Cables Connected to the RTM IP & ISDN Boards
All external connectors are located on the rear panel.
LAN 2 Connection
Figure 1-4
RMX 2000 Rear Panel View with Cables
Do not remove the protective caps from LAN1, LAN3 and ShMG ports.
Polycom RMX 2000 Hardware Guide
E1/T1 Connection
Power
Off/On
Cable
switch
1-11
