Chapter 1- Hardware Description
1-8
The following items appear on the RMX 2000 rear panel:
Table 1-3
RMX 2000 Rear Panel - RTM IP Component Description
Item
LAN 1
LAN 2
LAN 3
10/100 ShMG
Serial
USB
Standby button
Description
NA - Disconnected.
Note: LAN 1 is covered with a plastic cap that should not
be removed.
Used for the Network connection.
For Remote Access only using the Permanent
Management Network. For more information, see the
RMX 2000 Administrator's Guide, Appendix F: "Alternate
Management Network" on page G-1.
Note: When not in use, LAN 3 is covered with a plastic
cap that should not be removed.
NA - For debugging purposes only.
Note: 10/100 ShMG is covered with a plastic cap that
should not be removed.
NA - For debugging purposes only.
USB key connection. For more information, see the RMX
2000 Getting Started Guide, "First Time Installation and
Configuration" on page 2-1.
Toggle between CPU activation and standby.
