Chore-Time TURBO MV1864P Installation & Operator's Manual page 13

Belt Tensioner Position
When the Belt is installed the Tensioner will rotate to a set position. The notches on the outside wheel of the
Tensioner should line up with the etched mark (A,B, or C per chart) on the inside wheel of the Tensioner based on
the chart below.
Note:
When a Belt is worn the Tensioner position may vary as much as 1 full notch from new.
3 4
2
1
Inside Wheel
Fan Part No. Tensioner Position
49862-22 Series
"A" etched mark
49862-42 Series
MV1864P
49862-42
52" TURBO ® (BD)
208-230/460 V, 60 HZ, 3PH, 1.5 HP
MILFOR D , IN 46542 C H OR E-TIME EQU IPMEN T 39002-450
Belt
Outside Wheel
C
B
A
Fan Part No.
3rd Notch
49862-21 Series
49862-41 Series
Figure 14. Tensioner position
49862-42
52" TURBO
208-230/460 V, 60 HZ, 3PH, 1.5 HP
CHORE-TIME EQUIPMENT
MILFORD, IN 46542
4
3
2
1
C
B
A
Tensioner Position
4th Notch
"C" etched mark
Fan Model Number
(see chart for correct Tensioner
positioning with newbelt installed)
®
(BD)
39002-450
3 4
2
1
Fan Part No. Tensioner Position
49862-51 Series
Maintenance
C
B
A
4th Notch
"B" etched mark
13
