Table of Contents

Advertisement

Quick Links

Download this manual See also: Troubleshooting Manual, Administrator's Manual
53-1001338-01
®
28 July 2009
Fabric OS
Message Reference
Supporting Fabric OS v6.3.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1606 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Brocade Communications Systems 1606

Summary of Contents for Brocade Communications Systems 1606

  • Page 1 53-1001338-01 ® 28 July 2009 Fabric OS Message Reference Supporting Fabric OS v6.3.0...
  • Page 2 Copyright © 2006-2009 Brocade Communications Systems, Inc. All Rights Reserved. Brocade, the B-wing symbol, BigIron, DCX, Fabric OS, FastIron, IronPoint, IronShield, IronView, IronWare, JetCore, NetIron, SecureIron, ServerIron, StorageX, and TurboIron are registered trademarks, and DCFM, Extraordinary Networks, and SAN Health are trademarks of Brocade Communications Systems, Inc., in the United States and/or in other countries.
  • Page 3 Title Publication Summary of changes Date number Diagnostic and System Error 53-0000515-08 Update software and hardware support March 2004 Message Reference v4.2.0 Fabric OS System Error Message 53-0000515-09 Updated for v4.4.0, August 2004 Reference Manual First RASLog release Fabric OS System Error Message 53-0000515-10 Added 22 ZONE messages April 2005...
  • Page 4 Title Publication Summary of changes Date number Fabric OS Message Reference 53-1000600-02 Updated for Fabric OS v6.1.0: Jun 2008 -Revised and added new messages to: AG, BL, C2, EM, FABR, FCR, FCIP, FW, SEC, NS, PDM, PLAT, SULB, SWCH, ZONE, WEBD -Added new Audit chapter: FW -Added new Audit messages to: SEC...

  • Page 5: Table Of Contents

    Contents About This Document In this chapter ........... .lxiii How this document is organized .
  • Page 6 Responding to a System Message........11 Looking Up a System Message .
  • Page 7 AG-1026............32 AG-1027 .
  • Page 8 AUTH-1023 ............44 AUTH-1025 .
  • Page 9 BL-1002 ............59 BL-1003 .
  • Page 10 Chapter 8 BLL System Messages BLL-1000 ............73 Chapter 9 BLS System Messages BLS-1000.
  • Page 11 Chapter 12 CDR System Messages CDR-1001 ............87 CDR-1002 .
  • Page 12 CNM-1007 ............98 CNM-1008 .
  • Page 13 CNM-1044 ............107 CNM-1045 .
  • Page 14 CONF-1032 ........... . . 117 CONF-1040 .
  • Page 15 CVLM-1007 ........... . .130 CVLM-1008 .
  • Page 16 DOT1-1006 ........... . .140 DOT1-1007 .
  • Page 17 EM-1044 ............153 EM-1045 .
  • Page 18 ESW-1006 ............164 ESW-1007 .
  • Page 19 FABR-1035............178 FABR-1036.
  • Page 20 FCIP-1003 ............193 FCIP-1004 .
  • Page 21 FCR-1006............206 FCR-1007.
  • Page 22 FCR-1049............216 FCR-1053.
  • Page 23 FCR-1089............227 FCR-1091.
  • Page 24 FICN-1035 ............239 FICN-1036 .
  • Page 25 FICN-1072 ............249 FICN-1073 .
  • Page 26 Chapter 38 FLOD System Messages FLOD-1001............263 FLOD-1003 .
  • Page 27 FW-1004 ............276 FW-1005 .
  • Page 28 FW-1121 ............287 FW-1122 .
  • Page 29 FW-1177 ............299 FW-1178 .
  • Page 30 FW-1242 ............310 FW-1243 .
  • Page 31 FW-1319 ............322 FW-1320 .
  • Page 32 FW-1356 ............335 FW-1357 .
  • Page 33 FW-1432 ............346 FW-1433 .
  • Page 34 FW-1530 ............358 FW-1531 .
  • Page 35 HIL-1103 ............369 HIL-1104 .
  • Page 36 HIL-1510............380 HIL-1601 .
  • Page 37 Chapter 52 ICPD System Messages ICPD-1001 ............397 ICPD-1002 .
  • Page 38 Chapter 57 KAC System Messages KAC-1002............411 KAC-1004.
  • Page 39 LFM-1004 ............424 LFM-1005 .
  • Page 40 MS-1021 ............438 MS-1022 .
  • Page 41 Chapter 74 ONM System Messages ONMD-1001........... . .453 ONMD-1002 .
  • Page 42 Chapter 78 PMGR System Messages PMGR-1001 ........... . .465 PMGR-1002 .
  • Page 43 PSWP-1006 ........... . . 476 PSWP-1007 .
  • Page 44 Chapter 86 RPCD System Messages RPCD-1001 ........... . .491 RPCD-1002 .
  • Page 45 SEC-1032............504 SEC-1033.
  • Page 46 SEC-1079............515 SEC-1080.
  • Page 47 SEC-1118............525 SEC-1119.
  • Page 48 SEC-1180............536 SEC-1181.
  • Page 49 SEC-1310............546 SEC-1311.
  • Page 50 SNMP-1004 ........... . .558 SNMP-1005 .
  • Page 51 Chapter 93 SPM System Messages SPM-1001 ............571 SPM-1002 .
  • Page 52 SPM-3025 ............580 SPM-3026 .
  • Page 53 SULB-1003 ........... . .591 SULB-1004 .
  • Page 54 SWCH-1010 ........... . .607 SWCH-1011 .
  • Page 55 TRCE-1008............619 TRCE-1009.
  • Page 56 WEBD-1006 ........... . .632 WEBD-1007 .
  • Page 57 ZONE-1026 ........... . .644 ZONE-1027 .
  • Page 58 Chapter 114 AUDIT AUTH System Messages AUTH-3001 ........... . .659 AUTH-3002 .
  • Page 59 PORT-1007............677 PORT-1008 .
  • Page 60 SEC-3031............688 SEC-3032 .
  • Page 61 SULB-1030 ........... . .706 SULB-1031.
  • Page 62 ZONE-3016 ........... . . 719 ZONE-3017 .

  • Page 63: About This Document

    About This Document In this chapter • How this document is organized ....... . . lxiii •...
  • Page 64 • Brocade 5100 • Brocade 5300 • Brocade 5410 • Brocade M5424 • Brocade 5450 • Brocade 5480 • Brocade 7500 • Brocade 7500E • Brocade 7600 • Brocade 7800 • Brocade 8000 • Brocade Encryption Switch • Brocade DCX •...

  • Page 65: What's New In This Document

    What’s new in this document The following changes have been made since this document was last released: • Information that was modified “BKSW System Messages” “BL System Messages” “BKSW System Messages” “BLL System Messages” “CDR System Messages” “CEE CONFIG System Messages” “CONF System Messages”...
  • Page 66 “TRCK System Messages” “WEBD System Messages” “ZONE System Messages” • Information that was added: “AG System Messages” “AN System Messages” “AUTH System Messages” “BLS System Messages” “C2 System Messages” “CDR System Messages” “CEE CONFIG System Messages” “CHASSIS System Messages” “CNM System Messages” “CONF System Messages”...

  • Page 67: Document Conventions

    “PSWP System Messages” “RKD System Messages” “SEC System Messages” “SPC System Messages” “SPM System Messages” “SS System Messages” “SULB System Messages” “SWCH System Messages” “TAPE System Messages” “UCST System Messages” “UPTH System Messages” “XTUN System Messages” “ZONE System Messages” • Information that was deleted: “C2 System Messages”...

  • Page 68: Command Syntax Conventions

    Command syntax conventions Command syntax in this manual follows these conventions: command Commands are printed in bold. option, option Command options are printed in bold. argument, arg Arguments. Optional element. variable Variables are printed in italics. In the help pages, values are underlined or enclosed in angled brackets <...

  • Page 69: Additional Information

    Additional information This section lists additional Brocade and industry-specific documentation that you might find helpful. Brocade resources To get up-to-the-minute information, go to http://my.brocade.com and register at no cost for a user ID and password. For practical discussions about SAN design, implementation, and maintenance, you can obtain Building SANs with Brocade Fabric Switches through: http://www.amazon.com For additional Brocade documentation, visit the Brocade Web site:...

  • Page 70: Document Feedback

    2. Switch Serial Number The switch serial number and corresponding bar code are provided on the serial number label, as illustrated below.: *FT00X0054E9* FT00X0054E9 • The serial number label is located as follows: • Brocade 300, 4100, 4900, 5100, 5300, 7500, 7800, 8000, and Brocade Encryption Switch—On the switch ID pull-out tab located inside the chassis on the port side on the left •...

  • Page 71: Chapter 1 Introduction To System Messages

    Chapter Introduction To System Messages In this chapter • Overview of System Messages ........1 •...

  • Page 72: Event Auditing

    Overview of System Messages • Trace dump, first-time failure detection capture (FFDC), and core dump files can be uploaded to the FTP server using the supportSave command. • It is recommended to configure the syslogd facility as a management tool for error logs. This is particularly important for dual-domain switches because the syslogd facility saves messages from two logical switches as a single file and in sequential order.

  • Page 73: System Logging Daemon (Syslogd)

    Overview of System Messages • FCIP-related messages: FCIP 1002 and 1003 • FICU-related messages: FICU 1011 and 1012 • FW-related messages: FW - 3001 • HTTP configuration messages: HTTP-1002, 1003 • IPAD-related messages: IPAD 1002 • PORT related messages: PORT 1006 - 1009 •...

  • Page 74: System Console

    Viewing and Configuring System Message Logs System Console The system console displays messages only through the serial port. If you log in to a switch through the Ethernet port or modem port, you will not receive system console messages. The system console displays system messages, Audit messages (if enabled) and panic dump messages.
  • Page 75 Viewing and Configuring System Message Logs TABLE 2 Commands for Viewing or Configuring the System Parameters and Logs Command Description agtCfgDefault Resets the SNMP recipients to default values. agtCfgSet Modifies the SNMP agent configuration. agtCfgShow Displays the current SNMP agent configuration. auditCfg Configures the audit message log.

  • Page 76: Viewing System Messages From Web Tools

    Viewing and Configuring System Message Logs TABLE 2 Commands for Viewing or Configuring the System Parameters and Logs (Continued) Command Description supportFfdc Enables and disables FFDC (first failure data capture). supportSave Collects RASLog, trace files, and supportShow (active CP only) information for the local CP and then transfers the files to an FTP server.

  • Page 77: Viewing System Messages One Message At A Time

    Viewing and Configuring System Message Logs 2004/07/28-17:04:51, [EM-1055], 3,, WARNING, switch, Media 27: Port media incompatible. Reason: Configured port speed. 2004/07/28-17:04:54, [FABR-1001], 4,, WARNING, switch, port 4, ELP rejected by the other switch 2004/07/28-17:05:06, [FW-1050], 5,, WARNING, switch, Sfp Supply Voltage 0, is below low boundary(High=3600, Low=3150).

  • Page 78: Reading A Ras System Message

    Reading a RAS System Message 2. Verify the configuration: switch:admin> auditcfg --show Audit filter is enabled. 1-ZONE 2-SECURITY 3-CONFIGURATION 4-FIRMWARE 5-FABRIC 3. Enable the audit feature: switch:admin> auditcfg --enable Audit filter is enabled. 4. Configure up to six syslog servers to receive the audit events that will be generated through syslog (procedure will vary depending on server type).
  • Page 79 Reading a RAS System Message TABLE 3 System Message Field Description (Continued) Example Variable Name Description [EM-1031] Message Module The message module and number. These values uniquely identify and Message each message in the Fabric OS and reference the cause and Number actions recommended in this manual.

  • Page 80: Audit Event Messages

    Reading a RAS System Message Audit Event Messages Compared to RASLog error messages, messages flagged as AUDIT provide additional user and system-related information of interest for post event auditing and problem determination. Audit event message format: AUDIT, <timestamp>, [<Event ID>], <Severity>, <Event Class>, <User ID>/<Role>/<IP address>/<Interface>/<app name>.

  • Page 81: Message Severity Levels

    Responding to a System Message TABLE 4 Audit Message Field Description (Continued) Example Variable Name Description Switch name or chassis The defined switch name or the chassis name of the switchname name, depending on switch. This value is truncated if it is over 16 the action;...

  • Page 82: Looking Up A System Message

    Responding to a System Message Looking Up a System Message Error messages in this manual are arranged alphabetically. To look up an error message, copy down the module (see Table 5 on page 14) and the error code and compare this with the Table of Contents to determine the location of the information for that error message.

  • Page 83: Support

    System Module Descriptions Support Fabric OS creates a number of files that can help support personnel troubleshoot and diagnose a problem. This section describes those files and how to access and/or save the information for support personnel. Panic Dump and Core Dump Files The Fabric OS creates panic dump files and core files when there are problems in the Fabric OS kernel.
  • Page 84 System Module Descriptions Table 5 provides a summary of the system modules for which messages are documented in this reference guide; the system modules are listed alphabetically by name. TABLE 5 System Module Descriptions System Description Module Access Gateway allows multiple hosts (or HBAs) to access the fabric using fewer physical ports. Access Gateway mode transforms the Brocade switches as well as embedded switches into a device management tool that is compatible with different types of fabrics, including Brocade-, Cisco-, and McDATA-based fabrics.
  • Page 85 System Module Descriptions TABLE 5 System Module Descriptions (Continued) System Description Module The environmental monitor (EM) manages and monitors the various field replaceable units (FRUs), including the port cards, control processor (CP) blades, blower assemblies, power supplies, and world wide name (WWN) cards. EM controls the state of the FRUs during system startup, hot-plug sequences, and fault recovery.
  • Page 86 System Module Descriptions TABLE 5 System Module Descriptions (Continued) System Description Module The Fabric OS state synchronization framework provides facilities by which the active control processor (CP) can synchronize with the standby CP, enabling the standby CP to take control of the switch nondisruptively during failures and software upgrades.
  • Page 87 System Module Descriptions TABLE 5 System Module Descriptions (Continued) System Description Module KSWD The kernel software watchdog (KSWD) watches daemons for unexpected terminations and “hang” conditions and informs the HAM module to take corrective actions such as failover or reboot. The following daemons are monitored by KSWD: •...
  • Page 88 System Module Descriptions TABLE 5 System Module Descriptions (Continued) System Description Module MFIC MS-FICON messages relate to Fibre Connection (FICON) installations. Fibre Connection control unit port (FICON-CUP) messages are displayed under the FICU module. MPTH Multicast path uses the shortest path first (SPF) algorithm to dynamically compute a broadcast tree. Message queues are used for interprocess communication.
  • Page 89 System Module Descriptions TABLE 5 System Module Descriptions (Continued) System Description Module The reliable commit service daemon generates log entries when it receives a request from the zoning, security, or management server for passing data messages to switches in the fabric. RCS then requests reliable transport write and read (RTWR) to deliver the message.
  • Page 90 System Module Descriptions TABLE 5 System Module Descriptions (Continued) System Description Module TRCK The track change feature tracks the following events: Turning on or off the track change feature CONFIG_CHANGE LOGIN LOGOUT FAILED_LOGIN If any of these events occur, a message is sent to the system message log. Additionally, if the SNMP trap option is enabled, an SNMP trap is also sent.
  • Page 91 Section RASLog Messages This section provides the RASLog messages, including: • AG System Messages ......... . . 25 •...
  • Page 92 • FCR System Messages ......... 205 •...
  • Page 93 • ONM System Messages ........453 •...

  • Page 95: Ag System Messages

    Chapter AG System Messages AG-1001 Message <timestamp>, [AG-1001], <sequence-number>,, ERROR, <system-name>, N_Port ID virtualization (NPIV) is not supported by fabric port connected to port <port>. Probable Cause N_Port ID virtualization (NPIV) capability is not supported by the fabric port to which the Access Gateway is connected.
  • Page 96 AG-1004 Severity WARNING AG-1004 Message <timestamp>, [AG-1004], <sequence-number>,, ERROR, <system-name>, Invalid response to fabric login (FLOGI) request from the fabric for N_Port <port>. Probable Cause Indicates the fabric sent an invalid response to the FLOGI Extended Link Service (ELS) for the specified N_Port.
  • Page 97 AG-1008 Recommended Check the connectivity between the Access Gateway N_Port and the fabric switch port. Action Severity WARNING AG-1008 Message <timestamp>, [AG-1008], <sequence-number>,, WARNING, <system-name>, Invalid port login (PLOGI) response from the fabric on the N_Port <port>. Probable Cause Indicates the fabric switch management server did not accept the N_Port Login (PLOGI) request sent by the Access Gateway.
  • Page 98 AG-1011 AG-1011 Message <timestamp>, [AG-1011], <sequence-number>,, WARNING, <system-name>, Sending FDISC failed on N_Port <port>. Probable Cause Indicates there was a failure sending discover F_Port service parameter request from the Access Gateway to the fabric switch. Recommended Check the configuration of the fabric switch connected to the Access Gateway. Action If the message persists, run the supportFtp command (as needed) to set up automatic FTP transfers;...
  • Page 99 AG-1015 Severity INFO AG-1015 Message <timestamp>, [AG-1015], <sequence-number>,, WARNING, <system-name>, Unable to find online N_Ports to connect to the fabric. Probable Cause Indicates either no other N_Port is configured or all N_Ports are currently offline. Recommended Check whether or not any other N_Port is configured. Action If the message persists, run the supportFtp command (as needed) to set up automatic FTP transfers;...
  • Page 100 AG-1019 Recommended Run the switchShow command to display the status of all ports in the system. Run the portCfgShow Action command to display a list of ports currently configured as N_Ports. Ensure that the host is connected to an F_port. Severity ERROR AG-1019...
  • Page 101 AG-1022 AG-1022 Message <timestamp>, [AG-1022], <sequence-number>,, INFO, <system-name>, F_Port <fport> is failed over to its preferred N_Port <nport>. Probable Cause Indicates the specified F_Port is failing over to its preferred N_Port. Recommended Run the ag --mapshow command to display the updated F_Port-to-N_Port mapping. Action Severity INFO...
  • Page 102 AG-1026 AG-1026 Message <timestamp>, [AG-1026], <sequence-number>,, WARNING, <system-name>, Unable to handle the login request on port <port> due to insufficient resources. Probable Cause Indicates there are insufficient resources. Recommended Run configure CLI on AG switch and increase the number of allowed logins on this port. Action If the message persists, run the supportFtp (as needed) to set up automatic FTP transfers;...
  • Page 103 AG-1030 Severity WARNING AG-1030 Message <timestamp>, [AG-1030], <sequence-number>,, WARNING, <system-name>, N_Port ID: <port> has been determined to be unreliable. Probable Cause Indicates that the port goes online and offline very often. Recommended No action is required. Action Severity WARNING AG-1031 Message <timestamp>, [AG-1031], <sequence-number>,, WARNING, <system-name>, Loop Detected for device with Port WWN <port>...
  • Page 104 AG-1034 Severity INFO AG-1034 Message <timestamp>, [AG-1034], <sequence-number>,, INFO, <system-name>,F_Port cannot accept any more logins (<fport>) . Probable Cause Indicates that the F_Port has already logged in the maximum number of devices. Recommended No action is required. Action Severity INFO AG-1035 Message <timestamp>, [AG-1035], <sequence-number>,, INFO, <system-name>,Device cannot...
  • Page 105 AG-1037 Recommended If the switchshow command on the connected fabric switch port displays 'Persistently disabled: Action Area has been acquired', then check the cabling on the AG. All trunked ports in a single trunk should belong to the same ASIC Port Group. Severity INFO Fabric OS Message Reference...
  • Page 106 AG-1037 Fabric OS Message Reference 53-1001338-01...

  • Page 107: An System Messages

    Chapter AN System Messages AN-1001 Message <timestamp>, [AN-1001], <sequence-number>,, ERROR, <system-name>, Failed to allocate memory: <function name> Probable Cause Indicates that the specified function has failed to allocate memory. Recommended Check memory usage on the switch using the memShow command. Restart or power cycle the Action switch.
  • Page 108 AN-1003 Fabric OS Message Reference 53-1001338-01...

  • Page 109: Auth System Messages

    Chapter AUTH System Messages AUTH-1001 Message <timestamp>, [AUTH-1001], <sequence-number>,, INFO, <system-name>, <Operation type> has been successfully completed. Probable Cause Indicates that the secret database operation has been updated using the secAuthSecret command. The values for Operation type can be “set” or “remove”. Recommended No action is required.
  • Page 110 AUTH-1004 AUTH-1004 Message <timestamp>, [AUTH-1004], <sequence-number>,, ERROR, <system-name>, Failed to set <data type> type to <setting value>. Probable Cause Indicates that the authUtil command has failed to set the authentication configuration value. The data type is either authentication type, DH group type, or policy type. Recommended Retry the authUtil command.
  • Page 111 AUTH-1008 Recommended Run the authUtil command to make sure the local switch supports the specified protocols: Fibre Action channel authentication protocol (FCAP) or Diffie Hellman - challenge handshake authentication protocol (DH-CHAP). Severity ERROR AUTH-1008 Message <timestamp>, [AUTH-1008], <sequence-number>,, ERROR, <system-name>, No security license, operation failed.
  • Page 112 AUTH-1012 AUTH-1012 Message <timestamp>, [AUTH-1012], <sequence-number>,, WARNING, <system-name>, Authentication <code> is rejected: port <port number> explain <explain code> reason <reason code>. Probable Cause Indicates that an authentication is rejected because the remote entity does not support authentication. Recommended Make sure the entity at the other end of the link supports authentication. Action Severity WARNING...
  • Page 113 AUTH-1017 Probable Cause This may relate to an internal failure. Recommended Copy the message, collect switch information using the supportShow command, and contact your Action switch service provider. Severity ERROR AUTH-1017 Message <timestamp>, [AUTH-1017], <sequence-number>,, ERROR, <system-name>, Invalid value to start authentication request: port <port number>, operation code <operation code>.
  • Page 114 AUTH-1022 If the message persists, run the supportFtp command (as needed) to set up automatic FTP transfers; then run the supportSave command and contact your switch service provider. Severity INFO AUTH-1022 Message <timestamp>, [AUTH-1022], <sequence-number>,, ERROR, <system-name>, Failed to extract <data type> from <message> payload: port <port number>. Probable Cause Indicates that the authentication process failed to extract a particular value from the receiving payload.
  • Page 115 AUTH-1025 Severity ERROR AUTH-1025 Message <timestamp>, [AUTH-1025], <sequence-number>,, ERROR, <system-name>, Failed to get <data type> during <authentication phase>: port <port number>. Probable Cause Indicates that the authentication process failed to get the expected information during the specified authentication phase. Recommended Usually this problem is transient.
  • Page 116 AUTH-1028 If the message persists, run the supportFtp command (as needed) to set up automatic FTP transfers; then run the supportSave command and contact your switch service provider. Severity ERROR AUTH-1028 Message <timestamp>, [AUTH-1028], <sequence-number>,, ERROR, <system-name>, Failed to allocate <data type> for <operation phase>: port <port number>. Probable Cause Indicates that the authentication process failed because the system is low on memory.
  • Page 117 AUTH-1031 Recommended Usually this problem is transient. The authentication might fail. Action Reinitialize authentication using the portDisable and portEnable commands or the switchDisable and switchEnable commands. If the message persists, run the supportFtp command (as needed) to set up automatic FTP transfers;...
  • Page 118 AUTH-1034 Recommended Add the entity's world wide name (WWN) to the SCC policy and reinitialize authentication by using Action the portDisable and portEnable commands or the switchDisable and switchEnable commands. Severity ERROR AUTH-1034 Message <timestamp>, [AUTH-1034], <sequence-number>,, ERROR, <system-name>, Failed to validate name <entity name>...
  • Page 119 AUTH-1037 Severity ERROR AUTH-1037 Message <timestamp>, [AUTH-1037], <sequence-number>,, ERROR, <system-name>, Failed to <operation type> response for <authentication message>: init_len <data length>, resp_len <data length>, port <port number>. Probable Cause Indicates that a Diffie Hellman - challenge handshake authentication protocol (DH-CHAP) authentication operation failed on the specified port due to mismatched response values between two entities.
  • Page 120 AUTH-1040 Severity ERROR AUTH-1040 Message <timestamp>, [AUTH-1040], <sequence-number>,, INFO, <system-name>, Reject authentication on port <Port Number>, because switch authentication policy is set to OFF. Probable Cause Indicates that the local switch has rejected the authentication because the switch policy is turned off.
  • Page 121 AUTH-1043 If the message persists, run the supportFtp command (as needed) to set up automatic FTP transfers; then run the supportSave command and contact your switch service provider. Severity ERROR AUTH-1043 Message <timestamp>, [AUTH-1043], <sequence-number>,, ERROR, <system-name>, Failed to enforce device authentication mode:<Device Auth Policy>(error: <Reason Code>). Probable Cause Indicates that the Kernel mode setting for F_Port authentication failed.
  • Page 122 AUTH-1045 Fabric OS Message Reference 53-1001338-01...

  • Page 123: Anv System Messages

    DRAFT: BROCADE CONFIDENTIAL Chapter ANV System Messages ANV-1001 Message <timestamp>, [ANV-1001], <sequence-number>,, ERROR, <system-name>, Port <port number> port fault. Please change the SFP or check cable. Probable Cause Indicates a deteriorated small form-factor pluggable (SFP), an incompatible SFP pair, or a faulty cable between peer ports.
  • Page 124 DRAFT: BROCADE CONFIDENTIAL ANV-1004 ANV-1004 Message <timestamp>, [ANV-1004], <sequence-number>,, ERROR, <system-name>, <slot number>,<chip index>: Invalid DMA ch pointer, chan:<Channel number>, good_addr:0x<Good address> bad_addr:0x<Bad address>. Probable Cause Indicates an internal error in the application-specific integrated circuit (ASIC) hardware that may degrade data traffic. Recommended Restart the system at the next maintenance window.
  • Page 125 DRAFT: BROCADE CONFIDENTIAL ANV-1007 Severity CRITICAL Fabric OS Message Reference 53-1001338-01...
  • Page 126 DRAFT: BROCADE CONFIDENTIAL ANV-1007 Fabric OS Message Reference 53-1001338-01...

  • Page 127: Bksw System Messages

    Chapter BKSW System Messages BKSW-1003 Message <timestamp>, [BKSW-1003], <sequence-number>,, WARNING, <system-name>, kSWD: <warning message>. Probable Cause Indicates a warning state within the system. A critical application error was reported in the watchdog subsystem. This message is used to convey information regarding the state of the system. Refer to the string at the end of the error message for specific information.
  • Page 128 BKSW-1003 Fabric OS Message Reference 53-1001338-01...

  • Page 129: Bl System Messages

    Chapter BL System Messages BL-1000 Message <timestamp>, [BL-1000], <sequence-number>,, INFO, <system-name>, Initializing ports... Probable Cause Indicates that the switch has started initializing the ports. Recommended No action is required. Action Severity INFO BL-1001 Message <timestamp>, [BL-1001], <sequence-number>,, INFO, <system-name>, Port initialization completed.
  • Page 130 BL-1003 Severity CRITICAL BL-1003 Message <timestamp>, [BL-1003], <sequence-number>, FFDC, CRITICAL, <system-name>, Faulting blade in slot <slot number> Probable Cause Indicates a faulty blade in the specified slot number. Recommended Make sure that the blade is seated correctly. If the blade is seated correctly, restart or power cycle Action the blade.
  • Page 131 BL-1007 BL-1007 Message <timestamp>, [BL-1007], <sequence-number>,, WARNING, <system-name>, blade #<blade number>: blade state is inconsistent with EM. bl_cflags 0x<blade control flags>, slot_on <slot_on flag>, slot_off <slot_off flag>, faulty <faulty flag>, status <blade status>. Probable Cause Indicates that a failover occurred while a blade was initializing on the previously active control processor (CP).
  • Page 132 BL-1010 If the message persists, replace the blade. Severity CRITICAL BL-1010 Message <timestamp>, [BL-1010], <sequence-number>,, WARNING, <system-name>, Blade in slot <slot number> inconsistent with the hardware settings. Probable Cause Indicates that a failover occurred while some hardware changes were being made on the previously active control processor (CP) (such as changing the domain ID).
  • Page 133 BL-1013 Probable Cause Indicates that the port generated an excessive number of interrupts that might prove unrecoverable to the switch operation. The port is disabled to prevent the control processor (CP) from becoming too busy. The bport is the blade port; this number might not correspond to a user port number.
  • Page 134 BL-1015 Run the diagPost command to ensure that Power-On Self-Test (POST) is enabled. If there is a hardware error, if the slotPowerOff or slotPowerOn fails on the bladed switch or if errors are encountered again: • On the Brocade 24000, and 48000, replace the blade field-replaceable unit (FRU). •...
  • Page 135 BL-1017 Run the systemVerification command to verify that the blade does not have hardware problems. To run this command root access is required. Run the diagPost command to ensure that Power-On Self-Test (POST) is enabled. Refer to the Fabric OS Command Reference for more information on these commands.
  • Page 136 BL-1020 BL-1020 Message <timestamp>, [BL-1020], <sequence-number>,, CRITICAL, <system-name>, Switch timed out initializing the chips. Probable Cause Indicates that the switch has failed to initialize the application-specific integrated circuit (ASIC) chips. Recommended Restart or power cycle the switch. Action Run the systemVerification command to verify that the switch does not have hardware problems. To run this command root access is required.
  • Page 137 BL-1023 Severity CRITICAL BL-1023 Message <timestamp>, [BL-1023], <sequence-number>,, CRITICAL, <system-name>, Blade in <slot number> slot was reset before blade init completed. As a result the blade is faulted. Probable Cause Indicates that the blade was reset before the initialization completed. Recommended Restart or power cycle the blade.
  • Page 138 BL-1027 Probable Cause Indicates that an internal port went offline during the warm recovery of the switch. The switch will reboot and start a cold recovery. Recommended Collect supportSave information, then restart the switch and run the diagPost command to ensure Action Power-On Self-Test (POST) is enabled.
  • Page 139 BL-1030 BL-1030 Message <timestamp>, [BL-1030], <sequence-number>,, INFO, <system-name>, All GigE/FCIP Virtualization/FC Fastwrite ports on the switch will be reset as part of the firmware upgrade. Probable Cause Indicates that a recent firmware upgrade caused the switch's internal processor firmware to be upgraded and resulted in the cold upgrade.
  • Page 140 BL-1034 Probable Cause Indicates that the system timed out while waiting for disable messages from the user ports after disabling the ports. Recommended Restart or power cycle the blade. Run the systemVerification command to verify that the blade does Action not have hardware problems.
  • Page 141 BL-1037 BL-1037 Message <timestamp>, [BL-1037], <sequence-number>,, CRITICAL, <system-name>, Faulting chip in slot = <slot number>, miniS = <miniS number>,port = <port number> due to BE/BI port fault. Probable Cause Indicates a fault on the chip and that all ports on the chip have been disabled. Recommended No action is required.
  • Page 142 BL-1039 Fabric OS Message Reference 53-1001338-01...

  • Page 143: Bll System Messages

    Chapter BLL System Messages BLL-1000 Message <timestamp>, [BLL-1000], <sequence-number>, FFDC, CRITICAL, <system-name>, ASIC driver detected Slot <slot number> port <port number> as faulty (reason: <reason>) Probable Cause Indicates a blade regulation problem was reported on the specified slot number. The blade is faulted.
  • Page 144 BLL-1000 Severity CRITICAL Fabric OS Message Reference 53-1001338-01...

  • Page 145: Bls System Messages

    Chapter BLS System Messages BLS-1000 Message <timestamp>, [BLS-1000], <sequence-number>,, ERROR, <system-name>, <command name> of GE <port number> failed. Please retry the command. Data: inst=<ASIC instance> st=<ASIC initializing state> rsn=<reason code> fn=<message function> oid=<ASIC ID>. Probable Cause Indicates that the hardware is not responding to a command request, possibly because it is busy. Recommended Retry the command.
  • Page 146 BLS-1004 Probable Cause Indicates that an IPsec or IKE policy was deleted and the configuration file was updated. Recommended No action is required. Action Severity INFO BLS-1004 Message <timestamp>, [BLS-1004], <sequence-number>,, INFO, <system-name>, Tape Read Pipelining is being disabled slot <slot number> port <user port index> tunnel <The configured tunnel ID (0-7)>.

  • Page 147: Bm System Messages

    Chapter BM System Messages BM-1001 Message <timestamp>, [BM-1001], <sequence-number>,, ERROR, <system-name>, BM protocol version <Protocol version> in slot <Slot number>. Probable Cause Indicates that the firmware running on the control processor (CP) cannot communicate with the application processor (AP) blade in the indicated slot and determine the AP blade's firmware version.
  • Page 148 BM-1004 Recommended Use the slotPowerOff and slotPowerOn commands or reseat the affected blade. Action Severity WARNING BM-1004 Message <timestamp>, [BM-1004], <sequence-number>,, INFO, <system-name>, Blade firmware <Blade firmware> on slot <Slot> is not consistent with system firmware <System firmware>. Auto-leveling blade firmware to match system firmware. Probable Cause Indicates the policy of the specified blade is to auto-level the blade firmware to the system firmware.
  • Page 149 BM-1007 BM-1007 Message <timestamp>, [BM-1007], <sequence-number>,, INFO, <system-name>, If set, clear EX/VEX/FC Fastwrite configuration for all ports for blade in slot <Slot number> Probable Cause Indicates the specified blade was detected for the first time after an FR4-18i was previously configured in the same slot.
  • Page 150 BM-1053 Severity INFO BM-1053 Message <timestamp>, [BM-1053], <sequence-number>,, WARNING, <system-name>, Failed to establish connection between CP and Application Processor. Faulting switch. Probable Cause Indicates the control processor (CP) could not establish a connection with the application processor to communicate. Recommended On the Brocade 7500 or 7600, turn off and turn on all the primary power to power-cycle the unit.
  • Page 151 BM-1058 Probable Cause Indicates the policy of the specified switch is to persistently disable all ports the first time the AP is detected. This may be caused by one of the following: • The AP was detected for the first time on this switch. •...
  • Page 152 BM-1058 Fabric OS Message Reference 53-1001338-01...

  • Page 153: C2 System Messages

    Chapter C2 System Messages C2-1001 Message <timestamp>, [C2-1001], <sequence-number>,, ERROR, <system-name>, Port <port number> port faulted due to SFP validation failure. Please check if the SFP is valid for the configuration. Probable Cause Indicates a deteriorated SFP, an incompatible SFP pair, or a faulty cable between the peer ports. Recommended Verify that you are using compatible SFPs on the peer ports.
  • Page 154 C2-1006 C2-1006 Message Message <timestamp>, [C2-1006], <sequence-number>,, WARNING, <system-name>, <slot number>,<chip index>: Internal link errors have been reported, no hardware faults identified, continuing to monitor for errors: fault1:<fault1_cnt>, fault2:<fault2_cnt> thresh1:0x<threshold_used>. Probable Cause Indicates a warning that some internal link errors have been detected. These can be normal in an active running system.
  • Page 155 C2-1009 C2-1009 Message Message <timestamp>, [C2-1009], <sequence-number>,, WARNING, <system-name>, <slot number>, <port number><blade port number>: portcfglongdistance vc_translation_link_init = 1 overwrites fill word IDLE. ARB will be used on the link. Probable Cause Indicates portcfglongdistance vc_translation_link_init 1 overwrites fill word IDLE. ARB will be used on the link.
  • Page 156 C2-1010 Fabric OS Message Reference 53-1001338-01...

  • Page 157: Cdr System Messages

    Chapter CDR System Messages CDR-1001 Message <port <timestamp>, [CDR-1001], <sequence-number>,, ERROR, <system-name>, Port number> port fault. Please change the SFP or check cable Probable Cause Indicates a deteriorated small form-factor pluggable (SFP), an incompatible SFP pair, a faulty cable between peer ports, or that the port speed configuration does not match the capability of the SFP. Recommended Ensure that you are using compatible SFPs on the peer ports.
  • Page 158 CDR-1004 Severity CRITICAL CDR-1004 Message <timestamp>, [CDR-1004], <sequence-number>, FFDC, ERROR, <system-name>, <slot number>, <chip index>: invalid DMA ch pointer, chan:<Channel number>, good_addr:0x<Good address>, bad_addr:0x<Bad address>. Probable Cause Indicates an internal error in the application specific integrated circuit (ASIC) hardware that may degrade data traffic.

  • Page 159: Cee Config System Messages

    DRAFT: BROCADE CONFIDENTIAL Chapter CEE CONFIG System Messages CCFG-1001 Message <timestamp>, [CCFG-1001], <sequence-number>,, ERROR, <system-name>, Failed to initialize <module>, rc = <error>. Probable Cause Indicates that initialization of a module within the Converged Enhanced Ethernet (CEE) configuration management daemon has failed. Recommended Download a new firmware version using the firmwareDownload command.
  • Page 160 DRAFT: BROCADE CONFIDENTIAL CCFG-1005 Probable Cause Indicates that the startup configuration has been moved or deleted, hence replaying the system configuration has failed. Recommended Use the copy file startup-config command to restore the startup configuration from any backup Action retrieved on the server. Severity ERROR CCFG-1005...
  • Page 161 DRAFT: BROCADE CONFIDENTIAL CCFG-1009 Probable Cause Indicates that the CMSH initialization has failed. Recommended No action is required. Action Severity ERROR CCFG-1009 Message <timestamp>, [CCFG-1009], <sequence-number>,, INFO, <system-name>, Successfully copied to <destination>. Probable Cause Indicates that the file has been successfully copied to the destination. Recommended No action is required.
  • Page 162 DRAFT: BROCADE CONFIDENTIAL CCFG-1012 Probable Cause Indicates that the mentioned slot has failed to reach the Online state within the specified time after system ready event. Recommended Run the slotpoweroff command followed by the slotpoweron command on the slot to retry bringing Action the slot online.

  • Page 163: Cer System Messages

    Chapter CER System Messages CER-1001 Message <timestamp>, [CER-1001], <sequence-number>,, ERROR, <system-name>, HA Sync broken, since standby Advanced Performance Tuning module does not support FICON Management Server (FMS). Probable Cause Indicates that the high-availability (HA) synchronization between the active and standby control processors (CPs) is broken, because there is downlevel firmware loaded on the standby CP.
  • Page 164 CER-1001 Fabric OS Message Reference 53-1001338-01...

  • Page 165: Chassis System Messages

    Chapter CHASSIS System Messages CHASSIS-1002 Message <timestamp>, [CHASSIS-1002], <sequence-number>,, ERROR, <system-name>, ki_gd_register_action failed with rc =<ret val>. Probable Cause Indicates an internal error. Recommended For a bladed system, run the slotPowerOff command and slotPowerOn command on the blade to Action recover the system.
  • Page 166 CHASSIS-1005 CHASSIS-1005 Message <timestamp>, [CHASSIS-1005], <sequence-number>,, ERROR, <system-name>, Diag attach failed during recovery, disabling slot = <slot number>. Probable Cause Indicates that the Diag blade attach has failed during failover or recovery. Recommended On a Brocade 24000 or 48000 switch, run the slotPowerOff command followed by the slotPowerOn Action command.

  • Page 167: Cnm System Messages

    Chapter CNM System Messages CNM-1001 Message <timestamp>, [CNM-1001], <sequence-number>,, ERROR, <system-name>, Failed to allocate memory: <function name>. Probable Cause Indicates that the specified function failed to allocate memory. Recommended Check memory usage on the switch using the memShow command. Reboot or power cycle the Action switch.
  • Page 168 CNM-1005 Probable Cause Indicates that the Crypto service is enabled or disabled on the switch. Recommended No action is required. Action Severity INFO CNM-1005 Message <timestamp>, [CNM-1005], <sequence-number>,, INFO, <system-name>, Posting event CNM_EVT_GRP_LEADER_ELECTED Name [<nodeName>], WWN [<WWn>]. Probable Cause Indicates that the cluster encryption group (EG) leader is elected. Recommended No action is required.
  • Page 169 CNM-1009 Recommended No action is required. Action Severity INFO CNM-1009 Message <timestamp>, [CNM-1009], <sequence-number>,, INFO, <system-name>, Posting event CNM_EVT_STANDALONE_MODE. Probable Cause Indicates that the node is in standalone mode. Recommended No action is required. Action Severity INFO CNM-1010 Message <timestamp>, [CNM-1010], <sequence-number>,, INFO, <system-name>, Posting event CNM_EVT_CLUSTER_UDATA_UPDATE cid [<client id>], ulen [<udata len>].
  • Page 170 CNM-1013 Recommended No action is required. Action Severity INFO CNM-1013 Message <timestamp>, [CNM-1013], <sequence-number>,, INFO, <system-name>,Posting event GL Node Split condition, isolating peer GL node <nodeName>. Probable Cause Indicates that the encryption group (EG) is split. Recommended No action is required. Action Severity INFO...
  • Page 171 CNM-1017 Recommended No action is required. Action Severity INFO CNM-1017 Message <timestamp>, [CNM-1017], <sequence-number>,, INFO, <system-name>,Got JOIN REQUEST from un-recognized GL node [<rxglname>], configured GL node is [<glname>]. Probable Cause Indicates a join request was received from an invalid group leader (GL) node. Recommended No action is required.
  • Page 172 CNM-1021 Probable Cause Indicates that the Node Admission Control has failed. Recommended No action is required. Action Severity INFO CNM-1021 Message <timestamp>, [CNM-1021], <sequence-number>,, INFO, <system-name>, Failed to sign the node authentication message, admission control might fail. Probable Cause Indicates that the Node Admission Control has failed. Recommended No action is required.
  • Page 173 CNM-1025 Probable Cause Indicates an operation is not required on a group leader (GL) node. Recommended No action is required. Action Severity INFO CNM-1025 Message <timestamp>, [CNM-1025], <sequence-number>,, INFO, <system-name>, Operation not allowed, as member is active with the Cluster. Eject member node and retry. Probable Cause Indicates an operation is not allowed because a member node is active with the cluster.
  • Page 174 CNM-1029 Probable Cause Indicates that the certificate file for the node already exists. Recommended No action is required. Action Severity INFO CNM-1029 Message <timestamp>, [CNM-1029], <sequence-number>,, WARNING, <system-name>, Certfile <cfname> content does not match the cert sent by GL. Probable Cause Indicates that the contents of the node's certificate file is different from the certificate file sent by the group leader (GL) node.
  • Page 175 CNM-1033 Probable Cause Indicates that there is a size mismatch between a node's certificate file and the certificate file received from the group leader. Recommended No action is required. Action Severity WARNING CNM-1033 Message <timestamp>, [CNM-1033], <sequence-number>,, WARNING, <system-name>, Some of the defined nodes in the Encryption Group are not ONLINE.
  • Page 176 CNM-1037 Probable Cause Indicates an event is being posted to indicate that the cluster is in a converged state. Recommended No action is required. Action Severity INFO CNM-1037 Message <timestamp>, [CNM-1037], <sequence-number>,, INFO, <system-name>, Split-Brain Arbitration lost!, minority GL Node, remote:local [<rem_count>:<loc_gl_ncount>]. Probable Cause Indicates that split arbitration is lost.
  • Page 177 CNM-1041 Recommended No action is required. Action Severity INFO CNM-1041 Message <timestamp>, [CNM-1041], <sequence-number>,, INFO, <system-name>, Updating persistent Cluster DB, please avoid powering off the switch. Probable Cause Indicates the system is updating the persistent database. Recommended No action is required. Action Severity INFO...
  • Page 178 CNM-1045 Recommended No action is required. Action Severity ERROR CNM-1045 Message <timestamp>, [CNM-1045], <sequence-number>,, ERROR, <system-name>, Member node <wwn> is having dual IP stack.Registering member node with dual IP in an EG with only IPV6 is not allowed. Probable Cause Indicates that the member node with a dual IP stack was registered with an IPV6 encryption group (EG).
  • Page 179 CNM-1049 Recommended No action is required. Action Severity INFO CNM-1049 Message <timestamp>, [CNM-1049], <sequence-number>,, ERROR, <system-name>, Failed to define node, Node Name <string>. Probable Cause Indicates the system failed to define the node object. Recommended No action is required. Action Severity ERROR CNM-1050...
  • Page 180 CNM-1053 Recommended No action is required. Action Severity ERROR CNM-1053 Message <timestamp>, [CNM-1053], <sequence-number>,, ERROR, <system-name>, Node is already a registered member of another EG. First eject the current node <nodename> from the existing EG and then try. Probable Cause Indicates that a mode is already a registered member of another EG.
  • Page 181 CNM-1057 Recommended No action is required. Action Severity INFO CNM-1057 Message <timestamp>, [CNM-1057], <sequence-number>,, INFO, <system-name>, Posting event CNM_EVT_ONLINE Slot <slot>, Wwn <wwn>, IP <ip>, flags <flags>. Probable Cause Indicates that the encryption engine (EE) is online in the encryption group (EG). Recommended No action is required.
  • Page 182 CNM-3003 Recommended No action is required. Action Severity INFO CNM-3003 Message <timestamp>, [CNM-3003],<sequence-number>,, INFO, <system-name>, Event: cryptocfg Status: success, Info: Membernode \<membernodeWWN>\ added to encryption group. Probable Cause Indicates a member node was added to an encryption group. Recommended No action is required. Action Severity INFO...
  • Page 183 CNM-3007 Recommended No action is required. Action Severity INFO CNM-3007 Message <timestamp>, [CNM-3007],<sequence-number>,, INFO, <system-name>, Event: cryptocfg Status: success, Info: Heartbeat timeout set to <hbtimeout>. Probable Cause Indicates that the heartbeat timeout value was set. Recommended No action is required. Action Severity INFO...
  • Page 184 CNM-3011 Recommended No action is required. Action Severity INFO CNM-3011 Message <timestamp>, [CNM-3011], <sequence-number>,, INFO, <system-name>, Event: cryptocfg Status: success, Info: Encryption group synchronized. Probable Cause Indicates an encryption group was synchronized. Recommended No action is required. Action Severity INFO Fabric OS Message Reference 53-1001338-01...

  • Page 185: Conf System Messages

    Chapter CONF System Messages CONF-1000 Message <timestamp>, [CONF-1000], <sequence-number>, AUDIT, INFO, <system-name>, configDownload completed successfully. <Info about the parameters and AD>. Probable Cause Indicates that the configDownload operation was initiated and completed successfully. The statement that follows, message strings, is the description of the classes of configuration parameters that were downloaded.
  • Page 186 CONF-1021 CONF-1021 Message <timestamp>, [CONF-1021], <sequence-number>,, INFO, <system-name>, configUpload not permitted <AD Number if AD is configured on the system>. Probable Cause Indicates a configUpload operation is not permitted. There are many possible causes. Recommended Check the error log, correct the error and rerun the configupload command. Action Severity INFO...
  • Page 187 CONF-1030 CONF-1030 Message <timestamp>, [CONF-1030], <sequence-number>,, WARNING, <system-name>, Configuration database full, data not committed (key:<Key of failed configuration data>. Probable Cause Indicates that the previous configuration commands have resulted in a database full condition. Configuration changes associated with the specified key have not been applied. Recommended Use the configure command and various other commands to erase configuration parameters no Action...
  • Page 188 CONF-1041 CONF-1041 Message <timestamp>, [CONF-1041], <sequence-number>,, INFO, <system-name>, configRemove failed. Probable Cause Indicates a configRemove error has occurred. Recommended Correct the error and try again. Action Severity INFO Fabric OS Message Reference 53-1001338-01...

  • Page 189: Ctap System Messages

    Chapter CTAP System Messages CTAP-1001 Message <timestamp>, [CTAP-1001], <sequence-number>,, INFO, <system-name>, Key acquisition for <Pool or Container> <Begins or Complete>. Probable Cause Indicates that a change in the tape pool database has triggered the key acquisition process for each pool. Recommended Do not start tape backup or restore operations involving tape pools until the process is complete.
  • Page 190 CTAP-1001 Fabric OS Message Reference 53-1001338-01...

  • Page 191: Cvlc System Messages

    Chapter CVLC System Messages CVLC-1001 Message <timestamp>, [CVLC-1001], <sequence-number>,, INFO, <system-name>, <Re-key type (First time encryption/Key expired/Manual)> re-key <Re-key action (started/completed/failed/cancelled)>, LUN SN: <LUN serial number>.\nContainer: <Target container name>, Initiator: <Initiator physical WWN>, LUN ID: <LUN ID>. Probable Cause Indicates the First time encryption, Key expired or Manual re-key operation is performed. The operation has been started, completed or cancelled.
  • Page 192 CVLC-1004 CVLC-1004 Message <timestamp>, [CVLC-1004], <sequence-number>,, INFO, <system-name>, Forceful encryption LUN removal while re-key session is still active.\nContainer: <Target container name>, Initiator: <Initiator physical WWN>, LUN ID: <LUN ID>. Probable Cause Indicates that the encryption LUN was forcefully removed while a re-key session was still active. Recommended No action is required.
  • Page 193 CVLC-1008 Recommended If you want to preserve the user data, use cryptocfg --modLUNpolicy -cleartext to convert to clear Action text LUN. Use cryptocfg ---modLUNpolicy -disable_allowdecrypt to disable decryption of existing data. Then try the LUN deletion again. Severity ERROR CVLC-1008 Message <timestamp>, [CVLC-1008], <sequence-number>,, ERROR, <system-name>, LUN discovery failure: <Discovery state>, Container: <Target container name>, Initiator:...
  • Page 194 CVLC-1011 CVLC-1011 Message <timestamp>, [CVLC-1011], <sequence-number>,, ERROR, <system-name>, Third party license is required for encryption LUN in third party mode.\nContainer: <Target container name>, Initiator: <Initiator physical WWN>, LUN ID: <LUN ID>. Probable Cause Indicates that the encryption LUN is configured with non-Brocade mode but there is no valid license.
  • Page 195 CVLC-1015 Recommended Use cryptocfg command to add the key ID, if available. Action Severity ERROR CVLC-1015 Message <timestamp>, [CVLC-1015], <sequence-number>,, ERROR, <system-name>, LUN is set to read only mode. Reason: <Reason for LUN is set to read only mode>.\nContainer: <Target container name>, Initiator: <Initiator physical WWN>, LUN ID: <LUN ID>. Probable Cause Indicates that the LUN is set as read-only because there is a conflict in the configuration.
  • Page 196 CVLC-1019 Probable Cause Indicates an informational event. Recommended No action is required. Action Severity INFO CVLC-1019 Message <timestamp>, [CVLC-1019], <sequence-number>,, ERROR, <system-name>, Metadata exists while data state is clear text.\nContainer: <Target container name>, Initiator: <Initiator physical WWN>, LUN ID: <LUN ID>. Probable Cause Indicates that the data state in the LUN configuration is in clear text state but metadata exists on the LUN.
  • Page 197 CVLC-1022 CVLC-1022 Message <timestamp>, [CVLC-1022], <sequence-number>,, INFO, <system-name>, User provided key ID <Key ID from metadata> is ignored while data state is clear text.\nContainer: <Target container name>, Initiator: <Initiator physical WWN>, LUN ID: <LUN ID>. Probable Cause Indicates that the key ID provided is ignored because the data state is clear text. Recommended No action is required.
  • Page 198 CVLC-1022 Fabric OS Message Reference 53-1001338-01...

  • Page 199: Cvlm System Messages

    Chapter CVLM System Messages CVLM-1001 Message <timestamp>, [CVLM-1001], <sequence-number>,, ERROR, <system-name>, Failed to allocate memory: <function name>. Probable Cause Indicates that the specified function has failed to allocate memory. Recommended Check the memory usage on the switch using the memShow command. Restart or power cycle the Action switch.
  • Page 200 CVLM-1005 Probable Cause Indicates that EE nodes in the cluster encryption group have different configurations. Recommended Synchronize the configuration in the cluster group using the cryptocfg --commit command. Refer to Action the Fabric OS Command Reference Manual for more information on this command. Severity WARNING CVLM-1005...
  • Page 201 CVLM-1009 Recommended Check the ISL port connected to the fabric. Action Severity WARNING CVLM-1009 Message <timestamp>, [CVLM-1009], <sequence-number>,, INFO, <system-name>, The member <EE node WWN><EE slot num> of HAC <HAC name> is in the fabric. Probable Cause Indicates that the member of HAC is found in the fabric. Recommended No action is required.
  • Page 202 CVLM-3001 Recommended No action is required. Action Severity INFO CVLM-3001 Message <timestamp>, [CVLM-3001], <sequence-number>,, INFO, <system-name>, Event: cryptocfg Status: success, Info: Failback mode set to <failbackmode>. Probable Cause Indicates that the failback mode was set. Recommended No action is required. Action Severity INFO...
  • Page 203 CVLM-3005 Recommended No action is required. Action Severity INFO CVLM-3005 Message <timestamp>, [CVLM-3005], <sequence-number>,, INFO, <system-name>, Event: cryptocfg Status: success, Info: Cluster member removed from HA cluster <HAClusterName>. Probable Cause Indicates an HA cluster member was removed from an HA cluster. Recommended No action is required.
  • Page 204 CVLM-3009 Recommended No action is required. Action Severity INFO CVLM-3009 Message <timestamp>, [CVLM-3009], <sequence-number>,, INFO, <system-name>, Event: cryptocfg Status: success, Info: Manual failback from EE <currentnodeWWN>/<currentSlot> to EE <newnodeWWN>/<newnodeSlot>. Probable Cause Indicates a manual failback was performed to an encryption engine. Recommended No action is required.
  • Page 205 CVLM-3013 Probable Cause Indicates an initiator was removed from a cryptotarget container. Recommended No action is required. Action Severity INFO CVLM-3013 Message <timestamp>, [CVLM-3013], <sequence-number>,, INFO, <system-name>, Event: cryptocfg Status: success, Info: LUN <LUNSpec>, attached through Initiator \<Initiator>\, added to crypto target container \<cryptoTargetContainer>\. Probable Cause Indicates a LUN was added to a cryptotarget container.
  • Page 206 CVLM-3016 CVLM-3016 Message <timestamp>, [CVLM-3016], <sequence-number>,, INFO, <system-name>, Event: cryptocfg Status: success, Info: Lun <LUNNumber>, attached through Initiator \<Initiator>\, in crypto target container \<cryptoTargetContainer>\ enabled. Probable Cause Indicates a LUN in a cryptotarget container was enabled. Recommended No action is required. Action Severity INFO...
  • Page 207 CVLM-3020 CVLM-3020 Message <timestamp>, [CVLM-3020], <sequence-number>,, INFO, <system-name>, Event: cryptocfg Status: success, Info: Manual rekey of LUN <LUNSpec> attached through Initiator \<Initiator>\ in crypto tgt container \<cryptoTargetContainer>\. Probable Cause Indicates a manual rekey of a LUN was performed. Recommended No action is required. Action Severity INFO...
  • Page 208 CVLM-3024 CVLM-3024 Message <timestamp>, [CVLM-3024], <sequence-number>,, INFO, <system-name>, Event: cryptocfg Status: success, Info: Transaction <transactionID> aborted. Probable Cause Indicates a transaction abort operation was performed. Recommended No action is required. Action Severity INFO Fabric OS Message Reference 53-1001338-01...

  • Page 209: Dauth System Messages

    Chapter DAUTH System Messages DOT1-1001 Message <timestamp>, [DOT1-1001], <sequence-number>,, INFO, 802.1X is enabled globally. Probable Cause Indicates that the 802.1X is enabled globally. Recommended No action is required. Action Severity INFO DOT1-1002 Message <timestamp>, [DOT1-1002], <sequence-number>,, INFO, 802.1X is disabled globally. Probable Cause Indicates that the 802.1X is disabled globally.
  • Page 210 DOT1-1005 Recommended No action is required. Action Severity INFO DOT1-1005 Message <timestamp>, [DOT1-1005], <sequence-number>,, INFO, 802.1X Authentication is successful on port <port_name>. Probable Cause Indicates that the authentication has succeeded on a particular port. Recommended No action is required. Action Severity INFO DOT1-1006...
  • Page 211 DOT1-1009 Recommended No action is required. Action Severity INFO DOT1-1009 Message <timestamp>, [DOT1-1009], <sequence-number>,, INFO, 802.1X is disabled for port <port_name>. Probable Cause Indicates that the 802.1X is disabled for a particular port. Recommended No action is required. Action Severity INFO DOT1-1010 Message...
  • Page 212 DOT1-1010 Fabric OS Message Reference 53-1001338-01...

  • Page 213: Ecc System Messages

    Chapter EM System Messages EM-1001 Message <FRU <timestamp>, [EM-1001], <sequence-number>, FFDC, CRITICAL, <system-name>, ID> is over heating: Shutting down. Probable Cause Indicates that a field-replaceable unit (FRU) is shutting down due to overheating. This is typically due to a faulty fan but can also be caused by the switch environment. Recommended Verify that the location temperature is within the operational range of the switch.
  • Page 214 EM-1004 Run the systemVerification command to verify that the switch does not have hardware problems. To run this command root access is required. Refer to the Fabric OS Command Reference for more information on this command. On the Brocade 24000 and 48000, replace the specified FRU. For the Brocade 3900, replace the motherboard FRU.
  • Page 215 EM-1006 EM-1006 Message <FRU <timestamp>, [EM-1006], <sequence-number>, FFDC, CRITICAL, <system-name>, Id> has faulted. Sensors below minimum limits. Probable Cause Indicates that the sensors show the voltage is below minimum limits. The switch or specified blade is being shut down for environmental reasons; the voltage is too low. Recommended If this problem occurs on a blade, it usually indicates a hardware problem on the blade;...
  • Page 216 EM-1009 EM-1009 Message <FRU <timestamp>, [EM-1009], <sequence-number>, FFDC, CRITICAL, <system-name>, Id> powered down unexpectedly. Probable Cause Indicates that the environmental monitor (EM) received an unexpected power-down notification from the specified field-replaceable unit (FRU). This might indicate a hardware malfunction in the FRU.
  • Page 217 EM-1013 Probable Cause Indicates that a switch blade or nonbladed switch failed to transition from one state to another. It is faulted. The specific failed target state is displayed in the message. There are serious internal Fabric OS configuration or hardware problems on the switch. Recommended On Brocade DCX, 24000 and 48000, try reseating the indicated field-replaceable unit (FRU).
  • Page 218 EM-1016 Severity WARNING EM-1016 Message <timestamp>, [EM-1016], <sequence-number>,, WARNING, <system-name>, Cold recovery <Return code> failed ( Probable Cause Indicates that a problem was discovered when performing consistency checks during a cold boot. Recommended Monitor the switch. Action If the message persists, run supportFtp (as needed) to set up automatic FTP transfers; then run the supportSave command and contact your switch service provider.
  • Page 219 EM-1028 Probable Cause Indicates that the current chassisConfig option is not supported by the firmware on the standby control processor (CP). This is true even if the standby comes up and appears to be operational. High availability (HA) synchronization of the CPs will not be allowed. Recommended Either change the chassisConfig option to 1 with the chassisConfig command, or upgrade the Action...
  • Page 220 EM-1033 Probable Cause Indicates that the environmental monitor (EM) has found a switch blade that is inserted, but the ejector switch is not closed. The blade in the specified slot is treated as not inserted. Recommended Close the ejector switch (raise the slider in most blades, or completely screw in the upper Action thumbscrew for the FC4-48 port blade) if the field-replaceable unit (FRU) is intended for use.
  • Page 221 EM-1035 EM-1035 Message <timestamp>, [EM-1035], <sequence-number>,, ERROR, <system-name>, 2 circuit <Switch side> paired Power Supplies are faulty, please check the AC main switch/circuit to see if it has power. Fabric OS Message Reference 53-1001338-01...
  • Page 222 EM-1036 Probable Cause Suggests that since both power supplies associated with one of the two main circuits are present but faulty, maybe the circuit's switch has been turned off, or the AC power source has been interrupted for that circuit. The Switch side value is either "left"...
  • Page 223 EM-1041 EM-1041 Message <timestamp>, [EM-1041], <sequence-number>,, WARNING, <system-name>, Sensor values for <FRU Id>: <Sensor Value> <Sensor Value> <Sensor Value> <Sensor Value> <Sensor Value> <Sensor Value> <Sensor Value>. Probable Cause Indicates that sensors detected a warning condition. All significant sensors for the field-replaceable unit (FRU) are displayed;...
  • Page 224 EM-1045 Probable Cause Indicates that the specified field-replaceable unit (FRU) cannot be powered on because the associated logical switch is shut down. Recommended Run the switchStart command on the associated logical switch. Action Severity WARNING EM-1045 Message <timestamp>, [EM-1045], <sequence-number>,, WARNING, <system-name>, <FRU Id> is being powered <new state>.
  • Page 225 EM-1048 Probable Cause Indicates that the control processor (CP) is no longer faulted. This message usually follows EM-1033. The new standby CP is in the process of rebooting and has turned off the CP_ERR signal. Recommended No action is required. Action Severity INFO...
  • Page 226 EM-1051 EM-1051 Message <FRU Id> <timestamp>, [EM-1051], <sequence-number>,, INFO, <system-name>, Inconsistency detected, FRU re-initialized. Probable Cause Indicates that an inconsistent state was found in the field-replaceable unit (FRU). This occurs if the state of the FRU was changing during a failover. The FRU is reinitialized and traffic might have been disrupted.
  • Page 227 EM-1060 Recommended Replace the blade. Make sure the replacement is compatible with your switch type. Action Severity ERROR EM-1060 Message <timestamp>, [EM-1060], <sequence-number>,, WARNING, <system-name>, Stopping synchronization of the system due to blade incompatibility with software version on standby CP. Probable Cause Indicates a blade in the system is not supported by the release on the standby control processor (CP).
  • Page 228 EM-1063 EM-1063 Message <timestamp>, [EM-1063], <sequence-number>,, CRITICAL, <system-name>, Blade in slot <Slot Id> faulted because it exceeds the maximum support limit of <Limit> blades with Blade IDs <Applicable blade Type IDs> in the chassis. Probable Cause Indicates too many blades of a set of particular types are in the system. Recommended Remove the faulted blade.
  • Page 229 EM-1067 Probable Cause Indicates the previously incompatible Fabric OS or Storage Application Services (SAS) firmware has been upgraded and is now compatible. Recommended No action is required. Action Severity INFO EM-1067 Message <timestamp>, [EM-1067], <sequence-number>,, WARNING, <system-name>, Stopping synchronization of the system due to version incompatibility with standby CP. Probable Cause Indicates that the software version on the standby CP is not compatible with this software version.
  • Page 230 EM-1070 EM-1070 Message <timestamp>, [EM-1070], <sequence-number>,, INFO, <system-name>, Slot <FRU slot number> is being powered on. Probable Cause Indicates a blade is being intentionally powered on. Recommended No action is required. Action Severity INFO EM-2003 Message <timestamp>, [EM-2003], <sequence-number>,, ERROR, <system-name>, <Slot Id or Switch for pizza boxes>...

  • Page 231: Ess System Messages

    Chapter ESS System Messages ESS-1001 Message <timestamp>, [ESS-1001], <sequence-number>,, WARNING, <system-name>, A few switches in the fabric do not support the Coordinated HotCode protocol. Probable Cause Indicates one or more switches in the fabric do not support the Coordinated HotCode protocol. Continuing with the firmware download may cause data traffic disruption.
  • Page 232 ESS-1004 ESS-1004 Message <timestamp>, [ESS-1004], <sequence-number>,, WARNING, <system-name>, The resume message is rejected by the domain <domain id>. Probable Cause Indicates that during the Coordinated HotCode protocol, a switch in the fabric has rejected the resume message which prevented the protocol from completing. Any data traffic disruption observed during the firmware download may have been due to the rejected resume message.

  • Page 233: Eswch System Messages

    DRAFT: BROCADE CONFIDENTIAL Chapter ESWCH System Messages ESW-1001 Message <timestamp>, [ESW-1001], <sequence-number>,, ERROR, <system-name>, Switch is not in ready state - Switch enable failed switch status= 0x<switch status>, c_flags = 0x<switch control flags>. Probable Cause Indicates that the switch enable has failed. Recommended If the message persists, run the supportFtp command (as needed) to set up automatic FTP Action...
  • Page 234 DRAFT: BROCADE CONFIDENTIAL ESW-1004 ESW-1004 Message <timestamp>, [ESW-1004], <sequence-number>,, ERROR, <system-name>,Blade attach failed during recovery, disabling slot = <slot number>. Probable Cause Indicates that the blade has failed during failover or recovery. Recommended On a Brocade 8000 switch, restart or power cycle the switch. Action Severity ERROR...
  • Page 235 DRAFT: BROCADE CONFIDENTIAL ESW-1008 Severity WARNING ESW-1008 Message <timestamp>, [ESW-1008], <sequence-number>,, WARNING, <system-name>,<area string> are port swapped on ports that do not support port swap. Slot <slot number> will be faulted. Probable Cause Indicates that the blade has area swapped ports on ports that do not support this feature. Recommended Replace the blade with ports that support port swap.
  • Page 236 DRAFT: BROCADE CONFIDENTIAL ESW-1008 Fabric OS Message Reference 53-1001338-01...

  • Page 237: Evmd System Messages

    Chapter EVMD System Messages EVMD-1001 Message <timestamp>, [EVMD-1001], <sequence-number>,, WARNING, <system-name>, Event could <Remote proxy switch id.> not be sent to remote proxy. = Probable Cause Indicates the event could not be sent to remote proxy. This could happen if the remote proxy switch cannot be reached through in-band.
  • Page 238 EVMD-1001 Fabric OS Message Reference 53-1001338-01...

  • Page 239: Fabr System Messages

    Chapter FABR System Messages FABR-1001 Message <timestamp>, [FABR-1001], <sequence-number>,, WARNING, <system-name>, port <port number>, <segmentation reason>. Probable Cause Indicates that the specified switch port is isolated because of a segmentation resulting from mismatched configuration parameters. Recommended Based on the segmentation reason displayed within the message, look for a possible mismatch of Action relevant configuration parameters in the switches at both ends of the link.
  • Page 240 FABR-1004 Run the fabStateShow command on both the receiving and transmitting switches. If the message persists, run supportFtp (as needed) to set up automatic FTP transfers; then run the supportSave command and contact your switch service provider. Severity WARNING FABR-1004 Message <timestamp>, [FABR-1004], <sequence-number>,, WARNING, <system-name>, port: <port number>, req iu: 0x<address of IU request sent>, state: 0x<command sent>, resp iu:...
  • Page 241 FABR-1007 Recommended In case of severe memory corruption, the system might recover by performing an automatic Action failover. If the message persists, run supportFtp (as needed) to set up automatic FTP transfers; then run the supportSave command and contact your switch service provider. Severity WARNING FABR-1007...
  • Page 242 FABR-1010 Recommended The fabric daemon will discard the EFP. The system will recover through the EFP retrial process. Action If the message persists, run supportFtp (as needed) to set up automatic FTP transfers; then run the supportSave command and contact your switch service provider. Severity WARNING FABR-1010...
  • Page 243 FABR-1013 FABR-1013 Message <timestamp>, [FABR-1013], <sequence-number>, FFDC, CRITICAL, <system-name>, No Memory: pid=<fabric process id> file=<source file name> line=<line number within the source file>. Probable Cause Indicates that there is not enough memory in the switch for the fabric module to allocate. This message is rare and usually indicates a problem with the Fabric OS.
  • Page 244 FABR-1016 FABR-1016 Message <timestamp>, [FABR-1016], <sequence-number>,, WARNING, <system-name>, ficonMode is enabled. Probable Cause Indicates that FICON mode is enabled on the switch through a user interface command. Recommended No action is required. Action Severity WARNING FABR-1017 Message <timestamp>, [FABR-1017], <sequence-number>,, WARNING, <system-name>, ficonMode is disabled.
  • Page 245 FABR-1020 Probable Cause Indicates that this switch is a value-line switch and has exceeded the limited fabric size: that is, a specified limit to the number of domains. This limit is defined by your specific value-line license key. The fabric size has exceeded this specified limit, and the grace period counter has started. If the grace period is complete and the size of the fabric is still outside the specified limit, Web Tools is disabled.
  • Page 246 FABR-1023 Probable Cause Indicates that the fabric size has exceeded the value-line limit, and the grace period counter has started. If the grace period is complete and the size of the fabric is still outside the specified limit, Web Tools is disabled. Recommended Bring the fabric size within the licensed limits.
  • Page 247 FABR-1030 • VC_RDY mode: Virtual-channel flow control mode. This is a proprietary protocol. • R_RDY mode: Receiver-ready flow control mode. This is the Fibre Channel standard protocol, that uses R_RDY primitive for flow control. • DUAL_CR mode: Dual-credit flow control mode. In both of the previous modes, the buffer credits are fixed, based on the port configuration information.
  • Page 248 FABR-1034 Severity WARNING FABR-1034 Message <timestamp>, [FABR-1034], <sequence-number>, INFO, <system-name>, Area <Area that has already been acquired> have been acquired by port <Port that has already acquired the area>. Persistently disabling port <Port that is being disabled>. Probable Cause Indicates you must enable Trunk Area on a port for another port to use the same area. Recommended Move the cable to a port area that is not in use, or disable Trunk Area.
  • Page 249 FABR-1038 Probable Cause Indicates the specified port is being disabled because when the port attempts to go online, the Switch finds that Trunk Area enabled is incompatible with port configuration such as long distance, port mirror, fast write or EX_port. Recommended Check the port configuration to disable long distance, port mirror, fast write or EX_port.
  • Page 250 FABR-1041 FABR-1041 Message <timestamp>, [FABR-1041], <sequence-number>, ERROR, <system-name>, Port <Port that is being disabled> is disabled due to trunk protocol error. Probable Cause Indicates that a link reset was received before the completion of the trunking protocol on the port. Recommended Enable the port by running the portEnable command.
  • Page 251 FABR-1046 Recommended Make sure that all the switches in the fabric have the same Base Switch attribute or disable VF Action mode for the conflicting switch using the fosconfig command. Severity ERROR FABR-1046 Message <timestamp>, [FABR-1046], <sequence-number>, ERROR, <system-name>, Detected Base Switch conflict with neighbor switch <Switchname>...
  • Page 252 FABR-1046 Fabric OS Message Reference 53-1001338-01...

  • Page 253: Fabs System Messages

    Chapter FABS System Messages FABS-1001 Message <timestamp>, [FABS-1001], <sequence-number>, FFDC, CRITICAL, <system-name>, <Function name> <Description of memory need> Probable Cause Indicates that the system is low on memory and cannot allocate more memory for new operations. This is usually an internal Fabric OS problem or file corruption. Description of memory need indicates how much memory was being requested.
  • Page 254 FABS-1005 FABS-1005 Message <timestamp>, [FABS-1005], <sequence-number>,, WARNING, <system-name>, <Function name and description of problem> (<ID type>= <ID number>) Probable Cause Indicates that an unsupported operation has been requested. This is usually an internal Fabric OS problem or file corruption. The possible value for function name and description of problem is: fabsys_write: Unsupported write operation: process xxx where xxx is the process ID (PID), which could be any whole number.
  • Page 255 FABS-1008 Severity WARNING FABS-1008 Message <Function <timestamp>, [FABS-1008], <sequence-number>,, WARNING, <system-name>, name> : Media oid mapping failed Probable Cause Indicates that the Fabric OS was unable to locate a necessary object handle. This is usually an internal Fabric OS problem or file corruption. Recommended Reboot or power cycle the switch.
  • Page 256 FABS-1012 Recommended Reboot or power-cycle the CP or system. Action If the message persists, run the firmwareDownload command to update the firmware. Severity ERROR FABS-1012 Message <timestamp>, [FABS-1012], <sequence-number>,, ERROR, <system-name>, <Method name>[<Method tag number>]:FRU state transition failed. Current state 0x<Current state of FRU>...
  • Page 257 FABS-1015 Severity ERROR FABS-1015 Message <timestamp>, [FABS-1015], <sequence-number>,, ERROR, <system-name>, <Method name>[<Method tag number>]:Request to enable FRU type 0x<FRU Object type>, unit <Unit number> failed. err code <Error code> Probable Cause Indicates the specified FRU could not be enabled. This is usually an internal Fabric OS problem. Recommended Try removing and reinserting the FRU.
  • Page 258 FABS-1015 Fabric OS Message Reference 53-1001338-01...

  • Page 259: Fbc System Messages

    Chapter FBC System Messages FBC-1001 Message <timestamp>, [FBC-1001], <sequence-number>,, ERROR, <system-name>, Firmware version on AP blade is incompatible with that on the CP. Probable Cause The CP determined that the version of firmware running on the AP blade is not compatible with the version of firmware running on the CP.
  • Page 260 FBC-1001 Fabric OS Message Reference 53-1001338-01...

  • Page 261: Fcmc System Messages

    Chapter FCMC System Messages FCMC-1001 Message <timestamp>, [FCMC-1001], <sequence-number>, FFDC, CRITICAL, <system-name>, System is low on memory and has failed to allocate new memory. Probable Cause Indicates that the switch is low on memory and failed to allocate new memory for an information unit (IU).
  • Page 262 FCMC-1001 Fabric OS Message Reference 53-1001338-01...

  • Page 263: Fcip System Messages

    Chapter FCIP System Messages FCIP-1000 Message <timestamp>, [FCIP-1000], <sequence-number>, FFDC, ERROR, <system-name>, <command name> of GE <port number> failed. Please retry the command. Data: inst=<ASIC instance> st=<ASIC initializing state> rsn=<reason code> fn=<message function> oid=<ASIC ID> Probable Cause Indicates that the hardware is not responding to a command request, possibly because it is busy. Recommended Retry the command.
  • Page 264 FCIP-1004 Probable Cause Indicates that an IPsec/IKE policy was deleted and the config file was updated. Recommended No action is required. Action Severity INFO FCIP-1004 Message <timestamp>, [FCIP-1004], <sequence-number>, INFO, CFG, <system-name>, Tape Read Pipelining is being disabled slot (<slot number>) port (<user port index>) tunnel (<The configured tunnel ID (0-7)>).

  • Page 265: Fcoe System Messages

    DRAFT: BROCADE CONFIDENTIAL Chapter FCOE System Messages FCOE-1001 Message <timestamp>, [FCOE-1001], <sequence-number>,, ERROR, <system-name>, calloc failed for <object>. Probable Cause Indicates a memory failure. Recommended Check the switch memory status. Action Severity ERROR FCOE-1002 Message <timestamp>, [FCOE-1002], <sequence-number>,, WARNING, <system-name>, Max login Group limit reached at <limit>.
  • Page 266 DRAFT: BROCADE CONFIDENTIAL FCOE-1005 Recommended Remove the failed member from the login group. Action Severity ERROR FCOE-1005 Message <timestamp>, [FCOE-1005], <sequence-number>,, ERROR, <system-name>, <device>: membership check failed in lg: <lg> Probable Cause Indicates that the Membership check for the device has failed. Recommended Check the device for failed Membership.
  • Page 267 DRAFT: BROCADE CONFIDENTIAL FCOE-1009 Recommended No action is required. Action Severity INFO FCOE-1009 Message <timestamp>, [FCOE-1009], <sequence-number>,, INFO, <system-name>, Addition of nport mapping failed. Max nport mapping limit reached: <maxnport>. Probable Cause Indicates that the N_port mapping has reached its maximum limit. Recommended Remove unwanted N_port mappings and try adding N_port mapping.
  • Page 268 DRAFT: BROCADE CONFIDENTIAL FCOE-1013 Recommended Rerequest to delete port from VLAN. Action Severity ERROR FCOE-1013 Message <timestamp>, [FCOE-1013], <sequence-number>,, ERROR, <system-name>, Request to add VLAN <vid> failed. Probable Cause Indicates an add request to a VLAN has failed. Recommended Rerequest to add VLAN. Action Severity ERROR...
  • Page 269 DRAFT: BROCADE CONFIDENTIAL FCOE-1017 Recommended The VLAN may be in use; disable the active FCoE login session and try deleting the VLAN again. Action Severity ERROR FCOE-1017 Message <timestamp>, [FCOE-1017], <sequence-number>,, ERROR, <system-name>, Request to add fcmap failed for vlan <vid>. Probable Cause Indicates an add request to VLAN has failed.
  • Page 270 DRAFT: BROCADE CONFIDENTIAL FCOE-1018 Fabric OS Message Reference 53-1001338-01...

  • Page 271: Fcpd System Messages

    Chapter FCPD System Messages FCPD-1001 Message <timestamp>, [FCPD-1001], <sequence-number>,, WARNING, <system-name>, Probing failed on <error string> Probable Cause Indicates that a Fibre Channel Protocol (FCP) switch probed devices on a loop port, and probing failed on the L_Port, AL_PA address, or the F_Port. For the AL_PA, the valid range is 00 through FF. The error string can be either of the following: •...
  • Page 272 FCPD-1003 Fabric OS Message Reference 53-1001338-01...

  • Page 273: Fcph System Messages

    Chapter FCPH System Messages FCPH-1001 Message <timestamp>, [FCPH-1001], <sequence-number>, FFDC, CRITICAL, <system-name>, <function>: <failed function call> failed, out of memory condition Probable Cause Indicates that the switch is low on memory and failed to allocate new memory for a Fibre Channel driver instance.
  • Page 274 FCPH-1002 Fabric OS Message Reference 53-1001338-01...

  • Page 275: Fcr System Messages

    Chapter FCR System Messages FCR-1001 Message <timestamp>, [FCR-1001], <sequence-number>,, INFO, <system-name>, FC router proxy device in edge created at port <port number>. Probable Cause Indicates that a proxy device at the port in the edge fabric has been imported at the specified port. Recommended No action is required.
  • Page 276 FCR-1005 Recommended Verify that the devices were intended to be taken offline. If not, verify that the devices are Action functioning properly. Verify that all small form-factor pluggables (SFPs) are seated correctly. Check for faulty cables, deteriorated SFPs, or dirty connections. Replace the cables and SFPs if necessary. Severity INFO FCR-1005...
  • Page 277 FCR-1009 Probable Cause Indicates that a logical storage area network (LSAN) zone was created at the specified port in the edge fabric. Recommended No action is required. Action Severity INFO FCR-1009 Message <timestamp>, [FCR-1009], <sequence-number>,, INFO, <system-name>, FC router LSAN zone enabled at port <port number>: <enabled name>.
  • Page 278 FCR-1012 FCR-1012 Message <timestamp>, [FCR-1012], <sequence-number>,, INFO, <system-name>, FC Router fabric build completed on port <port number>. Probable Cause Indicates that the fibre channel router has completed a fabric build at the specified port. Recommended No action is required. Action Severity INFO FCR-1013...
  • Page 279 FCR-1018 FCR-1018 Message <timestamp>, [FCR-1018], <sequence-number>,, ERROR, <system-name>, FC router proxy device entries exhausted on port <port number>. Probable Cause Indicates that the number of proxy devices is greater than allowed by the port resource. Recommended Remove excess logical storage area network (LSAN) zones or devices until the number of proxy Action devices exported is within the range allowed by the port resource.
  • Page 280 FCR-1021 3. Use Zoning commands on the edge fabrics, to reduce the LSAN zone entries on the edge fabrics. 4. Run portEnable on each EX_Port, one at a time, and verify that this error is not reported again. Severity WARNING FCR-1021 Message <timestamp>, [FCR-1021], <sequence-number>,, WARNING, <system-name>, Local LSAN...
  • Page 281 FCR-1024 FCR-1024 Message <timestamp>, [FCR-1024], <sequence-number>,, WARNING, <system-name>, Local LSAN <zone name> zone device entries for edge LSAN exhausted. Probable Cause Indicates that the number of devices in a logical storage area network (LSAN) defined in the edge fabric exceeds the local LSAN zone database limitations. Recommended Remove excess device entries from this LSAN zone until the number of devices is within the range Action...
  • Page 282 FCR-1028 Probable Cause Indicates that the port world wide name (WWN) pool has rolled over in the specified slot, and WWN entries detected to not be in use are reused as needed. Recommended It is unlikely that WWN conflicts will occur as a result of pool rollover unless the switch is deployed Action in a very large MetaSAN environment with large number of logical storage area network (LSAN) devices and fabrics, or there are highly dynamic changes to EX_Port connectivity.
  • Page 283 FCR-1030 FCR-1030 Message <timestamp>, [FCR-1030], <sequence-number>,, INFO, <system-name>, Physical device <device WWN> came online at fabric <fabric ID>. Probable Cause Indicates that the physical device world wide name (WWN) came online in the specified fabric. Recommended No action is required. Action Severity INFO...
  • Page 284 FCR-1034 FCR-1034 Message <timestamp>, [FCR-1034], <sequence-number>,, INFO, <system-name>, LSAN zone added in backbone fabric. Probable Cause Indicates that a new logical storage area network (LSAN) zone was added to the backbone fabric. Recommended No action is required. Action Severity INFO FCR-1035 Message <timestamp>, [FCR-1035], <sequence-number>,, INFO, <system-name>, LSAN zone...
  • Page 285 FCR-1038 FCR-1038 Message <timestamp>, [FCR-1038], <sequence-number>,, WARNING, <system-name>, Total zone entries exceeded local fabric limits by <overflow> entries, in zone: <zone name>, zone limit: <LSAN zone limit>. Probable Cause Indicates that the number of cfg/zone/alias entries created in a local fabric is greater than the local switch&apos zone database limitations.
  • Page 286 FCR-1042 Severity INFO FCR-1042 Message <timestamp>, [FCR-1042], <sequence-number>,, INFO, <system-name>, LSAN zone removed in the backbone fabric. Probable Cause Indicates that a logical storage area network (LSAN) zone within the backbone fabric was removed. Recommended No action is required. Action Severity INFO FCR-1043...
  • Page 287 FCR-1053 Recommended Run the portEnable and portDisable commands to enable and disable the port. Action If the problem persists contact your switch service provider. Severity ERROR FCR-1053 Message <timestamp>, [FCR-1053], <sequence-number>,, WARNING, <system-name>, Port <port number> was disabled, <disable reason>. Probable Cause Indicates that the specified port was disabled because of a mismatched configuration parameter.
  • Page 288 FCR-1056 Severity INFO FCR-1056 Message <timestamp>, [FCR-1056], <sequence-number>,, INFO, <system-name>, Switch <switch WWN> with front domain ID <domain ID> does not support backbone to edge imports. Probable Cause Indicates that a switch that does not support backbone-to-edge routing is running in the MetaSAN. Recommended No action is required if backbone-to-edge routing is not needed.
  • Page 289 FCR-1059 FCR-1059 Message <port <timestamp>, [FCR-1059], <sequence-number>,, INFO, <system-name>, EX_Port number> was disabled due to an authentication failure. Probable Cause Indicates that the authentication, which uses the Diffie Hellman - challenge handshake authentication Protocol (DH-CHAP), failed on the EX_Port. Recommended Verify that the shared secrets on both sides of the link match.
  • Page 290 FCR-1063 Probable Cause Indicates that the maximum number of supported EX_ports or VEX_ports was exceeded. To enable the specified port, disable any other operational port then re-enable the port. Recommended No action is required. Action Severity INFO FCR-1063 Message <timestamp>, [FCR-1063], <sequence-number>,, INFO, <system-name>, Fabric <fabric ID>...
  • Page 291 FCR-1066 FCR-1066 Message <timestamp>, [FCR-1066], <sequence-number>,, ERROR, <system-name>, Fabric on port <port number> has the same fabric ID as another fabric. Probable Cause Indicates that either the fabric split, or there is another fabric (possibly the backbone) that has the same fabric ID as the fabric connected to the specified port.
  • Page 292 FCR-1070 Probable Cause Indicates that the FC Routing service is enabled. This is caused by either fosConfig –-enable fcr, or a configDownload with the fcrState set to 1 (enabled). Note that the FC Routing service is disabled by the factory. Recommended No action is required.
  • Page 293 FCR-1073 FCR-1073 Message <timestamp>, [FCR-1073], <sequence-number>,, INFO, <system-name>, Switch with domain ID <domain ID> in fabric <fabric ID> has lower limit of LSAN Zones supported. Probable Cause Indicates that an earlier version of the switch in the backbone or edge that supports a different limit of logical storage area network (LSAN) zones was detected.
  • Page 294 FCR-1076 FCR-1076 Message <timestamp>, [FCR-1076], <sequence-number>,, ERROR, <system-name>, Port <port number> disabled, system only supports <maximum fds> front domains. Probable Cause Indicates that the maximum number of supported front domains was exceeded. To enable the specified port, disable any other operational front domain and then re-enable the port. Recommended Make sure to remain within the maximum of supported front domains.
  • Page 295 FCR-1080 Recommended Change the matrix database. Action Severity WARNING FCR-1080 Message <timestamp>, [FCR-1080], <sequence-number>,, WARNING, <system-name>, The pause response timer for domain <Domain> expired. Probable Cause Indicates that during the Coordinated HotCode protocol, a switch in the fabric has not responded to the pause message which prevented the protocol from completing.
  • Page 296 FCR-1083 FCR-1083 Message <timestamp>, [FCR-1083], <sequence-number>,, WARNING, <system-name>, The resume message is rejected by the domain <Domain>. Probable Cause Indicates that during the Coordinated HotCode protocol, a switch in the fabric has rejected the pause message which prevented the protocol from completing. Any data traffic disruption observed during the firmware download may have been due to the rejected resume message.
  • Page 297 FCR-1087 Recommended Disable Condor2-based EX_ports or upgrade the remote CP. Action Severity ERROR FCR-1087 Message <timestamp>, [FCR-1087], <sequence-number>,, ERROR, <system-name>, ExPort <ExPort> connects to fabric <fabric> with capability to use XISL domain <domain>. Probable Cause Indicates that the EX_Port connects to logical fabric containing a domain has the capability to use XISL.
  • Page 298 FCR-1092 Recommended No action is required. Action Severity INFO FCR-1092 Message <timestamp>, [FCR-1089], <sequence-number>,, ERROR, <system-name>, FCR ELS trap entries exhausted. Probable Cause Indicates that the FCR ELS trap entries are exhausted. Recommended Collect supportsave data and send it to support. Action Severity ERROR...

  • Page 299: Ficon System Messages

    Chapter FICON System Messages The FICON messages in this chapter include in many of the messages. The FICON <FICON Path> Path is a string that includes, where: VEHDHPDDDPLPCUDV VE - VE Port Number: This number represents the FCIP Tunnel number through its VE Port number.
  • Page 300 FICN-1004 Severity WARNING FICN-1004 Message <timestamp>, [FICN-1004], <sequence-number>,, WARNING, <system-name>, FICON XRC Emulation License Key is not installed. Probable Cause Indicates FICON XRC Emulation requires a License Key. Recommended Use the appropriate License Key. Action Severity WARNING FICN-1005 Message <timestamp>, [FICN-1005], <sequence-number>,, INFO, <system-name>, FICON GEPort <GE port number>...
  • Page 301 FICN-1007 FICN-1007 Message <timestamp>, [FICN-1007], <sequence-number>,, ERROR, <system-name>, DevDiskEgr:FICON Selective Reset:Path=<VEPortNumber HostDomain HostPort DeviceDomain> <DevicePort LPAR CUADDR DeviceAddr> State=0x<current Emulation State> stat_array=0x<last 4 Status values that were received from the device>. Probable Cause Indicates a Selective Reset from the channel was received as either a normal part of path recovery or starting sequence in an error case.
  • Page 302 FICN-1011 Probable Cause Indicates a Device Level Exception frame was received from the FICON Channel. Recommended If there was a job or IO failure associated with this event, please contact your vendor's customer Action support for assistance. Severity INFO FICN-1011 Message <timestamp>, [FICN-1011], <sequence-number>,, ERROR, <system-name>, DevDiskIng:XRC Incorrect RRS SeqNum Rcvd Path=0x<VEPortNumber HostDomain HostPort...
  • Page 303 FICN-1014 Severity INFO FICN-1014 Message <timestamp>, [FICN-1014], <sequence-number>,, INFO, <system-name>, DevEgr:Device level exception flag found for Path=0x<VEPortNumber HostDomain HostPort DeviceDomain>8X<DevicePort LPAR CUADDR DeviceAddr>8X: Oxid=0x<The OXID used to deliver the non-AS Device Level Exception>4X. Probable Cause Indicates a frame was received that indicated device level exception. Recommended If there was an IO failure associated with this event, please contact your vendor's customer support Action...
  • Page 304 FICN-1018 Probable Cause Indicates the FICON Control Unit sent an LPE frame to the FICON channel. Recommended This is an informational message and does not require any action. Action Severity INFO FICN-1018 Message <timestamp>, [FICN-1018], <sequence-number>,, ERROR, <system-name>, DevIng:FCUB Lookup failed for Path=0x<VEPortNumber HostDomain HostPort DeviceDomain>8x<DevicePort LPAR>2x.
  • Page 305 FICN-1021 FICN-1021 Message <timestamp>, [FICN-1021], <sequence-number>,, ERROR, <system-name>, DevTapeEgr:FICON Tape Cancel:Path=0x<VEPortNumber HostDomain HostPort DeviceDomain>8X<DevicePort LPAR CUADDR DeviceAddr>8X Elapsed Time=<the current SIO time in seconds for the device>.<the current SIO time in milliseconds for the device> seconds. Probable Cause Indicates the FICON channel issued a Cancel sequence for a device in emulation. Recommended If there was an unexpected job failure associated with this event, contact your vendor's customer Action...
  • Page 306 FICN-1024 FICN-1024 Message <timestamp>, [FICN-1024], <sequence-number>,, ERROR, <system-name>, DevTapeEgr:FICON Purge received Path=<VEPortNumber HostDomain HostPort DeviceDomain> <DevicePort LPAR CUADDR DeviceAddr>. Probable Cause Indicates the FICON channel issued a Purge Path command sequence for a device. Recommended If there was an unexpected job failure or IO Error associated with this event, contact your vendor's Action customer support for assistance.
  • Page 307 FICN-1028 Recommended If there was an unexpected job failure or IO Error associated with this event, contact your vendor's Action customer support for assistance. Severity ERROR FICN-1028 Message <timestamp>, [FICN-1028], <sequence-number>,, ERROR, <system-name>, HostDiskIng:FICON Cancel received Path=<VEPortNumber HostDomain HostPort DeviceDomain> <DevicePort LPAR CUADDR DeviceAddr>state=0x<The current emulation state of the device>.
  • Page 308 FICN-1031 FICN-1031 Message <timestamp>, [FICN-1031], <sequence-number>,, WARNING, <system-name>, HostDiskIng:FICON System Reset received on Path=<VEPortNumber HostDomain HostPort DeviceDomain><DevicePort LPAR><CUADDR>. Probable Cause Indicates the FICON channel sent a System Reset to the disk control unit. Recommended No action is required. The MVS system was either set to IPL or performing error recovery. Action Severity WARNING...
  • Page 309 FICN-1035 Probable Cause Indicates the channel emulation processing received a frame with an invalid FICON LRC from the peer. This indicates that the channel side noted corruption from the device/CU side processing. Recommended Contact your vendor's customer support for assistance. Action Severity ERROR...
  • Page 310 FICN-1038 FICN-1038 Message <timestamp>, [FICN-1038], <sequence-number>,, ERROR, <system-name>, fcFicIngHost:FDCB Lookup failed for Path=<VEPortNumber HostDomain HostPort DeviceDomain> <DevicePort>. Probable Cause Indicates a locally connected FICON channel sent a frame that could not be associated with a FICON device. Recommended Contact your vendor's customer support for assistance. Action Severity ERROR...
  • Page 311 FICN-1042 Probable Cause Indicates an LRJ received from a device indicates that the CU has lost the logical path to the LPAR. Recommended If this was an unexpected event, contact your vendor's customer support for assistance. Action Severity ERROR FICN-1042 Message <timestamp>, [FICN-1042], <sequence-number>,, WARNING, <system-name>, HostTapeIng:FICON Cancel received Path=<VEPortNumber HostDomain HostPort...
  • Page 312 FICN-1045 FICN-1045 Message <timestamp>, [FICN-1045], <sequence-number>,, WARNING, <system-name>, HostTapeIng:FICON Purge received:Path=<VEPortNumber HostDomain HostPort DeviceDomain> <DevicePort LPAR CUADDR DeviceAddr>. Probable Cause Indicates a purge path was received from the locally connected FICON channel. This is performed during the path recovery. Recommended If this was an unexpected event, contact your vendor's customer support for assistance.
  • Page 313 FICN-1049 Probable Cause Indicates the operator has cancelled a read or write job. Recommended This is an unexpected event; contact your vendor's customer support for assistance. Action Severity WARNING FICN-1049 Message <timestamp>, [FICN-1049], <sequence-number>,, WARNING, <system-name>, ProcessIngTirData:Lost Logical Path for Path=<VEPortNumber HostDomain HostPort DeviceDomain>...
  • Page 314 FICN-1052 Severity INFO FICN-1052 Message <timestamp>, [FICN-1052], <sequence-number>,, INFO, <system-name>, XRC Session Terminated: SessID=<SDM Assigned Session ID>, Path=<VEPortNumber HostDomain HostPort DeviceDomain> <DevicePort LPAR CUADDR DeviceAddr>. Probable Cause Indicates a PSF command has been received to break an XRC session with the extended DASD device.
  • Page 315 FICN-1056 Probable Cause Indicates a suspend all devices from XRC session PSF command has been received to break an XRC session with the extended DASD device. Recommended If this was an unexpected event, contact your vendor's customer support for assistance. Action Severity WARNING...
  • Page 316 FICN-1059 FICN-1059 Message <timestamp>, [FICN-1059], <sequence-number>,, ERROR, <system-name>, Error return from frame generation for a FICON Image: Path=<VEPortNumber HostDomain HostPort DeviceDomain> <DevicePort LPAR >. Probable Cause Indicates an internal resource shortage caused an error such that an emulation frame could not be created and sent to an LPAR.
  • Page 317 FICN-1063 Probable Cause Indicates an abort operation has been received from the local FC interface for an active emulation exchange. Recommended This is an unexpected event, contact your vendor's customer support for assistance. Action Severity ERROR FICN-1063 Message <timestamp>, [FICN-1063], <sequence-number>,, ERROR, <system-name>, Egress Abort:Oxid=0x<the OXID of the aborted exchange>:Path=<VEPortNumber HostDomain HostPort DeviceDomain>...
  • Page 318 FICN-1066 FICN-1066 Message <timestamp>, [FICN-1066], <sequence-number>,, WARNING, <system-name>, MemAllocFailed for GEPort=<GE0 or GE1 Number> VEport=<VEPortNumber> could not create required structure. Probable Cause Indicates an internal resource limit has been encountered such that additional control block memory could not be allocated. Recommended This is an unexpected event, either the maximum number of emulation devices are already in use Action...
  • Page 319 FICN-1070 Recommended If resolution of the configuration issue cannot be completed, contact your vendor's customer Action support for assistance. Severity ERROR FICN-1070 Message <timestamp>, [FICN-1070], <sequence-number>,, INFO, <system-name>, DevTapeIngr:Exceptional Status rcvd on Path=<VEPortNumber HostDomain HostPort DeviceDomain> <DevicePort LPAR CUADDR DeviceAddr> state=0x<current emulation state>...
  • Page 320 FICN-1073 FICN-1073 Message <timestamp>, [FICN-1073], <sequence-number>,, INFO, <system-name>, HostTapeIngr:Unloaded:Path=<VEPortNumber HostDomain HostPort DeviceDomain> <DevicePort LPAR CUADDR DeviceAddr>:states=0x<4 prior emulation states>:cmds=0x<last 4 commands received from the channel for this device>:status=0x<last 4 status values sent to the channel for this device>:flags=0x<tape report bit flags (0x80-Tape Loaded,0x40-WriteEmul,0x20-RdBlkEmul,0x10-RdCpEmul)>.
  • Page 321 FICN-1076 Severity INFO FICN-1076 Message <timestamp>, [FICN-1076], <sequence-number>,, INFO, <system-name>, HostTapeIngr:ReadCpReport:Path=<VEPortNumber HostDomain HostPort DeviceDomain> <DevicePort LPAR CUADDR DeviceAddr>:Emuls=0x<the number of idle state to non-idle state transitions while this tape was loaded>:Cmds=0x<the number of emulated host read commands processed while this tape was loaded>:Chains=0x<the number of emulated host chains processed while this tape was loaded>:MBytes=<the number of emulated read megabytes processed while this tape was loaded>.
  • Page 322 FICN-1079 Recommended No action is required. Action Severity INFO FICN-1079 Message <timestamp>, [FICN-1079], <sequence-number>,, INFO, <system-name>, DevTapeEgr:WriteReport:Path=<VEPortNumber HostDomain HostPort DeviceDomain> <DevicePort LPAR CUADDR DeviceAddr>:Emuls=0x<the number of idle state to non-idle state transitions while this tape was loaded>:Cmds=0x<the number of emulated host read commands processed while this tape was loaded>:Chains=0x<the number of emulated host chains processed while this tape was loaded>:MBytes=<the number of emulated read Kilobytes processed while this tape was loaded>.
  • Page 323 FICN-1082 Recommended This is normally an unexpected event, contact your vendor's customer support for assistance. Action Severity WARNING FICN-1082 Message <timestamp>, [FICN-1082], <sequence-number>,, WARNING, <system-name>, EmulEls:CSWR_RSCN received on GEPort=<GEPortNumber> VEPort=<VEPortNumber> Domain=0x<Domain Port Host> Port=0x<Device Side>. Probable Cause Indicates an attached port which had a FICON emulated path established has logged out from the switch.
  • Page 324 FICN-1086 Probable Cause Indicates a FICON FCIP tunnel has been established successfully to the peer switch. Recommended No action is required. Action Severity INFO FICN-1086 Message <timestamp>, [FICN-1086], <sequence-number>,, ERROR, <system-name>, FICON FCIP Tunnel is Down on GE<Either GE0 or GE1>,tunnel Id=<The configured tunnel ID (0-7)>.

  • Page 325: Ficu System Messages

    Chapter FICU System Messages FICU-1001 Message <timestamp>, [FICU-1001], <sequence-number>,, ERROR, <system-name>, <function name>: config<config Set(key)|Get(key)| Save> failed rc = <error>. Probable Cause Indicates that one of the configuration management functions failed. The key variable is a part of the Fabric OS configuration database and is for support use only. The error variable is an internal error number.
  • Page 326 FICU-1004 Severity WARNING FICU-1004 Message <timestamp>, [FICU-1004], <sequence-number>,, WARNING, <system-name>, <function name>: Failed to set fabric manager server (FMS) mode: conflicting PID Format:<pid_format>, FMS Mode:<mode>. Probable Cause Indicates that a process ID (PID) format conflict was encountered. The core PID format is required for fibre connectivity control unit port (FICON-CUP).
  • Page 327 FICU-1007 Recommended Check if the FICON channel corresponding to the PID in the message is functioning correctly. Action Severity WARNING FICU-1007 Message <timestamp>, [FICU-1007], <sequence-number>,, WARNING, <system-name>, <function name>: Failed to allocate memory while performing <message>. Probable Cause Indicates that memory resources are low. This might be a transient problem. Recommended If the message persists, check the memory usage on the switch, using the memShow command.
  • Page 328 FICU-1010 FICU-1010 Message <timestamp>, [FICU-1010], <sequence-number>,, WARNING, <system-name>, FMS Mode enable failed due to address conflict with port <port number> Probable Cause Indicates that the Fibre Connectivity (FICON) Management Server mode (fmsMode) was not enabled because the specified port which has an address conflict with the CUP management port is in use.
  • Page 329 FICU-1014 FICU-1014 Message <timestamp>, [FICU-1014], <sequence-number>,, INFO, <system-name>, CUP SBTOV Timeout - %s, Type(%s). Probable Cause Indicates that the FICON Host failed to send an IU within the SBTOV. Recommended No Action is required. Action Severity INFO FICU-1015 Message CUP SB <timestamp>, [FICU-1015], <sequence-number>,, INFO, <system-name>, Recovery DIB - %s, DIB_Type(%s).
  • Page 330 FICU-1016 Fabric OS Message Reference 53-1001338-01...

  • Page 331: Fklb System Messages

    Chapter FKLB System Messages FKLB-1001 Message <timestamp>, [FKLB-1001], <sequence-number>,, WARNING, <system-name>, exchange <xid> overlapped, pid=<pid> Probable Cause Indicates that the FC kernel driver has timed out the exchange while the application is still active. When the FC kernel driver reuses the exchange, the application will overlap. This happens on a timed-out exchange;...
  • Page 332 FKLB-1001 Fabric OS Message Reference 53-1001338-01...

  • Page 333: Flod System Messages

    Chapter FLOD System Messages FLOD-1001 Message <timestamp>, [FLOD-1001], <sequence-number>, FFDC, WARNING, <system-name>, Unknown LSR type: port <port number>, type <LSR header type> Probable Cause Indicates that the link state record (LSR) type is unknown. The following two LSR header types are the only known types: 1 - Unicast and 3 - Multicast.
  • Page 334 FLOD-1006 Probable Cause Indicates that the received LSR contained an invalid domain number. Recommended No action is required because the LSR is discarded. Action Severity WARNING FLOD-1006 Message <timestamp>, [FLOD-1006], <sequence-number>,, WARNING, <system-name>, Transmitting invalid domain ID: <domain number> Probable Cause Indicates that the transmit LSR contained an invalid domain number.

  • Page 335: Fspf System Messages

    Chapter FSPF System Messages FSPF-1001 Message <timestamp>, [FSPF-1001], <sequence-number>,, ERROR, <system-name>, Input Port <port number> out of range Probable Cause Indicates that the specified input port number is out of range; it does not exist on the switch. Recommended No action is required. Action Severity ERROR...
  • Page 336 FSPF-1005 FSPF-1005 Message <timestamp>, [FSPF-1005], <sequence-number>,, ERROR, <system-name>, Wrong Section Id <section number>, should be <section number>, input port = <port number> Probable Cause Indicates that an incorrect section ID was reported from the specified input port. The section ID is used to identify a set of switches that share an identical topology database.
  • Page 337 FSPF-1008 Recommended No action is required. Action Severity INFO Fabric OS Message Reference 53-1001338-01...
  • Page 338 FSPF-1008 Fabric OS Message Reference 53-1001338-01...

  • Page 339: Fss System Messages

    Chapter FSS System Messages FSS-1001 Message <timestamp>, [FSS-1001], <sequence-number>, SLOT cp-slot-number | CHASSIS, WARNING, <system-name>, Component (<component name>) dropping HA data update (<update ID>). Probable Cause Indicates that an application has dropped a high availability (HA) data update. Recommended Run the haSyncStart command if this is a dual-CP system, or reboot the switch if it is a nonbladed Action system.
  • Page 340 FSS-1004 If the message persists, run the supportFtp (as needed) to set up automatic FTP transfers; then run the supportSave command and contact your switch service provider. Severity WARNING FSS-1004 Message <timestamp>, [FSS-1004], <sequence-number>, SLOT cp-slot-number | CHASSIS, ERROR, <system-name>, Memory shortage Probable Cause Indicates that the system ran out of memory.
  • Page 341 FSS-1008 Probable Cause Indicates that the Ethernet connection between the active control processor (CP) and standby CP is not healthy. The error occurs when the standby CP does not respond to a request from the active CP within five seconds. This usually indicates a problem with the internal Ethernet connection and a disruption of the synchronization process.
  • Page 342 FSS-1011 FSS-1011 Message <timestamp>, [FSS-1011], <sequence-number>, SLOT cp-slot-number | CHASSIS, INFO, <system-name>, FSS Info: <Info Message>. Probable Cause Indicates an informational message only. Recommended No action is required. Action Severity INFO Fabric OS Message Reference 53-1001338-01...

  • Page 343: Fssm System Messages

    Chapter FSSM System Messages FSSM-1002 Message <timestamp>, [FSSM-1002], <sequence-number>, SLOT cp-slot-number | CHASSIS, INFO, <system-name>, HA State is in sync. Probable Cause Indicates that the high availability (HA) state for the active control processor (CP) is in synchronization with the HA state of the standby CP. If the standby CP is healthy, then a failover is nondisruptive.
  • Page 344 FSSM-1004 Probable Cause Indicates that the active control processor (CP) and the standby CP in a dual CP system are running firmware that are incompatible with each other. If the active CP fails, the failover will be disruptive. In a switch system, this message is logged when a firmware upgrade or downgrade was invoked. The new firmware version is not compatiable with the current running version.

  • Page 345: Fw System Messages

    Chapter FW System Messages FW-1001 Message <timestamp>, [FW-1001], <sequence-number>,, INFO, <system-name>, <label>, value has changed(High=<High value>, Low=<Low value>). Current value is <Value> <Unit>. Probable Cause Indicates that the internal temperature of the switch has changed. Recommended No action is required. Respond to this message as is appropriate to the particular policy of the Action end-user installation.
  • Page 346 FW-1004 Severity WARNING FW-1004 Message <timestamp>, [FW-1004], <sequence-number>,, INFO, <system-name>, <Label>, is between high and low boundaries(High=<High value>, Low=<Low value>). Current value is <Value> <Unit>. Probable Cause Indicates that the internal temperature of the switch has changed from a value outside of the acceptable range to a value within the acceptable range.
  • Page 347 FW-1007 FW-1007 Message <timestamp>, [FW-1007], <sequence-number>,, WARNING, <system-name>, <Label>, is above high boundary(High=<High value>, Low=<Low value>). Current value is <Value> <Unit>. Probable Cause Indicates that the speed of the fan has risen above the high boundary. Fan problems typically contribute to temperature problems. Recommended Consistently abnormal fan speeds generally indicate that the fan is failing.
  • Page 348 FW-1011 Recommended Verify that you have installed the power supply correctly and that it is correctly seated in the Action chassis. If the problem persists, replace the faulty power supply. Severity WARNING FW-1011 Message <timestamp>, [FW-1011], <sequence-number>,, INFO, <system-name>, <Label>, is above high boundary(High=<High value>, Low=<Low value>).
  • Page 349 FW-1035 Probable Cause Indicates that the temperature of the small form-factor pluggable (SFP) has fallen below the low boundary. Recommended No action is required. Respond to this message as is appropriate to the particular policy of the Action end-user installation. Severity WARNING FW-1035...
  • Page 350 FW-1038 Severity INFO FW-1038 Message <timestamp>, [FW-1038], <sequence-number>,, WARNING, <system-name>, <Label>, is below low boundary(High=<High value>, Low=<Low value>). Current value is <Value> <Unit>. Probable Cause Indicates that the receive power value of the small form-factor pluggable (SFP) has fallen below the low boundary.
  • Page 351 FW-1041 FW-1041 Message <timestamp>, [FW-1041], <sequence-number>,, INFO, <system-name>, <Label>, value has changed(High=<High value>, Low=<Low value>). Current value is <Value> <Unit>. Probable Cause Indicates that the transmit power value of the small form-factor pluggable (SFP) has changed. The transmit performance area measures the amount of outgoing laser to help you determine if the SFP is in good working condition or not.
  • Page 352 FW-1044 FW-1044 Message <timestamp>, [FW-1044], <sequence-number>,, INFO, <system-name>, <Label>, is between high and low boundaries(High=<High value>, Low=<Low value>). Current value is <Value> <Unit>. Probable Cause Indicates that the transmit power value of the small form-factor pluggable (SFP) has changed from a value outside of the acceptable range to a value within the acceptable range.
  • Page 353 FW-1048 Probable Cause Indicates that the value of the small form-factor pluggable (SFP) voltage has risen above the high boundary. The supplied current of the SFP transceiver is outside of the normal range, indicating possible hardware failure. Recommended If the current rises above the high boundary, you must replace the SFP. Action Severity WARNING...
  • Page 354 FW-1051 FW-1051 Message <timestamp>, [FW-1051], <sequence-number>,, WARNING, <system-name>, <Label>, is above high boundary(High=<High value>, Low=<Low value>). Current value is <Value> <Unit>. Probable Cause Indicates that the value of the small form-factor pluggable (SFP) voltage has risen above the high boundary. High voltages indicate possible hardware failures. Frequent voltage fluctuations are an indication that the SFP is deteriorating.
  • Page 355 FW-1115 Probable Cause Indicates that the number of times E_Ports have gone down has fallen below the low boundary. E_Ports go down each time you remove a cable or small form-factor pluggable (SFP). SFP failures also cause E_Ports to go down. E_Port downs might be caused by transient errors. A low number of E_Port failures means that the switch is functioning normally.
  • Page 356 FW-1118 • two fabrics have joined. • an E_Port has gone offline. • a principal link has segmented from the fabric. Recommended Verify that the cable is properly connected at both ends. Verify that the small form-factor pluggables Action (SFPs) have not become faulty. An inexplicable fabric reconfiguration might be a transient error and might not require troubleshooting.
  • Page 357 FW-1120 FW-1120 Message <timestamp>, [FW-1120], <sequence-number>,, INFO, <system-name>, <Label>, is between high and low boundaries(High=<High value>, Low=<Low value>). Current value is <Value> <Unit>. Probable Cause Indicates that the number of fabric reconfigurations has changed from a value outside of the acceptable range to a value within the acceptable range.
  • Page 358 FW-1123 FW-1123 Message <timestamp>, [FW-1123], <sequence-number>,, INFO, <system-name>, <Label>, is above high boundary(High=<High value>, Low=<Low value>). Current value is <Value> <Unit>. Probable Cause Indicates that the number of domain ID changes has risen above the high boundary. Domain ID changes occur when there is a conflict of domain IDs in a single fabric and the principal switch has to assign another domain ID to the switch.
  • Page 359 FW-1126 FW-1126 Message <timestamp>, [FW-1126], <sequence-number>,, INFO, <system-name>, <Label>, is below low boundary(High=<High value>, Low=<Low value>). Current value is <Value> <Unit>. Probable Cause Indicates that the number of segmentations has fallen below the low boundary. Segmentation changes might occur due to: •...
  • Page 360 FW-1129 • Zone conflicts. • Domain conflicts. • Segmentation of the principal link between two switches. • Incompatible link parameters. During E_Port initialization, ports exchange link parameters. Rarely, incompatible parameters result in segmentation. Recommended No action is required. Respond to this message as is appropriate to the particular policy of the Action end-user installation.
  • Page 361 FW-1132 Recommended No action is required. Respond to this message as is appropriate to the particular policy of the Action end-user installation. Severity INFO FW-1132 Message <timestamp>, [FW-1132], <sequence-number>,, INFO, <system-name>, <Label>, is between high and low boundaries(High=<High value>, Low=<Low value>). Current value is <Value>...
  • Page 362 FW-1135 FW-1135 Message <timestamp>, [FW-1135], <sequence-number>,, INFO, <system-name>, <Label>, is above high boundary(High=<High value>, Low=<Low value>). Current value is <Value> <Unit>. Probable Cause Indicates that the number of fabric logins has risen above the high boundary. Fabric logins occur when a port or device initializes with the fabric. The event is called a fabric login or FLOGI. Recommended No action is required.
  • Page 363 FW-1139 Probable Cause Indicates that the number of small form-factor pluggable (SFP) state changes has fallen below the low boundary. SFP state changes occur when the SFP is inserted or removed. A low number of SFP state changes means that the switch is functioning normally. Recommended No action is required.
  • Page 364 FW-1161 Recommended Check both ends of your cable connection. Verify that the cable and small form-factor pluggables Action (SFPs) are not faulty. Losses of synchronization commonly causes link failures. If you receive concurrent loss of synchronization errors, troubleshoot the loss of synchronization. Severity INFO FW-1161...
  • Page 365 FW-1164 Probable Cause Indicates that the number of link failures that the port experiences has changed from a value outside of the acceptable range to a value within the acceptable range. Link loss errors occur when a link experiences a loss of signal and fails. Both physical and hardware problems can cause link loss errors.
  • Page 366 FW-1167 Probable Cause Indicates that the number of synchronization losses that the port experiences has risen above the high boundary. Loss-of-synchronization errors frequently occur due to a faulty small form-factor pluggable (SFP) or cable. Signal losses often create synchronization losses. Recommended Check both ends of your cable connection.
  • Page 367 FW-1170 Recommended No action is required. Respond to this message as is appropriate to the particular policy of the Action end-user installation. A low number of signal loss errors means that the switch is functioning normally. Severity INFO FW-1170 Message <timestamp>, [FW-1170], <sequence-number>,, WARNING, <system-name>, <Port Name>, <Label>, is above high boundary(High=<High value>, Low=<Low value>).
  • Page 368 FW-1173 Severity INFO FW-1173 Message <timestamp>, [FW-1173], <sequence-number>,, INFO, <system-name>, <Port Name>, <Label>, is below low boundary(High=<High value>, Low=<Low value>). Current value is <Value> <Unit>. Probable Cause Indicates that the number of protocol errors that the port experiences has fallen below the low boundary.
  • Page 369 FW-1176 FW-1176 Message <timestamp>, [FW-1176], <sequence-number>,, INFO, <system-name>, <Port Name>, <Label>, value has changed(High=<High value>, Low=<Low value>). Current value is <Value> <Unit>. Probable Cause Indicates that the number of invalid words that the port experiences has changed. Invalid words usually indicate a hardware problem with an small form-factor pluggable (SFP) or cable. Recommended Check both ends of your connections, your SFP, and your cable to verify that none are faulty.
  • Page 370 FW-1180 Probable Cause Indicates that the number of invalid words that the port experiences has changed from a value outside of the acceptable range to a value within the acceptable range. Invalid words usually indicate a hardware problem with an small form-factor pluggable (SFP) or cable. Recommended No action is required.
  • Page 371 FW-1183 Recommended This error generally indicates an deteriorating fabric hardware. Check your small form-factor Action pluggables (SFPs), cables, and connections for faulty hardware. Verify that all optical hardware is clean. Severity WARNING FW-1183 Message <timestamp>, [FW-1183], <sequence-number>,, INFO, <system-name>, <Port Name>, <Label>, is between high and low boundaries(High=<High value>, Low=<Low value>).
  • Page 372 FW-1186 FW-1186 Message <timestamp>, [FW-1186], <sequence-number>,, INFO, <system-name>, <Port Name>, <Label>, is above high boundary(High=<High value>, Low=<Low value>). Current value is <Value> <Unit>. Probable Cause Indicates that the percentage of incoming traffic that the port experiences has risen above the high boundary.
  • Page 373 FW-1190 Recommended No action is required. Respond to this message as is appropriate to the particular policy of the Action end-user installation. Severity INFO FW-1190 Message <timestamp>, [FW-1190], <sequence-number>,, INFO, <system-name>, <Port Name>, <Label>, is above high boundary(High=<High value>, Low=<Low value>). Current value is <Value>...
  • Page 374 FW-1193 FW-1193 Message <timestamp>, [FW-1193], <sequence-number>,, INFO, <system-name>, <Port Name>, <Label>, is below low boundary(High=<High value>, Low=<Low value>). Current value is <Value> <Unit>. Probable Cause Indicates that the number of state changes that the port experiences has fallen below the low boundary.
  • Page 375 FW-1196 FW-1196 Message <timestamp>, [FW-1196], <sequence-number>,, INFO, <system-name>, <Port Name>, <Label>, value has changed(High=<High value>, Low=<Low value>). Current value is <Value> <Unit>. Probable Cause Indicates that the number of link resets that the port experiences has changed. Link resets occur due to link timeout errors that indicate no frame activity at all.
  • Page 376 FW-1200 Probable Cause Indicates that the number of link resets that the port experiences has changed from a value outside of the acceptable range to a value within the acceptable range. Link resets occur due to link timeout errors that indicate no frame activity at all. Both physical and hardware problems can cause link resets to increase.
  • Page 377 FW-1203 FW-1203 Message <timestamp>, [FW-1203], <sequence-number>,, INFO, <system-name>, <Port Name>, <Label>, is between high and low boundaries (High=<High value>, Low=<Low value>). Current value is <Value> <Unit>. Probable Cause Indicates that the number of C3 discard frames is between the low and high threshold limits. Recommended Check the target device;...
  • Page 378 FW-1207 Severity WARNING FW-1207 Message <timestamp>, [FW-1207], <sequence-number>,, INFO, <system-name>, <Port Name>, <Label>, is between high and low boundaries (High=<High value>, Low=<Low value>). Current value is <Value> <Unit>. Probable Cause Indicates that the trunk utilization is between low and high thresholds. Recommended No action required.
  • Page 379 FW-1218 Severity INFO FW-1218 Message <timestamp>, [FW-1218], <sequence-number>,, WARNING, <system-name>, <Label>, is above high boundary(High=<High value>, Low=<Low value>). Current value is <Value> <Unit>. Probable Cause Indicates that the number of cyclic redundancy check (CRC) errors has risen above the high boundary.
  • Page 380 FW-1241 Recommended No action is required. Respond to this message as is appropriate to the particular policy of the Action end-user installation. Severity INFO FW-1241 Message <timestamp>, [FW-1241], <sequence-number>,, INFO, <system-name>, <Label>, is below low boundary(High=<High value>, Low=<Low value>). Current value is <Value> <Unit>.
  • Page 381 FW-1244 Probable Cause Indicates that the number of end-to-end (EE) cyclic redundancy check (CRC) errors has changed from a value outside of the acceptable range to a value within the acceptable range. Invalid CRC messages occur when the number of CRC errors in Fibre Channel frames for specific source ID (S_ID) and destination ID (D_ID) pairs change.
  • Page 382 FW-1247 Recommended No action is required. Respond to this message as is appropriate to the particular policy of the Action end-user installation. Severity INFO FW-1247 Message <timestamp>, [FW-1247], <sequence-number>,, INFO, <system-name>, <Label>, is between high and low boundaries(High=<High value>, Low=<Low value>). Current value is <Value>...
  • Page 383 FW-1250 FW-1250 Message <timestamp>, [FW-1250], <sequence-number>,, INFO, <system-name>, <Label>, is above high boundary(High=<High value>, Low=<Low value>). Current value is <Value> <Unit>. Probable Cause Indicates that the number of end-to-end (EE) word frames that the switch transmits has risen above the high boundary. Transmit performance messages appear due to the number of word frames that travel from the configured S_ID to the D_ID pair.
  • Page 384 FW-1274 Probable Cause Indicates that the number of frame types or commands that the port receives has fallen below the low boundary. The port has received a small computer system interface (SCSI) Read, SCSI Write, SCSI Read and Write, SCSI Traffic, or IP commands in a frame. Recommended No action is required.
  • Page 385 FW-1297 Recommended Run the errShow command to determine the IP address that sent the request. Responses to Action security-class messages depend on user policies. Consult your security administrator for response strategies and policies. Severity INFO FW-1297 Message <timestamp>, [FW-1297], <sequence-number>,, INFO, <system-name>, <Label>, is below low boundary(High=<High value>, Low=<Low value>).
  • Page 386 FW-1300 Recommended No action is required. Action Severity INFO FW-1300 Message <timestamp>, [FW-1300], <sequence-number>,, INFO, <system-name>, <Label>, value has changed(High=<High value>, Low=<Low value>). Current value is <Value> <Unit>. Probable Cause Indicates that the number of hypertext transfer protocol (HTTP) violations has changed. HTTP violations indicate that a browser connection request has been received from an unauthorized IP address.
  • Page 387 FW-1303 Recommended Run the errShow command to determine the IP address that sent the request. Responses to Action security-class messages depend on user policies. Consult your security administrator for response strategies and policies. Severity WARNING FW-1303 Message <timestamp>, [FW-1303], <sequence-number>,, INFO, <system-name>, <Label>, is between high and low boundaries(High=<High value>, Low=<Low value>).
  • Page 388 FW-1306 Probable Cause Indicates that the number of application programming interface (API) violations has fallen below the low boundary. API violations indicate that an API connection request has been received from an unauthorized IP address. The simple network management protocol policy (SNMP_POLICY) contains a list of internet protocol (IP) addresses that are authorized to establish API connections to switches in the fabric.
  • Page 389 FW-1309 Probable Cause Indicates that the number of simple network management protocol read (RSNMP) violations has changed. RSNMP violations indicate that an SNMP “get” operation request has been received from an unauthorized IP address. Recommended Run the errShow command to determine the IP address that sent the request. Responses to Action security-class messages depend on user policies.
  • Page 390 FW-1312 Probable Cause Indicates that the number of simple network management protocol read (RSNMP) violations has changed from a value outside of the acceptable range to a value within the acceptable range. RSNMP violations indicate that an SNMP “get” operation request has been received from an unauthorized IP address.
  • Page 391 FW-1315 Recommended Run the errShow command to determine the IP address that sent the request. Responses to Action security-class messages depend on user policies. Consult your security administrator for response strategies and policies. Severity WARNING FW-1315 Message <timestamp>, [FW-1315], <sequence-number>,, INFO, <system-name>, <Label>, is between high and low boundaries(High=<High value>, Low=<Low value>).
  • Page 392 FW-1318 Recommended No action is required. Action Severity INFO FW-1318 Message <timestamp>, [FW-1318], <sequence-number>,, WARNING, <system-name>, <Label>, is above high boundary(High=<High value>, Low=<Low value>). Current value is <Value> <Unit>. Probable Cause Indicates that the number of SES violations has risen above the high boundary. SES violations indicate that a small computer system interface (SCSI) Enclosure Services (SES) request has been received from an unauthorized world wide name (WWN).
  • Page 393 FW-1321 Recommended Run the errShow command to determine the WWN of the device that sent the request. Responses Action to security-class messages depend on user policies. Consult your security administrator for response strategies and policies. Severity INFO FW-1321 Message <timestamp>, [FW-1321], <sequence-number>,, INFO, <system-name>, <Label>, is below low boundary(High=<High value>, Low=<Low value>).
  • Page 394 FW-1324 Recommended No action is required. Action Severity INFO FW-1324 Message <timestamp>, [FW-1324], <sequence-number>,, INFO, <system-name>, <Label>, value has changed(High=<High value>, Low=<Low value>). Current value is <Value> <Unit>. Probable Cause Indicates that the number of serial violations has changed. Serial violations indicate that an unauthorized serial port request has been received.
  • Page 395 FW-1327 FW-1327 Message <timestamp>, [FW-1327], <sequence-number>,, INFO, <system-name>, <Label>, is between high and low boundaries(High=<High value>, Low=<Low value>). Current value is <Value> <Unit>. Probable Cause Indicates that the number of serial violations has changed from a value outside of the acceptable range to a value within the acceptable range.
  • Page 396 FW-1330 FW-1330 Message <timestamp>, [FW-1330], <sequence-number>,, WARNING, <system-name>, <Label>, is above high boundary(High=<High value>, Low=<Low value>). Current value is <Value> <Unit>. Probable Cause Indicates that the number of front panel violations has risen above the high boundary. Front panel violations indicate that an unauthorized front panel request has been received. The FRONTPANEL_POLICY contains a list of switch world wide names (WWNs) for which front panel access is enabled.
  • Page 397 FW-1333 FW-1333 Message <timestamp>, [FW-1333], <sequence-number>,, INFO, <system-name>, <Label>, is below low boundary(High=<High value>, Low=<Low value>). Current value is <Value> <Unit>. Probable Cause Indicates that the number of switch connection control policy (SCC) violations has fallen below the low boundary. SCC violations indicate that an unauthorized switch tried to join the fabric. The SCC_POLICY contains a list of switches by world wide names (WWNs) that are allowed to be members of a fabric.
  • Page 398 FW-1336 FW-1336 Message <timestamp>, [FW-1336], <sequence-number>,, INFO, <system-name>, <Label>, value has changed(High=<High value>, Low=<Low value>). Current value is <Value> <Unit>. Probable Cause Indicates that the number of device cable connection (DCC) violations has changed. DCC violations indicate that an unauthorized device tried to join the fabric. The DCC_POLICY allows for the specification of rules for binding device ports (typically host bus adaptor (HBA) ports) to specific switch ports.
  • Page 399 FW-1339 Recommended Run the errShow command to determine the device WWN, switch WWN, and switch port. Action Responses to security-class messages depend on user policies. Consult your security administrator for response strategies and policies. Severity WARNING FW-1339 Message <timestamp>, [FW-1339], <sequence-number>,, INFO, <system-name>, <Label>, is between high and low boundaries(High=<High value>, Low=<Low value>).
  • Page 400 FW-1342 Severity INFO FW-1342 Message <timestamp>, [FW-1342], <sequence-number>,, WARNING, <system-name>, <Label>, is above high boundary(High=<High value>, Low=<Low value>). Current value is <Value> <Unit>. Probable Cause Indicates that the number of login violations has risen above the high boundary. Login violations indicate that a login failure has been detected.
  • Page 401 FW-1345 FW-1345 Message <timestamp>, [FW-1345], <sequence-number>,, INFO, <system-name>, <Label>, is below low boundary(High=<High value>, Low=<Low value>). Current value is <Value> <Unit>. Probable Cause Indicates that the number of invalid timestamps has fallen below the low boundary. Invalid-timestamp violations indicate a packet with an invalid timestamp has been received from the primary world wide name (WWN).
  • Page 402 FW-1348 Recommended No action is required. Action Severity INFO FW-1348 Message <timestamp>, [FW-1348], <sequence-number>,, INFO, <system-name>, <Label>, value has changed(High=<High value>, Low=<Low value>). Current value is <Value> <Unit>. Probable Cause Indicates that the number of invalid signatures has changed. Invalid-signature violations indicate that a packet with an invalid signature has been received from the primary fabric configuration server (FCS).
  • Page 403 FW-1351 Probable Cause Indicates that the number of invalid signatures has risen above the high boundary. Invalid-signature violations indicate that a packet with an invalid signature has been received from the primary fabric configuration server (FCS). When the primary FCS downloads a new configuration to the other switches in the fabric, the packet is signed using the private key of the primary FCS.
  • Page 404 FW-1353 FW-1353 Message <timestamp>, [FW-1353], <sequence-number>,, INFO, <system-name>, <Label>, is below low boundary(High=<High value>, Low=<Low value>). Current value is <Value> <Unit>. Probable Cause Indicates that the number of invalid certificates has fallen below the low boundary. This violation indicates that a packet with an invalid certificate has been received from the primary fabric configuration server (FCS).
  • Page 405 FW-1356 Recommended No action is required. Action Severity INFO FW-1356 Message <timestamp>, [FW-1356], <sequence-number>,, INFO, <system-name>, <Label>, value has changed(High=<High value>, Low=<Low value>). Current value is <Value> <Unit>. Probable Cause Indicates that the number of authentication failures has changed. Authentication failures can occur for many reasons.
  • Page 406 FW-1359 Recommended Responses to security-class messages depend on user policies. Consult your security administrator Action for response strategies and policies. Severity WARNING FW-1359 Message <timestamp>, [FW-1359], <sequence-number>,, INFO, <system-name>, <Label>, is between high and low boundaries(High=<High value>, Low=<Low value>). Current value is <Value>...
  • Page 407 FW-1362 FW-1362 Message <timestamp>, [FW-1362], <sequence-number>,, WARNING, <system-name>, <Label>, is above high boundary(High=<High value>, Low=<Low value>). Current value is <Value> <Unit>. Probable Cause Indicates that the number of switch link authentication protocol (SLAP) faulty packets has risen above the high boundary. This counter keeps track of the number of unexpected SLAP packets and SLAP packets with faulty transmission IDs.
  • Page 408 FW-1366 Probable Cause Indicates that the number of time service (TS) out-of-sync violations has fallen below the low boundary. Recommended No action is required. Action Severity INFO FW-1366 Message <timestamp>, [FW-1366], <sequence-number>,, WARNING, <system-name>, <Label>, is above high boundary(High=<High value>, Low=<Low value>). Current value is <Value> <Unit>.
  • Page 409 FW-1369 Severity INFO FW-1369 Message <timestamp>, [FW-1369], <sequence-number>,, INFO, <system-name>, <Label>, is below low boundary(High=<High value>, Low=<Low value>). Current value is <Value> <Unit>. Probable Cause Indicates that the number of no-FCS violations has fallen below the low boundary. This counter records how often the switch loses contact with the primary fabric configuration server (FCS) switch.
  • Page 410 FW-1372 Probable Cause Indicates that the number of no-FCS violations has changed from a value outside of the acceptable range to a value within the acceptable range. This counter records how often the switch loses contact with the primary fabric configuration server (FCS) switch. When the primary FCS switch in the fabric sends its certificate to a switch, the receiving switch saves the world wide name (WWN) of that primary FCS switch.
  • Page 411 FW-1374 FW-1374 Message <timestamp>, [FW-1374], <sequence-number>,, WARNING, <system-name>, <Label>, is above high boundary(High=<High value>, Low=<Low value>). Current value is <Value> <Unit>. Probable Cause Indicates that the number of incompatible security database violations has risen above the high boundary. This violation indicates the number of secure switches with different version stamps have been detected.
  • Page 412 FW-1377 FW-1377 Message <timestamp>, [FW-1377], <sequence-number>,, INFO, <system-name>, <Label>, is below low boundary(High=<High value>, Low=<Low value>). Current value is <Value> <Unit>. Probable Cause Indicates that the number of illegal commands has fallen below the low boundary. This counter tracks how many times commands allowed only on the primary fabric configuration server (FCS) switch have been executed on a non-primary FCS switch.
  • Page 413 FW-1400 Recommended No action is required. Action Severity INFO FW-1400 Message <timestamp>, [FW-1400], <sequence-number>,, INFO, <system-name>, <Label>, value has changed(High=<High value>, Low=<Low value>). Current value is <Value> <Unit>. Probable Cause Indicates that the flash usage percentage has changed. Flash increases and decreases slightly with normal operation of the switch.
  • Page 414 FW-1403 FW-1403 Message <timestamp>, [FW-1403], <sequence-number>,, INFO, <system-name>, <Label>, is between high and low boundaries(High=<High value>, Low=<Low value>). Current value is <Value> <Unit>. Probable Cause Indicates that the flash usage percentage has changed from a value outside of the acceptable range to a value within the acceptable range.
  • Page 415 FW-1426 Severity INFO FW-1426 Message <timestamp>, [FW-1426], <sequence-number>,, WARNING, <system-name>, Switch status change contributing factor Power supply: <Number Bad> bad, <Number Missing> absent. Probable Cause Indicates that the switch status is not in a healthy state. This occurred because the number of faulty or missing power supplies is greater than or equal to the policy set by the switchStatusPolicySet command.
  • Page 416 FW-1430 Probable Cause Indicates that the switch status is not in a healthy state. This occurred because the power supplies are not in the correct slots for redundancy. Recommended Rearrange the power supplies so that one is in an odd slot and other in an even slot to make them Action redundant.
  • Page 417 FW-1433 FW-1433 Message <timestamp>, [FW-1433], <sequence-number>,, WARNING, <system-name>, Switch status change contributing factor CP: CP non-redundant. Probable Cause Indicates that the switch status is not in a healthy state. This occurred because the number of faulty CPs is greater than or equal to the policy set by the switchStatusPolicySet command. The CPs are non-redundant.
  • Page 418 FW-1436 FW-1436 Message <timestamp>, [FW-1436], <sequence-number>,, WARNING, <system-name>, Switch status change contributing factor Marginal ports: <Num of marginal ports and the port numbers> marginal ports. (Ports <Unknown>) Probable Cause Indicates that the switch status is not in a healthy state. This occurred because the number of marginal ports is greater than or equal to the policy set using the switchStatusPolicySet command.
  • Page 419 FW-1440 Probable Cause Indicates that the switch status is not in a healthy state. This occurred because the switch is offline. Recommended Run the switchEnable command. Action Severity WARNING FW-1440 Message <timestamp>, [FW-1440], <sequence-number>,, INFO, <system-name>, <FRU label> state has changed to <FRU state>. Probable Cause Indicates that the state of the specified field-replaceable unit (FRU) has changed to “absent”.
  • Page 420 FW-1444 Probable Cause Indicates that the state of the specified field-replaceable unit (FRU) changed to “off”. Recommended No action is required. Verify that the event was planned. Action Severity INFO FW-1444 Message <timestamp>, [FW-1444], <sequence-number>,, WARNING, <system-name>, <FRU label> state has changed to <FRU state>. Probable Cause Indicates that the state of the specified field-replaceable unit (FRU) has changed to “faulty”.
  • Page 421 FW-1500 Recommended To maintain full (2X) redundancy and proper monitoring by Fabric Watch, 4 active power supplies Action should be supplied and the default values associated with the presence of an AP blade should be entered with switchStatusPolicyset command. Severity WARNING FW-1500 Message...
  • Page 422 FW-1511 FW-1511 Message <timestamp>, [FW-1511], <sequence-number>,, INFO, <system-name>, <Port Name>, <Label>, has crossed lower threshold boundary to in between(High=<High value>, Low=<Low value>). Current value is <Value> <Unit>. Probable Cause Indicates that the number of link failures that the port experiences has changed and crossed lower threshold boundary to a value within the acceptable range.
  • Page 423 FW-1514 FW-1514 Message <timestamp>, [FW-1514], <sequence-number>,, INFO, <system-name>, <Port Name>, <Label>, has dropped below upper threshold boundary to in between(High=<High value>, Low=<Low value>). Current value is <Value> <Unit>. Probable Cause Indicates that the number of synchronization losses that the port experiences has changed and dropped below upper threshold boundary to a value within the acceptable range.
  • Page 424 FW-1517 FW-1517 Message <timestamp>, [FW-1517], <sequence-number>,, INFO, <system-name>, <Port Name>, <Label>, has crossed lower threshold boundary to in between(High=<High value>, Low=<Low value>). Current value is <Value> <Unit>. Probable Cause Indicates that the number of protocol errors that the port experiences has changed and crossed lower threshold boundary to a value within the acceptable range.
  • Page 425 FW-1521 Probable Cause Indicates that the number of invalid words that the port experiences has changed and dropped below upper threshold boundary to a value within the acceptable range. Invalid words usually indicate a hardware problem with a small form-factor pluggable (SFP) or cable. Recommended No action is required.
  • Page 426 FW-1524 Recommended No action is required. Respond to this message as is appropriate to the particular policy of the Action end-user installation. Severity INFO FW-1524 Message <timestamp>, [FW-1524], <sequence-number>,, INFO, <system-name>, <Port Name>, <Label>, has dropped below upper threshold boundary to in between(High=<High value>, Low=<Low value>).
  • Page 427 FW-1527 FW-1527 Message <timestamp>, [FW-1527], <sequence-number>,, INFO, <system-name>, <Port Name>, <Label>, has crossed lower threshold boundary to in between(High=<High value>, Low=<Low value>). Current value is <Value> <Unit>. Probable Cause Indicates that the number of state changes that the port experiences has changed and crossed lower threshold boundary to a value within the acceptable range.
  • Page 428 FW-1530 FW-1530 Message <timestamp>, [FW-1530], <sequence-number>,, INFO, <system-name>, <Port Name>, <Label>, has dropped below upper threshold boundary to in between(High=<High value>, Low=<Low value>). Current value is <Value> <Unit>. Probable Cause Indicates that the number of link resets that the port experiences has changed and dropped below upper threshold boundary to a value within the acceptable range.
  • Page 429 FW-1534 Probable Cause Indicates that the trunk utilization crossed lower threshold boundary to in between low and high thresholds. Recommended No action required. Action Severity INFO FW-1534 Message <timestamp>, [FW-1534], <sequence-number>,, INFO, <system-name>, <Port Name>, <Label>, has dropped below threshold boundary to in between(High=<High value>, Low=<Low value>).
  • Page 430 FW-3012 FW-3012 Message <timestamp>, [FW-3012], <sequence-number>,, WARNING, <system-name>, <Port Name>,<Label> is above high boundary(High=<High value>, Low=<Low value>). Current value is <Value> <Unit>. Probable Cause Indicates that the circuit utilization is above threshold. Recommended No action is required. Action Severity WARNING FW-3013 Message <timestamp>, [FW-3013], <sequence-number>,, INFO, <system-name>, <Port...
  • Page 431 FW-3016 Severity INFO FW-3016 Message <timestamp>, [FW-3016], <sequence-number>,, WARNING, <system-name>, <Port Name>,<Label> is above high boundary(High=<High value>, Low=<Low value>). Current value is <Value> <Unit> Probable Cause Indicates the packet loss that the circuit experiences is above threshold. Recommended No action is required. Action Severity WARNING...
  • Page 432 FW-3020 Probable Cause Indicates the number of state changes that the circuit experiences has reduced below the low boundary level. The state of the circuit has changed for either of the reason that if the circuit has gone offline or it has come online. Recommended No action is required.

  • Page 433: Ham System Messages

    Chapter HAM System Messages HAM-1001 Message <timestamp>, [HAM-1001], <sequence-number>, SLOT cp-slpt-number | FFDC | CHASSIS, FFDC, CRITICAL, <system-name>, Standby CP is not healthy, device <device name> status BAD, Severity = <Log="YES" Class="NONE" Severity> Probable Cause Indicates that a standby control processor (CP) device error is reported by the high-availability manager (HAM) Health Monitor, with a specific device and Log="YES”...
  • Page 434 HAM-1005 • Fastboot • Giveup Master:SYSM • CP Faulty:SYSM • FirmwareDownload • ConfigDownload:MS • ChangeWWN:EM • Reboot:WebTool • Fastboot:WebTool • Software Fault:Software Watchdog • Software Fault:Kernel Panic • Software Fault:ASSERT • Reboot:SNMP • Fastboot:SNMP • Reboot • Chassis Config • Reboot:API •...
  • Page 435 HAM-1007 Recommended The standby CP will take over and reset the active CP. The system will be non-redundant as the Action standby becomes the active CP. Run the supportSave command and contact your switch service provider. Severity CRITICAL HAM-1007 Message <timestamp>, [HAM-1007], <sequence-number>, SLOT cp-slpt-number | FFDC | CHASSIS, FFDC, CRITICAL, <system-name>,Need to reboot the system for recovery, reason: <reason name>.
  • Page 436 HAM-1012 HAM-1012 Message <timestamp>, [HAM-1012], <sequence-number>, SLOT cp-slot-number | CHASSIS, CRITICAL, <system-name>,Password database conversion failed. Probable Cause Indicates the password database conversion failed. Recommended No action is required. Action Severity CRITICAL Fabric OS Message Reference 53-1001338-01...

  • Page 437: Hamk System Messages

    Chapter HAMK System Messages HAMK-1001 Message <timestamp>, [HAMK-1001], <sequence-number>, SLOT cp-slot-number | CHASSIS, FFDC, CRITICAL, <system-name>, Warm recovery failed. Probable Cause Indicates the switch failed during the warm recovery. Recommended This message triggers a switch reboot automatically and attempts a cold recovery. Run the Action supportFtp command (as needed) to set up automatic FTP transfers;...
  • Page 438 HAMK-1004 HAMK-1004 Message <timestamp>,[HAMK-1004], <sequence-number>, SLOT cp-slot-number | CHASSIS, INFO, <system-name>, Resetting standby CP (double reset may occur). Probable Cause Indicates that the standby control processor (CP) is being reset due to a loss of heartbeat. This message is typically seen when the standby CP has been rebooted. Note that in certain circumstances a CP may experience a double reset and reboot twice in a row.

  • Page 439: Hil System Messages

    Chapter HIL System Messages HIL-1101 Message <timestamp>, [HIL-1101], <sequence-number>,, ERROR, <system-name>, Slot <slot number> faulted, <nominal voltage> (<measured voltage>) is above threshold. Probable Cause Indicates that the blade voltage is above the threshold. Recommended Replace the faulty blade or switch (for nonbladed switches). Action Severity ERROR...
  • Page 440 HIL-1104 HIL-1104 Message <timestamp>, [HIL-1104], <sequence-number>,, ERROR, <system-name>, Blower <blower number> faulted, <nominal voltage> (<measured voltage>) is below threshold. Probable Cause Indicates that the fan voltage is below the threshold. Recommended Run the psShow command to verify the power supply status. Action Try to reseat the faulty fan field-replaceable unit (FRU) and power supply FRU to verify that they are seated properly.
  • Page 441 HIL-1107 HIL-1107 Message <timestamp>, [HIL-1107], <sequence-number>, FFDC, ERROR, <system-name>, Switch faulted, <nominal voltage> (<measured voltage>)above threshold. Probable Cause Indicates that the switch voltage is above threshold. This message is specific to nonbladed switches and is not applicable to the Brocade 24000 or 48000. Recommended For the Brocade 200E, 3250, 3850, 4012, 4016, 4018, 4020, and 4024, the entire switch must Action...
  • Page 442 HIL-1202 If the fan continues to generate this message, replace the fan FRU. Severity WARNING HIL-1202 Message <timestamp>, [HIL-1202], <sequence-number>,, ERROR, <system-name>, Blower <blower number> faulted, speed (<measured speed> RPM) below threshold. Probable Cause Indicates that the specified fan speed (in RPMs) has fallen below the minimum threshold. Recommended Replace the fan field-replaceable unit (FRU).
  • Page 443 HIL-1206 HIL-1206 Message <timestamp>, [HIL-1206], <sequence-number>,, ERROR, <system-name>, Fan <fan number> sensor <sensor number> , speed (<measured speed> RPM) below threshold. Probable Cause Indicates that the specified fan speed (in RPMs) has fallen below the minimum threshold. This problem can quickly cause the switch to overheat. This message is specific to nonbladed switches and is not applicable to the Brocade 24000 or 48000.
  • Page 444 HIL-1301 HIL-1301 Message <timestamp>, [HIL-1301], <sequence-number>,, WARNING, <system-name>, 1 blower failed or missing. Replace failed or missing blower assembly immediately. Probable Cause Indicates that a fan field-replaceable unit (FRU) has failed or has been removed. This message is often preceded by a low speed error message. This problem can cause the switch to overheat. Recommended Replace the affected fan FRU immediately.
  • Page 445 HIL-1305 Severity ERROR HIL-1305 Message <timestamp>, [HIL-1305], <sequence-number>,, ERROR, <system-name>, One or two fans failed. Replace failed fan FRUs immediately. Probable Cause Indicates that multiple fan field-replaceable units (FRUs) have failed. This message is often preceded by a low fan speed message. Recommended Replace the faulty fan FRUs immediately.
  • Page 446 HIL-1309 Recommended Replace the faulty fan field-replaceable units (FRUs) immediately. Action Severity ERROR HIL-1309 Message <count> <timestamp>, [HIL-1309], <sequence-number>,, ERROR, <system-name>, FRUs failed. Replace failed fan FRUs immediately. Probable Cause Indicates that multiple fans have failed. This message is often preceded by a low fan speed message.
  • Page 447 HIL-1402 Probable Cause Indicates that one fan field-replaceable unit (FRU) has been removed. Recommended Install the missing fan FRU. Action Severity WARNING HIL-1402 Message <timestamp>, [HIL-1402], <sequence-number>,, WARNING, <system-name>, Two fan FRUs missing. Install fan FRUs immediately. Probable Cause Indicates that two fan field-replaceable units (FRUs) have been removed. Recommended Install the missing fan FRUs immediately.
  • Page 448 HIL-1502 Recommended Run the fanShow command to verify all the fans are working properly. Action Make sure that the area is well-ventilated and that the room temperature is within operational range of your switch. Refer to the hardware reference manual for your switch for the operational temperature range.
  • Page 449 HIL-1505 Recommended No action is required. Action Severity INFO HIL-1505 Message <timestamp>, [HIL-1505], <sequence-number>,, WARNING, <system-name>, High <measured temperature> temperature ( C) exceeds environmental specifications. Probable Cause Indicates that temperatures in the system have risen above the warning threshold and the fan speed is increased.
  • Page 450 HIL-1508 Severity CRITICAL HIL-1508 Message <timestamp>, [HIL-1508], <sequence-number>, FFDC, CRITICAL, <system-name>, Fan faulty warning time expired. System preparing for shutdown. Probable Cause Indicates that temperatures in the system have remained above the critical threshold too long. Recommended To avoid causing damage to the switch, the system shuts down automatically. To help prevent Action future problems, make sure that all the fans are working properly.
  • Page 451 HIL-1601 HIL-1601 Message <timestamp>, [HIL-1601], <sequence-number>,, ERROR, <system-name>, Using backup temperature sensor. Service immediately. Probable Cause Indicates that temperature readings from the primary sensor are out of range. Recommended Run the fanShow command to verify that all fans are operating correctly. Replace any deteriorating Action fan field-replaceable units (FRUs).
  • Page 452 HIL-1650 Recommended Ensure that the power cord is connected to the unit with a valid power source and then switch on Action the unit. If the problem persists, try reseating the unit. If the problem still persists replace the FRU. Severity WARNING HIL-1650...

  • Page 453: Hlo System Messages

    Chapter HLO System Messages HLO-1001 Message <timestamp>, [HLO-1001], <sequence-number>, FFDC, ERROR, <system-name>, Incompatible Inactivity timeout <dead timeout> from port <port number>, correct value <value>. Probable Cause Indicates that the HLO message was incompatible with the value specified in the FSPF protocol. The Brocade switch will not accept FSPF frames from the remote switch.
  • Page 454 HLO-1003 The switch has received an invalid HLO because either the domain or port number in the HLO message has an invalid value. This error can only occur when the Brocade switch is connected to a switch from another manufacturer. Recommended The HLO message of the remote switch must be compatible with the value specified in the FSPF Action...

  • Page 455: Hmon System Messages

    Chapter HMON System Messages HMON-1001 Message <timestamp>, [HMON-1001], <sequence-number>, FFDC, CRITICAL, <system-name>, <Failure description> Probable Cause Indicates there was a problem reading an essential file containing configuration information from the nonvolatile storage device. This could be the result of a missing file or a corrupt file system. Recommended Run the firmwareDownload command to reinstall the firmware to your switch.
  • Page 456 HMON-1001 Fabric OS Message Reference 53-1001338-01...

  • Page 457: Hsl System Messages

    DRAFT: BROCADE CONFIDENTIAL Chapter HSL System Messages HSL-1000 Message <timestamp>, [HSL-1000], <sequence-number>,, CRITICAL, <system-name>, HSL initialization failed. Probable Cause Indicates an HSL initialization failure. Recommended No action is required. Action Severity CRITICAL HSL-1001 Message <timestamp>, [HSL-1001], <sequence-number>,, CRITICAL, <system-name>, Failed to acquire system mac address pool.
  • Page 458 DRAFT: BROCADE CONFIDENTIAL HSL-1004 Recommended No action is required. Action Severity INFO HSL-1004 Message <timestamp>, [HSL-1004], <sequence-number>,, ERROR, <system-name>, Incompatible SFP for interface <Interface name> is detected. Probable Cause Indicates an incompatible SFP for the interface has been inserted. Recommended Use the correct SFP for this interface.
  • Page 459 DRAFT: BROCADE CONFIDENTIAL HSL-1007 Recommended Install more memory on board. Action Severity CRITICAL HSL-1007 Message <timestamp>, [HSL-1007], <sequence-number>,, ERROR, <system-name>, Failed to read SFP for interface <InterfaceName>. Probable Cause Indicates a failure to read an SFP. Recommended No action is required. Action Severity ERROR...
  • Page 460 DRAFT: BROCADE CONFIDENTIAL HSL-1007 Fabric OS Message Reference 53-1001338-01...

  • Page 461: Http System Messages

    Chapter HTTP System Messages HTTP-1001 Message <timestamp>, [HTTP-1001], <sequence-number>,, INFO, <system-name>, Switch PIDformat has changed to <current PID format>. Probable Cause Indicates that the PID format was changed by the administrator. Recommended No action is required. For more information on PID format, refer to the Fabric OS Administrator’s Action Guide.
  • Page 462 HTTP-1003 Fabric OS Message Reference 53-1001338-01...

  • Page 463: Ibd System Messages

    Chapter IBD System Messages IBD-1001 Message <timestamp>, [FKLB-1001], <sequence-number>,, ERROR, <system-name>, Slot <slot number>, Port GE<port number>: Maximum attempts to restart failed. Disabling port. Probable Cause Indicates that the specified port has crashed unexpectedly and restarting attempts have failed. Recommended Power off and power on the blade using the slotPowerOff and slotPowerOn commands.
  • Page 464 IBD-1001 Fabric OS Message Reference 53-1001338-01...

  • Page 465: Ibpd System Messages

    Chapter IBPD System Messages IBPD-1001 Message <timestamp>, [IBPD-1001], <sequence-number>,, WARNING, <system-name>, <Function name>:<Line number> initiator name length exceeds the <Max length limit> character limit [<Initiator name>] Probable Cause Indicates that the initiator name length exceeds the supported limit of characters. Recommended Change the initiator name, keeping the number of characters within the supported limit.
  • Page 466 IBPD-1003 Fabric OS Message Reference 53-1001338-01...

  • Page 467: Icpd System Messages

    Chapter ICPD System Messages ICPD-1001 Message <timestamp>, [ICPD-1001], <sequence-number>,, ERROR, <system-name>, Failed to allocate memory: (<function name>). Probable Cause Indicates that the specified function failed to allocate memory. Recommended Check memory usage on the switch using the memShow command. Action Reboot or power cycle the switch.
  • Page 468 ICPD-1005 Recommended Enable the iSNS Client service on a single switch in the fabric using the fosConfig command. Refer Action to the Fabric OS Command Reference for more information on this command. Severity WARNING ICPD-1005 Message <timestamp>, [ICPD-1005], <sequence-number>,, WARNING, <system-name>, iSCSI configuration between local switch (<local domain id>) and peer (<peer domain id>) is out of sync.
  • Page 469 ICPD-1008 Recommended No action is required. Action Severity INFO Fabric OS Message Reference 53-1001338-01...
  • Page 470 ICPD-1008 Fabric OS Message Reference 53-1001338-01...

  • Page 471: Ipad System Messages

    Chapter IPAD System Messages IPAD-1000 Message <timestamp>, [IPAD-1000], <sequence-number>,, INFO, <system-name> <Type of managed entity> <Instance number of managed entity> <Type of network interface> <Instance number of network interface> <Protocol address family> <Source of address change> <Value of address and prefix> <DHCP enabled or not>. Probable Cause Indicates that a change in the local IP address has occurred.
  • Page 472 IPAD-1001 Fabric OS Message Reference 53-1001338-01...

  • Page 473: Ips System Messages

    Chapter IPS System Messages IPS-1001 Message <timestamp>, [IPS-1001], <sequence-number>,, WARNING, <system-name>, <message> FCIP License Not Installed (<error>) Probable Cause Indicates that the FCIP license is not installed on the switch. Recommended Run the licenseShow command to check the installed licenses on the switch. Contact your switch Action supplier for a FCIP license.
  • Page 474 IPS-1005 Probable Cause Indicates that configured Port Mode is different from the intended use. Recommended Change the port configuration (by deleting configured FCIP tunnels or iSCSI sessions) to return the Action port mode to neutral before attempting to configure the port for a different mode or use. Severity WARNING IPS-1005...

  • Page 475: Iscs System Messages

    Chapter ISCS System Messages ISCS-1000 Message <timestamp>, [ISCS-1000], <sequence-number>,, ERROR, <system-name>, Slot <slot number> Port GE<port number> crashed unexpectedly. Probable Cause Indicates the specified port has crashed. Recommended No action is required; the port will restart automatically. Action Severity ERROR Fabric OS Message Reference 53-1001338-01...
  • Page 476 ISCS-1000 Fabric OS Message Reference 53-1001338-01...

  • Page 477: Isns System Messages

    Chapter ISNS System Messages ISNS-1001 Message <timestamp>, [ISNS-1001], <sequence-number>,, INFO, <system-name>, Configuration peering with external iSNS server <New config iSNS server IP address> slot/port <New config Slot number>/ge<New config port number> (current <Current iSNS server IP address> <Current slot number>/ge<Current port number>). Probable Cause Indicates that the user has issued the isnscCfg command.
  • Page 478 ISNS-1004 ISNS-1004 Message <timestamp>, [ISNS-1004], <sequence-number>,, WARNING, <system-name>, Timeout refreshing iSNS database with iSNS server <iSNS server IP address> slot/port <Slot number>/ge<Port number> Reg-Period <Registration-Period in seconds>. Probable Cause Indicates that the internet storage name service (iSNS) client failed to receive a successful response for a DevAttrQry within the specified Registration-Period.
  • Page 479 ISNS-1009 Recommended No action is required. You may change the configuration and retry the peering with the external Action iSNS server. Severity INFO ISNS-1009 Message <timestamp>, [ISNS-1009], <sequence-number>,, INFO, <system-name>, Peering with external iSNS server <iSNS server IP address> not started because no virtual targets found.
  • Page 480 ISNS-1014 Probable Cause Indicates that the internet storage name service (iSNS) client failed to establish a connection with the iSNS server. Recommended Verify the connection of the iSNS server to the slot or port. Use the isnscCfg command to display or Action correct the server IP address.

  • Page 481: Kac System Messages

    Chapter KAC System Messages KAC-1002 Message <timestamp>, [KAC-1002], <sequence-number>,, ERROR, <system-name>, KAC(<Key Vault Type>) communication Error: Error connecting to <Backup or Primary>. Probable Cause Indicates that the key archival client is unable to communicate with the primary or backup key vault.
  • Page 482 KAC-1008 Probable Cause Indicates that the key archival client is unable to put to the primary or backup key vault. Recommended Determine whether the configured key value is operational, and if it is not, change the switch key Action vault settings or resolve the operational problem at the vault. Severity ERROR KAC-1008...

  • Page 483: Kswd System Messages

    Chapter KSWD System Messages KSWD-1001 Message <timestamp>, [KSWD-1001], <sequence-number>, FFDC, WARNING, <system-name>, <Software component>:<Software component Process ID> failed to refresh (<Current time>:<Refresh time>). Probable Cause Indicates that one of the critical daemons is found to be nonresponsive. An abort signal is sent. Recommended Copy the warning message along with any core file information, and contact your switch service Action...
  • Page 484 KSWD-1002 Fabric OS Message Reference 53-1001338-01...

  • Page 485: Ktrc System Messages

    Chapter KTRC System Messages KTRC-1001 Message <timestamp>, [KTRC-1001], <sequence-number>,, WARNING, <system-name>, Dump memory size exceeds dump file size Probable Cause Indicates the dump memory size has exceeded the dump file size. Recommended No action is required. Action Severity WARNING KTRC-1002 Message <timestamp>, [KTRC-1002], <sequence-number>,, INFO, <system-name>, Concurrent trace dumping.
  • Page 486 KTRC-1005 Recommended No action is required. Action Severity ERROR KTRC-1005 Message <timestamp>, [KTRC-1005], <sequence-number>,, ERROR, <system-name>, Trace initialization failed. <Reason initialization failed>. <Internal error code>. Probable Cause Indicates that a trace was unable to initialize. Recommended No action is required. Action Severity ERROR...

  • Page 487: L2Sys System Messages

    DRAFT: BROCADE CONFIDENTIAL Chapter L2SYS System Messages L2SS-1001 Message <timestamp>, [L2SS-1001], <sequence-number>,, ERROR, <system-name>, Socket Error: <reason> for socket <sockname> the error code <errorname>. Probable Cause Indicates an error has occurred in the Linux socket. Recommended Restart the l2ssd daemon. Action Severity ERROR...
  • Page 488 DRAFT: BROCADE CONFIDENTIAL L2SS-1005 Recommended Restart the l2sysd daemon. Action Severity ERROR L2SS-1005 Message <timestamp>, [L2SS-1005], <sequence-number>,, ERROR, <system-name>, Mac-address-table hash failed even after two attempts for slot <slot> chip <chip>. Probable Cause Indicates a mac-address-table hash failure happened even after two hash changes on the chip. Recommended Restart the l2sysd daemon.

  • Page 489: Lacp System Messages

    DRAFT: BROCADE CONFIDENTIAL Chapter LACP System Messages LACP-1001 Message <timestamp>, [LACP-1001], <sequence-number>,, ERROR, <system-name>, <module> Error opening socket (<error>). Probable Cause Indicates that the initialization of a module within the LACP daemon has failed. Recommended Download a new firmware version using the firmwareDownload command. Refer to the Fabric OS Action Command Reference Manual for more information on this command.
  • Page 490 DRAFT: BROCADE CONFIDENTIAL LACP-1001 Fabric OS Message Reference 53-1001338-01...
  • Page 491 Chapter LANCE System Messages LANCE-1000 Message <timestamp>, [LANCE-1000], <sequence-number>,, ERROR, <system-name>, Slot <slot number> Port GE <port number>: Maximum attempts to restart failed. Disabling port. Probable Cause Indicates that the port is disabled. Recommended No action is required. Action Severity ERROR Fabric OS Message Reference 53-1001338-01...
  • Page 492 LANCE-1000 Fabric OS Message Reference 53-1001338-01...

  • Page 493: Lfm System Messages

    Chapter LFM System Messages LFM-1001 Message <timestamp>, [LFM-1001], <sequence-number>,, INFO, <system-name>, The Logical Fabric Manager service is disabled. Probable Cause Indicates that the Logical Fabric Manager service is disabled. Note that the Logical Fabric Manager service is enabled by the factory setting and it is not user configurable. Recommended No action is required.
  • Page 494 LFM-1004 LFM-1004 Message <timestamp>, [LFM-1004], <sequence-number>,FFDC, CRITICAL, <system-name>, HA is out of sync for opcode <HA OPCODE>, error value <error value>. Probable Cause Indicates the trigger for some internal logging purpose. Recommended Send the ffdc log to the support. Action Severity CRITICAL LFM-1005...

  • Page 495: Log System Messages

    Chapter LOG System Messages LOG-1000 Message <timestamp>, [LOG-1000], <sequence-number>,, INFO, <system-name>, Previous <repeat count> message repeated times Probable Cause Indicates the previous message repeated the specified number of times. Recommended No action is required. Action Severity INFO LOG-1001 Message <timestamp>, [LOG-1001], <sequence-number>, FFDC, WARNING, <system-name>, A log message was dropped Probable Cause Indicates a log message was dropped.
  • Page 496 LOG-1003 LOG-1003 Message <timestamp>, [LOG-1003], <sequence-number>,, INFO, <system-name>, The log has been cleared. Probable Cause Indicates the persistent error log has been cleared. Recommended No action is required. Action Severity INFO Fabric OS Message Reference 53-1001338-01...

  • Page 497: Lsdb System Messages

    Chapter LSDB System Messages LSDB-1001 Message <timestamp>, [LSDB-1001], <sequence-number>,, ERROR, <system-name>, Link State ID <link state ID> out of range Probable Cause Indicates the specified link state database ID is out of the acceptable range. The valid link state ID is the same as the valid domain ID, whose range is from 1 through 239.
  • Page 498 LSDB-1004 Severity CRITICAL LSDB-1004 Message <timestamp>, [LSDB-1004], <sequence-number>,, WARNING, <system-name>, No Link <local domain> State Record for domain Probable Cause Indicates there is no link state record for the specified local domain. Recommended No action is required. The other switch will pass the LSD once the fabric is stable. Action Severity WARNING...

  • Page 499: Mfic System Messages

    Chapter MFIC System Messages MFIC-1001 Message <timestamp>, [MFIC-1001], <sequence-number>,, ERROR, <system-name>, failure at sysmod_scn registry rc= <failure reason> Probable Cause Indicates the system is temporarily out of resources. Recommended No action is required; this message is often transitory. Action If the message persists, run a switch reboot or an haFailover command (if applicable). If the message persists, run the supportFtp command (as needed) to set up automatic FTP transfers;...
  • Page 500 MFIC-1003 Recommended IDID mode is a fabric-wide mode; make sure that any switches added to the fabric are configured Action with the same IDID mode as the fabric. If you are enabling or disabling IDID mode, this message is for information purposes only, and no action is required. IDID mode can be set using the configure command in the CLI or checking the Advanced Web Tools Switch Admin >...

  • Page 501: Mpth System Messages

    Chapter MPTH System Messages MPTH-1001 Message <timestamp>, [MPTH-1001], <sequence-number>, FFDC, ERROR, <system-name>, Null <number> parent, lsId = Probable Cause Indicates a null parent was reported. MPATH uses a tree structure in which the parent is used to connect to the root of the tree. Recommended No action is required.
  • Page 502 MPTH-1003 Fabric OS Message Reference 53-1001338-01...

  • Page 503: Mq System Messages

    Chapter MQ System Messages MQ-1004 Message <timestamp>, [MQ-1004], <sequence-number>,, ERROR, <system-name>, mqRead, queue = <queue name>, queue ID = <queue ID>, type = <message type> Probable Cause Indicates an unexpected message has been received in the specified message queue. The queue name is always fspf_q.
  • Page 504 MQ-1004 Fabric OS Message Reference 53-1001338-01...

  • Page 505: Ms System Messages

    Chapter MS System Messages MS-1001 Message <timestamp>, [MS-1001], <sequence-number>,, WARNING, <system-name>, MS Platform Segmented port=<port number> (<port number (hex)>) (<reason for segmentation> <domain> (<domain (hex)>)) Probable Cause Indicates the management server (MS) has segmented from another switch domain at the specified port number because of errors or inconsistencies defined in the MS platform service.
  • Page 506 MS-1003 • <GCAP Rejected (reason =BUSY) by> Run the firmwareDownload command to upgrade the firmware level on the switch to a level that supports RCS. RCS is supported in Fabric OS v2.6, v3.1 and greater, and v4.1 and greater. • <Reject EXGPLDB from>...
  • Page 507 MS-1005 Severity INFO MS-1005 Message <timestamp>, [MS-1005], <sequence-number>,, ERROR, <system-name>, MS Invalid CT <domain> Response from d= Probable Cause Indicates the management server (MS) received an invalid common transport (CT) response from the switch domain. MS expects either a CT accept IU or a reject IU; the MS received neither response, which violates the Fibre Channel Generic Services (FS-GS) specification.
  • Page 508 MS-1009 MS-1009 Message <timestamp>, [MS-1009], <sequence-number>,, ERROR, <system-name>, RLIR event. Switch Port ID is <port number> (<PID (hex)>). Device Port Tag is <port tag>. <message text>. Probable Cause Indicates a registered link incident record (RLIR) has been generated for one of the actions indicated by the <message>.
  • Page 509 MS-1023 MS-1023 Message <timestamp>, [MS-1023], <sequence-number>,, INFO, <system-name>, Management Server Topology Discovery Service <Enabled or Disabled>. Probable Cause Indicates Management Server Topology Discovery Service is being enabled or disabled. Recommended No action is required. Action Severity INFO MS-1024 Message <timestamp>, [MS-1024], <sequence-number>,, INFO, <system-name>, Management Server Access Control List is Updated.
  • Page 510 MS-1025 Fabric OS Message Reference 53-1001338-01...

  • Page 511: Mstp System Messages

    DRAFT: BROCADE CONFIDENTIAL Chapter MSTP System Messages MSTP-1001 Message <timestamp>, [MSTP-1001], <sequence-number>,, ERROR, <system-name>, <msg>:<msg>. Probable Cause Indicates that the system has failed to allocate memory. Recommended Check the memory usage on the switch using the memShow command. Action Restart or power cycle the switch. Severity ERROR MSTP-1002...
  • Page 512 DRAFT: BROCADE CONFIDENTIAL MSTP-2002 Recommended No action is required Action Severity INFO MSTP-2002 Message <timestamp>, [MSTP-2002], <sequence-number>,, INFO, <system-name>, <Bridge mode information>. My Bridge ID: <Bridge ID> Old Root: <Old Root id> New Root: <New Root ID> Probable Cause Indicates that the MSTP bridge or bridge instance root has changed. Recommended No action is required.

  • Page 513: Nbfs System Messages

    Chapter NBFS System Messages NBFS-1001 Message <timestamp>, [NBFS-1001], <sequence-number>,, INFO, <system-name>, Duplicate E_Port SCN from port <portnumber> in state <state change name> (<state change number>) Probable Cause Indicates a duplicate E_Port State Change Number was reported. The neighbor finite state machine (NBFSM) states are as follows: •...
  • Page 514 NBFS-1003 Severity ERROR NBFS-1003 Message <timestamp>, [NBFS-1003], <sequence-number>,, WARNING, <system-name>, DB_XMIT_SET flag not set in state <current state name>, input <state name>, port <portnumber> Probable Cause Indicates the database transmit set flag was not set for the specified input state on the specified port.

  • Page 515: Ns System Messages

    Chapter NS System Messages NS-1001 Message <timestamp>, [NS-1001], <sequence-number>,, WARNING, <system-name>, The response for request 0x<CT command code> from remote switch 0x<Domain Id> is larger than the max frame size the remote switch can support! Probable Cause Indicates the response payload exceeds the maximum frame size the remote switch can handle. Recommended Run the firmwareDownload command to upgrade the remote switch with firmware v4.3 or higher, Action...
  • Page 516 NS-1004 Reduce the local device count to follow the capability of the lowest version of firmware. Severity INFO NS-1004 Message <timestamp>, [NS-1004], <sequence-number>,, INFO, <system-name>, Number of local devices <Current local device count>, exceeds the standby can support <Local device count that standby can support>, can't sync. Probable Cause Indicates the name server on the standby CP has lower supported capability than the active CP because of different firmware versions running on the active and standby CPs.
  • Page 517 NS-1007 NS-1007 Message <timestamp>, [NS-1007], <sequence-number>,, WARNING, <system-name>, NS has detected a logical ISL port <LISL port number> in TI zone <TI zone name> in fabric <Fabric ID>. Routing may not be setup correctly. Probable Cause Indicates that a logical ISL is detected in the TI zone. Recommended Remove the LISL port from the TI zone because the routing may not be set up correctly.
  • Page 518 NS-1007 Fabric OS Message Reference 53-1001338-01...

  • Page 519: Nsm System Messages

    DRAFT: BROCADE CONFIDENTIAL Chapter NSM System Messages NSM-1001 Message <timestamp>, [NSM-1001], <sequence-number>,, INFO, <system-name>, Interface <Interface Name> is online. Probable Cause Indicates that the interface is online after the protocol dependencies are resolved. Recommended No action is required. Action Severity INFO NSM-1002 Message...
  • Page 520 DRAFT: BROCADE CONFIDENTIAL NSM-1005 Recommended No action is required. Action Severity INFO NSM-1005 Message <timestamp>, [NSM-1005], <sequence-number>,, INFO, <system-name>,The FCoE VLAN: <Vlan name> is in use. First remove all the FCoE sessions of its member ports and then try again to disable it. Probable Cause Indicates that the FCoE VLAN is used in FCoEd.
  • Page 521 DRAFT: BROCADE CONFIDENTIAL NSM-1008 Recommended No action is required. Action Severity INFO Fabric OS Message Reference 53-1001338-01...
  • Page 522 DRAFT: BROCADE CONFIDENTIAL NSM-1008 Fabric OS Message Reference 53-1001338-01...

  • Page 523: Onm System Messages

    DRAFT: BROCADE CONFIDENTIAL Chapter ONM System Messages ONMD-1001 Message <timestamp>, [ONMD-1001], <sequence-number>,, ERROR, <system-name>, Feature Mismatch: <feature>. Probable Cause Indicates the content of a specific feature does not match with the link partner. Recommended Change the setting for that feature on both ends to match them. Action Severity ERROR...
  • Page 524 DRAFT: BROCADE CONFIDENTIAL ONMD-1003 Fabric OS Message Reference 53-1001338-01...

  • Page 525: Pdm System Messages

    Chapter PDM System Messages PDM-1001 Message <timestamp>, [PDM-1001], <sequence-number>,, WARNING, <system-name>, Failed to parse the pdm config. Probable Cause Indicates the parity data manager (PDM) process could not parse the configuration file. This might be caused by a missing configuration file during the installation. Recommended Run the firmwareDownload command to reinstall the firmware.
  • Page 526 PDM-1004 PDM-1004 Message <timestamp>, [PDM-1004], <sequence-number>,, WARNING, <system-name>, PDM memory shortage. Probable Cause Indicates the parity data manager (PDM) process ran out of memory. Recommended Reboot or power cycle the switch. Action If the message persists, run the supportFtp command (as needed) to set up automatic FTP transfers;...
  • Page 527 PDM-1008 Recommended Run the firmwareDownload command to reinstall the firmware. Action If the message persists, run the supportFtp command (as needed) to set up automatic FTP transfers; then run the supportSave command and contact your switch service provider. Severity WARNING PDM-1008 Message <timestamp>, [PDM-1008], <sequence-number>,, WARNING, <system-name>, Failed to...
  • Page 528 PDM-1011 PDM-1011 Message <timestamp>, [PDM-1011], <sequence-number>,, WARNING, <system-name>, File read failed: <file name>, Length(read=<Number of character read>, expected=<Number of characters expected>), errno=<errno returned by read>. Probable Cause Indicates the parity data manager (PDM) process could not read data from the specified file. Recommended Run the firmwareDownload command to reinstall the firmware.
  • Page 529 PDM-1017 Recommended Run the firmwareDownload command to reinstall the firmware. Action If the message persists, run the supportFtp command (as needed) to set up automatic FTP transfers; then run the supportSave command and contact your switch service provider. Severity WARNING PDM-1017 Message <timestamp>, [PDM-1017], <sequence-number>, FFDC, CRITICAL, <system-name>, System...
  • Page 530 PDM-1022 Probable Cause Indicates a system call failed. Recommended Run the firmwareDownload command to reinstall the firmware. Action If the message persists, run the supportFtp command (as needed) to set up automatic FTP transfers; then run the supportSave command and contact your switch service provider. Severity WARNING PDM-1022...

  • Page 531: Pdtr System Messages

    Chapter PDTR System Messages PDTR-1001 Message <timestamp>, [PDTR-1001], <sequence-number>,, INFO, <system-name>, <informational message>. Probable Cause Indicates information has been written to the panic dump files. The watchdog register codes are as follows: • 0x10000000 bit set means that the watch dog timer (WDT) forced a core reset. •...
  • Page 532 PDTR-1002 Fabric OS Message Reference 53-1001338-01...

  • Page 533: Plat System Messages

    Chapter PLAT System Messages PLAT-1000 Message <timestamp>, [PLAT-1000], <sequence-number>, FFDC, CRITICAL, <system-name>, <Function name> <Error string> Probable Cause Indicates nonrecoverable PCI errors have been detected. Recommended The system will be faulted and might automatically reboot. Action If the system does not reboot, then try issuing the reboot command from a command-line prompt. Run the supportFtp command (as needed) to set up automatic FTP transfers;...
  • Page 534 PLAT-1003 Severity CRITICAL PLAT-1003 Message <timestamp>, [PLAT-1003], <sequence-number>, FFDC, CRITICAL, <system-name>, <Info message> Slot <Blade Slot number> C/BE: <Captured Command/Byte-Enables data> ADBUS: <Captured AD bus data> misc_intr <Bridge reset interrupts>. Probable Cause Indicates a PCI bus hang was detected. Recommended The FRU must be replaced.

  • Page 535: Pmgr System Messages

    Chapter PMGR System Messages PMGR-1001 Message <timestamp>, [PMGR-1001], <sequence-number>, INFO, <system-name>, Attempt to create switch <FID> succeeded. Probable Cause Indicates that the switch with the specified FID was successfully created. Recommended No action is required. Action Severity INFO PMGR-1002 Message <timestamp>, [PMGR-1002], <sequence-number>, WARNING, <system-name>, Attempt to create switch <FID>...
  • Page 536 PMGR-1005 Recommended No action is required. Action Severity WARNING PMGR-1005 Message <timestamp>, [PMGR-1005], <sequence-number>, INFO, <system-name>, Attempt to move port(s) <Ports> on slot <Slot> to switch <FID> succeeded. Probable Cause Indicates the successful attempt to move the ports to the specified switch. Recommended No action is required.
  • Page 537 PMGR-1009 Recommended No action is required. Action Severity WARNING PMGR-1009 Message <timestamp>, [PMGR-1009], <sequence-number>, INFO, <system-name>,Attempt to change the base switch to switch <FID> succeeded. Probable Cause Indicates the successful change of the base switch. Recommended No action is required. Action Severity INFO...
  • Page 538 PMGR-1011 Fabric OS Message Reference 53-1001338-01...

  • Page 539: Port System Messages

    Chapter PORT System Messages PORT-1003 Message <port <timestamp>, [PORT-1003], <sequence-number>,, WARNING, <system-name>, Port number> Faulted because of many Link Failures Probable Cause Indicates that the specified port is now disabled because the link on this port had multiple failures that exceeded an internally set threshold on the port. This problem is typically related to hardware. Recommended Check and replace (if necessary) the hardware attached to both ends of the specified port number, Action...
  • Page 540 PORT-1006 Recommended Invoke the portCfgLport command to clear the L_port configuration. Action Severity WARNING PORT-1006 Message <timestamp>, [PORT-1006], <sequence-number>,, INFO, <system-name>, Configuration changed for port (ID: <port number>) in No_Module or No_Light state. Probable Cause Indicates the configuration changes were made to an offline port in No_Module or No_Light state. Recommended No action is required.
  • Page 541 PORT-1010 Recommended No action is required. Action Severity INFO PORT-1010 Message <timestamp>, [PORT-1010], <sequence-number>,, WARNING, <system-name>, Port (ID: <port number>) QOS is disabled. Probable Cause The Port QOS is disabled because the port currently has Best Effort Setting that requires QOS to be disabled on a 4G or 8G long distance platform.
  • Page 542 PORT-1010 Fabric OS Message Reference 53-1001338-01...

  • Page 543: Ps System Messages

    Chapter PS System Messages PS-1000 Message <timestamp>, [PS-1000], <sequence-number>, FFDC, CRITICAL, <system-name>, Failed to initialize Advanced Performance Monitoring. Probable Cause Indicates an unexpected software error has occurred in Advanced Performance Monitoring (APM). The performance monitor has failed to initialize. Recommended The control processor (CP) should restart (or fail over) automatically If this does not happen, restart Action or power cycle the switch to re-initiate the firmware.
  • Page 544 PS-1004 Probable Cause Indicates that the restoring configuration has failed to set the end-to-end monitoring mask on at least one ISL port. Recommended No action is required. End-to-end monitoring is not supported on ISL ports when ISL monitoring is Action enabled.

  • Page 545: Pswp System Messages

    Chapter PSWP System Messages PSWP-1001 Message <timestamp>, [PSWP-1001], <sequence-number>,, INFO, <system-name>, Areas for port <wwn name corresponding to source port> and port <wwn name corresponding to destination port> are swapped. New area for port <wwn name corresponding to source port> is <wwn name corresponding to destination port> and port <new area corresponding to source wwn>...
  • Page 546 PSWP-1004 PSWP-1004 Message <timestamp>, [PSWP-1004], <sequence-number>,, INFO, <system-name>, Blade Swap complete for slots <slot number corresponding to the source blade> and <slot number corresponding to the destination blade>. Probable Cause Indicates that the bladeSwap command has been issued. Recommended No action is required. Action Severity INFO...
  • Page 547 PSWP-1007 Fabric OS Message Reference 53-1001338-01...
  • Page 548 PSWP-1007 Fabric OS Message Reference 53-1001338-01...

  • Page 549: Ras System Messages

    Chapter RAS System Messages RAS-1001 Message <timestamp>, [RAS-1001], <sequence-number>,, INFO, <system-name>, First failure data capture (FFDC) event occurred. Probable Cause Indicates that a failure data event was captured. Recommended Run the supportFtp command (as needed) to set up automatic FTP transfers and run the Action supportSave command then contact your switch service provider.
  • Page 550 RAS-1006 Probable Cause Indicates an internal software error. Recommended Run the supportSave command and contact your switch service provider. Action Severity WARNING RAS-1006 Message <timestamp>, [RAS-1006], <sequence-number>, INFO, <system-name>, Support data file (<Uploaded file name>) automatically transferred to remote address ' <Remote target designated by user>...
  • Page 551 RAS-3001 Probable Cause Indicates that the configured classes of the audit feature have been changed. Recommended No action is required. Action Severity INFO RAS-3001 Message <timestamp>, [RAS-3001], <sequence-number>, INFO, <system-name>, USB storage device plug-in detected. Probable Cause Indicates that the USB storage device plug-in is being detected. Recommended No action is required.
  • Page 552 RAS-3004 Recommended No action is required. Action Severity INFO Fabric OS Message Reference 53-1001338-01...

  • Page 553: Rcs System Messages

    Chapter RCS System Messages RCS-1001 Message <timestamp>, [RCS-1001], <sequence-number>,, INFO, <system-name>, RCS has been disabled. Some switches in the fabric do not support this feature. Probable Cause Indicates that the RCS feature has been disabled on the local switch because not all switches in the fabric support RCS or the switch is in nonnative mode.
  • Page 554 RCS-1004 RCS-1004 Message <timestamp>, [RCS-1004], <sequence-number>,, ERROR, <system-name>, Application(<application name>) not registered.(<error string>) Probable Cause Indicates that a specified application did not register with RCS. Recommended Run the haShow command to view the HA state. Action Run the haDisable and the haEnable commands. Run the rcsInfoShow command to view RCS capability on the fabric.
  • Page 555 RCS-1007 Severity INFO RCS-1007 Message <timestamp>, [RCS-1007], <sequence-number>,, ERROR, <system-name>, Zone DB size and propogation overhead exceeds domain <domain number>'s maximum supported Zone DB size <max zone db size>. Retry after reducing the Zone DB size. Probable Cause Indicates that a domain cannot handle the zone database being committed. Recommended Reduce the zone database size.
  • Page 556 RCS-1008 Fabric OS Message Reference 53-1001338-01...

  • Page 557: Rkd System Messages

    Chapter RKD System Messages RKD-1001 Message <timestamp>, [RKD-1001], <sequence-number>,, INFO, <system-name>, <Re-key type (First time encryption/Rekey/Write Metadata)> operation <Re-key action (started/completed/cancelled)>.\nTarget: <Target physial WWN>, Initiator: <Initiator physical WWN>, LUN ID: <LUN ID>.\n SessionId:<Session ID>/<Session MN> Probable Cause Indicates that a First time encryption/re-key/Write Metadata was started/completed/cancelled. Recommended No action is required.
  • Page 558 RKD-1004 RKD-1004 Message <timestamp>, [RKD-1004], <sequence-number>,, INFO, <system-name>, Message: <Re-key type (First time encryption/Rekey/Write Metadata)> encountered a FATAL SCSI error and will be suspended.\n<I/T/L String>.\nCommand: <Read/Write>\nLBA: <LBA>\nNum Blocks: <Num of Blocks>\nError: <Error String>\nSK/ASC: <SCSI Sense Key>/<SCSI ASC>. Probable Cause Indicates the generic rekey message. Recommended No action is required.

  • Page 559: Rmond System Messages

    DRAFT: BROCADE CONFIDENTIAL Chapter RMOND System Messages RMON-1001 Message <timestamp>, [RMON-1001], <sequence-number>,, INFO, <system-name>, RMON rising threshold alarm from SNMP OID <oid>. Probable Cause Indicates that the threshold level has exceeded for the sample type of RMON alarm. Recommended Check the traffic on the interface. Action Severity INFO...
  • Page 560 DRAFT: BROCADE CONFIDENTIAL RMON-1002 Fabric OS Message Reference 53-1001338-01...

  • Page 561: Rpcd System Messages

    Chapter RPCD System Messages RPCD-1001 Message <timestamp>, [RPCD-1001], <sequence-number>,, WARNING, <system-name>, Authentication Error: client \"<IP address>\" has bad credentials: <bad user name and password pair> Probable Cause Indicates an authentication error was reported. The specified client IP address has faulty credentials.
  • Page 562 RPCD-1004 RPCD-1004 Message <timestamp>, [RPCD-1004], <sequence-number>,, WARNING, <system-name>, Invalid certificate file. Secure RPCd is disabled. Probable Cause Indicates the SSL certificate file has been corrupted. Recommended To enable RPCD in Secure mode, install a valid SSL certificate in the switch. Action Severity WARNING...

  • Page 563: Rtwr System Messages

    Chapter RTWR System Messages RTWR-1001 Message <timestamp>, [RTWR-1001], <sequence-number>,, ERROR, <system-name>, RTWR <routine: error message> 0x<detail 1>, 0x<detail 2>, 0x<detail 3>, 0x<detail 4>, 0x<detail 5> Probable Cause Indicates that an error has occurred in the RTWR. The message provides the name of the routine having the error, and more specific error information.
  • Page 564 RTWR-1003 RTWR-1003 Message <timestamp>, [RTWR-1003], <sequence-number>,, INFO, <system-name>, <module name>: RTWR retry <number of times retried> to domain <domain ID>, iu_data <first word of iu_data> Probable Cause Indicates the number of times the RTWR has failed to get a response. Recommended Run the dom command to verify that the specified domain ID is reachable.

  • Page 565: Sas System Messages

    Chapter SAS System Messages SAS-1001 Message <timestamp>, [SAS-1001], <sequence-number>,, ERROR, <system-name>, string description of command which failed> of GE <GE port number which failed> failed. Please retry the command. Data inst=<chip instance> st=<chip init state> rsn=<failure reason> fn=<message function> oid=<chip OID>. Probable Cause The Hardware is not responding to the command request;...
  • Page 566 SAS-1001 Fabric OS Message Reference 53-1001338-01...

  • Page 567: Scn System Messages

    Chapter SCN System Messages SCN-1001 Message <timestamp>, [SCN-1001], <sequence-number>, FFDC, CRITICAL, <system-name>, SCN <daemon name> queue overflow for process Probable Cause Indicates that an attempt to write a state change notification (SCN) message to a specific queue has failed because the SCN queue for the specified daemon name is full. This might be caused by the daemon hanging or the system being busy.
  • Page 568 SCN-1001 Fabric OS Message Reference 53-1001338-01...

  • Page 569: Sec System Messages

    Chapter SEC System Messages SEC-1001 Message <timestamp>, [SEC-1001], <sequence-number>,, ERROR, <system-name>, RCS process <reason code> fails: Probable Cause Indicates that the reliable commit service (RCS) process failed to complete. RCS is a mechanism for transferring data from one switch to other switches within the fabric. RCS ensures that either all or none of the switches commit to the database.
  • Page 570 SEC-1003 SEC-1003 Message <timestamp>, [SEC-1003], <sequence-number>,, WARNING, <system-name>, Fail to download security data to domain <Domain number> after <Number of retires> retries Probable Cause Indicates the specified domain has failed to download security data after the specified number of attempts, and that the failed switch encountered an error accepting the database download. The primary switch will segment the failed switch after 30 tries.
  • Page 571 SEC-1007 SEC-1007 Message <timestamp>, [SEC-1007], <sequence-number>,, INFO, <system-name>, Security <IP address of the violating violation: Unauthorized host with IP address host> tries to establish API connection. Probable Cause Indicates a security violation was reported. The IP address of the unauthorized host is displayed in the message.
  • Page 572 SEC-1022 Recommended Check for unauthorized access to the switch through the SSH connection. Action Severity INFO SEC-1022 Message <timestamp>, [SEC-1022], <sequence-number>,, WARNING, <system-name>, Failed to <operation> PKI objects. Probable Cause Indicates the fabric has failed to generate or validate either the public or private key pair or the certificate signing request (CSR).
  • Page 573 SEC-1026 SEC-1026 Message <timestamp>, [SEC-1026], <sequence-number>,, ERROR, <system-name>, Invalid format <switch member ID> or character in switch member Probable Cause Indicates a corruption occurred during the distribution of the security database. This can occur only when the primary fabric configuration server (FCS) distributes the security database to the other switches in the fabric, then local validation finds the error in the security database.
  • Page 574 SEC-1030 SEC-1030 Message <timestamp>, [SEC-1030], <sequence-number>, ERROR, <system-name>, The length of the name invalid. Probable Cause Indicates a corruption occurred during the distribution of the security database. This can occur only when the primary fabric configuration server (FCS) distributes the security database to the other switches in the fabric, then local validation finds the error in the security database.
  • Page 575 SEC-1034 Probable Cause Indicates a member parameter in the secPolicyAdd command is invalid (e. g., it may include an invalid character, such as an asterisk). A valid switch identifier (a WWN, a domain ID, or a switch name) must be provided as a member parameter in the secPolicyAdd command. Only the secPolicyCreate command supports use of the asterisk for adding switches to policies.
  • Page 576 SEC-1037 SEC-1037 Message <timestamp>, [SEC-1037], <sequence-number>,, ERROR, <system-name>, Invalid WWN <invalid WWN> format Probable Cause Indicates the world wide name (WWN) entered in the policy member list had an invalid format. Recommended Run the command again using the standard WWN format, 16 hexadecimal digits grouped as eight Action colon separated pairs.
  • Page 577 SEC-1042 Severity ERROR SEC-1042 Message <timestamp>, [SEC-1042], <sequence-number>,, ERROR, <system-name>, Invalid index/area member <port member> in portlist (<Port list>). Out of range (<Minimum value> - <Maximum value>). Probable Cause Indicates the specified index or area member is not within the minimum and maximum range. Recommended Use valid syntax when entering index or area numbers.
  • Page 578 SEC-1046 Recommended Run the secFabricShow command to verify that the fabric is still consistent. All the switches should Action be in the ready state. If a switch is in the error state, the database might not be correctly updated for that specific switch. Severity ERROR SEC-1046...
  • Page 579 SEC-1051 Severity ERROR SEC-1051 Message <timestamp>, [SEC-1051], <sequence-number>,, ERROR, <system-name>, Missing brace <port list> for port list Probable Cause Indicates there has been a corruption during the distribution of the security database. This can only occur when the primary fabric configuration server (FCS) is distributing the security database to the other switches in the fabric and local validation finds that there is an error in the security database.
  • Page 580 SEC-1054 SEC-1054 Message <timestamp>, [SEC-1054], <sequence-number>,, ERROR, <system-name>, Invalid FCS <list length> list length Probable Cause Indicates there has been a corruption during the distribution of the security database. This can only occur when the primary fabric configuration server (FCS) is distributing the security database to the other switches in the fabric and local validation finds that there is an error in the security database.
  • Page 581 SEC-1057 SEC-1057 Message <timestamp>, [SEC-1057], <sequence-number>,, ERROR, <system-name>, No change. Both positions are the same. Probable Cause Indicates there has been a corruption during the distribution of the security database. This can only occur when the primary fabric configuration server (FCS) is distributing the security database to the other switches in the fabric and local validation finds that there is an error in the security database.
  • Page 582 SEC-1064 Severity ERROR SEC-1064 Message <timestamp>, [SEC-1064], <sequence-number>,, ERROR, <system-name>, Failed to sign message. Probable Cause Indicates the public key infrastructure (PKI) objects on the switch are not in a valid state and the signature operation failed. Recommended Run the pkiShow command to verify that all PKI objects are valid. If PKI objects are not valid, Action generate the PKI objects and install the certificate by following the field upgrade process.
  • Page 583 SEC-1072 Severity ERROR SEC-1072 Message <Policy <timestamp>, [SEC-1072], <sequence-number>,, ERROR, <system-name>, type> Policy List is Empty! Probable Cause Indicates the specific policy type is empty. The security database is corrupted for unknown reasons. Recommended Run supportFtp (as needed) to set up automatic FTP transfers; then run the supportSave command Action and contact your switch service provider.
  • Page 584 SEC-1076 Probable Cause Indicates there has been a corruption during the distribution of the security database. This can only occur when the primary fabric configuration server (FCS) is distributing the security database to the other switches in the fabric and local validation finds that there is an error in the security database. This is a rare occurrence.
  • Page 585 SEC-1079 SEC-1079 Message <timestamp>, [SEC-1079], <sequence-number>,, ERROR, <system-name>, The policy name <policy name> is invalid. Probable Cause Indicates the policy name entered in the secPolicyCreate|Activate|Add|Delete command was invalid. Recommended Run the command again using a valid policy name. Action Severity ERROR SEC-1080 Message...
  • Page 586 SEC-1083 Recommended Use proper syntax when creating policies. If the security database is too large, you must delete Action other members within the database before adding new members to a policy. Severity ERROR SEC-1083 Message <timestamp>, [SEC-1083], <sequence-number>,, ERROR, <system-name>, Name already exists.
  • Page 587 SEC-1087 Probable Cause Indicates the security database has more data than the flash can accommodate. Recommended Reduce the number of entries in some policies to decrease the security database size. Action Severity ERROR SEC-1087 Message <timestamp>, [SEC-1087], <sequence-number>,, ERROR, <system-name>, The security database is larger than the data distribution limit of fabric <fabric data distribution limit>...
  • Page 588 SEC-1090 SEC-1090 Message <timestamp>, [SEC-1090], <sequence-number>,, ERROR, <system-name>, SCC list contains FCS member. Please remove member from the FCS policy first. Probable Cause Indicates there has been a corruption during the distribution of the security database. This can only occur when the primary fabric configuration server (FCS) is distributing the security database to the other switches in the fabric and local validation finds that there is an error in the security database.
  • Page 589 SEC-1094 Probable Cause Indicates the new fabric configuration server (FCS) list does not have a common member with the existing FCS list. Recommended Resubmit the command with at least one member of the new FCS list in common with the current Action FCS list.
  • Page 590 SEC-1097 Severity ERROR SEC-1097 Message <timestamp>, [SEC-1097], <sequence-number>,, ERROR, <system-name>, Cannot find <active or defined> policy set. Probable Cause Indicates the specified policy could not be found. Recommended If the message persists, run supportFtp (as needed) to set up automatic FTP transfers; then run the Action supportSave command and contact your switch service provider.
  • Page 591 SEC-1101 Probable Cause Indicates there has been a corruption during the distribution of the security database. This can only occur when the primary fabric configuration server (FCS) is distributing the security database to the other switches in the fabric and local validation finds that there is an error in the security database. This is a rare occurrence.
  • Page 592 SEC-1105 Severity ERROR SEC-1105 Message <timestamp>, [SEC-1105], <sequence-number>,, ERROR, <system-name>, Fail to disable secure mode on all switches. Probable Cause Indicates the switch failed to disable security in the fabric. This could happen if the switch cannot get the required resources to complete the command, and sending to a remote domain fails or the remote domain returns an error.
  • Page 593 SEC-1110 Probable Cause Indicates that a version reset operation failed either because the switch could not get all the required resources to perform the operation or because it failed to send the message to all switches in the fabric. Recommended Verify that the security event was planned.
  • Page 594 SEC-1113 Recommended Make sure that the new FCS policy is the same as the current FCS policy on the switch. Action Severity ERROR SEC-1113 Message <timestamp>, [SEC-1113], <sequence-number>,, WARNING, <system-name>, <Key> [ <Feature> license ] going to expire in <Expiry_days> days. Probable Cause Indicates the license period will expire soon.
  • Page 595 SEC-1117 Probable Cause Indicates there has been a corruption during the distribution of the security database. This can only occur when the primary fabric configuration server (FCS) is distributing the security database to the other switches in the fabric and local validation finds that there is an error in the security database. This is a rare occurrence.
  • Page 596 SEC-1121 SEC-1121 Message <timestamp>, [SEC-1121], <sequence-number>,, ERROR, <system-name>, Time is out of <text> range when Probable Cause Indicates the time on the switch is not synchronized with the primary fabric configuration server (FCS), the data packet is corrupted, or a replay attack is launched on the switch. Recommended Verify the security event was planned.
  • Page 597 SEC-1126 Severity INFO SEC-1126 Message <timestamp>, [SEC-1126], <sequence-number>,, INFO, <system-name>, Secure mode has been disabled. Probable Cause Indicates that a secure mode disable operation completed successfully. Recommended Verify the security event was planned. If the security event was planned, no action is required. If the Action security event was not planned, take appropriate action as defined by your enterprise security policy.
  • Page 598 SEC-1137 Probable Cause Indicates the receiving switch fails to validate the security database sent from the primary fabric configuration server (FCS) switch. This message usually indicates that the data package is corrupted, the time stamp on the package is out of range as a result of a replay attack or out-of-sync time service, or the signature verification failed.
  • Page 599 SEC-1142 Probable Cause Indicates that the receiving switch failed to validate the security database sent from the primary fabric configuration server (FCS) switch. This message usually indicates that the data package is corrupted, the time stamp on the package is out of range as a result of a replay attack or out-of-sync time service, or the signature verification failed.
  • Page 600 SEC-1153 Probable Cause Indicates the PID format of the switch was changed either to extended-edge PID or from extended-edge PID. If the device connection control (DCC) polices existed, all index/area ID values either increased or decreased by 16. The values wrap around after 128. If a DCC policy contains an index/area of 127 before changing to extended-edge PID, then the new index/area is 15, because of the wraparound.
  • Page 601 SEC-1156 Probable Cause Indicates that either the defined or active policy was too large after modifying the index/area ID. The status values can be either defined, active, or both. A negative value means that a policy set was failed by the daemon. Recommended Reduce the size of the specified policy database.
  • Page 602 SEC-1159 SEC-1159 Message <timestamp>, [SEC-1159], <sequence-number>,, INFO, <system-name>, Non_Reachable domain <Domain ID>. Probable Cause Indicates there has been a corruption during the distribution of the security database. This can only occur when the primary fabric configuration server (FCS) is distributing the security database to the other switches in the fabric and local validation finds that there is an error in the security database.
  • Page 603 SEC-1165 Severity ERROR SEC-1165 Message <timestamp>, [SEC-1165], <sequence-number>,, ERROR, <system-name>, Low memory, failed to enable security on all switches. Probable Cause Indicates the system is low on memory. Recommended Wait a few minutes and try the command again. Action Severity ERROR SEC-1166 Message...
  • Page 604 SEC-1170 Probable Cause Indicates there has been a corruption during the distribution of the security database. This can only occur when the primary fabric configurations server (FCS) is distributing the security database to the other switches in the fabric and local validation finds that there is an error in the security database.
  • Page 605 SEC-1173 Recommended Verify all switches in the fabric are in time synchronization with the primary and that no external Action entity is trying to access the fabric. When verification is complete, retry the operation. Severity ERROR SEC-1173 Message <timestamp>, [SEC-1173], <sequence-number>,, ERROR, <system-name>, Lost contact with Primary FCS switch.
  • Page 606 SEC-1180 Recommended Verify all switches in the fabric are in time synchronization with the primary and that no external Action entity is trying to access the fabric. When verification is complete, retry the operation. Severity ERROR SEC-1180 Message <timestamp>, [SEC-1180], <sequence-number>,, INFO, <system-name>, Added account <user name>...
  • Page 607 SEC-1184 Recommended Retry the command with a valid value. Action If the message persists, run supportFtp (as needed) to set up automatic FTP transfers; then run the supportSave command and contact your switch service provider. Severity ERROR SEC-1184 Message <timestamp>, [SEC-1184], <sequence-number>,, INFO, <system-name>, <server> configuration change, action <action>, server ID <server>.
  • Page 608 SEC-1187 SEC-1187 Message <timestamp>, [SEC-1187], <sequence-number>,, INFO, <system-name>, Security <switch WWN> violation: Unauthorized switch tries to join fabric. Probable Cause Indicates a switch connection control (SCC) security violation was reported. The specified unauthorized switch attempts to join the fabric. Recommended Check the switch connection control policy (SCC) policy to verify the switches allowed in the fabric.
  • Page 609 SEC-1190 SEC-1190 Message <timestamp>, [SEC-1190], <sequence-number>,, INFO, <system-name>, Security <IP address> violation: Unauthorized host with IP address tries to do SNMP read operation. Probable Cause Indicates an SNMP security violation was reported. The specified unauthorized host attempted to perform a read SNMP operation. Recommended Check the RSNMP policy to verify the hosts allowed access to the fabric through SNMP read Action...
  • Page 610 SEC-1194 Probable Cause Indicates a specified login security violation was reported. The incorrect password was used while trying to log in through the specified connection method; the login failed. Recommended The error message lists the violating IP address. Verify that this IP address is being used by a valid Action switch admin.
  • Page 611 SEC-1197 Severity WARNING SEC-1197 Message <timestamp>, [SEC-1197], <sequence-number>,, INFO, <system-name>, Changed account <user name>. Probable Cause Indicates the specified account has changed. Recommended No action is required. Action Severity INFO SEC-1198 Message <timestamp>, [SEC-1198], <sequence-number>,, INFO, <system-name>, Security <IP address> violation: Unauthorized host with IP address tries to establish API connection.
  • Page 612 SEC-1201 Probable Cause Indicates a management server (MS) forward security violation was reported. A management server command was forwarded from a non-primary fabric configuration server (FCS) switch. Recommended Check the MS policy and verify that the connection is allowed. If the connection is allowed but not Action specified, enable the connection in the MS policy.
  • Page 613 SEC-1250 Severity INFO SEC-1250 Message <timestamp>, [SEC-1250], <sequence-number>,, WARNING, <system-name>, DCC enforcement API failed: <failed action> err=<status>, key=<data> Probable Cause Indicates an internal error caused the DCC policy enforcement to fail. Recommended Retry the failed security command. Action If the message persists, run supportFtp (as needed) to set up automatic FTP transfers; then run the supportSave command and contact your switch service provider.
  • Page 614 SEC-1301 Probable Cause Indicates the switch is set up with VC-encoded mode. Recommended Turn off VC-encoded mode before enabling security. Action Severity INFO SEC-1301 Message <timestamp>, [SEC-1301], <sequence-number>,, INFO, <system-name>, This switch is in interop mode. Security is not supported. Probable Cause Indicates the switch is interop-mode enabled.
  • Page 615 SEC-1304 SEC-1304 Message <timestamp>, [SEC-1304], <sequence-number>,, INFO, <system-name>, This switch has no security license. Probable Cause Indicates there has been a corruption during the distribution of the security database. This can only occur when the primary fabric configuration server (FCS) is distributing the security database to the other switches in the fabric and local validation finds that there is an error in the security database.
  • Page 616 SEC-1307 SEC-1307 Message <timestamp>, [SEC-1307], <sequence-number>,, INFO, <system-name>, Got response from <Radius/LDAP server identity> server <Radius/LDAP server identity>. Probable Cause Indicates that after some servers timed out, the specified remote authentication dial-in user service (RADIUS/LDAP) server responded to a switch request. Recommended If the message appears frequently, move the responding server to the top of the RADIUS/LDAP Action...
  • Page 617 SEC-1311 Severity INFO SEC-1311 Message <timestamp>, [SEC-1311], <sequence-number>,, ERROR, <system-name>, Security mode cannot be enabled because one or more of the password policies is not set to default value. Probable Cause Indicates the security enable failed on the fabric because one or more switches in the fabric have password policies that are not set to the default value.
  • Page 618 SEC-1315 Probable Cause Indicates the call to the EM module to retrieve the IP address failed. Recommended Restart the system to fix this error. If the problem persists contact your switch service provider. Action Severity ERROR SEC-1315 Message <timestamp>, [SEC-1315], <sequence-number>,, ERROR, <system-name>, <Name of command >...
  • Page 619 SEC-1318 SEC-1318 Message <timestamp>, [SEC-1318], <sequence-number>,, INFO, <system-name>, Transaction rejected due to inconsistent fabric Probable Cause Indicates that some domains detected an inconsistent fabric. Recommended Resolve the policy conflict, if there is one, then wait for the fabric to stabilize. Retry the distribution. Action Severity INFO...
  • Page 620 SEC-1322 Severity ERROR SEC-1322 Message <timestamp>, [SEC-1322], <sequence-number>,, WARNING, <system-name>, Some DCC policy is too large, distribution cancelled Probable Cause Indicates this fabric is not able to support a device connection control (DCC) policy with more than 256 ports. Recommended Reconfigure any policy that includes more than 256 ports in its member list, then save the policy Action configuration changes.
  • Page 621 SEC-1326 Recommended No action is required unless the switch must remain in the fabric. If the switch must remain in the Action fabric, add the switch world wide name (WWN) to the SCC policy, then attempt to join the switch with the fabric.
  • Page 622 SEC-1329 SEC-1329 Message <timestamp>, [SEC-1329], <sequence-number>,, ERROR, <system-name>, IPFilter enforcement: Failed to enforce ipfilter policy of <policy Type> type because of <Error code>. Probable Cause Indicates the IP filter policy enforcement failed due to internal system failure. Recommended Run supportFtp (as needed) to set up automatic FTP transfers; then run the supportSave command Action and contact your switch service provider.
  • Page 623 SEC-1333 Recommended Remove either the FCS from the fabric-wide policy, or remove 5.3 and 5.2 switches from the fabric, Action or set the fabric-wide mode for FCS as Strict. Severity ERROR SEC-1333 Message <timestamp>, [SEC-1333], <sequence-number>,, INFO, <system-name>, <Name of command>...
  • Page 624 SEC-3036 SEC-3036 Message <timestamp>, [SEC-3036], <sequence-number>, AUDIT, INFO, <system-name>, Event: ipfilter, Status: failed, Info: Failed to save changes for <IP Filter Policy> ipfilter policies. Probable Cause Indicates that that the specified IP filter policy has not been saved. Recommended Verify that the security event was planned. If the security event was planned, no action is required. Action If the security event was not planned, take appropriate action as defined by your enterprise security policy.
  • Page 625 SEC-3050 Recommended Check for unauthorized access to the switch through the specified protocol connection. Action Severity INFO SEC-3050 Message <timestamp>, [SEC-3050], <sequence-number>, AUDIT, INFO, <system-name>, Event: <Event Name>, Status: success, Info: <Event Specific Info>. Probable Cause Indicates the specified sshutil operation was performed. Recommended Verify the security event was planned.
  • Page 626 SEC-3051 Fabric OS Message Reference 53-1001338-01...

  • Page 627: Snmp System Messages

    Chapter SNMP System Messages SNMP-1001 Message <timestamp>, [SNMP-1001], <sequence-number>,, ERROR, <system-name>, SNMP service is not available <Reason>. Probable Cause Indicates the simple network management protocol (SNMP) service could not be started because of the specified Reason. You will not be able to query the switch through SNMP. Recommended Verify the IP address for the Ethernet and Fibre Channel interface is set correctly.
  • Page 628 SNMP-1004 SNMP-1004 Message <timestamp>, [SNMP-1004], <sequence-number>, FFDC, ERROR, <system-name>, Incorrect SNMP configuration. Probable Cause Indicates the simple network management protocol (SNMP) configuration is incorrect and the SNMP service will not work correctly. Recommended Change the SNMP configuration back to the default. Action Severity ERROR...
  • Page 629 SNMP-1008 Severity INFO SNMP-1008 Message <timestamp>, [SNMP-1008], <sequence-number>,, INFO, <system-name>, The last device change happened at: <string>. Probable Cause Indicates the last device change time. Recommended Execute the nsshow command to view the current device status. Action Severity INFO Fabric OS Message Reference 53-1001338-01...
  • Page 630 SNMP-1008 Fabric OS Message Reference 53-1001338-01...

  • Page 631: Spc System Messages

    Chapter SPC System Messages SPC-1001 Message <timestamp>, [SPC-1001], <sequence-number>,, INFO, <system-name>, <slot number containing Encryption Engine>, Cryptographic operation enabled. Probable Cause Indicates the cryptographic operation is enabled on an encryption engine. Recommended No action is required. Action Severity INFO SPC-1002 Message <timestamp>, [SPC-1002], <sequence-number>,, INFO, <system-name>, <slot number containing Encryption Engine>, Cryptographic operation disabled.
  • Page 632 SPC-2001 SPC-2001 Message <timestamp>, [SPC-2001], <sequence-number>,, ERROR, <system-name>, <slot number containing Encryption Engine>, <module name>: Crypto error asserted by Vader/OB1 0x%x. Probable Cause Indicates the Crypto error is asserted by FPGA. Recommended No action is required. Action Severity ERROR SPC-2002 Message <timestamp>, [SPC-2002], <sequence-number>,, CRITICAL, <system-name>, <slot number containing Encryption Engine>, <module name>: Tamper Event: Crypto...
  • Page 633 SPC-2005 SPC-2005 Message <timestamp>, [SPC-2005], <sequence-number>,, INFO, <system-name>, <slot number containing Encryption Engine>, <module name>: FPGA firmware download success: 0x%x. Probable Cause Indicates the FPGA download was successful. Recommended No action is required. Action Severity INFO SPC-2006 Message <timestamp>, [SPC-2006], <sequence-number>,, ERROR, <system-name>, <slot number containing Encryption Engine>, <module name>: Crypto post tests failed: 0x%x.
  • Page 634 SPC-2009 SPC-2009 Message <timestamp>, [SPC-2009], <sequence-number>,, CRITICAL, <system-name>, <slot number containing Encryption Engine>, <module name>: Tamper event: User zeroization. Probable Cause Indicates the Tamper event triggered due to a user zeroize request. Recommended EE is zeroized. Run the initEE and regEE commands. Action Severity CRITICAL...
  • Page 635 SPC-3001 SPC-3001 Message <timestamp>, [SPC-3001], <sequence-number>,, ERROR, <system-name>, <slot number containing Encryption Engine>, <module name>: No input KEK for DEK inject, DEK: <DEK octet 1> <DEK octet 2> <DEK octet 3> <DEK octet 4>, KEK: <KEK octet 1> <KEK octet 2> <KEK octet 3> <KEK octet 4>. Probable Cause Indicates the wrapping KEK for the DEK to be injected does not exist within the EE Crypto Module.
  • Page 636 SPC-3005 Probable Cause Indicates the output wrapping KEK for the DEK to be created does not exist within the EE Crypto Module. Recommended For opaque key vaults such as RKM, recover the missing Master Key to current or alternate Action position.
  • Page 637 SPC-3007 SPC-3007 Message <timestamp>, [SPC-3007], <sequence-number>,, ERROR, <system-name>, <slot number containing Encryption Engine>, <module name>: DEK create error: <SP status code>, info: <other info>. Probable Cause Indicates the cause depends on the SP status code: • 2 - Invalid input DEK specification •...
  • Page 638 SPC-3010 SPC-3010 Message <timestamp>, [SPC-3010], <sequence-number>,, WARNING, <system-name>, <slot number containing Encryption Engine>, <module name>: SEK integrity failure during initialization. Probable Cause Indicates the Crypto Module internal Secret Encryption Key has been corrupted or has not been initialized. Recommended Run the initEE and regEE commands. Action Severity ERROR...
  • Page 639 SPC-3014 Recommended Contact your technical support. Action Severity ERROR SPC-3014 Message <timestamp>, [SPC-3014], <sequence-number>,, ERROR, <system-name>, <slot number containing Encryption Engine>, <module name>: RNG compare failure: successive values match. Probable Cause Indicates the Crypto Module internal random number generator has failed. Recommended Contact technical support.
  • Page 640 SPC-3015 Fabric OS Message Reference 53-1001338-01...

  • Page 641: Spm System Messages

    Chapter SPM System Messages SPM-1001 Message <timestamp>, [SPM-1001], <sequence-number>,, ERROR, <system-name>, Init fails: <Reason>. Probable Cause Indicates the SPM has failed to initialize. Recommended Check the system resources and restart the switch. Action Severity ERROR SPM-1002 Message <timestamp>, [SPM-1002], <sequence-number>,, WARNING, <system-name>, Generic SPM Warning: <Reason>.
  • Page 642 SPM-1005 Recommended No action is required. Action Severity INFO SPM-1005 Message <timestamp>, [SPM-1005], <sequence-number>,, INFO, <system-name>, Set EE Control slot <slot> action <action>. Probable Cause Indicates encryption engine (EE) control slot configuration. Recommended No action is required. Action Severity INFO SPM-1006 Message <timestamp>, [SPM-1006], <sequence-number>,, INFO, <system-name>, Registered...
  • Page 643 SPM-1009 Recommended No action is required. Action Severity INFO SPM-1009 Message <timestamp>, [SPM-1009], <sequence-number>,, ERROR, <system-name>, <cert> Certificate is missing. Probable Cause Indicates that a certificate is missing. Recommended Run the cryptocfg --initnode command. Action Severity ERROR SPM-1010 Message <timestamp>, [SPM-1010], <sequence-number>,, ERROR, <system-name>, <cert> Key Vault Certificate is missing.
  • Page 644 SPM-3001 Recommended No action is required. Action Severity INFO SPM-3001 Message <timestamp>, [SPM-3001], <sequence-number>,, INFO, <system-name>,Event: cryptocfg Status: success, Info: Node initialized. Probable Cause Indicates a node was initialized. Recommended No action is required. Action Severity INFO SPM-3002 Message <timestamp>, [SPM-3002], <sequence-number>,, INFO, <system-name>,Event: cryptocfg Status: success, Info: EE in slot <slot>...
  • Page 645 SPM-3005 Recommended No action is required. Action Severity INFO SPM-3005 Message <timestamp>, [SPM-3005], <sequence-number>,, INFO, <system-name>,Event: cryptocfg Status: success, Info: EE in slot <slot> disabled. Probable Cause Indicates an encryption engine was disabled. Recommended No action is required. Action Severity INFO SPM-3006 Message...
  • Page 646 SPM-3009 Recommended No action is required. Action Severity INFO SPM-3009 Message <timestamp>, [SPM-3009], <sequence-number>,, INFO, <system-name>,Event: cryptocfg Status: success, Info: DH response accepted. Probable Cause Indicates a DH challenge was accepted. Recommended No action is required. Action Severity INFO SPM-3010 Message <timestamp>, [SPM-3010], <sequence-number>,, INFO, <system-name>,Event: cryptocfg Status: success, Info: EE in slot <slot>...
  • Page 647 SPM-3013 Recommended No action is required. Action Severity INFO SPM-3013 Message <timestamp>, [SPM-3013], <sequence-number>,, INFO, <system-name>,Event: cryptocfg Status: success, Info: Key vault with certificate label \"<certLabel>\" deregistered. Probable Cause Indicates a key vault was de-registered. Recommended No action is required. Action Severity INFO...
  • Page 648 SPM-3017 Recommended No action is required. Action Severity INFO SPM-3017 Message <timestamp>, [SPM-3017], <sequence-number>,, INFO, <system-name>,Event: cryptocfg Status: success, Info: Master key exported. Probable Cause Indicates a master key was exported. Recommended No action is required. Action Severity INFO SPM-3018 Message <timestamp>, [SPM-3018], <sequence-number>,, INFO, <system-name>,Event: cryptocfg Status: success, Info: <currentOrAlternate>master key recovered.
  • Page 649 SPM-3021 Recommended No action is required. Action Severity INFO SPM-3021 Message <timestamp>, [SPM-3021], <sequence-number>,, INFO, <system-name>,Event: cryptocfg Status: success, Info: Authentication card registered. Certificate label: \"<certLabel>\" Certificate file: \"<certFilename>\". Probable Cause Indicates an authentication card was registered. Recommended No action is required. Action Severity INFO...
  • Page 650 SPM-3025 Recommended No action is required. Action Severity INFO SPM-3025 Message <timestamp>, [SPM-3025], <sequence-number>,, INFO, <system-name>,Event: cryptocfg Status: success, Info: File imported via usb: Source: <sourcePath> Destination: <destinationFilename>. Probable Cause Indicates a file was imported through the USB device. Recommended No action is required.

  • Page 651: Ss System Messages

    Chapter SS System Messages SS-1000 Message <timestamp>, [SS-1000], <sequence-number>,, INFO, <system-name>, supportSave has uploaded support information to the host with IP address <host ip>. Probable Cause Indicates the supportSave command was used to transfer support information to a remote location. Recommended No action is required.
  • Page 652 SS-1003 SS-1003 Message <timestamp>, [SS-1003], <sequence-number>,, WARNING, <system-name>, supportSave's operation to USB storage device aborted. Probable Cause Indicates a USB operation error has occurred during execution of the supportSave command. Complete error information cannot always be displayed in this message due to possible errors in subcommands being executed by the supportSave command.

  • Page 653: Ssm System Messages

    DRAFT: BROCADE CONFIDENTIAL Chapter SSM System Messages SSMD-1001 Message <timestamp>, [SSMD-1001], <sequence-number>,, ERROR, <system-name>,Failed to allocate memory: <function name>. Probable Cause Indicates that the specified function has failed to allocate memory. Recommended Check the memory usage on the switch using the memShow command. Action Restart or power cycle the switch.
  • Page 654 DRAFT: BROCADE CONFIDENTIAL SSMD-1005 Probable Cause Indicates that the specified function has failed to unlock the mutex (semaphore). Recommended Restart or power cycle the switch. Action Severity ERROR SSMD-1005 Message <timestamp>, [SSMD-1005], <sequence-number>,, ERROR, <system-name>,SSM startup failed. Probable Cause Indicates the DCE System Services Manager (SSM) encountered an unexpected, severe error during basic startup and initialization.
  • Page 655 DRAFT: BROCADE CONFIDENTIAL SSMD-1202 SSMD-1202 Message <timestamp>, [SSMD-1202], <sequence-number>,, WARNING, <system-name>,QoS failed programming interface 0x<Interface ID> x 802.3x Pause flow control. Probable Cause Indicates the DCE System Services Manager (SSM) encountered an unexpected error in programming the dataplane ASIC for enforcing the interface 802.3x Pause flow control feature. Recommended Delete and reapply QoS 802.3x Pause flow control policy.
  • Page 656 DRAFT: BROCADE CONFIDENTIAL SSMD-1206 Severity WARNING SSMD-1206 Message <timestamp>, [SSMD-1206], <sequence-number>,, WARNING, <system-name>,CEE failed programming CoS to PGID policy for CEE Map <CEE Map name>. Probable Cause Indicates the DCE System Services Manager (SSM) encountered an unexpected error in programming the dataplane ASIC for enforcing the CEE Map CoS to PGID mapping feature. Recommended Delete and reapply the CEE Map CoS to PGID policy.
  • Page 657 DRAFT: BROCADE CONFIDENTIAL SSMD-1210 Recommended Delete and reapply the QoS interface CoS Mutation policy. Restart or power cycle the switch. Action Severity WARNING SSMD-1210 Message <timestamp>, [SSMD-1210], <sequence-number>,, WARNING, <system-name>,QoS failed programming interface 0x <Interface ID> x CoS to Traffic Class map. Probable Cause Indicates the DCE System Services Manager (SSM) encountered an unexpected error in programming the dataplane ASIC for enforcing the CoS to Traffic Class mapping feature.
  • Page 658 DRAFT: BROCADE CONFIDENTIAL SSMD-1214 Probable Cause Indicates the DCE System Services Manager (SSM) encountered an unexpected error in programming the dataplane ASIC for enforcing the interface CoS Tail Drop Threshold feature. Recommended Delete and reapply the QoS CoS Tail Drop Threshold policy. Restart or power cycle the switch. Action Severity WARNING...
  • Page 659 DRAFT: BROCADE CONFIDENTIAL SSMD-1217 SSMD-1217 Message <timestamp>, [SSMD-1217], <sequence-number>,, WARNING, <system-name>,QoS CEE could not comply with FCoE scheduler policy for CEE Map <CEE Map name>. Probable Cause Indicates the DCE System Services Manager (SSM) was unable to translate CEE Map and FCoE configuration into an ETS scheduler policy implementable by the dataplane ASIC.
  • Page 660 DRAFT: BROCADE CONFIDENTIAL SSMD-1217 Fabric OS Message Reference 53-1001338-01...

  • Page 661: Sulb System Messages

    Chapter SULB System Messages SULB-1001 Message <timestamp>, [SULB-1001], <sequence-number>, AUDIT, WARNING, <system-name>, Firmwaredownload command has started. Probable Cause Indicates the firmwareDownload command has been started. This process should take approximately 17 minutes. The process is set to time out after 30 minutes. Recommended Do not fail over or power down the system during firmware upgrade.
  • Page 662 SULB-1004 SULB-1004 Message <timestamp>, [SULB-1004], INFO, FIRMWARE, <event-initiator-details>, <event-location>, , Firmwarecommit has completed. Probable Cause Indicates the FirmwareCommit command is executed. Recommended No action is required. Run the firmwareDownloadStatus command for more information. Action Severity INFO SULB-1005 Message <timestamp>, [SULB-1005], <sequence-number>,, INFO, <system-name>, Current Active CP is preparing to failover.
  • Page 663 SULB-1008 SULB-1008 Message <timestamp>, [SULB-1008], <sequence-number>,, INFO, <system-name>, Standby CP booted successfully with new firmware. Probable Cause Indicates the standby CP has rebooted successfully. Recommended No action is required. The firmwareDownload command is progressing as expected. Action Run the firmwareDownloadStatus command for more information. Severity INFO SULB-1009...
  • Page 664 SULB-1009 TABLE 6 Status Messages and Status Codes Status Message Status Code “firmwareCommit operation failed due to IPC error.” 0x55 "Unable to check the firmware version on Standby CP due to IPC error." 0x56 “Unable to restore the original firmware due to Standby CP timeout.” 0x57 "Standby CP failed to reboot and was not responding."...
  • Page 665 SULB-1009 TABLE 6 Status Messages and Status Codes Status Message Status Code "The original firmware has been restored successfully on Standby CP." 0x7e "Unable to restore the original firmware on Standby CP." 0x7f "Standby CP reboots." 0x80 "Standby CP failed to reboot." 0x81 "Standby CP booted up with new firmware."...
  • Page 666 SULB-1009 TABLE 6 Status Messages and Status Codes Status Message Status Code “firmwareRestore is entered. System will reboot and a firmwareCommit operation will start 0xa8 upon boot up.” "Switch is relocating the AP image." 0xa9 "The AP image is relocated successfully." 0xaa "Switch reboots during relocating the AP image.
  • Page 667 SULB-1009 TABLE 7 Error Messages and Error Codes Error Message Error Code “firmwareDownload timed out.” 0x23 "Our of disk space." 0x24 “Primary filesystem is inconsistent. Run firmwareRestore to restore the original firmware, or 0x25 contact your service provider for recovery.” "The post-install script failed."...
  • Page 668 SULB-1009 0x24 - out of disk space. This error may occur because some coredump files have not been removed from the filesystem and are using up disk space. Remove these coredump files using the supportSave command before proceeding. 0x29 - The pre-install script failed. This error may be caused by an unsupported blade type in the chassis.
  • Page 669 SULB-1010 In a director-class switch, when firmwareDownload fails, the two CPs may end up with different versions of firmware and they may not gain high-availability (HA) sync. In that case, run firmwareDownload single mode (-s) to upgrade the firmware on the standby CP to the same version as the active CP.
  • Page 670 SULB-1018 Recommended Run the slotShow command. If the blade is in a FAULTY state, run the slotPowerOff and Action slotPowerOn commands to trigger another firmwareDownload. If the blade is stuck in LOADING state, remove and re-insert the blade to trigger another firmwareDownload. If the problem persists, contact your switch service provider.
  • Page 671 SULB-1022 SULB-1022 Message <timestamp>, [SULB-1022], <sequence-number>,, WARNING, <system-name>, The blade in slot <Slot number> has rebooted successfully with new firmware. Probable Cause Indicates that the blade in the specified slot has rebooted with new firmware. This is a normal step in the firmwareDownload process.
  • Page 672 SULB-1025 SULB-1025 Message <timestamp>, [SULB-1025], <sequence-number>,, WARNING, <system-name>, The blade in slot <Slot number> will reboot with the new firmware. Probable Cause Indicates new firmware has been downloaded to the specified AP blade and that the AP blade will reboot to activate it. Recommended Wait for the blade to reboot.
  • Page 673 SULB-1032 Recommended Wait for the operation to complete. Action Severity WARNING SULB-1032 Message <timestamp>, [SULB-1032], <sequence-number>, AUDIT, WARNING, <system-name>, Relocating an internal firmware image on the CP. Probable Cause Indicates the switch has started a firmware download to the co-CPU. Recommended Wait for the operation to complete.
  • Page 674 SULB-1036 Probable Cause Indicates an error has occurred during the relocation of the internal image. The error may be caused by inconsistent internal firmware image. It may also be caused by the internal Ethernet or persistent storage hardware failure. Recommended Reset the switch.

  • Page 675: Swch System Messages

    Chapter SWCH System Messages SWCH-1001 Message <timestamp>, [SWCH-1001], <sequence-number>,, ERROR, <system-name>, Switch is not in ready state - Switch enable failed switch status= 0x<switch status>, c_flags = 0x<switch control flags>. Probable Cause Indicates the switch is enabled before it is ready. Recommended If the message persists, run the supportFtp command (as needed) to set up automatic FTP Action...
  • Page 676 SWCH-1004 SWCH-1004 Message <timestamp>, [SWCH-1004], <sequence-number>,, ERROR, <system-name>, Blade attach <slot number>. failed during recovery, disabling slot = Probable Cause Indicates a blade has failed during failover or recovery. Recommended On a Brocade 24000 or 48000 switch, run the slotPowerOff command and then the slotPowerOn Action command.
  • Page 677 SWCH-1008 Recommended Based on the disable reason displayed, proper corrective action may to be required to restore the Action port. If the disable reason is due to insufficient frame buffers, reduce the distance or speed settings for the port to reduce the buffer requirement of the link. Alternatively, one or more ports in the port group must be disabled to make more buffers available for the link.
  • Page 678 SWCH-1011 Severity WARNING SWCH-1011 Message <timestamp>, [SWCH-1011], <sequence-number>,, WARNING, <system-name>, HA state out of sync: Standby CP (ver = <standby SWC version>) does not support Trunk Area functionality. (active ver = <active SWC version>, Trunk Area enabled on switch = <'1' if Trunk Area ports exist;...
  • Page 679 SWCH-1015 Recommended No action is required. Action Severity INFO SWCH-1015 Message <timestamp>, [SWCH-1015], <sequence-number>,, WARNING, <system-name>, <Function name> <Description of problem>. Probable Cause Indicates that an internal problem has been detected by the software. This is usually an internal Fabric OS problem or due to file corruption. Recommended Restart or power cycle the switch Action...
  • Page 680 SWCH-1019 SWCH-1019 Message <timestamp>, [SWCH-1019], <sequence-number>,, INFO, <system-name>, Device <wwn name of device> tries to flogi, reject FLOGI as persistent PID is set on device and port <port number> has user area <area> bound to it. Probable Cause Indicates a WWN-PID and PortAddress binding collision. Recommended The Peristent PID is set on the device and requested area cannot be assigned because it is user Action...

  • Page 681: Sysc System Messages

    Chapter SYSC System Messages SYSC-1001 Message <timestamp>, [SYSC-1001], <sequence-number>, FFDC, CRITICAL, <system-name>, Failed to run <Name of program that could not be run (string)>:<System internal error message (string)>. Probable Cause Indicates that during the boot sequence, one of the programs does not run on the system. Recommended If the message is reported during a restart after new firmware has been loaded, try reloading the Action...
  • Page 682 SYSC-1004 It could also indicate that the current option number could not be read from the chassis option storage device (the world wide name (WWN) card). This message occurs only on the Brocade 24000 and 48000. Recommended As indicated in the message, run the chassisConfig command to change to one that is valid on this Action platform running this firmware.

  • Page 683: Sysm System Messages

    Chapter SYSM System Messages SYSM-1001 Message <timestamp>, [SYSM-1001], <sequence-number>, FFDC, CRITICAL, <system-name>, No memory. Probable Cause Indicates the switch has run out of system memory. Recommended Run the memShow command to view the switch memory usage. Action Restart or power cycle the switch. Run the supportFtp command to set up automatic FTP transfers;...
  • Page 684 SYSM-1004 SYSM-1004 Message <timestamp>, [SYSM-1004], <sequence-number>,, ERROR, <system-name>, Failed to retrieve current chassis configuration option, ret=<Unknown> Probable Cause Indicates there was a failure to read configuration data from the WWN card. Recommended Verify that the world wide name (WWN) card is present and operational and that the affected Action control processor (CP) is properly seated in its slot.

  • Page 685: Tape System Messages

    Chapter TAPE System Messages TAPE-1001 Message <timestamp>, [TAPE-1001], <sequence-number>, FFDC, INFO, <system-name>, Key acquisition for <Pool or Container><Begins or Complete>. Probable Cause Indicates that the key acquisition for the pool or the container has begun or is complete. Recommended No action is required. Action Severity INFO...
  • Page 686 TAPE-1001 Fabric OS Message Reference 53-1001338-01...

  • Page 687: Trce System Messages

    Chapter TRCE System Messages TRCE-1001 Message <timestamp>, [TRCE-1001], <sequence-number>,, WARNING, <system-name>, Trace dump available< optional slot indicating on which slot the dump occurs >! (reason: <Text explanation of what triggered the dump. (PANIC DUMP, WATCHDOG EXPIRED, MANUAL, TRIGGER)>) Probable Cause Indicates that trace dump files have been generated on the switch or the indicated slot.
  • Page 688 TRCE-1004 Probable Cause Indicates that a trace dump has been created on the switch or the indicated slot but is not automatically transferred from the switch due to an FTP error, such as a wrong FTP address, FTP site down, or network down. Recommended If the message persists, run the supportFtp command to set up automatic FTP transfers;...
  • Page 689 TRCE-1007 TRCE-1007 Message <timestamp>, [TRCE-1007], <sequence-number>,, ERROR, <system-name>, Notification of this CP has failed. Parameters temporarily out of synch with other CP. Probable Cause Indicates that the active CP is unable to alert the standby CP of a change in trace status. This message is only applicable to the Brocade 24000, and 48000.
  • Page 690 TRCE-1011 Probable Cause Indicates that the trace daemon (traced), used for transferring trace files, failed to start. The trace capability within the switch is unaffected. The traced facility is normally restarted automatically by the system after a brief delay. Recommended If the message persists, restart the CP (dual-CP system) or restart the switch.

  • Page 691: Trck System Messages

    Chapter TRCK System Messages TRCK-1001 Message <timestamp>, [TRCK-1001], <sequence-number>,, INFO, <system-name>, Successful login by user <User>. Probable Cause Indicates the track change feature has recorded a successful login. Recommended No action is required. Action Severity INFO TRCK-1002 Message <timestamp>, [TRCK-1002], <sequence-number>,, INFO, <system-name>, Unsuccessful login by user <User>...
  • Page 692 TRCK-1005 Probable Cause Indicates the track change feature recorded a configuration change for the switch. The track change feature records any change to the configuration file in nonvolatile memory, including a configDownload command. This message is not generated for a configUpload command. All configuration changes occur through the PDM server, so the PDMIPC is the only task possible.

  • Page 693: Ts System Messages

    Chapter TS System Messages TS-1001 Message <timestamp>, [TS-1001], <sequence-number>,, WARNING, <system-name>, NTP Query failed: <error code>. Probable Cause Indicates a network time protocol (NTP) query to the configured external clock server failed. Local clock time on the principal or primary fabric configuration server (FCS) switch is used for fabric synchronization.
  • Page 694 TS-1006 TS-1006 Message <timestamp>, [TS-1006], <sequence-number>,, INFO, <system-name>, <message>. Probable Cause Indicates a time service event is occurring or has failed. The message might be one of the following: • Init failed. Time Service exiting Probable Cause: Initialization error, Time Server exits. •...
  • Page 695 TS-1008 Fabric OS Message Reference 53-1001338-01...
  • Page 696 TS-1008 Fabric OS Message Reference 53-1001338-01...

  • Page 697: Ucst System Messages

    Chapter UCST System Messages UCST-1003 Message <timestamp>, [UCST-1003], <sequence-number>,, INFO, <system-name>, Duplicate Path to Domain <domain ID>, Output Port = <port number>, PDB pointer = 0x<value> Probable Cause Indicates the duplicate paths were reported to the specified domain from the specified output port. The path database (PDB) pointer is the address of the path database and provides debugging information.
  • Page 698 UCST-1025 UCST-1025 Message <timestamp>, [UCST-1025], <sequence-number>,, INFO, <system-name>, In-order delivery option has been enabled with Lossless-DLS option. Probable Cause Indicates the IOD option has been enabled for the switch. This option guarantees in-order delivery of frames during topology changes. Recommended No action is required.

  • Page 699: Upth System Messages

    Chapter UPTH System Messages UPTH-1001 Message <timestamp>, [UPTH-1001], <sequence-number>,, WARNING, <system-name>, No minimum cost path in candidate list. Probable Cause Indicates the specified switch is unreachable because no minimum cost path (FSPF UPATH) exists in the candidate list (domain ID list). Recommended No action is required.
  • Page 700 UPTH-1002 Fabric OS Message Reference 53-1001338-01...

  • Page 701: Webd System Messages

    Chapter WEBD System Messages WEBD-1001 Message <timestamp>, [WEBD-1001], <sequence-number>,, WARNING, <system-name>, Missing or Invalid Certificate file -- HTTPS is configured but could not be started. Probable Cause Indicates the SSL certificate file is either invalid or absent. Recommended Install a valid key file. Action Severity WARNING...
  • Page 702 WEBD-1006 Recommended No action is required. Action Severity WARNING WEBD-1006 Message <timestamp>, [WEBD-1006], <sequence-number>,, INFO, <system-name>, HTTP server and weblinker restarted due to logfile truncation. Probable Cause Indicates the size of the HTTP log file exceeded the maximum limit. Recommended No action is required.

  • Page 703: Xtun System Messages

    Chapter XTUN System Messages XTUN-1000 Message <timestamp>, [XTUN-1000], <sequence-number>,, ERROR, <system-name>, Missed Data frame:I/T/L:<FC Initiator ID> <FC Target ID> <FCP Logical Unit Number>. Probable Cause Indicates a missed frame with one or more FCP data information units during a SCSI write or read operation.
  • Page 704 XTUN-1004 Probable Cause Indicates a message transmission failure. Recommended If there was an unexpected job failure associated with this event, contact your customer support for Action assistance. Severity ERROR XTUN-1004 Message <timestamp>, [XTUN-1004], <sequence-number>,, ERROR, <system-name>, Exchange aborted:I/T/L:<FC Initiator ID> <FC Target ID> <FCP Logical Unit Number>. Probable Cause Indicates that the FCP exchange has been aborted by the Initiator.
  • Page 705 XTUN-2001 Recommended No action is required. Action Severity INFO XTUN-2001 Message <timestamp>, [XTUN-2001], <sequence-number>,, ERROR, <system-name>, FCIP Tunnel <Tunnel Number> DOWN <Reason>. Probable Cause Indicates that the specified tunnel has gone down. Recommended If the tunnel has not been administratively disabled or deleted, a possible network error or Action disruption has occurred.
  • Page 706 XTUN-2005 Recommended No action is required. Action Severity INFO XTUN-2005 Message <timestamp>, [XTUN-2005], <sequence-number>,, INFO, <system-name>, FCIP Tunnel <Tunnel Number> <Priority Class> Pri QoS DOWN <Reason>. Probable Cause Indicates that the specified quality of service has gone down. This applies to the data classes only. If the f-class goes down, the tunnel itself is marked as down.

  • Page 707: Zeus System Messages

    DRAFT: BROCADE CONFIDENTIAL Chapter ZEUS System Messages ZEUS-1001 Message <timestamp>, [ZEUS-1001], <sequence-number>,, ERROR, <system-name>, Port <port number> port fault. Please change the SFP or check cable. Probable Cause Indicates a deteriorated small form-factor pluggable (SFP), an incompatible SFP pair, or a faulty cable between peer ports.
  • Page 708 DRAFT: BROCADE CONFIDENTIAL ZEUS-1001 Fabric OS Message Reference 53-1001338-01...

  • Page 709: Zolb System Messages

    Chapter ZOLB System Messages ZOLB-1001 Message <timestamp>, [ZOLB-1001], <sequence-number>,, ERROR, <system-name>, ZONELIB <error message> Probable Cause Indicates there was an internal timeout on the inter process communication (IPC) between the name server (NS) and the zoning modules. This usually indicates that the system was busy. Recommended This message generates core dump files of the related modules (zoned, nsd, rcsd).
  • Page 710 ZOLB-1001 Fabric OS Message Reference 53-1001338-01...

  • Page 711: Zone System Messages

    Chapter ZONE System Messages ZONE-1003 Message <timestamp>, [ZONE-1003], <sequence-number>,, WARNING, <system-name>, zone(<current zone>) contains (<domain id>, <port number>) which does not exist. Probable Cause Indicates the port zone member that is targeted for the local switch contains a non-existent port. The effective zoning configuration (displayed in the error message) contains a port number that is out of range.
  • Page 712 ZONE-1008 Recommended There are two ways to avoid this problem. Action • Avoid having too many hosts zoned with a set of target devices at a single port. • Avoid having too many zones directed at a single port group on the switch. Severity INFO ZONE-1008...
  • Page 713 ZONE-1017 ZONE-1017 Message <timestamp>, [ZONE-1017], <sequence-number>,, ERROR, <system-name>, FA Zone(<zone name>) contains incorrect number of Initiator and Target devices. Probable Cause Indicates the fabric assist (FA) zoning configuration has more than one initiator. The probable cause is incorrect entries in the FA zoning configuration. Recommended Edit the zone database to ensure that only one initiator is set for each FA zone configuration.
  • Page 714 ZONE-1022 Severity ERROR ZONE-1022 Message <timestamp>, [ZONE-1022], <sequence-number>,, INFO, <system-name>, The effective configuration has changed to <Effective configuration name>. <AD Id> Probable Cause Indicates the effective zone configuration has changed to the name displayed. Recommended Verify this zone configuration change was done on purpose. If the new effective zone configuration Action is correct, no action is necessary.
  • Page 715 ZONE-1027 Severity INFO ZONE-1027 Message <timestamp>, [ZONE-1027], <sequence-number>,, INFO, <system-name>, Zoning transaction aborted <error reason>. <AD Id>. Probable Cause Indicates the zoning transaction was aborted due to a variety of potential errors. The error reason variable can be one of the following: •...
  • Page 716 ZONE-1030 Recommended This error will save the faulty zone configuration in the zoned core file directory. Action If the message persists, run supportFtp (as needed) to set up automatic FTP transfers; then run the supportSave command and contact your switch service provider. Severity WARNING ZONE-1030...
  • Page 717 ZONE-1034 Probable Cause Indicates the specified domain has the lowest memory available for the zone database in the fabric. The zone database must be smaller than the memory available on this domain. Recommended Reduce the size of the zone database and retry the operation. Action Severity ERROR...
  • Page 718 ZONE-1038 ZONE-1038 Message <timestamp>, [ZONE-1038], <sequence-number>,, ERROR, <system-name>, Unable to allocate memory for <config file name>: error message <System Error Message>. Probable Cause Indicates the Fabric OS cannot allocate enough memory for the zone configuration file. Typically the zone configuration is too large for the memory available on the switch. Recommended Reduce the size of the zone database and retry the operation.
  • Page 719 ZONE-1042 ZONE-1042 Message <timestamp>, [ZONE-1042], <sequence-number>,, INFO, <system-name>, The effective configuration has been disabled. <AD Id>. Probable Cause Indicates the effective zone configuration has been disabled. Recommended Verify that this zone configuration change was done on purpose. If no effective zone configuration Action is needed, no action is necessary.
  • Page 720 ZONE-1046 ZONE-1046 Message <timestamp>, [ZONE-1046], <sequence-number>,, INFO, <system-name>, The Default Zone access mode is already set to All Access. Probable Cause Indicates the Default Zone access mode is already set to All Access. Recommended No action is required. Action Severity INFO ZONE-1047 Message...
  • Page 721 ZONE-1050 ZONE-1050 Message <timestamp>, [ZONE-1050], <sequence-number>,, INFO, <system-name>, The Interop Safe Zoning mode is set to Enabled. Probable Cause Indicates that the Interop Safe Zoning mode is enabled. Recommended Verify if the Safe Zoning mode change was done on purpose. Action Severity INFO...
  • Page 722 ZONE-1054 ZONE-1054 Message <timestamp>, [ZONE-1054], <sequence-number>,, WARNING, <system-name>, DEFZONE ALLACCESS set with Frame Redirection zones. Probable Cause Indicates the DEFZONE allaccess mode will not grant all access behavior when frame redirection zones are defined. Recommended Remove frame redirection zones or set the defzone command to no access mode. Action Severity WARNING...
  • Page 723 Section Audit Log Messages This section provides the Audit messages, including: • AUDIT AG System Messages ........655 •...

  • Page 725: Audit Ag System Messages

    Chapter AUDIT AG System Messages AG-1029 Message AUDIT, <timestamp>, [AG-1029], INFO, CFG, <event-initiator-details>, <event-location>, , F_Port to N_Port mapping has been updated for N_Port <n_port>. Probable Cause Indicates that the F_Ports mapped to an N_Port have changed and the config file has been updated.
  • Page 726 AG-1029 Fabric OS Message Reference 53-1001338-01...

  • Page 727: Audit An System Messages

    Chapter AUDIT AN System Messages AN-1003 Message <timestamp>, [AN-1003], <sequence-number>,, WARNING, <system-name>, Slot <slot number>, port <port number within slot number> is a latency bottleneck due to the device attached to it. <percentage of seconds affected by latency bottlenecking> percent of last <observation period over which the percentage of affected seconds is reported>...
  • Page 728 AN-1003 Fabric OS Message Reference 53-1001338-01...

  • Page 729: Audit Auth System Messages

    Chapter AUDIT AUTH System Messages AUTH-3001 Message AUDIT, <timestamp>, [AUTH-3001], INFO, SECURITY, <event-initiator-details>, <event-location>, , Event: <Event Name>, Status: success, Info: <Data type> type has been changed from [<Old value>] to [<New value>]. Probable Cause Indicates that an authentication configuration value was set to a specified value. The data type can be either “authentication type”, “DH group type”, “Hash type”...
  • Page 730 AUTH-3004 AUTH-3004 Message AUDIT, <timestamp>, [AUTH-3004], INFO, SECURITY, <event-initiator-details>, <event-location>, , Event: <Event Name>, Status: failed, Info: Neighboring switch has a conflicting authentication policy; Port <Port Number> disabled. Probable Cause The specified E_Port was disabled because the neighboring switch rejected the authentication negotiation, and the local switch has a strict switch authentication policy.
  • Page 731 AUTH-3007 AUTH-3007 Message AUDIT, <timestamp>, [AUTH-3007], INFO, SECURITY, <event-initiator-details>, <event-location>, , Event: <Event Name>, Status: failed, Info: Port <port number> disabled due to receiving an authentication reject with code '<Reason String>' and explanation '<Explanation String>'. Probable Cause Indicates that the specified port was disabled due to receiving an authentication reject response from the connected switch/device.
  • Page 732 AUTH-3008 Fabric OS Message Reference 53-1001338-01...

  • Page 733: Audit Bls System Messages

    Chapter AUDIT BLS System Messages BLS-1002 Message <timestamp>, [BLS-1002], <sequence-number>,, INFO, <system-name>, An IPsec/IKE policy was added. Probable Cause Indicates that an IPsec or IKE policy was added and the configuration file was updated. Recommended No action is required. Action Severity INFO BLS-1003...
  • Page 734 BLS-1003 Fabric OS Message Reference 53-1001338-01...

  • Page 735: Audit Conf System Messages

    Chapter AUDIT CONF System Messages CONF-1000 Message AUDIT, <timestamp>, [CONF-1000], INFO, CFG, <event-initiator-details>, <event-location>, , configDownload completed successfully. <Info about the parameters and AD>. Probable Cause The configDownload process was initiated and completed successfully. The message string describes the class of configuration parameters that were downloaded. If admin domain (AD) is enabled, the AD number is specified in the description.
  • Page 736 CONF-1022 Fabric OS Message Reference 53-1001338-01...

  • Page 737: Audit Fcip System Messages

    Chapter AUDIT FCIP System Messages FCIP-1002 Message AUDIT, <timestamp>, [FCIP-1002], INFO, CFG, <event-initiator-details>, <event-location>, , An IPsec/IKE policy was added. Probable Cause Indicates that an IPsec/IKE policy was added and the config file was updated. Recommended No action is required. Action Severity INFO...
  • Page 738 FCIP-1003 Fabric OS Message Reference 53-1001338-01...

  • Page 739: Audit Ficu System Messages

    Chapter AUDIT FICU System Messages FICU-1011 Message AUDIT, <timestamp>, [FICU-1011], INFO, CFG, <event-initiator-details>, <event-location>, , FMS mode has been enabled. Probable Cause Indicates that the FICON Management server mode has been enabled. Recommended No action is required. Action Severity INFO FICU-1012 Message AUDIT, <timestamp>, [FICU-1012], INFO, CFG, <event-initiator-details>,...
  • Page 740 FICU-1012 Fabric OS Message Reference 53-1001338-01...

  • Page 741: Audit Fw System Messages

    Chapter AUDIT FW System Messages FW-3001 Message AUDIT, <timestamp>, [FW-3001], INFO, <event-initiator-details>, <event-location>, , Event: <Event Name>, Status: success, Info:<Event Related info> Probable Cause Indicates that Port Fencing was enabled/disabled successfully. Recommended No action is required. Action Severity INFO Fabric OS Message Reference 53-1001338-01...
  • Page 742 FW-3001 Fabric OS Message Reference 53-1001338-01...

  • Page 743: Audit Http System Messages

    Chapter AUDIT HTTP System Messages HTTP-1002 Message AUDIT, <timestamp>, [HTTP-1002], INFO, ZONE, <event-initiator-details>, <event-location>, , Zoning transaction initiated by User: <User Name>, Role: <User Role> completed successfully. Probable Cause Indicates that the zoning database has been changed. Recommended Verify that the event was planned. If the event was planned, no action is required. If the event was Action not planned, take appropriate action as defined by your enterprise security policy.
  • Page 744 HTTP-1003 Fabric OS Message Reference 53-1001338-01...

  • Page 745: Audit Ipad System Messages

    Chapter AUDIT IPAD System Messages IPAD-1002 Message AUDIT, <timestamp>, [IPAD-1002], INFO, CFG, <event-initiator-details>, <event-location>, , Switchname has been successfully changed to <Switch name>. Probable Cause Indicates that a change with the switch name has occured. Recommended No action is required. Action Severity INFO...
  • Page 746 IPAD-1002 Fabric OS Message Reference 53-1001338-01...

  • Page 747: Audit Port System Messages

    Chapter AUDIT PORT System Messages PORT-1006 Message AUDIT, <timestamp>, [PORT-1006], INFO, CFG, <event-initiator-details>, <event-location>, , Configuration changed for port (ID: <port number>) in No_Module or No_Light state. Probable Cause Indicates the configuration changes were made to an offline port in No_Module or No_Light state. Recommended No action is required.
  • Page 748 PORT-1009 Probable Cause Indicates a GigE port has been disabled. Recommended No action is required. Action Severity INFO Fabric OS Message Reference 53-1001338-01...

  • Page 749: Audit Sec System Messages

    Chapter AUDIT SEC System Messages SEC-1113 Message <timestamp>, [SEC-1113], <sequence-number>,, WARNING, <system-name>, <Key> [ <Feature> license ] going to expire in <Expiry_days> days. Probable Cause Indicates the license period will expire soon. Recommended Get a new license for this feature. Action Severity WARNING...
  • Page 750 SEC-3002 SEC-3002 Message AUDIT, <timestamp>, [SEC-3002], INFO, SECURITY, <event-initiator-details>, <event-location>, , Event: <Event Name>, Status: success, Info: <Event Related Info>. Probable Cause Indicates the specified security event has occurred. The Event Name can be one of the following: • There has been an fabric configurations server (FCS) failover. •...
  • Page 751 SEC-3005 Severity INFO SEC-3005 Message AUDIT, <timestamp>, [SEC-3005], INFO, SECURITY, <event-initiator-details>, <event-location>, , Event: <Event Name>, Status: success, Info: Added members <Members added> to policy <Policy name>. Probable Cause Indicates new members have been added to the specified security policy. Note: If you use a wildcard (for example, an asterisk) in adding members to a policy, the audit report displays the wildcard in the event info field.
  • Page 752 SEC-3008 SEC-3008 Message AUDIT, <timestamp>, [SEC-3008], INFO, SECURITY, <event-initiator-details>, <event-location>, , Event: <Event Name>, Status: success, Info: FCS member moved from position <Old FCS position> to <New FCS position>. Probable Cause Indicates the fabric configuration server (FCS) list has been modified. One of the members of the list has been moved to a new position in the list, as identified in the message.
  • Page 753 SEC-3012 Recommended Verify that the security statistic was intentionally reset. If the security statistic were intentionally Action reset, no action is required. If the security statistic was not intentionally reset, take appropriate action as defined by your enterprise security policy. Severity INFO SEC-3012...
  • Page 754 SEC-3015 SEC-3015 Message AUDIT, <timestamp>, [SEC-3015], INFO, SECURITY, <event-initiator-details>, <event-location>, , Event: <Event Name>, Status: success, Info: Moved RADIUS server <Server name> to position <New position>. Probable Cause Indicates a user has changed the position of the remote authentication dial-in user service (RADIUS) server.
  • Page 755 SEC-3018 SEC-3018 Message AUDIT, <timestamp>, [SEC-3018], INFO, SECURITY, <event-initiator-details>, <event-location>, , Event: <Event Name>, Status: success, Info: Parameter [<Parameter Name>] changed from [<Old Value>] to [<New Value>]. Probable Cause Indicates the specified passwdCfg parameter is changed. Recommended Verify the passwdCfg parameter was intentionally changed. If the passwdCfg parameter was Action intentionally changed, no action is required.
  • Page 756 SEC-3022 Recommended Verify the security event was planned. If the security event was planned, no action is required. If the Action security event was not planned, take appropriate action as defined by your enterprise security policy. Severity INFO SEC-3022 Message AUDIT, <timestamp>, [SEC-3022], INFO, SECURITY, <event-initiator-details>, <event-location>, , Event: <Event Name>, Status: success, Info: Successful logout by user [<User>].
  • Page 757 SEC-3025 SEC-3025 Message AUDIT, <timestamp>, [SEC-3025], INFO, SECURITY, <event-initiator-details>, <event-location>, , Event: <Event Name>, Status: success, Info: User account [<User Name>] added. Role: [<Role Type>], Password [<Password Expired or not>], Home AD [<Home AD>], AD list [<AD membership List>]. Probable Cause Indicates a new user account was created.
  • Page 758 SEC-3029 Recommended Verify the security event was planned. If the security event was planned, no action is required. If the Action security event was not planned, take appropriate action as defined by your enterprise security policy. Severity INFO SEC-3029 Message AUDIT, <timestamp>, [SEC-3029], INFO, SECURITY, <event-initiator-details>, <event-location>, , Event: <Event Name>, Status: success, Info: Backup user account \"<User Account Name>\"...
  • Page 759 SEC-3032 SEC-3032 Message AUDIT, <timestamp>, [SEC-3032], INFO, SECURITY, <event-initiator-details>, <event-location>, , Event: <Event Name>, Status: success, Info: Switch is configured to <accept or reject> <Database name> database. Probable Cause Indicates the specified event has occurred to accept or reject a certain database. Recommended Verify the event was planned.
  • Page 760 SEC-3036 Recommended Verify the security event was planned. If the security event was planned, no action is required. If the Action security event was not planned, take appropriate action as defined by your enterprise security policy. Severity INFO SEC-3036 Message AUDIT, <timestamp>, [SEC-3036], INFO, SECURITY, <event-initiator-details>, <event-location>, , Event: ipfilter, Status: failed, Info: Failed to save changes for <IP Filter Policy>...
  • Page 761 SEC-3039 SEC-3039 Message AUDIT, <timestamp>, [SEC-3039], INFO, SECURITY, <event-initiator-details>, <event-location>, , Event: Securty Violation, Status: failed, Info: Unauthorized host with IP address <IP address of the violating host> tries to establish connection using <Protocol Connection Type>. Probable Cause Indicates a security violation was reported. The IP address of the unauthorized host is displayed in the message.
  • Page 762 SEC-3047 Recommended Verify the security event was planned. If the security event was planned, no action is required. If the Action security event was not planned, take appropriate action as defined by your enterprise security policy. Severity INFO SEC-3047 Message AUDIT, <timestamp>, [SEC-3047], INFO, SECURITY, <event-initiator-details>, <event-location>, RBAC permission denied for CLI : <Cmd Name>.
  • Page 763 SEC-3051 Probable Cause Indicates the specified sshutil operation was performed.. Recommended Verify the security event was planned. If the security event was planned, no action is required. If the Action security event was not planned, take appropriate action as defined by your enterprise security policy.
  • Page 764 SEC-3051 Fabric OS Message Reference 53-1001338-01...

  • Page 765: Audit Snmp System Messages

    Chapter AUDIT SNMP System Messages SNMP-1004 Message AUDIT, <timestamp>, [SNMP-1004], ERROR, CONFIGURATION, <event-initiator-details>, <event-location>, , Incorrect SNMP configuration. Probable Cause Indicates that the simple network management protocol (SNMP) configuration s incorrect and the SNMP service will not work correctly. Recommended Reset the SNMP configuration to default.
  • Page 766 SNMP-1006 Fabric OS Message Reference 53-1001338-01...

  • Page 767: Audit Sulb System Messages

    Chapter AUDIT SULB System Messages SULB-1001 Message AUDIT, <timestamp>, [SULB-1001], WARNING, FIRMWARE, <event-initiator-details>, <event-location>, , Firmwaredownload command has started. Probable Cause Indicates the firmwareDownload command has been started. This process should take approximately 17 minutes. The process is set to time out after 30 minutes. Recommended No action is required.
  • Page 768 SULB-1004 SULB-1004 Message AUDIT, <timestamp>, [SULB-1004], INFO, FIRMWARE, <event-initiator-details>, <event-location>, , Firmwarecommit has completed. Probable Cause Indicates the FirmwareCommit command is executed. Recommended No action is required. Run the firmwareDownloadStatus command for more information. Action Severity INFO SULB-1009 Message AUDIT, <timestamp>, [SULB-1009], INFO, FIRMWARE, <event-initiator-details>, <event-location>, , Firmwaredownload command failed.
  • Page 769 SULB-1009 TABLE 9 Status Messages and Status Codes Status Message Status Code “firmwareCommit operation failed due to IPC error.” 0x55 "Unable to check the firmware version on Standby CP due to IPC error." 0x56 “Unable to restore the original firmware due to Standby CP timeout.” 0x57 "Standby CP failed to reboot and was not responding."...
  • Page 770 SULB-1009 TABLE 9 Status Messages and Status Codes Status Message Status Code "The original firmware has been restored successfully on Standby CP." 0x7e "Unable to restore the original firmware on Standby CP." 0x7f "Standby CP reboots." 0x80 "Standby CP failed to reboot." 0x81 "Standby CP booted up with new firmware."...
  • Page 771 SULB-1009 TABLE 9 Status Messages and Status Codes Status Message Status Code “firmwareRestore is entered. System will reboot and a firmwareCommit operation will start 0xa8 upon boot up.” "Switch is relocating the AP image." 0xa9 "The AP image is relocated successfully." 0xaa "Switch reboots during relocating the AP image.
  • Page 772 SULB-1009 TABLE 10 Error Messages and Error Codes Error Message Error Code “firmwareDownload timed out.” 0x23 "Our of disk space." 0x24 “Primary filesystem is inconsistent. Run firmwareRestore to restore the original firmware, or 0x25 contact your service provider for recovery.” "The post-install script failed."...
  • Page 773 SULB-1009 0x24 - out of disk space. This error may occur because some coredump files have not been removed from the filesystem and are using up disk space. Remove these coredump files using the supportSave command before proceeding. 0x29 - The pre-install script failed. This error may be caused by an unsupported blade type in the chassis.
  • Page 774 SULB-1010 In a director-class switch, when firmwareDownload fails, the two CPs may end up with different versions of firmware and they may not gain high-availability (HA) sync. In that case, run firmwareDownload single mode (-s) to upgrade the firmware on the standby CP to the same version as the active CP.
  • Page 775 SULB-1020 Recommended Run the slotShow command. If the blade is in a FAULTY state, run the slotPowerOff and Action slotPowerOn commands to trigger another firmwareDownload. If the blade is stuck in LOADING state, remove and re-insert the blade to trigger another firmwareDownload. If the problem persists, contact your switch service provider.
  • Page 776 SULB-1024 Recommended The firmwareCommit command will be started automatically after the blade boots up to repair the Action secondary partition. If at the end of firmwareCommit, the blade firmware version is still inconsistent with the active CP firmware, firmwareDownload will automatically be restarted on the blade.
  • Page 777 SULB-1031 Recommended The firmwareDownload command will continue after the switch has rebooted. Run the Action firmwareDownloadStatus command to monitor progress. If the problem persists, contact your switch service provider. Severity WARNING SULB-1031 Message AUDIT, <timestamp>, [SULB-1032], WARNING, FIRMWARE, <event-initiator-details>, <event-location>, , Relocating an internal firmware image on the CP. Probable Cause Indicates the switch has rebooted with the new firmware and is relocating the AP firmware.
  • Page 778 SULB-1035 Recommended Restart the switch. This will cause the internal image to be relocated again. Use the Action firmwareDownloadStatus command to monitor the progress. If the problem persists, contact your switch service provider. Severity ERROR SULB-1035 Message AUDIT, <timestamp>, [SULB-1035], ERROR, FIRMWARE, <event-initiator-details>, <event-location>, , An error has occurred relocation of the internal image.

  • Page 779: Audit Swch System Messages

    Chapter AUDIT SWCH System Messages SWCH-1012 Message AUDIT, <timestamp>, [SWCH-1012], INFO, CFG, <event-initiator-details>, <event-location>, , Trunk Area (<trunk area>) has been enabled for one or more ports. Probable Cause Indicates a Trunk Area has been enabled for one or more ports and the config file has been updated.
  • Page 780 SWCH-1014 Fabric OS Message Reference 53-1001338-01...

  • Page 781: Audit Ucst System Messages

    Chapter AUDIT UCST System Messages UCST-1021 Message AUDIT, <timestamp>, [UCST-1021], INFO, CFG, <event-initiator-details>, <event-location>, , In-order delivery option has been enabled. Probable Cause Indicates the IOD option has been enabled for the switch. This option guarantees in-order delivery of frames during topology changes. Recommended No action is required.
  • Page 782 UCST-1024 UCST-1024 Message AUDIT, <timestamp>, [UCST-1024], INFO, CFG, <event-initiator-details>, <event-location>, , Dynamic Load Sharing option has been disabled. Probable Cause Indicates the DLS option has been disabled for the switch. Recommended No action is required. Action Severity INFO UCST-1025 Message AUDIT, <timestamp>, [UCST-1025], INFO, CFG, <event-initiator-details>, <event-location>, , In-order delivery option has been enabled with Lossless-DLS option.
  • Page 783 UCST-1027 Severity INFO Fabric OS Message Reference 53-1001338-01...
  • Page 784 UCST-1027 Fabric OS Message Reference 53-1001338-01...

  • Page 785: Audit Zone System Messages

    Chapter AUDIT ZONE System Messages ZONE-3001 Message AUDIT, <timestamp>, [ZONE-3001], INFO, ZONE, <event-initiator-details>, <event-location>, , Event: <Event Name>, Status: success, Info: <Zone object type> \"<Zone object member list>\" added to <Zone object set type> \"<Zone object set name>\". Probable Cause Indicates that a new zone object member or members have been added to the specified zone object set.
  • Page 786 ZONE-3004 The zone object type can be “alias”, “zone member”, “zone” or “zone configuration”. The string “...” appears at the end of the zone object member list if the list was truncated in the message. Recommended Verify the event was planned. If the event was planned, no action is required. If the event was not Action planned, take appropriate action as defined by your enterprise security policy.
  • Page 787 ZONE-3007 ZONE-3007 Message AUDIT, <timestamp>, [ZONE-3007], INFO, ZONE, <event-initiator-details>, <event-location>, , Event: <Event Name>, Status: success, Info: Zone configuration \"<Zone configuration>\" enabled. <AD Id>. Probable Cause Indicates the specified zone configuration has been enabled. Recommended Verify the event was planned. If the event was planned, no action is required. If the event was not Action planned, take appropriate action as defined by your enterprise security policy.
  • Page 788 ZONE-3011 Severity INFO ZONE-3011 Message AUDIT, <timestamp>, [ZONE-3011], INFO, ZONE, <event-initiator-details>, <event-location>, , Event: <Event Name>, Status: success, Info: Zone object \"<Zone object name>\" expunged. Probable Cause Indicates the specified zone object has been expunged. Recommended Verify the event was planned. If the event was planned, no action is required. If the event was not Action planned, take appropriate action as defined by your enterprise security policy.
  • Page 789 ZONE-3015 An AD object set type is “AD member”. The string “...” appears at the end of the AD object member list if the list was truncated in the message. Recommended Verify the event was planned. If the event was planned, no action is required. If the event was not Action planned, take appropriate action as defined by your enterprise security policy.
  • Page 790 ZONE-3018 ZONE-3018 Message AUDIT, <timestamp>, [ZONE-3018], INFO, FABRIC, <event-initiator-details>, <event-location>, , Event: <Event Name>, Status: success, Info: <AD object name> has been deactivated. Probable Cause Indicates the specified admin domain (AD) object has been deactivated. Recommended Verify the event was planned. If the event was planned, no action is required. If the event was not Action planned, take appropriate action as defined by your enterprise security policy.
  • Page 791 ZONE-3022 Severity INFO ZONE-3022 Message AUDIT, <timestamp>, [ZONE-3022], INFO, FABRIC, <event-initiator-details>, <Event Name> <event-location>, , Event: , Status: success, Info: Current AD configuration saved to flash. Probable Cause Indicates the current admin domain (AD) configuration has been saved to flash. Recommended Verify the event was planned.
  • Page 792 ZONE-3025 Severity INFO Fabric OS Message Reference 53-1001338-01...
