Chapter 1- Hardware Description

RMX 2000 LEDs

RMX 2000 Front Panel LEDs

1-12
The RMX includes LEDs located on the front panel and rear panel. In the
front panel, the LEDs reflect the state of the module. The LEDs on the rear
panel indicate the state of the external connections and the status of the
RTM IP board.
The following items appear on the RMX 2000 front panel:
Table 1-4 RMX 2000 Front Panel LED's
Component LED ID
Fan Status
Power Status
CNTL ERR
RDY
ACT
HD
HS
LED Color Description
Green OK.
Red Warning - Fan failure.
Green OK.
Red Error - Problem with power supply.
Red ON - Major system error.
Green ON - CPU board has successfully
completed startup.
Amber ON - At least one endpoint is
connected to the system.
Red OFF - Normal.
Flashes - Hard disk is active.
Blue Flashes - Indicates when the
power down process is initiated on
an MPM board. This Led flashes in
synchronization with the MPM's
boards HS Led.
ON - CPU may be removed.
