19 Annotating images

19.3 Adding a table

19.3.1 General

You can save a table with textual information to the image file. This feature is a very effi-
cient way of recording information when you are inspecting a large number of similar ob-
jects. The idea behind using a table with textual information is to avoid filling out forms or
inspection protocols manually.
The camera has a number of default table templates. You can also import your own table
templates from FLIR Tools. The templates are stored on the memory card.

19.3.2 Procedure

Follow this procedure:
1. Open the image in the image archive.
2. Push the joystick. This displays a context menu.
3. Select (Add table) and push the joystick.
4. Select (Add table contents) and push the joystick.
5. This displays the default table template that ships with the camera.
Note You can select another template by first selecting
template).
6. For each row in the table, do the following:
• Push the joystick. This displays the predefined values.
• Move the joystick up/down to select a predefined value. Push the joystick to
confirm.
• Instead of selecting a predefined value, you can select the keyboard
other text.
7. When completed, select Save & Exit at the bottom of the table. Push the joystick to
confirm.

19.4 Adding a voice annotation

19.4.1 General
A voice annotation is an audio recording that is saved to the infrared image file.
The voice annotation is recorded using a Bluetooth headset. The recording can be
played back in the camera, and in image analysis and reporting software from FLIR
Systems.
19.4.2 Procedure
Follow this procedure:
1. Open the image in the image archive.
2. Push the joystick. This displays a context menu.
3. Select (Add voice annotation) and push the joystick.
4. To start a recording, select
5. To stop the recording, select
6. To listen to the recording, select
7. To delete the recording, select
8. When completed, select
#T559880; r. AK/36075/36075; en-US
(Record) and push the joystick.
(Stop) and push the joystick.
(Play) and push the joystick.
(Delete) and push the joystick.
(Done) and push the joystick.
(Select default
and enter
