24 Technical data
24.23 FLIR T620 25° and 15° (incl. Wi-Fi)
P/N: 55903-5123
Rev.: 36069
General description
The FLIR T620 is designed for the expert requiring the highest performance and the latest technology
available. The camera combines excellent ergonomics and a walk-up-and-use interface with superior
image quality of 640 × 480 pixel infrared resolution. The FLIR T620 is flexible and can meet your every
need, and has extensive communication options.
Benefits:
• Highest performance with the latest technology: The FLIR T620 camera is equipped with the innova-
tive "Multi Spectral Dynamic Imaging (MSX)" feature, which produces an image richer in detail than
ever before.
• Ground-breaking efficiency: You can highlight objects of interest, on both the infrared and the visual
images, by sketching or adding predefined stamps directly onto the camera's capacitive touch
screen. The user interface is intuitive and logical for effective operation. Auto-orientation allows you
to tilt between landscape and portrait views.
• Extensive communication options: The Wi-Fi connectivity of the FLIR T620 allows you to connect to
smart phones or tablets for the wireless transfer of images or the remote control of the camera. The
Bluetooth-based METERLiNK function transfers readings from external measurement instruments
to the infrared image.
• Support for UltraMax: When enabling UltraMax in the camera, the resolution of images can be sub-
stantially enhanced when importing the images into FLIR Tools.
Imaging and optical data
IR resolution
UltraMax
Thermal sensitivity/NETD
Field of view (FOV)
Minimum focus distance
Focal length
Spatial resolution (IFOV)
Lens identification
F-number
Image frequency
Focus
Digital zoom
Digital image enhancement
Detector data
Detector type
Spectral range
Detector pitch
Image presentation
Display
Display type
Auto orientation
Automatic image adjustment
Manual image adjustment
#T559880; r. AK/36075/36075; en-US
640 × 480 pixels
Yes
<40 mK @ +30°C (+86°F)
25° × 19°
0.25 m (0.82 ft.)
25 mm (0.97 in.)
0.68 mrad
Automatic
1.0
30 Hz
Automatic (one shot) or manual
1–4× continuous
Adaptive digital noise reduction
Focal plane array (FPA), uncooled
microbolometer
7.5–14 µm
17 µm
Built-in touch screen, 4.3 in. wide screen LCD,
800 × 480 pixels
Capacitive touch screen
Automatic landscape or portrait
Continuous, histogram based
Linear based; possible to adjust level/span/max./
min.
