Chapter 1- Hardware Description
1-14
Table 1-5 RMX 2000 RTM IP LEDs (Continued)
LED
Component
Name
10/100 ShMG LNK
LEDs
100
SLOT (1-4) LNK (1-4)
LEDs
1Gb (1-4)
ShMG LEDs ERR
ACT
RDY
HS
Standby LED
LED Color Description
Green Lit with active network
connection, flickers with Packet
activity.
Amber Lit when active network is 10/
100Mb, flickers with Packet
activity.
Green Lit with active network
connection, flickers with Packet
activity.
Amber Lit when 1Gb connection online,
flickers with Packet activity.
Red ON - Major error on RTM board.
Red ON - Packet flow to and from
the MCU chassis.
Green ON - RTM IP board has
successfully completed startup.
Blue OFF - Normal.
Flashes - During power down
process.
ON - RTM IP board may be
removed.
Red ON - CPU & System are in a
standby (OFF) mode.
