RMX 2000 Components

On the RMX 2000 modules are located on both the front and rear of the

MCU as listed in Table 1-2, "Polycom RMX 2000 Component Description".

For more information see the descriptions of the "RMX 2000 Front Panel"

on page

Figure 1-1 shows the front panel of the RMX 2000. The front panel

provides access to the RMX 2000 main CNTL modules, MPM modules,

Power Supply drawer, Status LEDs, and Fans.

Power supply drawer

Figure 1-1

1-5

and "RMX 2000 Rear Panel" on page 1-7.

MPM Boards & LEDs

USB ports - are only

for debugging and not

for customer use

RMX 2000 Front Panel

Polycom RMX 2000 Hardware Guide

Fan drawer & Power

LED

Control Unit & LEDs

2nd CPU & LEDs

1-5
