19 Annotating images

19.5 Adding a sketch

19.5.1 General

You can add a freehand drawing to an image.

19.5.2 Procedure

Follow this procedure:
1. Open the image in the image archive.
2. Push the joystick. This displays a context menu.
3. Select (Add sketch) and push the joystick.
4. You are now in sketch mode. Draw the sketch by touching the screen.
5. Push the joystick. This displays a context menu. Do one or more of the following:
• To change the color of the sketch tools, select
Select the color and push the joystick.
• To erase, select
touching the screen.
• To add an arrow, circle, or cross, select
Select the type of stamp and push the joystick. The stamp is displayed in the cen-
ter of the screen. You can move the stamp by touching the screen.
• To clear, select (Clear all) and push the joystick.
• When the sketch is completed, select
#T559880; r. AK/36075/36075; en-US
(Eraser) and push the joystick. Erase parts of the sketch by
(Stamp sketch) and push the joystick.
(Save) and push the joystick.
(Draw) and push the joystick.
