24 Technical data
24.57 FLIR T650sc 25° and 45° w/case
P/N: 55904-7825
Rev.: 35951
General description
The FLIR T650sc is designed for the expert requiring the highest performance and the latest technology
available. The camera combines excellent ergonomics and feature-rich flexibility with superior image
quality of 640 × 480 pixel infrared resolution. High accuracy and sensitivity together with radiometric re-
cording and streaming options make the FLIR T650sc well suited for advanced research and
development.
Benefits:
• Tailor made for research and development: The FLIR T650sc has high accuracy and high sensitivity
to accurately measure the smallest temperature differences. With real-time radiometric recording by
the camera, it is possible to capture fast events on an SD card for further analysis by the supplied
analysis software.
• Flexible and feature rich: A wide variety of measuring and analysis functions makes the camera flexi-
ble and able to meet your every need. A programmable button provides easy access to favorite
functions.
• Highest performance with the latest technology: The FLIR T650sc is equipped with the innovative
Multi Spectral Dynamic Imaging (MSX) feature, which produces an image richer in detail than ever
before. Continuous auto-focus makes the FLIR T650sc the first fully automatic infrared camera on
the market.
• Extensive communication options: The Wi-Fi connectivity of the T650sc allows you to connect to
smart phones or tablets for the wireless transfer of images or the remote control of the camera. The
Bluetooth-based METERLiNK function transfers readings from external measurement instruments
to the infrared image.
• Support for UltraMax: When enabling UltraMax in the camera, the resolution of images can be sub-
stantially enhanced when importing the images into FLIR Tools.
Imaging and optical data
IR resolution
UltraMax
Thermal sensitivity/NETD
Field of view (FOV)
Minimum focus distance
Focal length
Spatial resolution (IFOV)
Lens identification
F-number
Image frequency
Focus
Digital zoom
Digital image enhancement
Detector data
Detector type
Spectral range
Detector pitch
Image presentation
Display
Display type
Auto orientation
Viewfinder
#T559880; r. AK/36075/36075; en-US
640 × 480 pixels
Yes
<20 mK @ +30°C (+86°F)
25° × 19°
0.25 m (0.82 ft.)
25 mm (0.97 in.)
0.68 mrad
Automatic
1.0
30 Hz
Continuous, one shot or manual
1–8× continuous
Adaptive digital noise reduction
Focal plane array (FPA), uncooled
microbolometer
7.5–14 µm
17 µm
Built-in touch screen, 4.3 in. wide screen LCD,
800 × 480 pixels
Capacitive touch screen
Automatic landscape or portrait
Built-in 800 × 480 pixels
383
