Summary of Contents for FLIR Txxx series

  • Page 1 Getting Started Guide FLIR Txxx series actoolsupply.com...
  • Page 2 Flir T640 Infrared Camera With 15 Degree Lens Flir T640 Infrared Camera With 45 Degree Lens Flir T640 Infrared Camera With NIST Calibration And 25 Degree Lens Flir T640 Infrared Camera With NIST Calibration And 15 Degree Lens Flir T640 Infrared Camera With NIST Calibration And 45 Degree Lens...
  • Page 3: Table Of Contents

    Table of contents The latest revision of this publication always applies, and can be downloaded from http://support.flir.com. Screen elements ..................7 Rear view ..................... 8 Front view....................10 Connectors and storage media..............11 Quick Start Guide..................12 To keep in mind ..................12 Additional resources...................13...
  • Page 4: Screen Elements

    actoolsupply.com EN-US English EN-US Screen elements 1. Back toolbar button. 2. Mode toolbar button. 3. Presets toolbar button. 4. Tools toolbar button. 5. Palette toolbar button. 6. Parameters toolbar button. 7. Result table. 8. Measurement box. 9. Measurement spotmeter. 10. Various status and mode icons, e.g., Bluetooth, battery, USB, and compass. 11.
  • Page 5: Rear View

    actoolsupply.com Rear view Touch screen LCD. Antenna for wireless communication. Digital zoom button. Programmable button. Joystick: Move up/down or left/right to navigate on menus, in dialog boxes, and in the image archive. Push to confirm choices. Menu/Back button: Push to display the menu on the screen, and to go back in dialog boxes.
  • Page 6 actoolsupply.com Manual min: Using this mode, the bottom temperature level in the scale ○ can be changed by pushing the joystick up/down, while the top temperature level remains fixed. Manual max: Using this mode, the top temperature level in the scale can ○...
  • Page 7: Front View

    actoolsupply.com Front view Laser pointer button: Push to activate the laser pointer. This button has two main functions: 1. Preview/Save: Push the button fully down to save an infrared image and a digital photo simultaneously. Note: The behavior of this button can be changed under Settings to one of the following: Preview/Save.
  • Page 8: Connectors And Storage Media

    actoolsupply.com Connectors and storage media To connect an external USB device to the camera, use a USB-A cable and this socket. To connect a computer to the camera to move images and files to and from the camera, use a USB Mini-B cable and this socket. To insert an SD memory card, use this card slot.
  • Page 9: Quick Start Guide

    actoolsupply.com Quick Start Guide Follow this procedure to get started right away: 1. Charge the battery for 4 hours. 2. Insert the battery into the camera. 3. Insert an SD memory card into the card slot (C3) at the bottom of the camera. 4.
  • Page 10: Additional Resources

    actoolsupply.com Additional resources • User documentation CD-ROM (in the transport case): User’s manual. ○ Technical data. ○ Application stories. ○ Guidebooks. ○ And more… ○ • Training by ITC (Infrared Training Center): http://www.infraredtraining.com ○ http://www.irtraining.com ○ http://www.irtraining.eu ○ actoolsupply.com...

This manual is also suitable for:

T420T440T420bxT440bxT620T640
