13 Handling the camera

13.4 Adjusting the viewfinder's dioptric correction

13.4.1 Figure

CAUTION
Applicability: Cameras with a viewfinder.
Make sure that the beams from the intensive energy sources do not go into the viewfinder. The beams
can cause damage to the camera. This includes the devices that emit laser radiation, or the sun.
Note This item is dependent on the camera model.

13.4.2 Procedure

Follow this procedure:
1. To adjust the viewfinder's dioptric correction, look at the displayed text or graphics on
the screen, and rotate the adjustment knob clockwise or counter-clockwise for best
sharpness.
Note
• Maximum dioptric correction: +2.
• Minimum dioptric correction: –2.
