack mount shelf brackets to a torque of 32 in-lb (37 cm-kg). Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 37: Installing The Device In The Rack

    Move the lift as close as possible to the rack, with the air-intake side of the device facing the front of the rack (see the following figure). If applicable, lock the wheels of the lift. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 38 Installing the 14U Rack Mount Kit for Four-Post Racks (XBR-DCX-0120 and XBR-DCX-0152) Gently slide the device onto the shelf brackets, ensuring that it remains supported during the transfer. FIGURE 7 Positioning the device for installation in a rack Rack Nonport side of device Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 39: Installing The 14U Chassis Mid-Mount Rack Kit For Two-Post Racks (Xbr-Dcx-0121)

    Installing the 14U Chassis Mid-Mount Rack Kit for Two-Post Racks (XBR-DCX-0121) Use the following instructions to install a Brocade modular device in a telecommunications (Telco) rack, using the 14U Chassis Mid- Mount Rack Kit for Two-Post Racks (XBR-DCX-0121). Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 40: Time And Items Required

    Hydraulic or assisted lift with a minimum raise of 140 cm (55 in.) and a minimum capacity of 113 kg (250 lbs). Parts list The following parts are provided with the 14U Chassis Mid-Mount Rack Kit for Two-Post Racks (XBR-DCX-0121). Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 41: Assembling The Rack Hardware

    Attach the rear tray (with or without adapter, as required) to both rack rails. Orient the tray (refer the following figure) and use nine screws (Item E) for each rail. Attach the front tray to both rack rails. Orient the tray (Figure 11) and use nine screws (Item E) for each rail. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 42 Verify that the rear edge of the front tray is seated into the front edge of the rear tray. FIGURE 10 Attaching the rear tray to the rack rails 2. Tray, rear, mid-mount, chassis 3. Adapter, rear, mid-mount, right 4. Adapter, rear, mid-mount, left 5. Screws Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 43: Installing The Device In The Rack

    5. Screws Installing the device in the rack DANGER Use safe lifting practices when moving the product. NOTE A fully populated device requires a hydraulic or assisted lift to install into a rack. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 44 Use three screws (Item 5) to attach each side of the rear tray to the device (refer the following figure). NOTE The screw holes in the device walls have pem nuts on the inside surface. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 45 Do not use the top or bottom holes of the Brocade mounting bracket because the door will interfere with the screw heads. FIGURE 13 Attaching trays to the device Reinstall the device door. For instructions, refer to the door removal and installation instructions in your device installation guide. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 46 Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 47: Cable Management

    If ISL Trunking is in use, group the cables by trunking group. The ports are color-coded to indicate which ports can be used in the same ISL Trunking group: eight ports marked with solid black ovals alternate with eight ports marked with oval outlines. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 48: Qualified Cables For The Fc8-64 Port Blade

    12 fiber, 12" breakout, (XXX = length) = length) OM3, 50/125 mSFP LC - MTP-female, 106272-0327 12 fiber, 6" breakout, OM3, 50/125 mSFP LC - MTP-female, 106272-0328 24 fiber, 12" breakout, OM3, 50/125 Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 49: Installing Icl Cables (Optional)

    Amphenol part number Bag of clips (quantity 64) TRIGGER-BP-NP Installing ICL cables (optional) Go to Removal and replacement of the inter-chassis link (ICL) cables on page 115 for the procedure to install the ICL cables Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 50 Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 51: Logging In And Configuring The Dcx Backbone

    Logging In and Configuring the DCX Backbone • Items required........................................51 • Providing power to the DCX Backbone..............................52 • Configuring the Brocade DCX..................................52 • Establishing a serial connection and logging on to the Brocade DCX..................53 • Logging in to the serial console port................................. 54 •...

  • Page 52: Providing Power To The Dcx Backbone

    Providing power to the DCX Backbone Providing power to the DCX Backbone ATTENTION Use the supplied power cords. Ensure the facility power receptacle is the correct type, supplies the required voltage, and is properly grounded. (D004) Connect the AC power cords to the power supply assemblies. One to four power cords are required depending on electrical service.

  • Page 53: Establishing A Serial Connection And Logging On To The Brocade Dcx

    Access the Brocade DCX using a terminal emulator application (such as HyperTerminal in a Windows environment or tip in a UNIX environment). Disable any serial communication programs running on the workstation (such as synchronization programs). Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 54: Logging In To The Serial Console Port

    The Brocade DCX requires three IP addresses, which are configured using the ipAddrSet command. IP addresses are required for both CP blades (CP0 and CP1) and for the chassis management IP (shown as SWITCH under the ipAddrShow command) in the Brocade DCX. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 55 Ethernet IP Address [10.77.77.74]: 123.123.123.122 Ethernet Subnetmask [0.0.0.0]: 123.123.123.123 Gateway IP Address [0.0.0.0]: 123.123.123.124 IP address of remote CP is being changed...Done. Committing configuration...Done. swDir:admin> reboot Type reboot to reboot the Brocade DCX. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 56: Logging Off The Serial Console Port And Disconnecting The Serial Cable

    Changing the name causes a domain address format RSCN to be issued. Type switchName followed by the new name in double quotes. swDir:admin> switchName "swModularSwitch5" Committing configuration... Done. swModularSwitch5:admin> Record the new name for reference. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 57: Customizing A Chassis Name

    However, because the date and time are used for logging, error detection, and troubleshooting, they should be set correctly. Setting the date To set the date, follow these steps. If necessary, log on to the Brocade DCX by Telnet, using the admin account. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 58: Setting The Time Zone

    Please identify a location so that time zone rules can be set correctly. Enter the appropriate number or Ctrl-D to quit. At the prompt, select a country location. At the prompt, enter the appropriate number to specify the time zone region or Ctrl-D to quit. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 59: Synchronizing Local Time

    Web license Zoning license Extended Fabric license Fabric Watch license Performance Monitor license Trunking license Security license In this example, the license key is AAbbccDDeeFFeeGG. Keep a copy of the license key for reference. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 60: Installing Transceivers And Attaching Cables

    ISL Trunking group: eight ports marked with solid black ovals alternate with eight ports marked with oval outlines. ® • Generally, Velcro type cable restraints are recommended to avoid creating sharp bends in the cables. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 61: Verifying Correct Operation And Backing Up The Configuration

    Alternatively, you can save the configuration file to a Brocade USB device by using the usbstorage command. NOTE Passwords are not saved in the configuration file, and are not uploaded during a configuration upload. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 62: Powering Off The Brocade Dcx

    Power off the chassis by flipping the AC power switches on the power supplies to "0" (LEDs inside AC power switches should turn off). To maintain the ground connections, leave power cords connected to the power supplies and to the electrical outlets. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 63: Monitoring System Components

    Figure 22 illustrates the FCOE10-24 FCOE blade. The LED patterns may temporarily change during POST and other diagnostic tests. For information about how to interpret the LED patterns, see the table after the illustrations. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 64 Determining the status of a port, application, or encryption blade Check the blade status by entering slotShow . FIGURE 16 FC8-16 Port blade Power LED Status LED Fibre Channel port Port Status LED Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 65 Determining the status of a port, application, or encryption blade FIGURE 17 FC8-32 Port blade Power LED Status LED Fibre Channel port Port Status LED Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 66 Determining the status of a port, application, or encryption blade FIGURE 18 FC8-48 Port blade Power LED Status LED Fibre Channel port Port Status LED Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 67 FIGURE 19 FC8-64 Port blade Status LED Power LED Fibre Channel port Port Status LED NOTE The FC8-64 port blade requires narrower OM-3 LC cables offered by major manufacturers like Corning, Molex, and Amphenol. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 68 Determining the status of a port, application, or encryption blade FIGURE 20 FS8-18 Encryption blade Power LED Status LED Fibre Channel port Port Status LED Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 69 Determining the status of a port, application, or encryption blade FIGURE 21 FX8-24 Extension blade Power LED Status LED GbE port 6 GbE port 6 LED 10GbE port 0 10GbE port 0 LED Port map Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 70 The following table describes the port and application blade LED patterns and the recommended actions for those patterns. TABLE 6 Port and application blade LED descriptions LED purpose Color Status Recommended action Power LED Steady green Blade is enabled. No action required. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 71 1 second) switch. used to locate/identify port. Amber, amber, pause (cycle is Beaconing initiated on the HBA No action required. Beaconing about 1 second) and reflected on the port. used to locate/identify port. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 72: Determining The Status Of A Control Processor Blade (Cp8)

    Check the LED indicators on the control processor (CP) blade. The LED patterns may temporarily change during POST and other diagnostic tests. For information about how to interpret the LED patterns, see the next table. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 73 Check the port blade status by entering slotShow and haShow . FIGURE 23 Control processor blade (CP8) Power LED Status LED USB LED USB port Console port (10101) Ethernet port (MGM IP) Ethernet port (SERVICE IP) Active CP LED Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 74: Determining The Status Of A Core Switch Blade (Cr8)

    Check the LED indicators on the core switch (CR) blade. The LED patterns may temporarily change during POST and other diagnostic tests. For information about how to interpret the LED patterns, see the next table. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 75 FIGURE 24 Core switch blade (CR8) Power LED Status LED LINK LED ATTN LED ICL connector The following table describes the core switch blade LED patterns and the recommended actions for those patterns. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 76: Determining The Status Of A Power Supply

    Check the LED indicator on the power supply. The LED patterns may temporarily change during POST and other diagnostic tests. For information about how to interpret the LED patterns, see the next table. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 77: Determining The Status Of A Blower Assembly

    Check the LED indicators on the blower assembly. The LED patterns may temporarily change during POST and other diagnostic tests. For information about how to interpret the LED patterns, see the next table. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 78 Slow-flashing amber(on 2 Blower assembly is not seated Pull the unit out and reseat it. If seconds, then off 2 seconds) correctly or is faulty. the LED continues to flash, replace the unit. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 79 Fast-flashing amber(on 1/2 Environmental range exceeded. Check for out-of-bounds seconds, then off 1/2 seconds) environmental condition, resolve any problems, and reseat the unit. If the LED continues to flash, replace the unit. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 80: Determining The Status Of A Wwn Card

    CR blade Status (above) and Power (below) LEDs Port blade Status (above) and Power (below) LEDs Slot numbers The following table describes the WWN card LED patterns and the recommended actions for those patterns. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 81 No light (LED is OFF) Blade is OK. No action required. NOTE: If a blade slot or power supply bay has a filler panel installed, the corresponding LEDs on the WWN blade do not light Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 82 Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 83: Removal And Replacement Procedures

    Time and items required The replacement procedure for the chassis door takes less than 5 minutes. Removing a chassis door Support the door to prevent it from falling. Pull and remove the door. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 84: Replacing A Chassis Door

    Align the holes in the door with the pins in the chassis Push the door into place. Removal and replacement of the cable management comb The Brocade DCX can continue to operate during the replacement of the cable management comb. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 85: Time And Items Required

    Unscrew and save the four (4) screws holding the comb to the chassis. Support the comb to prevent it from falling. Remove the cable management comb. FIGURE 29 Removal and replacement of the cable management comb Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 86: Replacing A Cable Management Comb

    The replacement procedure for each blade takes less than 10 minutes. The following items are required for the blade and filler panel replacement: • Electrostatic discharge (ESD) grounding strap • Workstation computer • Replacement blade or filler panel • #2 Phillips screwdriver Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 87: Removing A Blade

    If you move the blade without performing these steps and the blade faults, you must move the blade to the original slot and remove configuration. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 88: Replacing A Blade

    Tighten the upper and lower thumbscrews using the Phillips screwdriver. Verify that the power LED on the port blade is displaying a steady green light. If it does not turn on, ensure that the blade is firmly seated. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 89: Removal And Replacement Of The Blade Filler Panel

    Any slot that is not occupied by a blade should be occupied by a filler panel to ensure correct cooling of the chassis and protection from dust. Remove the chassis door (Removal and replacement of the chassis door on page 83). Unscrew the thumbscrew at the bottom of the panel using the Phillips screwdriver. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 90: Replacing A Filler Panel

    Slide the filler panel into the slot until it is firmly seated. Tighten the thumbscrew at the bottom of the panel. Replace the chassis door (Removal and replacement of the chassis door on page 83). Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 91: Removal And Replacement Of The Control Processor Blade (Cp8)

    – EM messages that indicate a problem with a CP blade – Function fail messages for the CP master For more information about error messages, refer to the Brocade Fabric OS Message Reference. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 92: Recording Critical Brocade Dcx Information

    The Brocade DCX continues to operate while a CP blade is being replaced if the redundant CP blade is active and a failover does not occur. You can prevent failover by entering the haDisable command. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 93 Unscrew the thumbscrews from both ejectors using the Phillips screwdriver. Open both ejectors simultaneously to approximately 45 degrees and pull the CP blade out of the chassis. FIGURE 32 Removal and replacement of the control processor blade (CP8) Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 94: Power-Down Procedure

    Tighten the thumbscrew inside each handle using the Phillips screwdriver. Turn the CP blade on by sliding the ON/OFF switch in the left handle to the left to cover the thumbscrew. Power up the chassis. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 95: Verifying Operation Of The New Cp Blade

    Using this command requires that existing telnet, secure telnet or SSH sessions to the standby CP blade to be restarted. • Run the firmwareDownload -s command on the replacement blade to bring it up to the proper level. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 96 Insert the USB device into the active CP blade. Attach a serial cable from the PC to the active CP blade. Log in to the active CP blade and type usbStorage - e to enable the USB device. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 97: Removal And Replacement Of The Core Switch Blade (Cr8)

    • The status LED on the core switch blade is lit amber, or the power LED is not lit. • The slotShow command does not show that the core switch blade is enabled. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 98: Removing A Core Switch Blade (Cr8)

    Power off the blade by sliding the slider switch in the top ejector down to the off position. Do not eject the blade until the power LED has gone off and you have completed the next two steps. Disconnect cables from the faulty core switch blade. Unscrew the thumbscrews from both ejectors using the Phillips screwdriver. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 99: Replacing A Core Switch Blade (Cr8)

    Align the flat metal side of the core switch blade inside the upper and lower blade guides in the slot. Slide the core switch blade into the slot until it is firmly seated. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 100: Removal And Replacement Of The Power Supply

    The replacement procedure for each power supply takes less than 5 minutes. A power supply unit or filler panel is required for the power supply replacement. Identifying power supplies The following figure shows the location and identification of the power supplies. FIGURE 34 Power supply identification Power supply 1 (PS1) Power supply 2 (PS2) Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 101: Power-Cord Notice

    Turn off the power switch. Remove the power cord. Loosen the thumbscrew. Grasp the handle and pull, sliding the power supply from the chassis and supporting the power supply from beneath as you remove it. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 102: Replacing A Power Supply

    Insert the power supply into the slot. Verify that the power supply is seated by gently pulling on the handle. The power supply should resist movement as you pull. Tighten the thumbscrew. Replace the power cord. Turn on the power switch. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 103: Removal And Replacement Of The Blower Assembly

    Before removing a blower assembly, verify that the other blower assemblies are functioning correctly. The power LEDs should be steady green. Use the screwdriver to loosen the captive screws at the top and bottom of the blower assembly. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 104: Replacing A Blower Assembly

    Orient the blower assembly and slide it into the chassis, pushing firmly to ensure that it is seated. Verify that the power LED displays a green light. Use the screwdriver or your fingers to tighten the captive screws. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 105: Wwn Card Removal And Replacement

    #2 Phillips screwdriver (required only for some versions of the WWN card) • If a serial console session is used: serial cable and a workstation computer with a terminal emulator application (such as HyperTerminal for Windows systems or TIP for Solaris systems) Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 106: Using The Wwnrecover Utility

    Error messages regarding WWN units #1 or #2 from the chassisshow output. • If an EM-1220 or EM-1222 error message occurs in the RASlog and WWN card recovery is not successful using wwnrecover. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 107: Preparing For Wwn Card Replacement

    Install the replacement WWN card into the empty slot. When replacing cards, hold each card by the edges and insert the WWN cable onto the WWN module until the cables are fully seated. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 108: Power-Down Replacement

    Follow electrostatic discharge (ESD) precautions. Wear a wrist grounding strap connected to chassis ground (if the chassis is plugged in) or a bench ground. DANGER For safety reasons, the ESD wrist strap should contain a series 1 megaohm resistor. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 109 11. Run the switchcfgpersistentenable command to persistently enable each logical switch, that was disabled before removing the WWN card(s): switch:FID128:root> switchcfgpersistentenable Switch's persistent state set to 'enabled' 12. Install the WWN bezel on the chassis. Orient the bezel on the chassis. Insert and tighten the screws. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 110: Removing The Wwn Card And Wwn Bezel (Logo Plate)

    Verify that you are logged in to the active CP. Run the haShow command to determine the active CP. Run the supportsave command on the active CP to capture all settings. If any problem occurs during the replacement, the supportsave information will be important for solving the problem. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 111 Time Awake: 3 days Chassis Factory Serial Num: AFY2530G00S switch:admin> ficonshow switchrnid {Switch WWN Flag Parm 10:00:00:05:1e:95:b1:00 0x00 0x200a00 Type number: SLKWRM Model number: Manufacturer: Plant of Manufacture: CA Sequence Number: 0AFX2533G001 tag: b6ff Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 112 Disconnect the WWN cable by depressing the cable connector latch and pulling the connector from the WWN module. Hold the WWN card by its edges and gently pull it out from the chassis. 10. Set the WWN card on a static-free surface, such as a grounding pad. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 113: Removal And Replacement Of The Transceivers

    To remove an SFP, SFP+, or XFP (FC6-10 blade only) transceiver, complete the following steps. Remove any cables that are inserted into the transceiver. Use the extraction tool to open the cable latching mechanism. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 114: Removing And Replacing An Msfp Optical Transceiver

    The mSFP transceivers are used only with the FC8-64 port blade. Narrower OM-3 LC cables are used to connect the FC8-64. These cables are offered by major manufacturers like Corning, Molex, and Amphenol. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 115: Removal And Replacement Of The Inter-Chassis Link (Icl) Cables

    ICL ports. ATTENTION If ICL cables are not in use, the ports must have EMI plugs installed to meet EMI and other regulatory certifications. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 116: Time And Items Required

    Using the latch release tabs, pull each plug on the cable from its respective socket on the core switch blades (CR-8). If you are installing cables for the first time, remove the EMI plugs from the sockets. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 117: Replacing An Icl Cable

    Repeat steps 1 and 2 for each cable that requires replacement. If you are installing ICL cables for the first time, pay particular attention to the configuration in which the cables must be installed. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 118 Once all the cables are attached, see the Brocade Fabric OS Administration Guide for the configuration procedure. FIGURE 42 ICL cable connections - Configuration 1 Chassis 1 Core switch blades (CR8) Control processor blades (CP8) Port blades ICL connector (ICL 1) ICL connector (ICL 0) ICL cables Chassis 2 Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 119 Removal and replacement of the inter-chassis link (ICL) cables FIGURE 43 ICL cable connections - Configuration 2 Chassis 1 Core switch blades (CR8) Control processor blades (CP8) Port blades ICL connector (ICL 1) ICL connector (ICL 0) ICL cables Chassis 2 Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 120 Removal and replacement of the inter-chassis link (ICL) cables FIGURE 44 ICL cable connections - Configuration 3 Chassis 1 Core switch blades (CR8) Control processor blades (CP8) Port blades ICL connector (ICL 1) ICL connector (ICL 0) ICL cables Chassis 2 Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 121 Removal and replacement of the inter-chassis link (ICL) cables FIGURE 45 ICL cable connections - Configuration 4 Chassis 1 Core switch blades (CR8) Control processor blades (CP8) Port blades ICL connector (ICL 1) ICL connector (ICL 0) ICL cables Chassis 2 Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 122 Removal and replacement of the inter-chassis link (ICL) cables FIGURE 46 3-way ICL cable connections Chassis 1 Core switch blades Chassis 2 Chassis 3 ICL connector (ICL 1) ICL connector (ICL 0) Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 123 The same general configuration applies regardless of which backbone chassis are used. To keep all three chassis in the same rack , any combination of DCX and DCX-4S backbones can be used except three DCX chassis. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 124 ICL connector (ICL 1) ICL connector (ICL 0) For Fabric OS 6.4.0 and later, you can use three DCX chassis is an ICL configuration if the third chassis is in an immediately adjacent rack. NOTE Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 125: Removal And Replacement Of The Brocade Dcx Chassis

    Any of the following events might indicate the need to replace the chassis: • Visible mechanical damage to the chassis, including damage to sheet metal or card guides that prevents correct installation of a blade. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 126: Recording Critical Brocade Dcx And San Information

    New serial number (if available) Open a Telnet session and log in to the Brocade DCX as admin. The default password is password. Enable the logging function on your Telnet or serial console connection. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 127 HostName : cp0 Gateway Address: 10.32.40.1 Ethernet IP Address: 10.32.50.11 Ethernet Subnetmask: 255.55.0.0 HostName : cp1 Gateway Address: 10.32.40.1 Backplane IP address of CP0 : 10.0.0.6 Backplane IP address of CP1 : 10.0.0.7 switch:admin>switch:admin> Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 128 <output truncated> switch:admin> nsallshow 12 Nx_Ports in the Fabric <output truncated> switch:admin> switchshow switchName: switch <output truncated> switch:admin> fabricshow Switch ID Worldwide Name Enet IP Addr FC IP Addr Name <output truncated> switch:admin> Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 129: Disconnecting From Network And Fabric

    Label the cables connected to all blades and record the connections in Cable routing table on page 135 and additional copies if necessary. Remove the chassis door (Removal and replacement of the chassis door on page 83). Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 130: Removing Components From The Chassis

    If the chassis is in a cabinet, remove it from the cabinet, remove the rack mount hardware, and save the hardware for use with the new chassis. Place the chassis on a lift or on the shipping pallet provided with the original chassis. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 131: Installing Components Into The New Chassis

    (Removal and replacement of the chassis door on page 83). 11. Power on the Brocade DCX (Providing power to the DCX Backbone on page 52). The Brocade DCX performs a power-on self-test (POST). The POST takes a minimum of three minutes and is complete when LED activity returns to standard state.

  • Page 132: Downloading The Configuration

    FC8-48 ENABLED UNKNOWN VACANT CORE BLADE 52 ENABLED CP BLADE ENABLED CP BLADE ENABLED CORE BLADE 52 ENABLED SW BLADE FC8-48 ENABLED SW BLADE FC8-48 ENABLED SW BLADE FC8-48 ENABLED UNKNOWN VACANT switch:admin> Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 133 HostName : cp0 Gateway Address: 10.32.40.1 Ethernet IP Address: 10.32.50.11 Ethernet Subnetmask: 255.55.0.0 HostName : cp1 Gateway Address: 10.32.40.1 Backplane IP address of CP0 : 10.0.0.5 Backplane IP address of CP1 : 10.0.0.6 switch:admin>switch:admin> Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 134: Reconnecting The System To The Network And Fabric

    Repeat the above two sub-steps for the remaining ports. ATTENTION Do not route cables in front of the air exhaust vent (located on the upper port side of the chassis). Organize the cables as required. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 135: Verifying Correct Configuration Of The Fabric

    The following table is a 64-port template for a cable routing table. Make copies of the table to cover the total number of ports in the Brocade DCX. TABLE 16 Cable routing table for Brocade DCX (64 ports shown) Slot/port Cable labels Connected device Slot/port of device Slot Port Switch end Device end Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 136 Removal and replacement of the Brocade DCX chassis TABLE 16 Cable routing table for Brocade DCX (64 ports shown) (continued) Slot/port Cable labels Connected device Slot/port of device Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 137 Removal and replacement of the Brocade DCX chassis TABLE 16 Cable routing table for Brocade DCX (64 ports shown) (continued) Slot/port Cable labels Connected device Slot/port of device Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 138 Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 139: Application And Encryption Blades

    Fibre Channel Routing Services.The GbE ports on the FX8-24 are not compatible with the GbE ports on the FR4-18i blade or the Brocade 7500 switch. NOTE The port diagram on the front panel uses the abbreviations GE for 1 GbE ports and 10GE for 10 GbE ports. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 140 EX_Port-attached edge fabrics do not merge. For more information refer to the Brocade Fabric OS Administration Guide. • Up to three FC trunking groups. The three groups are defined as: – Trunk group 0: FC ports 0, 1 – Trunk group 1: FC ports 6, 7 Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 141: Fcoe10-24 Blade

    With the switch in online state, if all the FCOE ports are shutdown, offline diags will continue to run. After this, the blade will be in inoperable state and you need to issue slotpoweroff and slotpoweron to recover. Refer to the Brocade Fabric OS Administration Guide for information on configuring these features. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 142 Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 143: Diagnostics And Troubleshooting

    Reboot the Brocade DCX or power the entire chassis off and then on (Powering off the Brocade DCX on page 147 and Providing power to the DCX Backbone on page 52). If the problem is still unresolved after these steps, contact your support provider. The information required by your support provider is...

  • Page 144: Interpreting Post And Boot Results

    Diagnostic tests are run on several functions, including circuitry, port functionality, ability to send and receive frames, all aspects of memory, parity, statistics counters, and serialization. Boot In addition to POST, boot includes the following steps after POST is complete: Universal port configuration is performed. Links are initialized. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 145: Diagnostics

    Serial port might be incompatible (only RS-232 Ensure that the Brocade DCX is connected to an is supported). RS-232 port. RS-423 serial ports might experience difficulties due to corner-case incompatibilities of the standards. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 146 Chassis is overheated. Enter the tempshow and sensorShow commands to check internal temperature. If components are overheating, shut down port blades as necessary to return the temperature to operating range. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 147: Powering Off The Brocade Dcx

    Power off the chassis by flipping all AC power switches on the power supplies to the off position (LEDs inside AC power switches should turn off). To maintain the ground connections, leave power cords connected to the power supplies and to the electrical outlets. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 148 Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 149: Port Numbering Template

    (Figure • FC8-32 port blade (Figure • FC8-48 port blade (Figure • FC8-64 high density port blade (Figure • FS8-18 encryption blade (Figure • FX8-24 extension blade (Figure • FCOE10-24 FCoE blade (Figure Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 150 FIGURE 49 FC8-16 port blade Blade Power LED Blade Status LED FC ports 0-15 (bottom to top) Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 151 FIGURE 50 FC8-32 port blade Blade Power LED Blade Status LED FC ports 0-15 (bottom to top) FC ports 16-31 (bottom to top) Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 152 FIGURE 51 FC8-48 port blade Blade Power LED Blade Status LED FC ports 0-23 (bottom to top) FC ports 24-47 (bottom to top) Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 153 FIGURE 52 FC8-64 port blade Blade Status LED Blade Power LED Port 63 Port 30 port 61 LED port 29 LED FC ports 32-63 (bottom to top) FC ports 0-31 (bottom to top) Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 154 FIGURE 53 FS8-18 encryption blades Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 155 FIGURE 54 FX8-24 extension blade 10 GbE ports 0-1 1 GbE ports 0-3 1 GbE ports 4-9 FC ports 6-11 FC ports 0-5 Blade Power LED Blade Status LED Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 156 FIGURE 55 FCOE10-24 FCoE blade 10-GbE CEE ports 12-23 10-GbE CEE ports 0-11 Power LED Status LED Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 157: Regulatory Statements

    European Council directives, laws, and standards: • Electromagnetic Compatibility (EMC) Directive 2014/30/EU • Low Voltage Directive (LVD) 2014/35/EU • EN 55032/EN 55024 (European Immunity Requirements) – EN61000-3-2/JEIDA (European and Japanese Harmonics Spec) – EN61000-3-3 Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 158: China Rohs

    This is a Class A product based on the standard of the Voluntary Control Council for Interference by Information Technology Equipment (VCCI). If this equipment is used in a domestic environment, radio disturbance might arise. When such trouble occurs, the user might be required to take corrective actions. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 159: Brocade Dcx Backbone Technical Specifications

    Brocade DCX Backbone Technical Specifications This document highlights the features and specifications for the Brocade DCX Backbone. System specifications System component Description Enclosure 14U, rack-mountable chassis in a standard 19-inch EIA cabinet Power inlet Power supplies Two 2000 W AC power supply modules (100-240 VAC auto-sensing), 2N redundancy...

  • Page 160: Other

    RS-232 cable has an adapter at one end that can be removed to provide an RJ-45 style connector RJ-45 connector Serial port 10/100/1000 Ethernet (RJ-45) per control processor Weight and physical dimensions Fully loaded: Brocade DCX Backbone 512-port configuration with eight FC8-64 port blades. Model Height Width...

  • Page 161: Power Consumption (Maximum Configuration)

    300 m (984 ft) (OM2) 500 m (1,640 ft) (OM3) 62.5 150 m (492 ft) 30 km (18.6 miles) 150 m (492 ft) (OM2) 380 m (1,246 ft) (OM3) 62.5 70 m (230 ft) Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 162: Serial Port Specifications (Db9)

    Serial port specifications (pinout mini-USB) Signal Description Not used UART0_TX Debug port UART0_RX Console port Not used Ground Serial port specifications (pinout RJ-45) Signal Description Not supported Not supported UART1_RXD Receive data Logic ground Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 163: Serial Port Specifications (Protocol)

    2011/65/EU - Restriction of the use of certain hazardous substance in electrical and electronic equipment (EU RoHS). • 2012/19/EU - Waste electrical and electronic equipment (EU WEEE). • 94/62/EC - packaging and packaging waste (EU). • 2006/66/EC - batteries and accumulators and waste batteries and accumulators (EU battery directive). Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 164 Section 1502 of the Dodd-Frank Wall Street Reform and Consumer Protection Act of 2010 - U.S. Conflict Minerals. • 30/2011/TT-BCT - Vietnam circular. • SJ/T 11363-2006 Requirements for Concentration Limits for Certain Hazardous Substances in EIPs (China). • SJ/T 11364-2006 Marking for the Control of Pollution Caused by EIPs (China). Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 165: Caution And Danger Notices

    Never leave tools inside the chassis. VORSICHT Lassen Sie keine Werkzeuge im Chassis zurück. MISE EN GARDE Ne laissez jamais d'outils à l'intérieur du châssis PRECAUCIÓN No deje nunca herramientas en el interior del chasis. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

  • Page 166: Danger Notices

    Netzkabel, bevor Sie Wartungsarbeiten durchführen, um dieGefahr eines Stromschlags auszuschließen. DANGER Ce commutateur peut comporter plusieurs cordons d'alimentation. Pour réduire les risques de choc électrique, déconnectez tous les cordons d’alimentation avant d’effectuerl’entretien de l’appareil. Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...
  • Page 167 Turn off the power switches and disconnect the power cords. GEFAHR Netzschalter ausschalten und Netzkabel abziehen. DANGER Mettre les interrupteurs hors tension et débrancher les câbles d’alimentation. PELIGRO Apague los interruptores de alimentación y desconecte los cables de alimentación Brocade DCX Backbone Hardware Installation Guide 53-1000685-24...

Table of Contents
