16 Working with measurement tools

16.6.2 Procedure

Follow this procedure:
1. To select the measurement tool, touch the tool on the screen. The tool is now dis-
played with one or more handles.
2. Push the joystick—or touch and hold the tool. This displays a context menu.
3. Use the joystick to go to (depending on the tool)
Alarm) or (Graph/Max/Min/Avg/Alarm).
4. Push the joystick. This displays a submenu.
• (Option available for the line tool.) Select
play a graph.
• Select (Max) and push the joystick to display the maximum value.
• Select (Min) and push the joystick to display the minimum value.
• Select (Avg) and push the joystick to display the average value.
• (Optional step.) You can choose to show or hide the maximum and minimum
markers (the hot/cold spots). Select
stick to toggle:
◦ When (icon with grey indicator) is displayed, the markers are hidden.
◦ When (icon with blue indicator) is displayed, the markers are shown.
5. When completed, move the joystick down to close the submenu.
6. Select (Done) and push the joystick.

16.7 Creating and setting up a difference calculation

16.7.1 General

A difference calculation gives the difference between the values of two known measure-
ment results.
16.7.2 Procedure
Note
• You can set up a difference calculation when defining user presets, or when editing an
image in the archive.
• This procedure assumes that you have previously laid out at least one measurement
tool on the screen.
16.7.2.1 Procedure
Follow this procedure:
1. To set up a difference calculation, select
#T559880; r. AK/36075/36075; en-US
, , or (Max/Min/Avg/
(Graph) and push the joystick to dis-
(Max & min markers) and push the joy-
(Add delta).
47
