RMX 2000 Rear Panel LEDs

Table 1-4 RMX 2000 Front Panel LED's (Continued)
Component LED ID
MPM ERR
RDY
ACT
HS

RTM IP

The following items appear on the RTM IP board:
Table 1-5 RMX 2000 RTM IP LEDs
LED
Component
Name
LAN LEDs (1-3) LNK
1 Gb
Polycom RMX 2000 Hardware Guide
LED Color Description
Red ON - Major error on board.
Green ON - The board has completed
startup successfully.
Amber ON - At least one participant is
connected to a conference.
Blue Flashes - Shut down process
initiated by lightly pulling the CPU
ejector levers. This Led flashes in
synchronization with the CNTL's
board's HS Led.
ON - The card can be removed
safely once the CPU ejector levers
are fully open.
LED Color Description
Green Lit with active network
connection, flickers with Packet
activity.
Amber Lit when 1Gb connection online,
flickers with Packet activity
1-13
